SERVICE MANUAL
Ver 1.0 2000. 03
SPECIFICATIONS
Recording media
Built-in flash memory, Monaural recording
Recording time
ICD-37: 45 minutes
ICD-57: 90 minutes
ICD-67: 180 minutes
Frequency response
280 Hz - 2 800 Hz
Speaker
approx. 3.6 cm (1
Power output
80 mW
Earphone jack (mini jack) for 8 - 300 Ω earphone
Output
Playback speed control
FAST: +50%
SLOW: –25%
Power requirements
One LR03 (size AAA) alkaline battery: 1.5 V DC
Dimensions (w/h/d) (not incl. projecting parts and controls)
58.0 × 83.5 × 14.2 mm (2
Mass (incl. battery)
ICD-37: 56 g (1.98 oz)
ICD-57/67: 57 g (2.01 oz)
LR03 (size AAA) alkaline battery × 1
Supplied accessories
(tourist model and ICD-57/67 for U.S.A. only)
Handstrap (attached to the unit) × 1
(ICD-57/67 only)
Design and specifications are subject to change without notice.
ICD-37/57/67
Photo: ICD-37
7
in.) dia.
16
× 3
×
3
3
9
in.)
8
8
16
Features
• 45 minutes (ICD-37)/90 minutes (ICD-57)/180 minutes (ICD-67)
recording time
This unit is useful for recording messages or appointments.
• Organizing message files
You can choose among 3 different files to record and store your
messages.
You can easily move messages from one file to another (see page 18).
Up to 99 messages can be recorded in each file.
• Alarm function
You can start playing back a desired message with an alarm on a desired
date and time (see page 21). You can use this function to remind you of
the time of the meeting, etc.
• Playback speed control
You can play back messages rapidly (+50%) or slowly (–25%) (see page
19). This is useful when playing back a long recording. The sound pitch
will be automatically adjusted when you change the playback speed.
• Adding a recording to previously recorded message
You can add a recording to the message being played back to count as
one message (see page 20).
US Model
Canadian Model
AEP Model
E Model
ICD-37/57/67
Tourist Model
ICD-57/67
IC RECORDER
