Motor Unit Assembly Parts

16
19
18
KEY PART
NO. NO.
1 31D380
2 41C4220A
3 41A2817
4 41B4245
5 143D100
6 175B88
7 108D36
8 30B532
9 12A373
10 41A3150
11 41D3058
20
17
3
16 15
14
12
DESCRIPTION
Sprocket cover
Gear and sprocket assembly.
Complete with: Spring
washer, thrust washer,
retaining ring, bearing plate,
roll pins (2), drive gear and
worm gear, helical gear
w/retainer and grease
Drive/worm gear kit w/grease,
Roll pins (2)
Line cord
End panel
Light socket
Lens
Capacitor - 1/2 HP
Capacitor bracket
Terminal block w/screws
Universal replacement motor
& bracket assembly.
Complete with: Motor, worm,
bracket, bearing assembly,
RPM sensor
1
2
4
3
8
9
10
11
13
(Down)
Contact
Brown
Wire
Drive
Gear
KEY PART
NO. NO.
12 41A3583-19
13 41A2818
14 41D3452
15 41C4398A
16 41C4246
17 41A2826
18 41A2822A
19 41A5021-1H-315 Receiver logic board
20 41A3712
41A2825
34
6
5
LIMIT SWITCH ASSY.
DN
Grey
Wire
UP
Center Limit
(Up) Yellow
Contact
Contact Wire
DESCRIPTION
Cover
Helical gear & retainer
w/grease
Limit switch assembly
RPM sensor assembly
Wire harness
Shaft bearing kit
Interrupter cup
assembly. Complete with:
Logic board, end panel
w/all labels, light socket
End panel w/all labels
NOT SHOWN
Opener assembly
hardware kit (includes
screws not designated by
a number in illustration).
7
