OWNER'S
MANUAL
MODELS SA5000, SA5015, SA7000, SA7015,
SA9000, SA9015, SA12000, SA12015
WARNING:
READ INSTRUCTIONS CAREFULLY BEFORE
ATTEMPTING TO INSTALL, OPERATE OR SERVICE THE STRONGARM
ELECTRIC WINCH. FAILURE TO COMPLY WITH INSTRUCTIONS COULD RESULT
IN SERIOUS OR FATAL INJURY. RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.
ELECTRIC WINCH RATING*
5000
4500
4000
3500
3000
2500
2000
1500
1000
500
10
LENGTH OF CABLE ON REEL (FT.)
GUIDE TO ROLLING LOAD CAPACITY**
Maximum weight in pounds and kilograms rolling load.
MODEL
5%
10%
(3°)
(6°)
10,000 lbs. 7,500 lbs. 5,100 lbs. 3,900 lbs. 2,700 lbs. 2,200 lbs.
SA5000
SA5015
4,536 kg 3,402 kg 2,313 kg
14,600 lbs. 11,000 lbs. 7,400 lbs. 5,700 lbs. 4,000 lbs. 3,300 lbs.
SA7000
SA7015
6,623 kg 4,990 kg 3,357 kg 2,586 kg 1,814 kg 1,497 kg
20,000 lbs. 15,000 lbs. 10,200 lbs. 7,700 lbs. 5,500 lbs. 4,500 lbs.
SA9000
SA9015
9,072 kg 6,804 kg 4,627 kg 3,493 kg 2,495 kg 2,041 kg
30,000 lbs. 22,600 lbs. 15,200 lbs. 11,600 lbs. 8,300 lbs. 6,800 lbs.
SA12000
SA12015
13,608 kg 10,251 kg 6,895 kg
(*) Load capacity (dead weight) is a measure of actual maximum force to which the
winch system may be subjected.
(**) All capacities shown are with 15' of cable on the reel and 10% rolling friction factor.
For full reel of cable adjust capacities according to graph above. Note 5% incline is
one-half foot rise in ten feet.
WINCH RATINGS
20
30
40
50
PERCENT INCLINE
20%
30%
50%
(11°)
(17°)
(26°)
1,769 kg 1,225 kg
5,262 kg 3,765 kg 3,084 kg
ELECTRIC WINCHES
DOUBLE LINE OPERATION
Models SA7000, SA7015, SA12000 and SA12015
are factory equipped with a pulley block and hook
and 50' of cable for double line operation. This
increases the pulling capacity of the winch as
shown, however, care must be taken to allow ade-
quate motor cooling. Note that with double line, a
pull of 25' requires reeling in 50' of cable.
For intermittent use only. Ratings at left are based
on 10' pull. For longer pulls motor cooling periods
must be allowed.
MAXIMUM CONTINUOUS RUN TIME 4 MINUTES
CAUTION: CONTINUOUS RUNNING IN
EXCESS OF 4 MINUTES WILL DAMAGE WINCH
MOTOR.
LOAD
70%
CAPACITY
(35°)
SA5000
1500 lbs.
SA5015
998 kg
681 kg
SA7000
2200 lbs.
SA7015
999 kg
SA9000
SA9015
3,000 lbs.
SA12000
1,362 kg
SA12015
4,500 lbs.
2,043 kg
LIFTING, SUPPORTING OR
TRANSPORTING PEOPLE OR
LOADS OVER AREAS WHERE
PEOPLE COULD BE PRESENT!
1
12 Volt DC
APPROXIMATE LOAD
SPEED
(FT./MIN.)
NO LOAD
FULL LOAD
Full
Empty
Full Empty
Reel
Reel
Reel Reel
33
12
8
16
6
4.5
11
5
4
5
2.5
2
WARNING: NOT TO BE
USED AS A HOIST FOR
E
N
G
L
I
S
H
F
R
A
N
Ç
4
A
I
3.5
S
2.5
1.5
