BLACKMER LB COMPRESSORS
Installation, Operation, and Maintenance Instructions
MODELS: LB161B, LB361B, LB601B,

TABLE OF CONTENTS

Safety Data ................................................................ 1
Compressor Data ................................................. 2
Nameplate Data .................................................... 3
Maximizing Compressor Life ................................ 4
Location and Piping .............................................. 5
Mounting the Compressor Unit ............................ 5
Stationary Compressors ....................................... 5
Truck Mounted Compressors ............................... 5
Compressor Flywheel ........................................... 6
V-Belt Drive ........................................................... 6
PTO Drive ............................................................. 6
Relief Valves ......................................................... 8
4-Way Valves ........................................................ 8
Liquid Traps .......................................................... 8
Pressure Gauges .................................................. 9

SAFETY DATA

This is a SAFETY ALERT SYMBOL.
When you see this symbol on the product, or in the
manual, look for one of the following signal words and
be alert to the potential for personal injury or property
Warns of hazards that WILL cause serious personal
injury, death or major property damage.
Warns of hazards that CAN cause serious personal
injury, death or major property damage.
Warns of hazards that CAN cause personal injury, or
property damage.
Indicates special instructions which are very important
and must be followed.
LB162B, LB362C, LB602C,
& Discontinued LB602B
damage.
NOTICE
Operation
Pre-Startup Check List ............................................ 9
Start Up Procedure ............................................... 10
Maintenance
Service Schedule .................................................. 11
Tool List ................................................................. 12
Bolt Torque Table.................................................. 12
Crankcase Lubrication .......................................... 13
Setting the Oil Pressure ........................................ 13
Compressor Disassembly ....................................... 14
Compressor Assembly ............................................ 15
Valve Replacement ................................................... 17
Seal (Packing) Replacement ................................... 19
S3R Seal Replacement ............................................. 20
Bearing Replacement ............................................... 21
Oil Pump Replacement ............................................ 22
Extended Storage ..................................................... 22
Troubleshooting ....................................................... 23
NOTICE
Blackmer compressors MUST only be installed in
systems which have been designed by qualified
engineering personnel. The system MUST conform to
all applicable local and national regulations and safety
standards.
These instructions are intended to assist in the
installation and operation of Blackmer compressors and
MUST be kept with the compressor.
Blackmer compressor service and maintenance shall
be performed by qualified technicians ONLY. Service
and maintenance shall conform to all applicable local
and national regulations and safety standards.
Thoroughly review this manual, all instructions and
hazard warnings, BEFORE performing any work on
the compressor.
Maintain ALL system and compressor operation and
hazard warning decals.
For handling liquefied gas, NFPA Pamphlet 58 should
be consulted.
960474
INSTRUCTIONS CB5A-021
Section
502
Effective
Aug 2021
Replaces
Oct 2019
r130716
