Thank you for purchasing this product.
- Read these instructions carefully for optimum
performance and safety before use.
- Keep this manual for future reference.
AWW9901D3003
AWW9901D3003_EN.indd 1
AWW9901D3003_EN.indd 1
Fully Automatic Washing Machine
Model No.
NA-F135A5 / NA-F135A5WSA
NA-F115A5 / NA-F115A5WSA
Operating & Installation
Instructions
(Household Use)
NA-F135V5
Contents
• Super Dry 90
T1118-30720 (SAUDI/ME/EG)
Printed in Thailand
2
6
7
8
10
12
14
16
19
20
21
24
28
29
30
07-2020
7/2/2563 BE 13:30
7/2/2563 BE 13:30
Advertisement
Table of Contents
Related Manuals for Panasonic NA-F135A5WSA
Summary of Contents for Panasonic NA-F135A5WSA
-
Page 1: Table Of Contents
Operating & Installation Instructions Fully Automatic Washing Machine (Household Use) NA-F135V5 Model No. NA-F135A5 / NA-F135A5WSA NA-F115A5 / NA-F115A5WSA Contents Safety Precautions Part Names / Accessories Before Washing Operation Panel Variety of Programs Detergent Washing Washing Options • Comforter • Delicate •... -
Page 2: Safety Precautions
Safety Precautions Read and follow these safety precautions. WARNING May cause serious injury or death. Do not allow children to use on their own. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. - Page 3 WARNING Never disassemble, repair or modify the appliance yourself. In case of malfunction or failure (burnt odour smell, fume, etc.), immediately stop use, unplug the power cord, and ask your nearest service centre for repair. Keep away from fire. Do not put flammable materials or clothes with such things attached in the tub.
- Page 4 Safety Precautions (continued) CAUTION May cause injury or property damage. Do not wash, rinse, or spin waterproof sheets or clothes. (To prevent injury, damage to the main unit, walls, floor or laundry, or water leakage if the appliance falls over or oscillates extremely while spinning) Raincoats, wet suits, etc.
- Page 5 CAUTION Observe the following Be careful not to get your fingers caught. Beware of sudden Soft closing when lid closing. fully opened. New hose-sets supplied with the appliance are to be used and old hose-sets should not be reused. Do not obstruct the openings of the bottom face with carpet, etc.
-
Page 6: Part Names / Accessories
Part Names / Accessories ●COLD Operation panel Water supply (P. 8) ●HOT valve (P. 27) Lid (Soft Closing) Leveller Drain hose (P. 27) (P. 25) Detergent and softener drawer Lint filter (P. 13) (P. 21) Power cord and plug* (P. 27) Pulsator * The plug shape varies with the... -
Page 7: Before Washing
Before Washing Laundry preparation and check Wash separately for clothes Use laundry nets for delicates losing colour easily Underwire brassieres, lacy clothes, lingerie and stockings Pre-laundry check (To prevent damage to clothes, Do not overpack. malfunction and drainage failure) ... -
Page 8: Operation Panel
Operation Panel Change water amount Water amount/remaining time During the wash process, press “Water Level” to check and change the water amount. Some water amounts cannot be selected depending on the After starting After approx. program. operation, indicates 5 seconds, indicates ... - Page 9 : 1 scoop of detergent Water level for “Soak Program” in accordance with standard SASO 2885 - NA-F135V5 / NA-F135A5WSA : Full load: 93 L / Half load: 73 L - NA-F115A5WSA : Full load: 86 L / Half load: 73 L ...
-
Page 10: Variety Of Programs
Variety of Programs Program Purpose Everyday clothes Normal (P. 14) Daily washing Speedy washing for light soil Speedy (P. 14) Delicates Delicate (P. 16) Washing delicates gently Clothes for babies & people with sensitive skin Baby Care (P. 14) Rinsing thoroughly ... - Page 11 Maximum capacity NA-F135V5 NA-F115A5 NA-F135A5 NA-F115A5WSA NA-F135A5WSA 13.5 kg 11.5 kg 13.5 kg 11.5 kg 5.0 kg 5.0 kg 13.5 kg 11.5 kg 13.5 kg 11.5 kg 4.2 kg 4.2 kg 13.5 kg 11.5 kg 5.0 kg 5.0 kg 3.0 kg 3.0 kg...
-
Page 12: Detergent
Detergent Put in detergent, bleach and softener according to the water amount Follow the instructions on each package Detergent/ Bleach inlet Bleach Do not use whiten bleach (chlorine bleach) for coloured clothes to prevent loss of colour. Do not use bleach for the “Delicate”... - Page 13 Detergent and softener drawer Do not fill above the MAX line. (Approx. 100 ml) NOTE Powder detergent Do not put in too much detergent. Liquid detergent For cleaning (P. 22) Softener Detergent Softener Do not put detergent directly into ...
-
Page 14: Washing
Washing Preparation: Check if the washing machine is properly installed. (P. 24) Turn on the water faucet. When using Temp Setting, turn on both hot and cold water faucets. Timer preset Temp Setting After loading laundry Press to select Hot/Warm/ Turn the power on. - Page 15 According to the water amount After pressing “Start” indication You can change the water level Put in detergent. until the end of the wash process. Approx. 20 seconds after the You can change each of the water amount is displayed, “Wash”, “Rinse”...
-
Page 16: Washing Options
Washing Options Comforter Delicate Washable comforters and Use this program to gently wash blankets delicate clothes and stylish garments. • Material: 100 % synthetic fibre or Load laundry evenly. 100 % cotton • Weight: 4.2 kg or less •... -
Page 17: Stain Master
Stain Master Preparation: Turn on the water faucet. When using Temp Setting, turn on both hot and cold water faucets. After loading laundry NOTE Turn the power on. Amount that can be washed at one time: Max. 5.0 kg Select a “Stain Master”... -
Page 18: Super Dry 90
Washing Options (continued) Super Dry 90 Wash / Rinse / Spin Water is removed from clothes by the Preparation: air blown from the tub rotation. Turn on the water faucet. Clothes that can be dried After loading laundry • Material: Synthetic fibre Turn the power on. -
Page 19: Contents Of Programs
Baby Care Water Save Comforter NA-F135V5 NA-F135A5 (Soak 70 min) + NA-F115A5 Soak NA-F135A5WSA (Soak 22 min) + NA-F115A5WSA Sweat Sauce (Soak 20 min) + Tub Hygiene (Soak 60 min) + *1 Remaining time of 99 minutes or less will be displayed. -
Page 20: Convenient Functions
Convenient Functions Cancelling end buzzer Setting Child Lock To prevent children from falling into Pressing down, the tub and drowning, if the lid is press. opened while the washing machine is operating, this function sounds a buzzer until it is closed. Not closing it Then hold on for 3 seconds. -
Page 21: Maintenance
Maintenance Lint filter After each operation Lint filter Attach the filter in its original position. Remove the filter. Click NOTE Do not wash laundry without the filter. (To prevent damage to Open the filter and remove clothes) lint. Turn the tub by hand if it is difficult ... - Page 22 Maintenance (continued) Detergent and softener drawer Main unit, lid If stained with detergent If stained with detergent or softener or softener Wipe with a soft cloth. Remove the drawer. (To prevent damage to resin parts or metal corrosion) For heavy soil, wipe with a neutral kitchen detergent.
- Page 23 Water supply filter If water does not flow smoothly Once a week <Super Dry 90> Follow the procedure below to After operation ends prevent splashing of water. Run the “Super Dry 90” program without loading laundry. (P. 18) After turning off the water faucet Once a month <Tub Hygiene>...
-
Page 24: Installation
Make sure to ask a service person for installation. Do not install by yourself. If the installation, test run and inspection of the washing machine are not carried out following this installation method, Panasonic will not be liable for any accident or damage caused. - Page 25 3. Attach the drain hose. Connect. Do not connect here. Insert all the way. Slide the hose band in the arrow direction. Slide all the way until it stops. Hose band Attach the hose to position A Hose holder or B with the hose holder and the screw.
- Page 26 Installation (continued) 4. Connect the water supply hose. CAUTION Water faucet Do not make wrong connection for the HOT and COLD water supply Water supply hose faucets. Tighten the nut firmly. Do not twist, squash, modify or cut the hose.
- Page 27 COLD 6. Check that the washing machine is level. Water supply valve screw The bubble should be at the centre COLD of the mark. Mark Bubble Leveller If the bubble is out of the mark Water supply hose 1 Turn the adjustable leg knob to the left to loosen.
-
Page 28: Error Display
Error Display The buzzer sounds and “U”/“H” and a number are alternately displayed. Cancel Child Lock if it is set. (P. 20) Error Display Points to be checked Check the drain water hose for the following abnormalities: - Is it crushed? - Is it clogged with lint? - Is the hose tip under water? When the above problems are solved, you can resume operation... -
Page 29: Troubleshooting
Troubleshooting Symptoms Points to be checked - Time indication is approximate. Remaining time is Time indication increases or does not decrease corrected during operation and displayed. - The operation time may be longer if laundry is Operation time is longer than the time indication. -
Page 30: Specifications
(P. 12) - This is normal. It is the noise of the drain pump There is noise when working. water drains out. Specifications Model No. NA-F135V5 NA-F135A5WSA NA-F135A5 NA-F115A5WSA NA-F115A5 Rated voltage 220 V 220 V 220-240 V 220 V... - Page 31 : Water quantity 128 L (NA-F135V5 / NA-F135A5WSA) / 124 L (NA-F115A5WSA) : Time 124 min per cycle Cotton 60 °C/ 40 °C partial : Water quantity 124 L (NA-F135V5 / NA-F135A5WSA) / 120 L (NA-F115A5WSA) : Time 121 min per cycle...
- Page 32 © Panasonic Appliances (Thailand) Co., Ltd. 2018-2020 AWW9901D3003_EN.indd 32 AWW9901D3003_EN.indd 32 7/2/2563 BE 13:30 7/2/2563 BE 13:30...
