User Guide
This is a 「User Guide」 installed on the TV.
The contents of this guide are subject to change without prior notice for quality
improvement.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 60LA8600-SA.KWGYLWK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LG 60LA8600-SA.KWGYLWK

Summary of Contents for LG 60LA8600-SA.KWGYLWK

  • Page 1 User Guide This is a 「User Guide」 installed on the TV. The contents of this guide are subject to change without prior notice for quality improvement.

  • Page 2: To❐View❐Program❐Information

    ❐ ❐ To❐view❐program❐information Displays information about the current program and/or current time, etc. 1 Move the pointer of the Magic remote control to the top of the TV screen. 2 Click the activated channel banner area. 3 The program details will be displayed at the bottom of the TV screen. ✎...

  • Page 3: To❐Set❐Favorite❐Channels

    To❐set❐favorite❐channels ❐ ❐ SMART❐ ❐➾ Settings❐➙ CHANNEL❐➙ Channel❐Edit 1 Move to the desired channel on Wheel (OK) button. Channel is selected. 2 Press Set as Favorite. 3 Select the desired favorite channel group. 4 Select Enter. Favorite is set. To❐use❐Favorite ❐ ❐ SMART❐ ❐➾❐Ch.❐List Channel list will appear. Select the desired preset favorite channel from Favorite List A to D.
  • Page 4 To❐set❐Auto❐Tuning ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐CHANNEL❐➙❐Auto❐Tuning Automatically tunes the channels. ✎ Channels are not registered properly unless the antenna/cable is connected correctly. ✎ Auto Tuning only sets channels that are currently broadcasting. ✎ If Lock System is turned on, a pop-up window will appear asking for password.
  • Page 5 To❐set❐channels❐manually ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐CHANNEL❐➙❐Manual❐Tuning Adjusts channels manually and saves the results. For digital broadcasting, signal strength, etc. can be checked.

  • Page 6: To❐Edit❐Channels

    To❐edit❐channels ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐CHANNEL❐➙❐Channel❐Edit Edits the saved channels. Set as favorite, block/unblock and Add/Delete etc. the selected channel.
  • Page 7 SMART ➾ Settings ➙ PICTURE ➙ Aspect Ratio Selects the screen aspect ratio. 16:9 Resizes the image ratio to fit a 16:9 screen. Displays high-quality image without loss. Just Scan ✎ In DTV/HDMI/Component (over 720p) mode, Just Scan available. Set by Depending on the input signal, screen aspect ratio changes to 4:3 Program or 16:9.
  • Page 8 ✎ While viewing an external device, these cases may result in image burn: - a video with stationary caption (such as network name) - 4 : 3 aspect ratio mode for an extended period Take caution when using these functions. ✎...
  • Page 9 SMART ➾ Settings ➙ PICTURE ➙ Energy Saving Reduces power consumption by adjusting screen brightness. [Depending on model] Auto TV sensor detects the ambient lighting and automatically adjusts the screen brightness. Turns off the Energy Saving mode. Minimum/ Medium/ Applies the pre-set Energy Saving mode. Maximum Screen is turned off and only sound is played.
  • Page 10 SMART ➾ Quick Menu ➙ AV Mode Views the TV with the best picture / audio optimized for different AV modes. Views with the value set at the picture / sound menu. Cinema Optimizes picture and audio settings for movies. Game Optimizes picture and audio settings for games.
  • Page 11 To❐adjust❐pictures❐with❐Picture❐Wizard ❐ ❐ SMART❐ ❐➾ Settings❐➙❐PICTURE❐➙❐Picture❐Wizard❐Ⅱ Use the remote control and follow the instructions of the Picture Wizard to calibrate and adjust for optimum picture quality without expensive pattern devices or help from a specialist. Follow the instructions to obtain the optimum picture quality.
  • Page 12 To❐select❐Picture❐Mode ❐ ❐ SMART❐ ❐➾ Settings❐➙❐PICTURE❐➙❐Picture❐Mode Selects the picture mode optimized for the viewing environment or the program. Heightens contrast, brightness and sharpness to Vivid display vivid images. Displays images in standard levels of contrast, Standard brightness and sharpness. The Energy Saver feature changes settings on the TV to reduce power consumption.
  • Page 13 Menu for adjusting picture quality that allows experts and amateurs to enjoy the best TV viewing. This menu is ISF-certified and provided for picture tuning experts. ꕋ Expert (ISF logo can only be used on ISF-certified TV units.) ISFccc : Imaging Science Foundation Certified Calibration Control ✎...
  • Page 14 To❐fine-tune❐picture❐mode ❐ ❐ SMART❐ ❐➾ Settings❐➙❐PICTURE❐➙❐Picture❐Mode❐➙❐Backlight❐/❐ Contrast❐/❐Brightness❐/❐Sharpness❐/❐Color❐/❐Tint❐/❐Color❐Temp. First select a Picture Mode of your choice. Adjusts the display brightness by varying the brightness of Backlight the LCD panel. Adjusts the difference between bright and dark regions of the Contrast screen. Brightness Adjusts the overall screen brightness.
  • Page 15 Color Adjusts the colors on the screen darker or lighter. Tint Adjusts the red/green color balance. Color Temp. Adjusts the overall tone of colors to warm or cool. ✎ Depending on the input signal or other picture settings, the range of detailed items for adjustment may differ.
  • Page 16 To❐set❐advanced❐control ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐PICTURE❐➙❐Picture❐Mode❐➙❐Advanced❐ control/Expert❐Control❐ Calibrates the screen for each picture mode or adjusts picture settings for a special screen. First select a Picture Mode of your choice. Adjusts the contrast to the optimal level according to the Dynamic Contrast brightness of the image.
  • Page 17 Skin Color : Skin color spectrum can be separately set to implement the skin color as defined by the user. Preferred Color Grass Color : Natural color spectrum (meadows, hills, etc.) can be separately set. Sky Color : Sky color is set separately. Provides a crystal-clear picture by improving the details in Super Resolution areas where the picture is blurry or unclear.
  • Page 18 Filters a specific color spectrum in RGB colours to fine-tune Color Filter colour saturation and hue accurately. Expert Pattern Patterns used for expert adjustment. Adjusts the overall tone of the screen as desired. White Balance In Expert mode, detailed fine-tuning can be set via the Method / Pattern etc.
  • Page 19 To❐set❐additional❐picture❐options ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐PICTURE❐➙❐Picture❐Mode❐➙❐Picture❐Option Adjusts detailed setting for images. Noise Reduction Reduces screen noise in the video. MPEG Noise Reduces noise caused by compressing digital video. Reduction Adjusts the brightness or darkness of the screen to suit the Black Level black level of the picture input using the degree of darkness (black level) of the screen.
  • Page 20 [Depending on model] Eye Care Adjusts screen brightness to prevent eye glare. [Depending on model] Saves power consumption by adjusting the brightness corresponding to the movement of the image on the Motion Eye Care screen. ✎ It does not work while watching 3D images. ✎...
  • Page 21 To❐reset❐Picture❐Mode ❐ ❐ SMART❐ ❐➾ Settings❐➙❐PICTURE❐➙❐Picture❐Mode❐➙❐Picture❐Reset Resets values customized by the user. Each picture mode is reset. Select the picture mode you wish to reset.
  • Page 22 SMART ➾ Settings ➙ PICTURE ➙ Picture Mode ➙ Picture Option ➙ TruMotion [Depending on model] Corrects images to display smoother motion sequences. Smooth De-Judder/De-Blur value is set at 3. Clear De-Judder/De-Blur value is set at 7. The screen appears clearer when Clear is selected.
  • Page 23 SMART ➾ Settings ➙ PICTURE ➙ Picture Mode ➙ Picture Option ➙ LED Local Dimming Brightens bright areas and darkens dark areas of the image for maximum contrast and minimum blur while reducing power consumption. [Depending on model] Turns off LED Local Dimming. Expresses in natural black tones.
  • Page 24 To❐use❐Sound❐Mode ❐ ❐ SMART❐ ❐➾ Settings❐➙❐SOUND❐➙❐Sound❐Mode Optimizes TV audio to the selected sound mode. Standard Suitable for all types of video. Music/Cinema/ [Depending on model] Sport/Game Sets audio optimized for a specific genre. Adjusts the volume to the desired level using the User User Setting...
  • Page 25 To❐fine-tune❐the❐volume ❐ ❐ SMART❐ ❐➾ Settings❐➙❐SOUND❐➙❐Sound❐Mode❐➙❐User❐EQ❐ Sets Sound Mode User Setting first. 100 Hz / 300 Hz / 1 kHz/ Sets EQ by manually adjusting sound bands. 3 kHz / 10 kHz Reset Resets previously changed equalizer value.
  • Page 26 To❐use❐Smart❐Sound❐Mode❐ ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐SOUND❐➙❐Smart❐Sound❐Mode Provides optimized sound adjusted for each content type. ✎ If the Smart Sound Mode function is enabled, Sound Mode, Virtual Surround Plus, and Clear Voice II are automatically adjusted.
  • Page 27 To❐use❐Virtual❐Surround❐sound ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐SOUND❐➙❐Virtual❐Surround❐plus LG’s proprietary audio processing technology allows 5.1 channel-like surround sound from two speakers. ✎ If Clear Voice ll is set to ON, Virtual Surround plus will not be chosen. To❐use❐Clear❐Voice❐ll❐function ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐SOUND❐➙❐Clear❐Voice❐ll Boosts voice clarity.
  • Page 28 To❐set❐Volume❐Mode❐ ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐SOUND❐➙❐Volume❐Mode Sets various modes for volume control. Sets Auto Volume The volume varies from channel to channel and program to program. When clicking through the Auto Volume channels, the volume is adjusted automatically to maintain the same level. Using a single volume curve may result in an inaudible or Volume Control loud sound depending on the environment.
  • Page 29 To❐synchronize❐audio❐and❐video ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐SOUND❐➙❐AV❐Sync.❐Adjust Synchronizes video and audio directly when they do not match. If you set AV Sync. Adjust you can adjust the sound output (TV speakers or SPDIF) to match the video. [Depending on model] Adjusts the synchronization of the sound from the TV's internal TV Speaker speakers.
  • Page 30 The + and - buttons allow the viewer to synchronize the audio Speaker with the video. ✎ LG audio device is supported only for models with the optical digital port. Outputs broadcasting signals or the audio of an external Bypass device without audio delay.
  • Page 31 To❐use❐Sound❐Option❐Setting ❐ ❐ [Depending on model] SMART❐ ❐➾❐Settings❐➙❐SOUND❐❐➙❐Sound❐Option❐Setting ❐ ❌ Analogue❐Out [Depending upon model] Allows the user to select the Headphone External Speaker (Audio Out) menu depending on the device connected. ❐ ❌ Balance [Depending on model] Adjusts left/right audio balance.
  • Page 32 ❐ ❌ Sound❐Optimizer [Depending on model] Allows optimized sound for custom TV installation. Normal General sound mode. Wall Mount Type Optimizes sound for a wall-mounted TV. Stand Type Optimizes sound for a stand-mounted TV.
  • Page 33 To use the TV’s speakers ❐ [Depending on model] SMART ➾ Settings ➙ SOUND ➙ Sound Out ➙ TV Speaker Sound is output through the TV speaker. To use External Speakers ❐ SMART ➾ Settings ➙ SOUND ➙ Sound Out ➙...
  • Page 34 To use Digital Sound Out ❐ SMART ➾ Settings ➙ SOUND ➙ Sound Out ➙ External Speaker(Optical/HDMI ARC) ➙ Digital Sound Out Sets up Digital Sound Output. Item Sound Input Digital Sound output MPEG Auto Dolby Digital Dolby Digital Dolby Digital Plus Dolby Digital...
  • Page 35 To connect and use an LG audio device ❐ LG audio device allows you to enjoy rich powerful sound. ❌ Wired Connection SMART ➾ Settings ➙ SOUND ➙ Sound Out ➙ LG Sound Sync (Optical) Connect an LG audio device with the logo to the optical digital audio output port.
  • Page 36 ✎ When connecting wirelessly, attach the dongle and connect it if the model needs the Magic Remote Control dongle. (AN-MR400, sold separately) ✎ For a wireless connection, if the device fails to connect, check the device power and make sure the LG Audio device is set up properly.
  • Page 37 ✎ If two or more devices are detected, the first detected device is connected first. To view more detected devices to connect, press the Show More button. ✎ When LG Sound Sync (Wireless) is active and you turn on the TV, it will search and try to connect the device which recently connected.
  • Page 38 Settings ➙ SOUND ➙ Sound Out ➙ LG Sound Sync (Wireless) Sound output is through the Bluetooth headset. ✎ The devices that can be connected are: LG BTS1, LG HBS-700, LG HBS-730, LG HBS-800 (Product availability may vary by country.)
  • Page 39 Magic Remote Control dongle. (AN-MR400, sold separately) ✎ For wireless connection, if the device fails to connect. Check the device power to connect and if the LG Audio device is in a proper operating condition. ✎ If two or more devices are detected, the first detected device is connected...
  • Page 40 To use Analog Out/Headphone ❐ [Depending on model] SMART ➾ Settings ➙ SOUND ➙ Sound Out ➙ External Speaker (Audio Out) Headphone Select Headphone External Speaker (Audio Out) depending on the device connected to the analog out port. ✎ The available menu may vary depending on whether you select Headphone External Speaker (Audio Out) in the...
  • Page 41 To❐select❐an❐external❐input ❐ ❐ SMART❐ ❐➾ Input❐List Selects external input. INPUT❐LIST Select❐an❐input❐device❐to❐view. Selects speaker. TV Speaker Selects input. Antenna HDMI1 HDMI2 DLNA Sets the Channel Mode. Change Device Name SIMPLINK Setting Set the Universal Control Channel Mode [Depending on country] Allows you to edit the Sets OSS.
  • Page 42 Using❐SIMPLINK ❐ ❐ SIMPLINK allows users to control and manage multiple multimedia devices using the TV remote control and SIMPLINK menu. 1 Connect the TV's HDMI IN terminal with the SIMPLINK device's HDMI output terminal using an HDMI cable. For home theater units with SIMPLINK support, connect the HDMI ports and then use an optical cable to connect the Optical Digital Audio Out from the TV to the Optical Digital Audio In of the SIMPLINK device.
  • Page 43 ✎ This function works only on devices with the SIMPLINK logo ( Make sure that the external device has a SIMPLINK logo. ✎ To use the SIMPLINK function, use a high-speed HDMIⓇ cable (with CEC, or Consumer Electronics Control feature added) and No. 13 pin connected for information exchange between devices.
  • Page 44 ❐ ❌ Explanation❐of❐SIMPLINK❐features❐❐ Play the multimedia device on the TV instantly without Direct Play extra steps. Select Select the desired device through the SIMPLINK menu and multimedia instantly control it from the TV screen. device. Manage the multimedia device with the TV remote Disc playback control.
  • Page 45 If the Auto Power function is set to On in the SIMPLINK Sync Power on settings, turning on a SIMPLINK device will turn the TV on. Speaker Selects speaker on the home theater unit or TV.
  • Page 46 To❐use❐Sleep❐Timer ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐TIME❐➙❐Sleep❐Timer Turns off the TV after a prescribed number of minutes. To cancel the Sleep Timer, select Off.
  • Page 47 To❐set❐current❐time ❐ ❐ SMART❐ ❐➾ Settings❐➙❐TIME❐➙❐Clock Checks or changes the time while watching TV. Synchronizes the TV clock to the digital time information sent by Auto the TV station. Sets the time and date manually if the auto setup does not Manual correspond to the current time.
  • Page 48 To❐set❐the❐TV❐to❐turn❐on❐and❐off❐automatically ❐ ❐ SMART❐ ❐➾ Settings❐➙❐TIME❐➙❐On❐Time/Off❐Time Sets On/Off time. Select Repeat to discontinue On Time/Off Time. ✎ To use On Time/Off Time, set the current time correctly. ✎ Even when the On Time function is on, the TV will turn off automatically in 120 minutes when no button is pressed within that time.
  • Page 49 To❐set❐password ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐LOCK❐➙❐Set❐Password Sets or changes TV password. ✎ The initial password is set as 「0000」.
  • Page 50 To❐lock❐system ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐LOCK❐➙❐Lock❐System Permits only specific programs by blocking channels or external input. Select the Lock System to On. Blocks the channels that contain inappropriate contents for children. The channels can be selected but the screen is blank Block Channel and the audio is muted.
  • Page 51 [Depending on model] Blocks the movies that are only broadcasted on the TV and contain inappropriate contents, based on the Motion Picture Association of America (MPAA) rating. • G : (General audiences) All ages admitted • PG : (Parental guidance suggested) Some material may not Movie Rating be suitable for children •...
  • Page 52 [Depending on model] Blocks the children’s TV programs that parents do not want their children to watch. To block other TV programs, you should set the TV Rating-General feature. TV Rating- • Age : TV-Y (All children, including children from ages 2-6), Children TV-Y7 (Directed to older children, suitable for children age 6 and above)
  • Page 53 Blocks the TV programs that you want based on the ratings by using the Parental Control Function (V-Chip). ✎ The V-Chip electronically reads TV program ratings and allows parents to block program that are unsuitable for children. • Age : TV-G (General audience, suitable for all ages) TV-PG (Parental guidance suggested, containing material that TV Rating- are unsuitable for younger children)
  • Page 54 [In Digital mode Only] Downloadable This function operates only when TV has received Region5 Rating Rating data. The name of the rating option may differ. Input Block Block the input sources. Application Lock the Application. Lock...
  • Page 55 To❐set❐password ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐LOCK❐➙❐Set❐Password Sets or changes TV password. ✎ The initial password is set as 「0000」.
  • Page 56 To❐lock❐system ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐LOCK❐➙❐Lock❐System Permits only specific programs by blocking channels or external input. Select the Lock System to On. Blocks the channels that contain inappropriate contents for children. The channels can be selected but the screen is blank Block Channel and the audio is muted.
  • Page 57 [Depending on model] Selecting Canadian English rating system. • E : Exempt • C : Children TV Rating- • C8+ : Children eight years and older English • G : General programming, suitable for all audiences • PG : Parental Guidance •...
  • Page 58 [Depending on model] Selecting Canadian French rating system. • E : Exempt • G : General • 8ans+ : General-Not convenient for little children TV Rating- • 13ans+ : Not convenient for children of 13 years and French younger • 16ans+ : Not convenient for children of 16 years and younger •...
  • Page 59 [In Digital mode Only] Downloadable This function operates only when TV has received Region5 Rating Rating data. The name of the rating option may differ. Input Block Block the input sources. Application Lock the Application. Lock...
  • Page 60 SMART ➾ Settings ➙ OPTION ➙ Language Selects Menu Language and Audio Language displayed on the screen. Menu Selects a screen menu language. Language [In Digital Mode Only] Audio Selects the desired language when watching digital Language broadcasting containing several audio languages. Voice Select the language to make voice search.
  • Page 61 SMART ➾ Settings ➙ OPTION ➙ Caption View subtitles when the TV station provides subtitled programing. Program subtitles work only on digital/analog broadcasts or external input. Change Caption and select caption setting. CC 1-4 (Closed Captioning) / Text 1-4 Text 1-4 Displays the audio portion of a TV program as text on the TV screen.
  • Page 62 Set up the size and color of the subtitles on Digital Option. Please Digital select Set by Program or Custom. Option Select Custom to adjust minute options such as the subtitles’ size and color.

  • Page 63: To❐Register❐The❐Magic❐Remote❐Control

    To❐register❐the❐Magic❐Remote❐Control ❐ ❐ To use the Magic Remote Control, register it with your TV first. Register Magic Remote Control as follows: 1 Turn on the TV and wait for about 10 seconds and then press Wheel(OK) button while pointing the remote control at the TV. 2 The remote control is automatically registered and a registration completion message appears on the TV screen.

  • Page 64: To❐Re-Register❐The❐Magic❐Remote❐Control

    To❐re-register❐the❐Magic❐Remote❐Control ❐ ❐ SMART❐ 1 Press the BACK buttons at the same time for about 5 seconds. 2 Press the Wheel (OK) button towards the TV to re-register the Magic Remote Control. SMART❐ ✎ Press the button and BACK button at the same time, for five seconds, to reset the Magic Remote Control.
  • Page 65 To❐set❐the❐pointer❐of❐the❐Magic❐Remote❐Control ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐OPTION❐➙❐Pointer Sets the speed and shape of the pointer that appears on the TV screen. Speed Sets the moving speed of the pointer. Shape Chooses from different shapes of the pointer. Size Chooses the size of the pointer. Set it to On.
  • Page 66 ✎ If the pointer has not been used for a certain period of time, it will disappear. When the pointer disappears from the screen, shake the Magic Remote Control to the right and left. Then, it appears again. ✎ If you press the navigation button while moving the pointer on the screen, the pointer disappears, and the Magic remote control works as a regular remote control.
  • Page 67 ✎ Electronic devices nearby may cause communication interference. Devices such as microwave oven and wireless LAN use the same frequency range (2.4 GHz) as the Magic Remote Control, which may interfere with the remote control. ✎ The Magic Remote Control may be broken if dropped or damaged in any other way.
  • Page 68 To❐use❐the❐pattern❐gesture❐function❐ ❐ ❐ Press the Wheel(OK) button with the normal video screen on and draw a pattern toward the screen. Previous channel: Moves back to the previous channel. Recent list: Shows channels recently watched. Shows channel lists which be related to pattern. Choose the channel.
  • Page 69 To❐set❐Power❐Indicator ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐OPTION❐➙❐Standby❐Light [Depending❐on❐model] Turns the standby light in the front panel of the TV on/off.
  • Page 70 To❐adjust❐the❐front❐LG❐Logo❐Light ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐OPTION❐➙❐LG❐Logo❐Light [Depending❐on❐model] You can adjust the LED brightness of the LG logo at the bottom of the TV. You can set the brightness of LG Logo Light to Off/Low/ Brightness Medium/High when the TV power is off.
  • Page 71 You can set the off time of LG Logo Light when the TV power is on. • Off right now : The light is turned off as the TV power is When TV is on • Off after 10 min.
  • Page 72 To❐change❐TV❐mode ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐OPTION❐➙❐Mode❐Setting Selects Home Use Store Demo. For use at home, select Home Use. Store Demo is a mode used for store display.
  • Page 73 To❐return❐to❐initial❐settings ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐OPTION❐➙❐Initial❐Setting Deletes all optional settings and returns to initial default mode. Once initialization is complete, the TV will turn off and on by itself. ✎ If Lock System is activated, a pop-up password prompt will appear. ✎...
  • Page 74 To❐set❐ZIP❐Code ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐OPTION❐➙❐ZIP❐Code This function sets your area as the ZIP Code. ✎ You can check the information of area when network is connected.

  • Page 75: Using The Home Screen

    Select desired card. News Sports Viral Video -1 MBC HD July 4 8:30 pm Monster Ghost Abata Photo Game Thanks My Boy My Apps More Input List Settings Internet Search Photos Smart Sh... LG Smart... Game Wo... User Guide Ch.List...
  • Page 76 To❐use❐and❐edit❐MY❐CARD ❐ ❐ SMART❐ ❐➾❐MY❐CARD To enable you to easily check and access a wide variety of content and functions, the main functions are grouped into categories and displayed on cards. By selecting the card name, you can go to that category page. Select Edit at the top of the home screen to switch the position of the cards or...

  • Page 77: To❐Use❐My❐Apps

    Select More to check apps pre-installed apps and apps you have downloaded. More Input List Settings Internet Search Photos Smart Sh... LG Smart... Game Wo... User Guide Ch.List Select the desired app to run.
  • Page 78 To❐edit❐items❐in❐My❐Apps ❐ ❐ SMART❐ ❐➾❐More❐➙My❐Apps❐➙❐Edit On the My Apps page, select Edit at the top of the screen to move or delete apps. Please note that system apps can be moved, but cannot be deleted. ✎ On models equipped with the Magic Remote Control, you can move apps or delete them by selecting and then dragging them.
  • Page 79 A wireless or wired network connection is necessary to use the Smart TV features. Once the network connection is established, Premium Content, LG Smart World, DLNA, and more are available. Network❐connection❐by❐one-click ❐ ❐ It’s easy to connect to a wired/wireless network.
  • Page 80 To❐connect❐network❐through❐Set❐Expert ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐NETWORK❐➙❐Network❐Connection Used in special circumstances such as in offices (For example, when a static IP is needed). 1 Select a network connection either through Wired or Wireless. 2 When connecting via Wi-Fi, use the one of the following network connection methods.
  • Page 81 Connects easily by pressing the button of a wireless WPS-PBC access point supporting PBC. Connects easily by typing in the PIN from the admin page WPS-PIN of the desired wireless AP.
  • Page 82 To❐use❐Wi-Fi❐direct❐function ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐NETWORK❐➙❐Wi-Fi❐direct Wi-Fi Direct is a function that allows your TV to connect with a Wi-Fi Direct device without going through a router or gateway. With SmartShare , you can watch the files stored on a device connected via Wi-Fi Direct.
  • Page 83 To❐use❐the❐Miracast™/Intel’s❐WiDi❐function ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐NETWORK❐➙❐Miracast™/Intel’s❐WiDi You can view the screen of a device with Miracast™ and Intel’s WiDi technologies on your TV. 1 Set Miracast™/Intel’s WiDi to On. (If you do plan on useing wither of these features, please change it to Off.) 2 Enable the Miracast™...
  • Page 84 ✎ You may not connect your TV to a non-LG Electronics device even when it is detected. ✎ It is recommended you to connect a device to a 5GHz router.
  • Page 85 OFF, disconnect and reconnect it, and then turn the power on to solve the problem. ✎ LG Electronics is not responsible for any network connection problems or any faults, malfunctions, or errors caused by network connection. ✎ The network connection may not work properly because of network settings...
  • Page 86 ✎ DSL service must use a DSL modem; and cable service must use a cable modem. Since only a limited number of network connections may be available, TV network setting may not be used depending on the contract with Internet service provider. (If the contract does not allow more than one device per line, only the already-connected PC may be used.) ✎...
  • Page 87 ✎ The access point device must support wireless connections and wireless connection feature must be enabled on the device to have AP (access point) connection. Contact the service provider for availability of wireless connections on the access point. ✎ Check SSID and security settings of the AP. Refer to the appropriate documentation for SSID and security settings of the AP.

  • Page 88: What❐Is❐Tag❐On

    What❐is❐Tag❐On? ❐ ❐ Tag On is a data transmission technology that can be used on smartphones with NFC (Near Field Communication). Simply by tapping your smartphone to a Tag On sticker, you can share content between your smartphone and TV. To connect your smartphone to the TV using Tag On, they must be connected on the same Wi-Fi network.
  • Page 89 ✎ Do not attach the sticker to a metal part of the TV. Otherwise, your smartphone cannot recognize the Tag On sticker. ✎ Do not crumple or fold the Tag On sticker. Otherwise, the Tag On is not recognized ✎ To purchase a Tag On sticker, please visit your local retailer. ✎...

  • Page 90: To❐Start❐Tag❐On❐For❐The❐First❐Time

    For more information on enabling NFC and setting the mode, refer to the owner's manual of your smartphone. 3 Tap your smartphone to a Tag On sticker. Make sure to follow the instructions on the smartphone screen and install the Tag On app and LG TV Remote app.
  • Page 91 4 Tap the smartphone to the Tag On sticker again. 5 Enter the pairing key displayed on the smart TV into the smartphone. When two or more TVs are detected, the pairing key is displayed only after the TV you want to connect to is selected in the device list. 6 When the connection is made properly, you can use Tag On.
  • Page 92 To❐use❐Tag❐On ❐ ❐ Follow the steps below to share content on your NFC-enabled smartphone. 1 Tap the NFC-enabled smartphone to a Tag On sticker. 2 The Tag On app starts running on the smartphone to connect to the smart - To use a Wi-Fi network, make sure that the smart TV is on the same network as your smartphone.
  • Page 93 ✎ If the Tag On app is not installed, the installation page appears automatically. ✎ For more information on how to share content between your smartphone and TV, refer to the Tag On app's help. Click to run the Tag On app on your smartphone and select the Settings menu to view the help.
  • Page 94 To❐connect❐a❐USB❐storage❐device ❐ ❐ Connect a USB storage device (external hard drive or USB memory) to the USB port of TV to enjoy multimedia files stored on the USB device. To remove a USB storage device, choose the Quick Menu ➙ USB Device disconnect the device.
  • Page 95 Caution❐when❐using❐USB❐storage❐device ❐ ❐ ✎ If a USB storage device has a built-in auto recognition program or uses its own driver, it may not work. ✎ Some USB storage devices may not work or work improperly. ✎ If you use a USB extension cable, the USB device may not be recognized or may not work properly.
  • Page 96 ✎ It is recommended to use USB Memory Sticks with 32 GB or less and USB hard drives with 2 TB or less. ✎ For USB hard drives with energy-saving features, turn off and turn on again if it does not work properly. For more information, refer to the user manual of USB HDD.

  • Page 97: To Use Smartshare

    To use SmartShare™ ❐ SMART ➾ SmartShare™ Playback photo/music/video files on the TV from a USB device or home network (DLNA). ✎ Image shown may differ from your TV. SmartShare™ Recently Played Recent Displays photo/music/video Video Photo files from all of the devices Music connected to the TV.

  • Page 98: To Control Video Playback

    To control video playback ❐ Controls playback and sets options while viewing videos. ✎ Image shown may differ from your TV. Selects the desired point and plays Option Sets Options Playback Controls Changes to 3D mode.

  • Page 99: To Control Photo View

    To control photo view ❐ Controls playback and sets options while viewing pictures in full screen. ✎ For 3D pictures, the Slide Show Effect does not work even when the Slideshow function is enabled. ✎ Image shown may differ from your TV. Option Displays photos as a Sets options.

  • Page 100: To Control Music Playback

    To control music playback ❐ Controls playback and sets options while playing music. ✎ Image shown may differ from your TV. Selects the desired point and plays Sets options Listens to music with the video Plays Sets the repeat/random turned off. function.
  • Page 101 ✎ You can control playback using the ꕚ , ꕖ and ꕙ keys on a standard remote control. ✎ If you use the USB device, time information will be not shown on screen.
  • Page 102 To set SmartShare™ related functions ❐ SMART ➾ SmartShare™ ➙ Settings Changes settings related to SmartShare content play. ❌ Advanced Setting Changes the name that appears when searching for the TV My TV Name from other devices. Network Status Checks the network connection. Allows use of wireless connection functions such as Wi-Fi Wi-Fi direct direct and WiDi.
  • Page 103 Registers or releases DivX. Checks DivX Registration Code for playing DivX-protected videos. Register at http://vod.divx.com. Uses Registration Code to rent or purchase movies at www. divx.com/vod. DivX(R) VOD ✎ When using the DivX Registration Code of another device, the rented/purchased DivX file cannot be played. Use only the DivX Registration Code granted to this device.
  • Page 104 ❌ Delete History To delete contents history, press Delete History button below. Use the contents Recent menu.
  • Page 105 SmartShare™ supporting file ❐ Maximum data transfer rate : • Full HD 1920 X 1080: 20 Mbps (Mega bit per second) • ULTRA HD [Depending on model] ULTRA HD Video 3840 X 2160 (H.264 L5.1) : 50 Mbps 3840 X 2160 (H.265 L5.0) : 25 Mbps...
  • Page 106 External supported subtitle formats : *.smi, *.srt, *.sub (MicroDVD, SubViewer 1.0/2.0), *.ass, *.ssa, *.txt (TMPlayer), *.psb (PowerDivX), *.dcs (DLP Cinema) Internal supported subtitle formats : • Full HD Video 1920 X 1080: XSUB (Supports internal subtitles generated from DivX6) • [Supports only ULTRA HD model] ULTRA HD Video: It does not support internal subtitles.
  • Page 107 ❌ Video Supported Codec Maximum: • Full HD :1920 x 1080 @30p • ULTRA HD [Depending on model] : 3840 x 2160 @ 30p Extension Codec Video VC-1 Advanced Profile, VC-1 Simple and Main Profile .asf .wmv Audio WMA Standard, WMA 9 Professional DivX3.11, DivX4, DivX5, DivX6, XViD, H.264/AVC, Video Motion Jpeg, MPEG-4 Part 2...
  • Page 108 Extension Codec .mp4 Video H.264/AVC, MPEG-4 Part 2 .m4v Audio MPEG-1 Layer III (MP3) .mov Video H.264/AVC, MPEG-4 Part 2 .3gp .3g2 Audio AMR-NB, AMR-WB Video H.264/AVC .mkv Audio Dolby Digital Video H.264/AVC, MPEG-2, VC-1 .trp MPEG-1 Layer I, II, MPEG-1 Layer III (MP3) Audio .mts Dolby Digital, Dolby Digital Plus...
  • Page 109 Extension Codec Video MPEG-1, MPEG-2 .vob Audio Dolby Digital, MPEG-1 Layer I, II, DVD-LPCM Video MPEG-1, MPEG-2 .mpg .mpeg Audio MPEG-1 Layer I, II, MPEG-1 Layer III(MP3)
  • Page 110 ❌ Available music file File type Item Info Bit rate 32 Kbps - 320 Kbps Sample freq. 16 kHz - 48 kHz Support MPEG1, MPEG2, Layer2, Layer3...
  • Page 111 ❌ Available photo file File type Item Profile Minimum: 64 x 64 Maximum: JPEG (jpeg, jpg, jpe) Normal Type: 15360 (W) x 8640 (H) Progressive Type: 1920 (W) x 1440 (H) Minimum: 64 x 64 3D(jps) Maximum: Normal Type: 15360 (W) x 8640 (H) 4:3 size 3648 x 2736 2592 x 1944...
  • Page 112 Caution for playing video ❐ ✎ Some subtitles created by users may not work properly. ✎ The video and subtitle files should be placed in the same folder. In this case, you must assign the same names for the video and subtitle files for proper display.
  • Page 113 ✎ [Supports only ULTRA HD model] ULTRA HD Video: 3840 X 2160 • It supports the playback through USB only. • LG’s ULTRA HD is fully compatible with most of ULTRA HD contents encode in HEVC delivering stunning high resolution contents. However it may not support certain types of codec contents.
  • Page 114 ✎ The file size limit is dependent on the encoding environment. ✎ Only Window Media Audio V2 and above is supported. ✎ Video files created by some encoders may not be played back. ✎ Video files in formats other than the ones specified here may not be played back.

  • Page 115: To❐Connect❐A❐Dlna-Authenticated❐Smartphone

    TV and the smartphone should be on the same network. 1 Enable Wi-Fi on the smartphone. 2 Install/run a DLNA app to share content on the smartphone (It’s called SmartShare on LG phones). 3 Run “Share my mobile phone Content”. 4 Select the kind of Content (video/music/photo) to play.
  • Page 116 To❐connect❐a❐DLNA❐DMR❐(Digital❐Media❐Renderer)❐ ❐ ❐ With the Windows 7 or Windows 8 PC operating system or DLNA-certified device (e.g. mobile phone), music/videos/photos may be played on the TV without installing a separate program. 1 Configure the TV and PC on the same network. Configure the Windows 7 or Windows 8 PC on the network.

  • Page 117: To❐Connect❐A❐Dlna❐Dmp❐(Digital❐Media❐Player)

    To❐connect❐a❐DLNA❐DMP❐(Digital❐Media❐Player) ❐ ❐ With a PC having SmartShare PC Software, music/video/photo files may be played on the TV via home networking. 1 Configure the TV and the PC on the same network. The TV and each device should be connected through a single access point to enable DLNA service. 2 Install the SmartShare PC Software from the web site onto a PC.
  • Page 118 ❐ ❌ If❐a❐DLNA❐malfunction❐occurs ✎ If a DLNA feature does not work properly, check network settings. ✎ A 5-GHz access point is needed to view 1080p videos via DLNA. A 2.4-GHz access point may cause frequent buffering or other problems. ✎ DLNA may not work properly on a wireless network. It is recommended to use a wired connection.
  • Page 119 ✎ The DLNA feature cannot be used with some access points that do not support multicasting. For more information, refer to access point manual or consult with the manufacturer. ✎ Supported file types may differ depending on the DLNA server environment, even for the file types supported by TV.
  • Page 120 To❐use❐Premium ❐ ❐ SMART❐ ❐➾❐Premium This service gives you easy access to a wide variety of content, such as video, news and UCC (User Created Content), at any time, as long as you are connected to a network. For Premium content, specialized country-specific services are offered that take into account regional content, in addition to globally provided content.

  • Page 121: To❐Use❐Paid❐Content

    LG Electronics’ proprietary billing system or that of each content provider. Before using the LG billing system, you will need to sign up for membership and register payment information on TV or the website (www.lgappstv.com) . You can sign up for membership on the login screen on your TV or our website.
  • Page 122 1 Click Sign In button in upper right corner of Home screen to sign in. 2 Move to the desired Premium service. (For some premium services, separate sign-in is required after signing up for the premium service.) 3 After checking the content’s pricing and service information, click the Purchase button.

  • Page 123: To❐Reset❐Premium

    To❐reset❐Premium ❐ ❐ SMART❐ ❐➾❐Premium❐➙❐Option❐➙❐Initialization❐of❐Premium Premium list, Premium information, country setting, and user sign-in information will be reset. When an error occurs during Premium update, reset will fix the problem.
  • Page 124 Refer to the web site of each content provider for questions, troubleshooting, or latest information about Content. LG Electronics does not take any legal responsibility for content services and related information including discontinuation of service by the service provider.

  • Page 125: To Use Lg Smart World

    [This function may not be applied some countries.] ➾ LG Smart World SMART LG Smart World is a TV application service available through Smart TV Service. You can download and enjoy many different apps (for fee or free) including education, entertainment, life and news. Sign in.

  • Page 126: To❐Sign❐Up❐With❐Lg❐Smart❐World

    To❐sign❐up❐with❐LG❐Smart❐World ❐ ❐ ❐➾❐Sign❐In SMART❐ Sign up is required to download and run apps. 1 Select Sign Up and agree to Legal Notice. 2 Enter ID and password. 3 In Confirm Password box, enter password again. 4 Select to complete sign-up process.
  • Page 127 1 Click the Sign In button at the top of the home screen to log in. 2 Select the LG Smart World card. 3 Select an app you want from the list. 4 Check the details of the app, then select the Install button.
  • Page 128 ✎ You can purchase apps from PC or TV but you must use the TV to install and run them. ✎ If you have insufficient storage space on the TV, you can download apps to a USB storage device connected to the TV’s USB Apps port. Apps stored on a USB device are available to run/delete/move via the My Apps screen.

  • Page 129: To❐Manage❐My❐Information

    To❐manage❐my❐information ❐ ❐ ❐➾❐LG❐Smart❐World SMART❐ 1 Sign in. 2 Select the currently signed-in ID at the top of the screen. 3 Select Page. 4 Manages by examining Member Information, My Purchased Apps List and TV Installed Apps List.
  • Page 130 Shows basic information about the ID currently signed My Information in. To change your member information, please visit www.lgappstv.com on your PC. Payment Inquiry Views Payment History with the ID you have signed in. Vews My Purchased Apps List with the ID you have Purchased Apps signed in.
  • Page 131 ➾ Search You can search apps and contents using the Search function of the LG Smart TV. When you enter keywords using the input device, such as the remote control, you can find apps from LG Smart World and some contents of the Premium service.

  • Page 132: To Use The Voice Recognition Function

    To use the voice recognition function ❐ ❌ Using this function through search 1 Go to SMART ➾ Search. Select the voice recognition icon ( ) on the left of the text field. 2 Speak slowly and clearly after the voice recognition window appears. After the voice recognition is completed, the Similar List window pops up.
  • Page 133 ❌ Using this function in the Internet (Web browser) 1 Go to SMART ➾ Internet. Move the Magic Remote Control pointer in the text field on a website to open the virtual keyboard. 2 Select the voice recognition icon ( ) on the left of the text field on the virtual keyboard.
  • Page 134 ✎ You can use Voice Search when you press the Voice recognition( ) on the Magic remote control even if QWERTY keyboard is shown on your screen. ✎ Check the network connection before using the voice recognition function. ✎ When speaking, hold the remote within 10cm of your mouth. ✎...

  • Page 135: What❐Is❐Voice❐Mate

    What❐is❐Voice❐Mate? ❐ ❐ Voice Mate allows you to search desirable programs and content with your voice and adjust the TV. 1 Press the Voice recognition ( ) button on the Magic Remote Control. 2 When the Voice Display bar ( ) is activated on the left of the screen, say what you want to watch.

  • Page 136: How❐To❐Use❐Voice❐Mate

    How❐to❐Use❐Voice❐Mate? ❐ ❐ ✎ To use all the functions and services of Voice Mate, you need to set Smart Wizard and Time. Set up the network, region, auto tuning, and universal remote control through the Smart Wizard. ✎ In order to use Voice Mate, you must set up the network, time, region, and tuning.
  • Page 137 ✎ It is recommended you to point the universal remote control towards the set- top box when you use Voice Mate with it. ✎ When speaking a command, hold the remote within 10cm of your face. ✎ The voice search may fail when you speak too fast or too slow. ✎...

  • Page 138: What❐Are❐Other❐Functions❐Of❐Voice❐Mate

    What❐are❐other❐functions❐of❐Voice❐Mate? ❐ ❐ You can access various TV features using Voice Mate. You can tune TV channels and search channel Channel information. Example: “What time is American Idol on?” You can recommend and search TV programs and Recommendation content files. and Search Example: “Look up American Idol”...
  • Page 139 SMART ➾ Internet (Web browser) You can type in a URL manually or visit a Web site from the Favorites list. Type in Web addresses here. Add the current page to favorites. Open a new tab.
  • Page 140 ✎ The Internet (Web browser) supports up to Flash 11 but does not support platform-dependent technology like ActiveX. ✎ The Internet (Web browser) only works with pre-installed plug-ins. ✎ The Internet (Web browser) only replays the following media file formats: JPEG / PNG / GIF ✎...
  • Page 141 Sign up is required to use LG Smart World. Free apps are available immediately after signing up, but you need to register your payment method in order to use paid apps. You can sign up and register payment methods on the TV or on our website (www.lgappstv.com).
  • Page 142 • If you sign up on your TV, no additional sign-up on the LG I already signed up on website (www.lgappstv.com) is required. TV. Do I need to sign...
  • Page 143 Problem Solution • It is possible to register and use more than one ID on one Can each family member • To check the ID registered with TV from use a different ID with a SMART ➾ Sign in ➙ ID List. single TV? • You can check the list of apps purchased by each ID.
  • Page 144 • To check purchased apps from the TV, sign in and open I purchased an app from the Purchased Apps menu. the LG TV Apps Web site. Select the ID at the top of Home and check the app in How can I use it on TV? My Page ➙ Purchased...
  • Page 145 • Please check if the TV model supports LG Smart World. Can I use apps from LG • The apps provided from LG Smart TV's LG Smart World can Smart TV's LG Smart only be used on an LG Smart TV.
  • Page 146 Problem Solution How can I check the ID • Select the ID at the top of Home and check the currently currently signed in on the signed-in ID in My Page ➙ My Information. I installed an app on the • Select SMART ➾ My Apps.
  • Page 147 I forgot my password on • If you provide other information than the ID and password the TV. What should I do? when signing up on your TV or the LG website (www. lgappstv.com), you can recover your password on the website.
  • Page 148 Problem Solution • To purchase paid apps, you should have a credit card registered on the LG Smart World website (www.lgappstv. com) or have an account credit. If you do not want your Do I have to enter credit card details to be saved, you may add a credit to payment information to your account before buying an app.
  • Page 149 Problem Solution • To purchase paid apps, you need to have a credit card registered with the website (www.lgappstv.com). I signed up on my TV, but Also, you can have place a credit on your account ahead of I cannot purchase paid time.
  • Page 150 • If you are already a member, you can still use your existing ID or change it to an email address. • The LG account allows you to sign into all of the LG Smart services with a single ID and password.
  • Page 151 SMART❐ ❐➾❐Settings❐➙❐OPTION❐➙❐Service❐Country❐Setting You can change the country setting of your Smart TV. The Premium service and LG Smart World that are available for the country you selected will be provided. Auto Setting A service country is automatically set for your Smart TV.

  • Page 152: To❐Use❐Screen❐Remote

    To❐use❐Screen❐Remote ❐ ❐ Press❐the❐ ❐button❐on❐the❐Magic❐Remote❐Control. Use the Magic Remote Control to select buttons on the Screen Remote displayed on the screen.
  • Page 153 ❐ ❌ To❐use❐Screen❐Remote ✎ The type of buttons on the Screen Remote varies depending on the region or the type of connected device. ✎ Image shown may differ from your TV. Change Device tab Exits the Screen Remote Moves the position of the Screen Remote to left or right TV operation buttons ✎...
  • Page 154 To❐control❐a❐device❐connected❐to❐the❐TV❐using❐the❐Screen❐ ❐ ❐ Remote You can control a device connected via SimpLink or MHL using the Screen Remote. 1 Check if the device is connected to the TV. 2 After pressing the button on the Magic Remote Control, select the device you want to control in the Change Device tab.

  • Page 155: To❐Use❐The❐Universal❐Control❐Function

    To❐use❐the❐Universal❐Control❐function ❐ ❐ [For Magic Remote Control only] [This function may not be applied some countries.] With the Magic Remote Control, you can control a set-top box, Blue-ray player, home theater system, etc. 1 Connect the device you wish to control to the TV. 2 After pressing the button on the Magic Remote Control, select the icon of a device you want in the Change Device tab.
  • Page 156 ❐ ❌ To❐change❐or❐clear❐the❐Universal❐Control❐settings 1 After pressing the button on the Magic Remote Control, select the (TV/input selection) button. 2 Select Change Setting Cancel Setting at the bottom of the device to be changed. ✎ When Change Setting, check if the power of the device to be changed is turned on.
  • Page 157 ✎ You can set one device per type. ✎ With the Screen Remote, you can only control the devices of a brand or manufacturer that you can select in the setup screen. ✎ If you connect to a network before setting the universal remote control, update for the latest manufacturer list is available.

  • Page 158: To❐View❐3D❐Images

    To❐view❐3D❐images ❐ ❐ 3D imaging is a technology that utilizes the slight difference in left/right eyes to make the images on TV appear just like real-life 3-dimensional space. 1 Play a 3D-image title or tune to a 3D channel. 2 Put on 3D glasses. 3 Press the button to activate 3D.
  • Page 159 To❐adjust❐details❐of❐3D❐images ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐PICTURE❐➙❐3D❐Settings Adjusts various aspects of 3D imaging. Provides the appropriate 3D depth. • 3D Depth : Adjust 3D depth between the 3D Mode foreground object(s) and the background. • 3D Viewpoint : 3D image can be made closer or farther from user.
  • Page 160 3D Sound Zooming Provides 3D-optimized sound. This will activate and deactivate 3D mode 3D Pattern Recognition automatically based on the input. Normal Image View This will down-convert a 3D signal to 2D. Corrects the color of 3D images. 3D Color Correction ✎...
  • Page 161 Caution❐when❐viewing❐3D❐images ❐ ❐ ✎ When viewing 3D images, it is recommended that the viewer maintain a distance of at least twice the screen's diagonal length. ✎ 3D images may not be viewed correctly with shutter-type glasses that require recharging. ✎ If a future 3D broadcasting format that is not supported by this TV becomes the standard, an additional device such as a set-top box may be required.
  • Page 162 Warning❐when❐using❐3D❐glasses ❐ ❐ ✎ Do not use the 3D glasses as a replacement for your own corrective glasses, sunglasses, or protective goggles. Improper use of 3D glasses may cause eye injuries. ✎ Do not store 3D glasses in extreme conditions. Exposure to excessively high or low temperatures may deform the lenses.
  • Page 163 What❐is❐Motion❐Recognition? ❐ ❐ You can control the TV simply by gesturing for the camera. You can use the Motion Recognition function to turn the TV off, change the channel, or control the volume. ✎ Motion Recognition is only active when watching TV and is not supported when using the smart menu, for example when connecting wireless devices, including TV apps and USB ports.
  • Page 164 1 Prepare the Smart TV camera for use. If your Smart TV is not equipped with a camera, install an LG video call camera (sold separately). (For more information, please refer to the installation manual or owner's manual of the camera.)
  • Page 165 5 Move your hand left or right to select a function. Bend and then straighten your index finger to start the function. 6 If you lower your hand out of the range of motion recognition, the controller disappears from the screen. ✎...
  • Page 166 ✎ Motion Recognition may not work properly if: • The room is either too bright or too dark. (Optimal ambient brightness: 50 lux - 600 lux) • When your hand cannot be recognized because of an intense bright light behind you. •...
  • Page 167 ✎ A gesture may not be recognized in the following cases. • If Motion Recognition is set to SMART ➾ Settings ➙ OPTION, : Set it to On. • If any other menu than the motion recognition controller is displayed on the TV screen, : Make it disappear.
  • Page 168 ✎ If multiple people attempt to perform motion recognition at the same time, only the first gesture is recognized. To switch hands when operating the controller, lower your first hand down to clear the controller from the screen and then raise your second hand up for motion recognition. ✎...
  • Page 169 1 Prepare the Smart TV camera for use. If your Smart TV is not equipped with a camera, install an LG video call camera (AN-VC500, sold separately). (For more information, please refer to the installation manual or owner's manual of the camera.)
  • Page 170 ❐ ❌ To❐take❐a❐video SMART❐ ❐➾❐MY❐APPS❐➙❐Camera❐➙❐ ❐(Video❐Mode)❐➙❐ ❐(Start) To❐stop❐taking❐a❐video,❐press❐ ❐(Stop)❐again. Zoom in/out Video mode Settings View the picture/video taken Take a picture Picture mode ✎ Image shown may differ from your TV.
  • Page 171 ❐ ❌ To❐set❐up❐the❐camera SMART❐ ❐➾❐MY❐APPS❐➙❐Camera❐➙❐ ❐(Settings) Properties You can set the properties of pictures/videos you will take. You can select a device where the pictures/videos taken will Storage device be saved.
  • Page 172 ✎ For a USB storage device, use only a USB hard disk that is formatted with an NTFS file system provided in Windows. If a storage device is formatted with a non-Windows file system, it may not be recognized. ✎ In case of watching the videos or seeing the pictures, you can only open one recent file.
  • Page 173 To❐turn❐on❐the❐TV❐with❐voice ❐ ❐ You can turn your TV on without using a remote control simply by speaking "TV Power On" towards the TV. SMART ➾ Settings ➙ OPTION and then check if Turn on by Voice is set to On. SMART ➾...
  • Page 174 ✎ Even when the built-in camera is hidden, you can use the Turn on by Voice function. ✎ The Turn on by Voice function may not work properly when: • You are too far away from the TV (Recommended distance: within 4.5 •...
  • Page 175 What is Dual Play mode? ❐ When playing a 2 player head-to-head game with a game console, such as Playstation, XBox and Wii, users used to play the game with the screen divided top and bottom or side by side. With Dual Play mode, each player can enjoy the game with a full screen.
  • Page 176 Starting Dual Play ❐ 1 Connect your game console to your TV. 2 Select SMART ➾ More ➙ Dual Play. The Dual Play mode starts. 3 Put on the Dual Play glasses to enjoy the game. 4 Dual Play mode turns off when you select SMART ➾...
  • Page 177 ✎ The game should support the Screen split mode to be played in Dual Play mode. ✎ If the screen does not look clear enough with the Dual Play glasses on, players can change the glasses with each other. You should choose proper glasses according to the operation type of Dual Play.
  • Page 178 Cautions When Using Dual Play Glasses ❐ ✎ Please note that Dual Play glasses are different from regular 3D glasses. There is the mark "Dual Play" written on the Dual Play glasses. ✎ Do not use Dual Play glasses as ordinary glasses, sunglasses or protective goggles.
  • Page 179 ✎ Do not drop Dual Play glasses or allow them to come into contact with other objects. This can result in damage to the product. ✎ The lenses of Dual Play glasses (polarizing film) are easily scratched. Use a soft clean cloth when cleaning them. Foreign particles on the cloth may cause scratches.
  • Page 180 Dual Play Supported Modes [FHD] ❐ Horizontal Frequency Vertical Frequency Input Signal Resolution (KHz) (Hz) Composite 480i 720x480 15.73 480i 720x480 15.73 Component 480p 720x480 31.50 720p 1280 x 720 1080i 1920 x 1080 33.75 HDMI/ 67.50 Component 1080p 1920 x 1080 33.75...
  • Page 181 Dual Play Supported Modes [ULTRA HD] : HDCP1.4 ❐ Horizontal Frequency Vertical Frequency Input Signal Resolution (KHz) (Hz) Composite 480i 720x480 15.73 480i 720x480 15.73 Component 480p 720x480 31.50 720p 1280 x 720 1080i 1920 x 1080 33.75 HDMI/ 67.50 Component 1080p 1920 x 1080...
  • Page 182 You can download the LG TV Remote app from Google Play Store or Apple App Store and control a TV that is on the same network ads your smartphone. • Now you can enjoy your favourite TV shows on your smartphone. (Some models only) • You can easily enter your account information to log in.
  • Page 183 • You can capture the screen you are watching and share it through social network services such as Twitter and Facebook. ✎ The supported functions may vary depending on the TV or the version of the LG TV Remote app.
  • Page 184 To❐use❐a❐USB❐wired/wireless❐mouse ❐ ❐ Connect your mouse to a USB port on the TV. Use the mouse to move the pointer on the TV screen and select the menu you want. Mouse Magic Remote Control Left Button OK Button on Magic Remote Control Wheel Button Wheel Button on Magic Remote Control ✎...
  • Page 185 ✎ It is recommended to use a product which has been tested for compatibility with LG TVs. LOGITECH K200, LOGITECH K400, MICROSOFT Comfort Curve 2000, MICROSOFT MS800, and LG Electronics ST-800 ✎ You can change the input language by pressing the language switch key (or the right Alt key) on your keyboard.
  • Page 186 Connect your gamepad to the USB port on the TV if the game requires a gamepad. ✎ It is recommended to use an authorized gamepad which is tested for compatibility with LG TVs. Logitech F310, Logitech F510, Logitech F710, Logitech Rumblepad 2 Logitech Cordless Rumblepad 2, Logitech Dual Action Gamepad,...
  • Page 187 SMART ➾ Settings ➙ SUPPORT ➙ Software Update Uses Software Update to check and obtain the latest version. It is also possible to check manually for available updates. Set it to On. Software Update If an update is available, a prompt will appear to perform the update.
  • Page 188 ✎ When the update starts, the update progress window appears for a short time and disappears. ✎ The latest version can be obtained via digital broadcast signals or internet connections. ✎ Changing the channel while downloading the software via digital broadcast signal interrupts the download process.
  • Page 189 If the following symptoms occur, please recheck the system. It may not be a failure. General ❐ ❐ Problem Solution Cannot view certain • Adjust the location or orientation of the antenna. channels. • Save the desired channels on Auto Tuning Channel Edit.
  • Page 190 Pictures ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐SUPPORT❐➙❐Picture❐Test Check if the image signal output is normal by beginning with Picture Test. If there is no problem with the test image, check external device connections or broadcast signals. Problem Solution Images from previous • Try adjusting the antenna to the direction of the TV channel or other channels station or refer to the manual for proper way to connect linger or the screen shows...
  • Page 191 Problem Solution • Such a problem may happen when there is strong Vibrating horizontal/vertical electronic interference. Turn off other electronic devices lines and fishnet patterns such as mobile phones, power tools and other small appear momentarily. electrical appliances. • It may happen when the signals are weak or the The screen display freezes reception unstable.
  • Page 192 Problem Solution • Check the HDMIⓇ cable specifications. Use only HDMIⓇ cable. Other cables may cause images to fade in and Image is not on or not clear out or not be displayed properly. when connected to HDMI. • Verify that all cable connections are securely connected.
  • Page 193 Sound ❐ ❐ SMART❐ ❐➾❐Settings❐➙❐SUPPORT❐➙❐Sound❐Test Try Sound Test first to verify that sound signal output is normal. When the test sound is normal, check external device connections or broadcast signals. Problem Solution Screen display is on but no • Check other TV channels. sound.
  • Page 194 Problem Solution • If it happens on a certain TV channel, it may be caused TV sound is not in sync with by problems with an individual station’s broadcast the lips or the sound breaks signal. Check with the TV station or local cable up occasionally.
  • Page 195 Problem Solution On certain channels, sound • On Language, set Language ➙ Audio Language as the does not come out or only desired language. Even if the language on Multi Audio the background music plays. is changed, once the power is turned off or the channel (If it is a program created for is changed, the default settings will be reset.

  • Page 196: Pc❐Connection❐Problem

    PC❐connection❐problem ❐ ❐ Problem Solution • Verify that the computer and the TV are securely connected. • Turn the TV off and back on using the remote control. The screen display is not • Restart the PC with the TV on. on after connecting to •...
  • Page 197 Problem Solution When connected to the computer, the display is • Set up the resolution supporting PC input. (If it does not partially cut off or shifts work, please reboot the computer.) to one side.
  • Page 198 Trouble❐with❐replaying❐movies❐in❐My❐Media. ❐ ❐ Problem Solution • Check if the file on the USB storage device can be read Files on the Movie List are on a computer. not displayed. • Check that the file extension is supported. "This file is invalid." The •...
  • Page 199 Problem Solution • Verify that the file replays normally on the video player in "Unsupported Audio." the computer. (Check for damaged files.) The above error message • Check that the audio codec is supported by the appears or the sound is not computer.
  • Page 200 Problem Solution • Verify that the file replays normally on the video player in the computer. (Check for damaged files.) • Check if the video file shares the same name with the subtitle file. Subtitle is not displayed. • Verify that the video and subtitle files are placed in the same folder.
  • Page 201 ❐ ❐ Federal❐Communications❐Commission❐(FCC)❐Statement You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
  • Page 202 • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules.
  • Page 203 ❐ ❐ Indoor❐use❐only FCC Caution: for indoor use only, use outdoors or in other modes not covered by this manual may violate the FCC regulation and violate the user authority to use the product. Specially, within the 5.15-5.25 GHz band, U-NII device is restricted to indoor operations to reduce any potential for harmful interference to co-channel MSS operations.
  • Page 204 ❐ ❐ Industry❐Canada❐Statement This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: 1 this device may not cause interference and 2 this device must accept any interference, including interference that may cause undesired operation of the device ❐...
  • Page 205 ❐ ❐ IC❐Radiation❐Exposure❐Statement This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
  • Page 206 ❐ ❐ Avis❐d’Industrie❐Canada❐sur❐l’exposition❐aux❐rayonnements Cet appareil est conforme aux limites d’exposition aux rayonnements d’Industrie Canada pour un environnement non contrôlé. REMARQUE : LE FABRICANT N’EST PAS RESPONSABLE DES INTERFÉRENCES RADIOÉLECTRIQUES CAUSÉES PAR DES MODIFICATIONS NON AUTORISÉES APPORTÉES À CET APPAREIL. DE TELLES MODIFICATIONS POURRAIENT ANNULER L’AUTORISATION ACCORDÉE À...
  • Page 207 Through these activities, LG seeks to contribute to conserving natural resources and protecting the environment. For more information about the LG Recycling Policy, please visit our global site at http://www.lg.com/global/sustainability/environment/take-back-recycling...

This manual is also suitable for:

55la8600.awd60la8600.awc60la8600.acc55la8600.acc

Table of Contents
