- Page 1 BACKSTOP TABLE TENNIS ASSEMBLY INSTRUCTIONS NG2310P3...
- Page 2 THANK YOU! Thank you for purchasing this product. We work around the clock and around the globe to ensure that our products maintain the highest possible quality. However, in the rare case of issues during assembly or use of this product, please contact our Consumer Hotline at 800-759-0977 for immediate assistance before contacting your retailer.
- Page 3 PARTS IDENTIFIER (NOT TO SCALE) LEG BOLT SET OUTER LEG T-INNER LEG HINGE LEVELER 8 pcs 4 pcs 4 pcs 2 pcs 4 pcs SAFETY LOCK WHEEL WHEEL WASHER CONTROL BRACE TABLE HALF 2 pcs 4 pcs 2 pcs 8 pcs 8 pcs *NOTE: these parts are pre-installed on table base.
-
Page 4: Assembly Tips
ASSEMBLY TIPS 1. Find a clean, level surface to begin the assembly of your game table. We recommend that two adults work together to assemble this game. You may want to carefully cut or tear the four corners of the box so that the bottom of the box can be used as your work surface. 2. - Page 5 ASSEMBLY INSTRUCTIONS TOOLS REQUIRED: ASSEMBLY INSTRUCTIONS 3. Unlock and unfold pre-assembled table and slide “T” rolling leg into designated position. WARNING: This table is shipped with safety lock in locked position. To prevent damage to table ALWAYS disengage lock before opening legs. ALWAYS open legs by lifting outer legs (hinged side), NOT “T”...
- Page 6 THANK YOU! OPERATING INSTRUCTIONS Security Lock Operation Unlocked Locked Release the lock before opening the tennis table, and lock it when in folded position. Leg Hinge Wheel Operation When in Use When Collapsing Locked Unlocked Straighten hinge when using table, Lock wheels tightly when using table, and collapse hinge to fold table.
- Page 7 THANK YOU! OPERATING INSTRUCTIONS (CONT.) Height Adjusting Method Figure 5 The wheel height can be adjusted to The foot height can also be adjusted a maximum of 15mm. to a maximum of 15mm. All feet can be adjusted slightly to ensure a level playing surface. To adjust the table height at wheel, turn To adjust table height at the foot, screw foot Part A (see figure 5 above) counter-clockwise...
-
Page 8: Note On Safety
CONGRATULATIONS! You have now assembled your Game Table. Please note the Care and Use instructions below to ensure years of trouble free use of your game table. Care and Use 1. This product is intended for INDOOR use only. 2. Do NOT sit, climb, lean, or place heavy objects on the table. 3. -
Page 9: Year Limited Warranty
1-YEAR LIMITED WARRANTY This product is warranted to the original purchaser to be free from defects in material or workmanship for a period of one year from the date of the original retail purchase. This warranty does not cover defects or damage due to improper installation, alteration, accident or any other event beyond the control of the manufacturer. -
Page 10: Parts List
BACKSTOP TABLE TENNIS - NG2310P3 Parts List ACCESORIES NGP5944 Paddles and Balls Set NGP5945 Net and Posts Set PARTS NGP5899 NGP5900 NGP5901* NGP5902* NGP5903* T-INNER LEG HINGE OUTER LEG LEG BOLT SET LEVELER 4 pcs 4 pcs 2 pcs 8 pcs...
