switel DH-100 User Manual

USER MANUAL
MA-600 is a plug-in receiver, it can carry two wireless transmitters
such as doorbell buttons with two distinguishable flash pattern.
The first coded transmitter will flash rapidly; the second coded
transmitter flashes slower.
PARTS & FUNCTION
Melody
button
Learn
button
MOUNTING & POWER
This receiver works with AC 80V to 240V. Simply plug into a well
visible AC wall socket, it'll turn on.

PAD TRANSMITTER

Part & Function
Switch for
Fall Mat or
Bed Pad +
Delay
Mono jack for
External sensor
Paring to the receiver
The Sensor is already paired with the receive. You can add (pair) one more
transmitter to the system follow the instructions of the receiver.
Code Conflict
If the universal transmitter coding is the same as another transmitter
you must change the code. When you have changed the code re-pair
the universal transmitter.
+
Open the cover
Press and hold the test button, insert
Remove the battery
the battery whilst holding the button
for 5 seconds. The LED will flash 5 times
Setting
when a new code is generated
Open the battery cover and slide the switch
to pad or mat position
Mat: for fall mat (normal open)
Mat
Pad: for Bed pad or chair pad (normal
Pad
+ 3S
+
+ 10Min
+3S: Alert after the person leave the pad
+10Min: Alert after the person leave the
Flasher
Speaker
Battery installation
Call
Button
+
* Unlock the screw
Battery
* Slide to open the cover
compartment
* Insert a CR2032
Battery "+" face up
+
close)
more than 3 seconds
pad more than 10 minutes seconds

1. ASSIGNMENT OF THE TRANSMITTER

* PLEASE NOTE THE TRANSMITTER & RECEIVER ARE
DH-100
READY TO USE
Two transmitters can be assigned to the receiver by sequence.
The transmitter can only be assigned if it is not yet known in the
memory of the receiver.
Step 1: Press & Hold the
Indicator
Step 2: Press the Melody
Function
switch
Step 3: Once the melody is selected, trigger the transmitter to
Wall plug
(AC plug)

2. CHANGE THE MELODY

Press & hold the
mode. Press the
transmitters , press the
have found the desired melody.
Trigger the transmitter to confirm the melody, when you hear a
twice short tone press the
3. CLEAR THE TRANSMITTER FROM THE RECEIVER
MEMORY
Press & hold the
pairing mode. Press & hold both the
Melody selector together for 3 seconds to delete the memory.
T h e r e c e i v e r w i l l g e n e r a t e a b e e p t o n e t o i n d i c a t e a l l
transmitters on the memory is deleted. The red LED will change
to blink. Now you can pair the new transmitters to the receiver
as per the previous section.

4. TRANSMITTER BATTERY LOW

When the indicator lights constantly after triggered, it indicates this
transmitter is battery low. Please replace its battery as soon as possible.
Temporary Cancel Call Button
To cancel the call button function, press and hold the call
button 5 secons. The LED will blink 4 time to indicate the call
button is disable.
To enable the call function, press and hold the call button 5
seconds again. The LED will blink 2 time to indicate the call
function is enable.

OPERATION

Connection
1. open the battery cover
2. Connect the pressure pad to the
transmitter
3. close the battery cover
Pad
The elder person normally lay on the mat, when the person leave the mat
more then 2 second, the transmitter will send out the alert signal to the
receiver
Mat
The transmitter will send out the alert signal to the receiver, when some
step on (fall on) the mat The universal transmitter can connected to other
type of sensor such as a switch.
Learn button
f o r 3 s e c o n d s . T h e r e d L E D
indicator inside the lens will blink.
(if the red LED indicator lights
c o n s t a n t l y t h a t m e a n s t h e
memory of the receiver is full.
Please see section 3)
♫ selector button
to scroll through the melodies.
Once you hear a melody you
prefer, do not press any button as
t h e m e l o d y i s s e t f o r t h a t
transmitter.
pair. If successful, the receiver (chime unit) will
generate a short tone. Press the
button to exit the pairing mode, the system is now
ready to use.
Learn button for 3 seconds to enter the pairing
Learn button to scroll between 1 and 2
♫ Melody selector repeatedly until you
Learn button to exit.
Learn button for 3 seconds to enter the
Melody
Learn
Learn selector
Learn button & the ♫
o 2.5 mono plug
/
EXIT
