- Page 1 PRODUCT MANUAL 58ST FS (V.2.0.F) 62ST FS (V.2.0.F) RON-WPM-710258-58STFS/62STFS-Rev.6...
- Page 2 58ST FS (V.2.0.F) 62ST FS (V.2.0.F) EXPLODED VIEW ITEM No. 3 - 736111 ITEM No. 17 - 775700 17 .1 17 .2 17 .3 17 .4 17 .5 17 .6 17 .7 17 .1 ITEM No. 18 - 774700 18. 1 18.2 18.3 18.4...
- Page 3 58ST FS (V.2.0.F) 62ST FS (V.2.0.F) PARTS LIST ITEM NO. QTY. DESCRIPTION PART NO. Screw 543312 Self-tailing arm - Model 58ST 544601 Self-tailing arm - Model 62ST 544610 Self-tailing top complete - Model ST FS 736111 Circlip 590400U Screw 585140 Top ring - Model ST 521201 O-ring...
- Page 4 58ST FS (V.2.0.F) 62ST FS (V.2.0.F) MOUNTING INSTRUCTIONS Installing the winch is easy, if you follow these instructions. The numbers in ( ) refer to the position numbers in the parts list. Tools required for the installation: • Allen key (5 mm) •...
- Page 5 58ST FS (V.2.0.F) 62ST FS (V.2.0.F) SERVICE INSTRUCTIONS Tools required for service: • Allen key (5 mm) • Winch handle • Allen key (6 mm) • ANDERSEN winch grease • Screwdriver (small) 1. Remove screws (1). 2. Remove self-tailing arm (2) and drum (4). 3.
- Page 6 58ST FS (V.2.0.F) 62ST FS (V.2.0.F) GENERAL INFORMATION Due to the best choice of materials and high precision in manufacturing, we recommend, for normal use, only to dismantle, clean and lubricate the winch once every second year. Under extensive use, such as racing, charter or blue water sailing, we recommend to lubricate the winch once every year.
- Page 7 58ST FS (V.2.0.F) 62ST FS (V.2.0.F) SAFETY NOTICES ALL WINCHES Read All Safety Notices and Product Manuals Do not install or operate this winch before reading and fully understanding the contents of this Product Manual. Stay Alert When Operating Andersen winches are very powerful and have the potential to cause significant damage and/or serious injury if used improperly or without due caution and vigilance.
- Page 8 PRODUCT MANUAL 58ST FS (V.2.0.F) 62ST FS (V.2.0.F) WORLDWIDE DISTRIBUTION & SERVICE Visit www.andersenwinches.com WARRANTY Visit www.ronstan.com/warranty Manufactured by Ronstan Denmark ApS. Jægervænget 36 - 7100 Vejle - Denmark office@ronstan.dk - www.andersenwinches.com...
