Rhino
®
HPP13
Flex
Hydraulic
Powerpack
Revised
01.2019
Prior to Operation
We thank you for choosing
®
Rhino
Power Pack.
Please note that the Rhino
Power Pack is delivered
without hydraulic oil, and
therefore, it must be filled up
with hydraulic oil prior to
operation.
To ensure smooth operation
and long-lasting performance
of your new post driver, we
recommend you study this
operation manual carefully
and pay special attention to
the
Safety and Service
Precautions
We hope you will be satisfied
with your new Rhino
Hydraulic Power Pack.
Best Regards,
Rhino Tool Co.
®
®
Rhino Tool Co. Inc. 1134
West South St.
P.O. Box 111
Kewanee, IL 61443
Tel: 309.853.5555 main
Tel: 866.707.1808 toll-free
Fax: 309.856.5905
info@rhinotool.com
www.rhinotool.com
000388.08.25.16
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for RHINO HPP13 Flex
Summary of Contents for RHINO HPP13 Flex
- Page 1 Revised 01.2019 Prior to Operation We thank you for choosing ® Rhino Power Pack. Please note that the Rhino ® Power Pack is delivered without hydraulic oil, and therefore, it must be filled up with hydraulic oil prior to operation.
-
Page 2: Table Of Contents
Contents Page Safety precautions .................... 2 Filling up hydraulic oil ..................2 Technical data ....................3 Starting instructions..................4 Service, maintenance and hydraulic settings ............5 Oil types ......................6 Warranty conditions ..................7... -
Page 3: Safety Precautions
Safety Precautions Always use protective earplugs. The powerpack complies with the EU noise limits, but by daily long-lasting operation there is a risk of hearing defects. Always connect hoses before starting. Never add fuel or oil when the engine is running. In case of non-operation or lack of performance, always turn off the engine. -
Page 4: Technical Data
Hydraulics ® The Rhino HPP13 Flex open centre hydraulic powerpack is designed in accordance with the EHTMA categories C and D, which prescribe a minimum performance of 5.25 gpm (20 l.p.m.) at 2000 p.s.i.(138 bar) and 8 g.p.m. (30 l.p.m.) at 2000 p.s.i.(138 bar), respectively. -
Page 5: Starting Instructions
Starting Instructions Please observe the starting instructions on the front of the powerpack. Start: • Check engine oil level • Check hydraulic oil level at sight glass • Connect hoses and tool • Switch fuel tap to “ON” • Activate choke •... -
Page 6: Service, Maintenance And Hydraulic Settings
Service, Maintenance and Hydraulic Settings Service/Maintenance Daily Weekly Yearly Engine oil Check 1 x replacement Hydraulic oil Check 1 x replacement Hydraulic oil filter * 1 x replacement Check hoses (tighten up if needed) Air filter 1 x replacement Fuel filter 1 x replacement * Use only filters with by-pass Hydraulic Settings... -
Page 7: Oil Types
Oil Types The Rhino HPP13 Flex Power Pack uses standard hydraulic oil, i.e. all types ® of mineral oil and biodegradable oil, which comply with the following values: Recommended viscosity ISO 32 (20-40 cSt) Permitted viscosity ISO 15-1000 (15-1000 cSt) Viscosity index Min. -
Page 8: Warranty Conditions
(12) months with regard to all other components, excluding the Honda 13 HP engine and Vanguard 18 HP engine for which Rhino provides no warranty and for which the warranty is provided by American Honda Motor Co., Inc and by Briggs and Stratton Corporation respectively and the shall be the sole warranty applicable thereto. - Page 9 HPP13/HPP13 FLEX spare parts list From serial No. 6109 Fig. 1 Pos. Part No. Description Pcs. 8222360 Chassis complete HPP13/13 FLEX 7721125 Tube plug 25x25 7621100 Shim ring 25/35/1 mm 7621098 Retaining ring 25x2 7721140 Wheel cover 7721139 Wheel HPP13/18...
- Page 10 HPP13/HPP13 FLEX spare parts list Pos. Part No. Description Pcs. From serial No. 6109 7321144 Engine 13 HP Honda GX390 7621172 Washer M10 8722356 Rubber damper ø30x25 Fig. 2 7621034 Washer M10 7621163 Screw M10x35 7621032 Set screw M6x8 Loctite 243 - 5 Nm...
- Page 11 HPP13/HPP13 FLEX spare parts list From serial No. 6109 Pos. Part No. Description Pcs. Fig. 3a HPP13 with POR 7421063 Fitting 1/2"x1/2" BSP 7621606 Retaining ring A17 7521609 O-ring 17x2 mm 8221731 Valve block 7621050 Roll pin ø5x14 7621037 Pipe plug 1/8"...
- Page 12 Pos. Part No. Description Pcs. HPP13/HPP13 FLEX spare parts list 7421063 Fitting 1/2"x1/2" BSP 7621647 Shoulder bolt ø10/M8x12 From serial No. 6109 Loctite 638 - 20 Nm 7621648 Disc spring ø10.2/ø20x0.8 8621658 Screw M5x8 Fig. 3b HPP13 FLEX Loctite 638...
- Page 13 HPP13/HPP13 FLEX spare parts list From serial No. 6109 Fig. 4 POR system Pos. Part No. Description Pcs. 8221023 POR bracket complete HPP13 8721110 POR hose HPP13 8221005 POR cylinder 8221006 Seal housing 8221007 Piston rod 8221008 Piston 8221009 Distance pipe...
- Page 14 HPP13/HPP13 FLEX spare parts list From serial No. 6109 Fig. 5 Pos. Part No. Description Pcs. 8721071 3/4" hose 8721070 1/2" hose 7421081 Hose clip 1/2" 7421079 Hose fitting 1/2"x3/4" 7521118 Seal ring 3/4" 7621045 Screw M8x30 Loctite 243 7421082 Hose clip 3/4"...
- Page 15 HPP13/HPP13 FLEX spare parts list From serial No. 6109 Fig. 6 NEW TYPE OLD TYPE Pos. Part No. Description Pcs. 9421189 Filter cover 9421193 Filter spring 9421502 Seal f/filter cover Also included in 9421188 9421190 Filter element O-ring ø3x22 Included in 9421188 Filter cup O-ring ø3x60...
- Page 16 HPP13/HPP13 FLEX spare parts list From serial No. 6109 Fig. 7 Pos. Part No. Description Pcs. 8721630 Cooler pressure hose 7421079 Hose fitting 1/2"x3/4" 7521118 Seal ring 3/4" 7621047 Screw M8x90 8221121 Plate 7421582 Fitting 1/2"x3/4" 8221116 Plate 8221086 Distance pipe ø12x1.5 8321093 Cooler ø280-12...
