TURBO ELITE BTE3221ALP Operator's Manual

Liquid propane and natural gas grill
Hide thumbs
Table of Contents

Advertisement

Quick Links

Liquid Propane Gas (LPG) Grill
Models BTE3221(A,B)LP & BTE3821BLP
Natural Gas (NG ) Grill
Models BTE3221(A,B)NG & BTE3821BNG
BTE3221BLP/NG
FREE HELP
Grill Information Center:
FROM THE GRILL EXPERTS
Barbeques Galore is the expert on this
product and trained to help you with:
Ÿ
Assembly Questions
Ÿ
Grill Operation
Ÿ
Replacement of Damaged or Missing parts
visit www.grandhall.com or call:
1-800-474-5587
Monday - Friday 8:00am-4:30pm PST
IMPORTANT:
Ÿ
NOTE TO ASSEMBLER / INSTALLER:
Leave this manual with the consumer.
Ÿ
NOTE TO CONSUMER:
Keep this manual for future reference.
Ÿ
RECORD YOUR SERIAL #
__________________
(see silver CSA label on main body of grill)
BTE3221ALP/NG
(BTE3221B+UN3216ACT)
WARNING
!
Ÿ
Failure to comply with these instructions could
result in a fire or explosion that could cause
serious bodily injury, death or property damage.
Ÿ
Whether this grill was assembled by you or
someone else, you must read this entire manual
before using your grill to ensure the grill is
properly assembled, installed and maintained.
Ÿ
Use your grill at least 3 feet away from any
wall or surface. Use your grill at least 3 feet
away from combustible objects that can melt or
catch fire such as vinyl or wood siding, fences
and overhangs or sources of ignition including
pilot lights on water heaters and live electrical
appliances.
Ÿ
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
Ÿ
Never use your gas grill in a garage, porch,
shed, breezeway or any other enclosed area.
Ÿ
Never obstruct the flow of ventilation air
around your gas grill housing.
Ÿ
Never disconnect the gas regulator or any gas
fitting while your grill is lit. A lit grill can ignite
leaking gas and cause a fire or explosion which
could result in property damage, personal injury
or death.
Operator's Manual
BTE3821BLP/NG
Manual # P80151147D - Date:2021/04/15
!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BTE3221ALP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TURBO ELITE BTE3221ALP

Summary of Contents for TURBO ELITE BTE3221ALP

  • Page 1: Primary Safety Warnings

    Operator's Manual Liquid Propane Gas (LPG) Grill Models BTE3221(A,B)LP & BTE3821BLP Natural Gas (NG ) Grill Models BTE3221(A,B)NG & BTE3821BNG BTE3221BLP/NG BTE3821BLP/NG BTE3221ALP/NG (BTE3221B+UN3216ACT) FREE HELP WARNING Grill Information Center: FROM THE GRILL EXPERTS Ÿ Failure to comply with these instructions could...

  • Page 2: Table Of Contents

    Table of Contents WARNING Primary Safety Warnings......1-3 Pre-Assembly Instructions.......3 Do not store or use gasoline or other Part Diagrams and Lists......4-11 flammable liquids or vapors in the Assembly Instructions.........12-16 vi c ini ty of t his or an y ot h er Use &...

  • Page 3: Pre-Assembly Instructions

    Pre-Assembly Instructions For Your Safety CAUTION PRE-ASSEMBLY Read and perform the following pre-assembly instruc- tions: Failure to comply with these instructions may result Tools Required for Assembly in a hazardous situation which, if not avoided, may • protective work gloves result in injury.

  • Page 4: Part Diagrams And Lists

    Hardware Parts List for Models BTE3221BLP/NG & BTE3821BLP/NG PART # PART DESCRIPTION PURPOSE OF PART P06013018C Hardware Pack For use in assembly of Models BTE3221B, BTE3821B S182G03061 Pan Head Screw 3/16" x 3/8" Install the Transformer Bracket (BTE3221B, BTE3821B) S182G03061 Pan Head Screw 3/16" x 3/8" Install the Bracket with LP Regulator (LPG Model Only) S182G03061 Pan Head Screw 3/16"...
  • Page 5 Parts Diagram for Models BTE3221BLP & BTE3221BNG...
  • Page 6 Parts List for Models BTE3221BLP & BTE3221BNG DESCRIPTION PART# QTY. Lid Assembly P0014763AA Temperature Gauge P00601551A Temperature Gauge Seat P00614031A Lid Handle Bracket, Left P00307052E Lid Handle Bracket, Right P00308052E Lid Handle P00215039H Protective Pad P05518002I Lid Assembly Bracket, Left P03320007C Lid Assembly Bracket, Right P03320008C...
  • Page 7 Parts List for Models BTE3221BLP & BTE3221BNG DESCRIPTION PART# QTY. Gas Collector Box with Electrode P02608059C Gas Collector Box with Electrode P02608060A Electric Wires Set/Electrode P02615204A Gas Valve/Manifold Assembly (NG) Y0060877 Gas Valve/Manifold Assembly (LPG) Y0060883 Bowl Front Trim Plate Assembly P02915781S Electric Wires Set P02627025A...
  • Page 8 Parts Diagram for Model BTE3821BLP & BTE3821BNG...
  • Page 9 Parts List for Model BTE3821BLP & BTE3821BNG DESCRIPTION PART# QTY. Lid Assembly P0014808AA Temperature Gauge P00601551A Temperature Gauge Seat P00614031A Lid Handle Bracket, Left P00307052E Lid Handle Bracket, Right P00308052E Lid Handle P00215040H Protective Pad P05518002I Lid Assembly Bracket, Left P03320007C Lid Assembly Bracket, Right P03320008C...
  • Page 10 Parts List for Model BTE3821BLP & BTE3821BNG DESCRIPT ION PART # QT Y. Bowl Front Trim Plate Assem bly P02916061S Electric W ires Set P02627026A LED Rectifier with W ire Assem bly P05383022B Control Panel P02916163S Switch for Lam p P05360004B Control Knob Seat with LED Light P03445014A...
  • Page 11 Rotisserie Assembly Parts Diagram for BTE3221(A,B)LP/NG & BTE3821BLP/NG Rotisserie Assembly Parts List for BTE3221(A,B)LP/NG & BTE3821BLP/NG PART# DESCRIPTION Rot. Collar P05508254A Rot. Thumbscrew 1/4"x1/2" S196G04081 P05508230A Rot. Spit (for BTE3221(A,B)LP/NG Models) P05508231A Rot. Spit (for BTE3821BLP/NG Models) P055082125 Rot. Holding Fork P03308012C Rot.
  • Page 12 Installation Instruction Combustible Clearance Island Construction BBQ Grills are It is required that the required to be 36” interior of the island/ 36" 36" away from any structure to be built combustible hollow and with proper material in all ventilation based on gas 36"...
  • Page 13 Installation Instructions for Models BTE3221BLP/NG & BTE3821BLP/NG Note:The grill head you purchased is to be installed on the island which is not included in this purchase. You either need to purchase a prebuilt island or you have to build your own island. Before building your grill island, please read the construction guidelines and clearances in Fig.6 and on pages 16 &...
  • Page 14 Install Natural Gas(NG) Regulator and 12 Foot Hose Connect the NG regulator to the inlet of gas manifold. ( See Fig. 4) Connect the swivel nut of the 12 ft. NG hose to the vertical fitting of the NG Regulator. WHEN YOU FINISHED THIS STEP, PLEASE SKIP TO STEP 6.
  • Page 15 Install Partition Panel The gas grill is designed for use with a maximum of 20 lb tank. As per standard, a partition panel (not included) or equivalent device is required to be installed in the left cabinet of the island for preventing the use of 30 lb tank.
  • Page 16 Main Burner Electrode Check with the Install Cooking Components assistance of another person, perform this Electrode Check before proceeding. Place the flame tamer with ceramic onto the lower ledge of the grill bowl above the burners. This test will ensure that the Spark Electrode Tips Place the cooking grids onto the upper ledge of are properly positioned so your grill lights easily.

  • Page 17: Use & Care Instructions

    USE AND CARE INSTRUCTIONS Keep fire extinguisher readily accessible. In the event CORRECT USE OF LP GAS TANK of a oil/grease fire, do not attempt to extinguish with LP Gas grill models are designed for use with a standard water. Use type B extinguisher or smother with dirt, 20 lb.
  • Page 18 USE AND CARE INSTRUCTIONS LP Gas Model only: NOTE about LP Gas Tank Exchange Programs Secure a 20lb LP Gas Tank to Gas Grill Ÿ Many retailers that sell grills offer you the option of re- (for BTE3221(A,B)LP & BTE3821BLP) placing your empty LP Gas tank through an exchange service.
  • Page 19 USE AND CARE INSTRUCTIONS Check all connections for LP Gas Leaks LP Gas Model only: Connect Regulator with Hose to your LP Gas Tank Never test for leaks with an open flame. Prior to first use, at the beginning of each season, or every time Turn all Burner Valves to the OFF position.

  • Page 20: Natural Gas Connection

    Natural Gas Connection Fig.1 Natural Gas Model only: Connecting Natural Gas To Your Grill Connect the Swivel nut of the 12' Natural Gas Hose to the vertical fitting of NG Regulator as Vertical Fitting shown in Fig.1. Connect the other hose end (male plug) to the gas supply line from your Swivel Nut home.
  • Page 21 USE AND CARE INSTRUCTIONS Grill Lighting Instructions Before each use, check all hoses for cracks, nicks, cuts, burns or abrasions. If a hose is damaged in any way, do not use your grill before replacing the hose with an authorized part from the Parts List. Also make sure all gas supply connections are securely tightened.

  • Page 22: Troubleshooting

    USE AND CARE INSTRUCTIONS Troubleshooting To purge air from your gas line and/or reset If the grill fails to light : the regulator excess gas flow device: Turn gas off at source and turn Control Knobs to OFF. Wait at least 5 minutes for gas to clear, then retry. Turn Control Knobs to the OFF position.

  • Page 23: Rotisserie Instruction

    USE AND CARE INSTRUCTIONS WARNING CORRECT USE OF ROTISSERIE Read all instructions before initial use. IMPORTANT: When using electrical appliances, basic safety To protect against electrical shock, do not immerse precautions should always be used. The Rotisserie Motor is set for 120V, 60Hz AC current. electrical cord, plugs or motor in water or expose to The Rotisserie is for outdoor use only.
  • Page 24 Rotisserie Assembly Instructions 1. Remove all components from the carton. Attach the Motor Bracket to the outside of the right bowl side panel. Align the two holes on the Bracket with the two holes on the right bowl side panel. Tighten securely using two Rotisserie Screws 3/16"x1/ 2"...
  • Page 25 Slide the pointed end of the Spit through the piece of meat. Place the Holding Forks onto each end of the Spit. Adjust spacing between Holding Forks to accommodate your food, then tighten the Thumbscrews to keep the Holding Forks in position. Slide the Collar onto the square end of the Spit. Do not tighten the Collar Thumbscrew until the Rotisserie is placed into your grill.

  • Page 26: Cleaning And Maintenance

    CLEANING AND MAINTENANCE Cleaning Exterior Stainless Steel Surfaces: Routine care and maintenance is required to preserve Proper care and maintenance will keep your grill in top operating the appearance and corrosion resistance of stainless condition and prolong its life. Follow these cleaning procedures steel.
  • Page 27 CLEANING THE BURNER TUBES AND BURNER PORTS Regardless of which Burner cleaning procedure you use, To reduce the chance of FLASHBACK FIRE you must clean we recommend that you also complete the following clea- the Burner Tubes as follows at least once a month in ning regimens to help prolong Burner life.
  • Page 28 Cooking Instructions Burn-Off Indirect Cooking using Main Burners Before cooking on your gas grill for the first time, you should "burn off" the grill to eliminate any odor or foreign The indirect cooking method can also be used with the matter.
  • Page 29 Guide to Grilling using the Main Burners and Direct Cooking Method Approximate Cooking Times Grilling Steak and Ribs Cut of Meat Rare: 4-8 minutes Turn the grill Burners on , close Lid and preheat your grill T-bone steak Medium: 10-14 minutes 10 to 15 minutes.
  • Page 30 Guide to Roasting and Baking Using the Main Burners Food preparation An Important Note About Heat Settings Trim meat of excess fat. Truss meat and poultry with cooking The suggested heat settings shown are approximate. There string to retain shape if desired. Bacon strips can be used to are many factors such as outside temperature, wind condi- cover the outside surface of lean meat and poultry to help tions and grill location that affect your grill performance.
  • Page 31 Guide to Rotisserie Cooking Guide to Smoking Slow Cooking with a Rotisserie Preparing to Smoke Rotisserie cooking produces foods that are moist, flavor- Smoking gives food a distinctive, delicious flavor. You will find ful and attractive. The rotisserie system is most com- a variety of wood chips available for use in smoking grilled monly used for cooking meat or poultry and is designed foods.

  • Page 32: Warranty

    Question: Question: Can I convert my grill from one fuel type to another in Sometimes I hear a humming sound coming from my other words from LPG to NG or vice versa? regulator. What causes this? And - My grill has a low flame and sometimes will not light.
  • Page 33 Question: The Regulator and Hose supplied with my gas grill After every use (after your grill has cooled down), wipe does not fit the older LP Gas tank I’ve used for years. stainless surfaces with a soft, soapy cloth or sponge Why not? then rinse with water.
  • Page 34 Limited Warranty Barbeques Galore will warrant to the ORIGINAL PURCHASER of this product that it will be free of defects in material and workmanship for set periods below from the date of purchase when used under normal outdoor use and correct assembly: Cooking Grids and SS Burners - Limited Lifetime (No rust through or burn through) Infrared Burner - 3 Year Limited Warranty Flame Tamers, Valves, and Plastic Components - 2 Year Limited Warranty...
