Operating and assembly instructuions
Please read carefully before commissioning!
ALLROUNDER M-Art. 100303 Modular
-
FOR OUTDOOR USE ONLY
- READ THE ASSEMBLY INSTRUCTIONS CAREFULLY BEFORE STARTING THE ASSEMBLY
- WARNING: ACCESSORIES MAY BE HOT, PLEASE KEEP CHILDREN AWAY
- THESE PARTS MUST BE KEPT AWAY FROMCOMBUSTIBLE MATERIALS
- AFTER USE, PLEASE TURN OFF THE GAS SUPPLY
- OPTICAL & TECHNICAL CHANGES POSSILE AT ANY TIME
B.M.S-Burger GmbH • Bahnholzstr. 20 • 75249 Kieselbronn • www.allgrill.de
Advertisement
Related Manuals for AllGrill ALLROUNDER M
Summary of Contents for AllGrill ALLROUNDER M
- Page 1 - WARNING: ACCESSORIES MAY BE HOT, PLEASE KEEP CHILDREN AWAY - THESE PARTS MUST BE KEPT AWAY FROMCOMBUSTIBLE MATERIALS - AFTER USE, PLEASE TURN OFF THE GAS SUPPLY - OPTICAL & TECHNICAL CHANGES POSSILE AT ANY TIME B.M.S-Burger GmbH • Bahnholzstr. 20 • 75249 Kieselbronn • www.allgrill.de...
- Page 5 CE 2531/22 Device Gas barbecue for outdoor use PIN NO.: 2531CU-0071 ALL‘GRILL ALLROUNDER 100303 WEEE-Reg.-Nr. DE 41898675 Devices category Gas type and their mixture Gas pressure Burner capacity Main burner: 3.5 kW x 3 Main combustion gland: 0.82 mm Side burner: 3.2 kW x 1 Side burner nozzle: 0.79 mm Steakzone®...
- Page 7 Detailed view and parts list warming rack, gas cylinder holder control knob bezel grill grate control knob grill grate door left door right, cover for folded down side shelf lid handle, spacer side panels, infrared burner rear cover infrared burner air collector infrared burner ignition cable infrared burner flame tamer...
- Page 8 Assembly instructions needed tools: 1. Phillips screwdriver Socket wrench 2. Gloves (if necessary 3. Phillips screwdriver longer than 400 mm (if required) 4. Socket wrench 10 mmm 1. Castor assembly (No. 2. Holder for gas cylinder (No.
- Page 9 3. Grill cart side wall assembly (No. 4. Grill cart back wall assembly (No.
- Page 10 5. Front door strut assembly (No. Fixing the firebox and the grill cart with screws...
- Page 11 Mounting the doors and door stop Side panel on the right (side burner, No. Tighten the screws after mounting...
- Page 12 Mount side burner (gas supply) and conect ignition cable to ignition box Make a 100% tight connection between the grill and the side burner!
- Page 13 ideburner grate WARNING! Never turn on the side burner with the lid closed ATTENTION! Never remove blind plug (gas supply to the left-hand side panel) in the basic model modular. Fold-down lid side panels...
- Page 14 Flame cover grate...
- Page 15 Warming rack Grease drip tray a inserting the battery (not included in the scope of delivery)
- Page 16 Optional accessories for your ALL‘GRILL ALLROUNDER Modular Side panel left shelf (Art. No. 1 Infrared side burner Steakzone® left (Art. No.
- Page 17 Mounting Side panel...
- Page 18 Mounting infrared side burner Steakzone® (Art. No. 300) optional Modular 1. Remove the blind plug from the gas connection 2.Mount the left side shelf 3. Connect the gas hose and the ignition cable 4. Insert the grease drip tray from behind Make a 100% tight connection between the grill and the side...
- Page 19 Disposal & Declaration of Conformity DISPOSAL Packing The packaging is made of environmentally friendly materials that you can dispose of at local recycling points. Grill Never throw the barbecue into the normal household waste! Dispose of it via an approved waste disposal company or via your municipal waste disposal facility.
- Page 20 Instructions for starting the Steakzone® and the Backburner First of all, it takes a little more time and patience to start a ceramic burner than a stainless steel burner! (because the gas has to develop under the ceramic) But when the burner develops its full power, it is more powerful than the conventional stainless steel burners.
- Page 21 Stainless steel: tips and information on care and much more... CHARACTERISTICS: CARE: Stainless steel essentially consists of the elements Fingerprints: Simply clean affected areas with iron, chromium and nickel. The metal alloy we use stainless steel care product. This will restore an has the material number according to EN 1.4000 even shine to the surface.
- Page 22 3. Please ensure that the grill has cooled down before cleaning! Please also note our core temperature table for a perfect BBQ and grilling experience with your ALLGRILL...
- Page 23 Pizza stone: care and use Optional accessories: Our pizza stones are made of cordierite. Before using the stone for the first time, wipe it with a damp cloth and let it dry well. Do not use oil or other liquids. Application: •...
- Page 24 Example pictures for mounting the skewer set for all-grills. Technical and optical changes possible! Enjoy your rotisserie grill and BBQ! Detail - Ring for spit guide Detail picture not for Allgrill Chef u. ExtremDetail - Ring for spit guide Detail picture not Detail picture not for Allgrill Chef u.
