Auto-scanning with digital control lcd color medical monitor (31 pages)
Summary of Contents for Advan AMM261WTD
Page 1
AUTO - SCANNING WITH DIGITAL CONTROL LCD COLOR MEDICAL MONITOR AMM261WTD Operation Manual For future reference, record the serial number of your display monitor in the space below : Serial Number The serial number is located on the back of the monitor...
Page 3
ADVAN INT’L CORP.2013 All other trademarks are the property of their reference owners. This document is subject to change without notice. Advan provides this information as reference only. Reference to other vendor’s products does not imply any recommendation or endorsement. Revision Control...
User Function / Messages................. OSD Section ....................Troubleshooting ..................Specification of (AMM261WTD) ..............Classification ..................... Electromagnetic Compatibility ..............Dimension Drawing (mm) of AC Adapter ........... Dimension Drawing (mm) of AMM261WTD..........Connectors ....................Description of Warranty ................Accessory Item List ..................
• AMM261WTD LCD Monitor(the equipment that displays information, graphic data, image and video on its LCD screen) and two video cables (1) HD15 VGA cable (1) DVI-I cable •...
Product(s), therefore, may not agree in detail to the published design or specifications. All specifications are subject to change without notice. Please contact ADVAN Int’l Corp directly or phone your local ADVAN Int’l Corp sales representative or agent for information on changes and new products.
Page 7
AMM261WTD 5 Warnings 1. Read the operating manual thoroughly and be familiar with its contents prior to using this equipment. 2. Carefully unpack the unit and check if any damage occurred during shipment. 3. Should any solid object or liquid fall into the panel, unplug the unit and have it checked by qualified personnel before operating it any further.
Page 8
Cautions 1. The AC Adapter must be plugged into a Grounded power outlet. 2. Use only the proprietary AMM261WTD power supply for the AMM261WTD monitor. Make a proper connection by ensuring that the shrink tubing completely secures the connection between the DC power cord and the extension cord.
AMM261WTD 7 Symbol Definitions Dangerous: High Voltage Indicates protective earth ground. For indoor use only. Direct Current Tested to comply with FCC Serial Number Class B standards. This way up DC power control switch Fragile, handle with care Tested to comply with Japan...
For a copy of the Declaration of Conformity document, please contact ADVAN Int’l Corp. and request for AMM261WTD DOC. Prepare for Unpack Before you unpack your monitor, prepare a suitable workspace. You...
AMM261WTD 9 SAFETY PRECAUTION · Avoid placing the monitor, or any other heavy object, on the power cord to prevent fire or electrical shock from damage to the power cord. · Do not expose the monitor to rain, excessive moisture, or dust to avoid fire or shock hazard.
LED blinks for 1 seconds On and 1 second Off. The screen is displayed after the vertical and horizontal sync signals are restored. Power Management System The AMM261WTD Medical Monitor power management proposal. Provides four phases of power-saving modes by detecting the horizontal sync signal as shown in the table below.
AMM261WTD 13 PIP / POP / PBP function The following combination options are available to you: omponent/ SDI1 SDI2 C-Video Main RGBs SDI1 SDI2 C-Video Component/ RGBs...
User’s Guide To make your installation easier, the monitor is able to Plug and Play with your system if your system also supports DDC protocol. The DDC (Display Data Channel) is a communication protocol through which the monitor automatically informs the host system about its capabilities, for example, supported resolutions and corresponding timing.
AMM261WTD 15 CONNECTING the POWER CORD * Check first to make sure that the power cord you use is the correct type required for your area. * This monitor has an universal AC adapter that allows operation in either AC 100 - 240 V ac voltage area. No user-adjustment is required.
User’s Guide User Functions / Messages Key Name and Function Power LED : Lights up to indicate the power is turned ON. Standby Power Button: To power ON or OFF the monitor. Rotary switch : With the OSD menu activated, increases the value of the selected (Turn Right) parameter or moves rightward in OSD menu.
AMM261WTD 17 OSD Section Main Menu Chromatic Adjust Color Temp, Gamma Visual Adjust Brightness, Contrast, Phase, Chroma, Sharpness-H, Sharpness-V Setting Adjust Scale Mode, Color Space, Mirror, Freeze Frame, Zoom / Pan, PIP, POP, PBP Advanced Adjust OSD Position Control, Screen Control, DPMS, Auto...
Page 20
User’s Guide OSD Section Chromatic Color Temp Change the color temperature - D65, D93, S1, S2 Gamma Change the gamma value - 1.8, 1.9, 1.95, 2.1, 2.1S, 2.2, 2.3, 2.4, 2.4S, S0, Radio graph Exit Exit the menu Visual Brightness Adjust the brightness of panel (Range 0 - 100) Contrast Adjust the contrast of video (Range 0 - 100)
Page 21
AMM261WTD 19 OSD Section Setting Scale Mode Change the scale mode - Fill all, One to One, Vertical - fill, Horizontal - fill, Fill aspect ratio Color Space Change color space between RGB and YPbPr available for Component and RGBS...
Page 22
User’s Guide OSD Section Sub menu of PIP Mode PIP Mode ON / Off Source PIP sub screen source - SDI1/2, C-Video, S-Video, Component/RGB, VGA, DVI Position PIP sub screen position - Top L, Top R, Bottom L, Bottom R Size PIP sub screen size - Small, Medium, Large Blending...
Page 23
AMM261WTD 21 OSD Section Sub menu of POP Mode POP Mode ON / Off Source POP sub screen source - SDI1/2, C-Video, S-Video, Component/RGB, VGA, DVI Position POP sub screen position - Top L, Top R, Bottom L, Bottom R...
Page 24
User’s Guide OSD Section Advanced OSD Position Change the OSD menu - Position, Background, Control OSD time out, Language Screen Control Control and adjust H and V position, Freqency, Phase Noise Reduction, Motion Offset DPMS Change the DPMS Auto Source Adjust Auto Source Select between on and off Select Smart Select...
Page 25
AMM261WTD 23 OSD Section Sub menu of OSD Control H-position Adjust OSD H - position (Range 0 - 100) V-position Adjust OSD V - position (Range 0 - 100) Back ground Adjust transparency of OSD back ground (Range 0 - 100)
Page 26
User’s Guide OSD Section Information Custom Entry Change the user or monitor’s name Display the serial number Run Time Display the total run time Input Format Display the current input resolution and vertical frequency Exit Exit the menu...
AMM261WTD 25 TROUBLESHOOTING Before sending your LCD monitor for servicing, please check the troubleshooting list below to see if you can self-diagnose the problem. Problems Current Status Remedy No Picture LED ON · Using OSD, adjust brightness and contrast to maximum or reset to their default settings.
User’s Guide SPECIFICATION* Model AMM261WTD Description a-Si TFT Active Matrix, LED Backlight Active Screen Size 26 inches diagonal Resolution 1920 (H) x 1080 (V) @60Hz Pixel Pitch 0.30 mm Display Color 1.07B colors Color Tone Up to 256 color tone Response Time <25ms Typ.
51LJ Medical Equipment E215822 This monitor is intended for use in Health Care Facilities model AMM261WTD Equipment is not suitable for use in the presence of flammable anesthetic mixture with air or with oxygen or nitrous oxide. No user serviceable parts inside, ask qualified personnel when accessing inside.
Consult the tables below for guidance in placing the AMM261WTD. Manufacturer’s declaration - electromagnetic emission The Model AMM261WTD is intended for use in the electromagnetic environment specified below. The customer or the user of AMM261WTD should assure that it is used in such an environment. Emission test Compliance...
Page 31
To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the AMM261WTD is used exceeds the applicable RF compliance level above, the AMM261WTD should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as reorienting or relocating the AMM261WTD.
Recommended Separation Distances Between Portable and Mobile RF Communications Equi- pement and the AMM261WTD System The AMM261WTD system is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The user of the AMM261WTD system can help prevent electromagnetic...
ADVAN standards, quality and specifications. Subject to the conditions and limitations set forth below, ADVAN will, at its option, either repair any component of its products that prove defective by reason of improper workmanship or materials or ADVAN has the exclusive right to replace with refurbished units or with an equivalent product.
Page 36
ADVAN or its ASC without prior authorization. Buyer will be responsible for packaging (preferably original container) and shipping the defective goods to ADVAN or its ASC, shipping charges prepaid. ADVAN or its ASC will return the in warranty product, at no cost to the buyer.
Page 37
(out-of-warranty). Buyer must notify ADVAN or its ASC of the defect and request an RMA number. If the configuration has been modified in any manner, the product must be returned to its original configuration before any service will be performed by ADVAN or its ASC.
Page 38
ARE THE SOLE AND EXCLUSIVE REMEDIES FOR BREACH OF WARRANTY OR ANY OTHER LEGAL THEORY. TO THE FULLEST EXTENT PERMITTED BY APPLICABLE LAW, ADVAN SHALL NOT BE LIABLE TO THE PURCHASER OR END USER CUSTOMER OF AN ADVAN PRODUCT FOR ANY DAMAGES,...
AMM261WTD 37 Accessory Item List Parts Name Q’ty Description Remark AC- Adaptor Model Number: BPM150S24F10 BridgePower Parts Number: PS-52141209002E VGA Cable RGB 15P TO 15P, 1.8M, IVORY DVI cable DVI-I type CABLE 29P TO 29P BNC Cable BNC TO BNC ,1.8M/ RG58(JTC-15) S-Video Cable S-VIDEO W.2F/C/1.8M,BLACK...
Page 40
Tel : +82 2 783 5197 Fax : +82 2 868 0880 Web Page : http://www.advancorp.com Manufacturer ADVAN INT’L CORP 47817 Fremont Blvd. Fremont, CA 94538, USA Tel : 1 510 490 1005 Fax : 1 510 490 1151 Web Page : http://www.advancorp.com...
