Arm Electronics B600MD2VAIVP Datasheet

B/W Super High Resolution
Varifocal Vandal Dome Cameras
B600mdVaiVp
4-9mm Auto Iris Lens
B600md2VaiVp
2.6-6mm Auto Iris Lens
vandal
Color Vandal Dome Cameras
c380mdVp
380 Lines of Resolution
c480mdVp
480 Lines of Resolution
prOdUct featUres
■
380 or 480 Lines of Resolution
■
1/3" Imaging Device
■
3.6mm Mini Lens
■
12VDC Power (110mA)
■
Lux (0.5 @ F1.2)
■
BNC Video Output
■
Dimensions (3.75" x 2.76")
■
Weight (0.84 lbs)
■
Operating Temp (14°F-122°F)
■
Weatherproof
20
PROOF
w w w . a r m e l e c t r o n i c s . c o m
prOdUct featUres
■
600 Lines of Resolution
■
1/3" Imaging Device
■
Varifocal Auto Iris Lens
■
3-Axis Camera Mount
■
Dual Voltage Power (350mA)
■
Lux (0.01 @ F1.2)
■
BNC Video Output
■
Dimensions (6.4" x 3.9")
■
Weight (1.98 lbs)
■
Operating Temp (14°F-122°F)
■
Optional Wall Mount (VPMDWMT)
■
Weatherproof (IP66)
Vandal Dome
Wall Mount
Vpmdwmt
n
8 8 8 . 7 7 1 . 4 5 4 4
