- Page 1 PC1017 10.1” Price Checking Terminal User's Manual Version 1.0 2019.10 P/N:...
- Page 2 This page is intentionally left blank. - II -...
- Page 3 Revision History Version Release Time Description 2019.10 Initial release - i -...
- Page 4 Copyright Copyright © 2017 ARBOR Technology Corp. All Rights Reserved. This document contains proprietary information protected by copyright. No part of this manual may be reproduced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer.
-
Page 5: Table Of Contents
Contents Contents Preface......................iv Declaration of Conformity ..................iv CE ........................iv FCC .......................iv RoHS ......................iv SVHC / REACH ....................v Symbols Descriptions ...................vi Important Safety Instructions ................vi General Cleaning Tips ..................viii Cleaning Tools ....................ix Recommended Cleaning Procedures ............ix Disposing of the Equipment ...................x Additional Information &... -
Page 6: Preface
(PBDE) in electrical and electronic products. Member states of the EU are to enforce by 7/1/2006. ARBOR Technology Corp. hereby states that the listed products do not contain unintentional additions of lead, mercury, hex chrome, PBB or PBDB that exceed a maximum concentration value of 0.1% by weight or for cadmium... -
Page 7: Svhc / Reach
Preface exceed 0.01% by weight, per homogenous material. Homogenous material is defined as a substance or mixture of substances with uniform composition (such as solders, resins, plating, etc.). Lead-free solder is used for all terminations (Sn(96-96.5%), Ag(3.0-3.5%) and Cu(0.5%)). SVHC / REACH To minimize the environmental impact and take more responsibility to the earth we live, ARBOR hereby confirms all products comply with the restriction of SVHC (Substances of Very High Concern) in (EC) 1907/2006 (REACH... -
Page 8: Symbols Descriptions
Preface Symbols Descriptions The tables below describe the symbols that may appear in the product. This symbol of “CAUTION” indicates that there is a danger of injury to the user or a risk of damage to the product, should warning notices be disregarded. This symbol indicates electrical warning. - Page 9 Preface 11. Remove dirt with a lightly moistened cloth and a mild solvent detergent. Then wipe the cabinet with a soft dry cloth. 12. The openings on the enclosure are for air convection and protect the equipment from overheating. DO NOT COVER THE OPENINGS. 13.
-
Page 10: General Cleaning Tips
Preface Do not use the power adapter that isn’t made for the equipment. Supplying the equipment with inappropriate voltage may cause harm to the battery (if any) or, even worse, burn the equipment. Risk of explosion if RTC (Real-Time Clock) battery is replaced by an incorrect type. -
Page 11: Cleaning Tools
Preface Cleaning Tools Although many companies have created products to help improve the process of cleaning your devices and peripherals, users can also use household items to clean their devices and peripherals. Below is a listing of items you may need or want to use while cleaning your devices or peripherals. -
Page 12: Disposing Of The Equipment
Preface Disposing of the Equipment Within the European Union • EU-wide legislation, as implemented in each Member State, requires that waste electrical and electronic products carrying the mark (left) must be disposed of separately from normal household waste. This includes monitors and electrical accessories, such as signal cables or power cords. -
Page 13: Additional Information & Technical Support
Preface Additional Information & Technical Support All ARBOR products are built to the most accurate specifications to ensure reliable performance in the harsh and demanding conditions typical of industrial environments. Whether your new equipment is destined for the laboratory or the factory floor, you can be assured that the computer will provide the reliability and ease of operation. -
Page 14: Warranty
Preface Warranty This product is warranted to be in good working order during the warranty period. Should this product fail to be in good working order at any time during this period, we will, at our option, replace or repair it at no additional charge except as set forth in the following terms. -
Page 15: Chapter 1 Introduction
Chapter 1 Introduction Chapter 1 Introduction - 1 -... -
Page 16: Product Highlights
Introduction 1.1 Product Highlights Quad-Core ARM Cortex-A35 CPU 1.5G Hz, • Android-based Price verification/updates in retail application • 10.1” LCD display • 10-point Projected Capacitive Multi-Touch • H.265/HEVC Video Decode • PoE connectivity (PD) • Operating temperature: 0~45ºC • 1.2 Package Contents Upon opening the package, carefully inspect the contents. -
Page 17: Dimensions
Introduction Optional Configuration (CTOS* Kit) (Not Sold Separately) RFID & NFC-1014 RFID & NFC module kit Barcode Scanner 1D barcode scanner Barcode Scanner 1D/2D barcode scanner Camera 2MP front-facing camera 1.4 Dimensions 248.3 Unit:mm - 3 -... -
Page 18: Specifications
Introduction 1.5 Specifications System ARM Quad-Core Cortex-A35 1.5GHz (SoC) Mali-G37 MP2 Memory 2GB DDR4 memory soldered on board Storage 16GB NAND Flash soldered on board Peripherals and Devices Camera 2MP front-facing camera (optional) WLAN & 1 x WLAN 802.11 b/g/n & Bluetooth 4.0 + BLE Bluetooth 1 x 13.56MHz RFID &... - Page 19 Introduction Video Streaming UDP Streaming Support multicast UDP stream decode RTSP Streaming Support RTSP stream decode HLS Streaming Support HLS stream Power Requirement Power Input PoE input or DC 12V/5A (either one) Adapter Input 100 ~ 240 VAC (full range) Adapter Output DC 12V, 5A Mechanical &...
-
Page 20: Barcode Scanner Specifications
Introduction 1.6 Barcode Scanner Specifications General Image Sensor 640 x 480 CMOS Light Source Red LED 625 ±10 nm Precision ≥ 5mil Field of View Horizontal: 44°, Vertical: 33.2° Symbologies PDF417, QR Code (QR1/2, Micro), Data Matrix (ECC200, ECC000, 050, 080, 100, 140), Chinese sensible code Code128, UCC/EAN-128, AIM128, EAN-8, EAN-13, ISBN/ISSN, UPC-E, UPC-A, Interleaved 2 of 5, ITF-6, ITF-4, Matrix 2 of 5, Industrial 25, Standard 25, Code39, Codabar, Code 93, Code 11,... -
Page 21: Chapter 2 Getting Started
Chapter 2 Getting Started Chapter 2 Getting Started - 7 -... -
Page 22: Getting To Know The Terminal
Getting Started 2.1 Getting to Know the Terminal Before starting to use the terminal, get to know it first. This section will quickly familiarize you with the terminal. No. Item Descriptions A 10-point projected capacitive multi-touch screen allowing Touch screen users to interact with the terminal without a mouse or keyboard. -
Page 23: Connection
Getting Started No. Item Descriptions USB port USB 2.0 Type-A port. To connect to a USB device. DC 12V power input jack. To connect to a power outlet using DC-IN jack the provided power adapter. 10/100M RJ-45 port with PoE support. To connect to a PoE power sourcing equipment (PSE), such as a switch or hub, to provide power to the terminal. - Page 24 Getting Started To verify the connection of the USB device after you power on the terminal, tap Settings > Device > Storage > USB Storage 2 and you should be able to find the USB device's information. 3. Connect to a local area network as needed. The terminal comes with a LAN port allowing you to connect the terminal to a wired local area network.
- Page 25 Getting Started Regular power PoE power To connect the terminal to AC power: Locate the DC-IN jack on the rear of the terminal. Plug the DC cord of the power adapter into the DC-IN jack. Then plug one end of the AC power cord into the AC adapter and the other end into an electrical outlet.
-
Page 26: Attaching To A Vesa Mount
Getting Started 5. Route the cable(s) through the openings on the bottom side. . Power connection USB device LAN connection connection 6. To restore the cover, push the latch of the cover into the terminal and then press the bottom of the cover firmly until it snaps into place. Latch 2.3 Attaching to a VESA Mount The terminal supports 75mm M4 VESA mount so you can attach the terminal to... -
Page 27: Powering On/Off The Terminal
Getting Started 2. Attach your VESA mount kit to the rear of the terminal by matching the mounting holes with the VESA mount kit. 3. Fix the assembly with screws. 2.4 Powering on/off the Terminal The terminal is powered on upon power connection. Also note that the barcode scanner functions right after the terminal boots into system. - Page 28 This page is intentionally left blank. - 14 -...
-
Page 29: Chapter 3 Using The Terminal
Chapter 3 Using the Terminal Chapter 3 Using the Terminal - 15 -... - Page 30 Using the Terminal The barcode scanner of the terminal starts to operate right after the terminal boots into system. To scan a barcode, position the barcode within the red light area. Aim the barcode at the red dot for accuracy. On a successful read, the beam dies out. If the scanner fails to read to barcode within about 4 seconds, the beam dies out and the scanner attempts to read again after 2~3 seconds.
