Carton Inventory

Your garage door opener is packaged in two cartons
which contain the motor unit and all parts illustrated
below. Accessories will depend on the model
L O C
K
L I G
H T
Motion Detecting
Door Control Console (LCD)
2-Conductor Bell Wire
White & White/Red
Safety Sensor
Bracket (2)

INSTALLATION HARDWARE

Hex Bolt 5/16"-18x7/8" (4)
Hex Screw #8 x 3/8" (2)
Lag Screw 5/16"-9x1-5/8" (2)
Lag Screw 5/16"-18x1-7/8" (2)
Clevis Pin 5/16"x2-3/4" (1)
Clevis Pin 5/16"x1-1/4" (1)
Clevis Pin 5/16"x1" (1)
Nut 5/16"-18 (4)
Lock Washer 5/16" (4)
Screw 6ABx1-1/4" (2)
SECURITY✚ ®
3-Button Remote Control
Motor Unit w/Light Lenses
Trolley
Belt
Pulley Bracket
The Protector System
(2) Safety Reversing Sensors
(1 Sending Eye and 1 Receiving Eye)
with 2-Conductor White & White/Black
Bell Wire attached
purchased. If anything is missing, carefully check the
packing material. Parts may be stuck in the foam.
Hardware for installation is also listed below.
Remote Control
Transmitter Visor Clip
Belt
One-Piece
Rail
Header Bracket
®
Self-Threading Screw 1/4"-14x5/8" (2)
Screw 6-32x1" (2)
Insulated Staples (30)
Ring Fastener (3)
Drywall Anchors (2)
Rope
Handle
Rail Grease
Carriage Bolt 1/4"-20x1/2" (2)
Wing Nut 1/4"-20 (2)
5
Belt Cap Retainer
Styrofoam
Door Bracket
Curved Door
Arm Section
Straight Door
Safety Labels Arm Section
and
Literature
