- Page 1 LIGHT OVEN “SolarDOM” OWNER’S MANUAL PLEASE READ THIS OWNER’S MANUAL THOROUGHLY BEFORE OPERATING. MP9489SCR P/No.: MFL30374536...
-
Page 2: Precautions
Precautions Precautions to avoid possible exposure to excessive microwave energy. You cannot operate your oven with the door open due to the safety interlocks When heating liquids, e.g. soups, sauces and beverages in your oven with built into the door mechanism. These safety interlocks automatically switch off microwave function, delayed eruptive boiling can occur without evidence of any cooking activity when the door is opened;... -
Page 3: Table Of Contents
Contents How the Microwave Function Works Precautions ................2 Contents ..................3 Microwaves are a form of energy similar to radio and television waves and Unpacking & Installing ..............4 ~ 5 ordinary daylight. Normally, microwaves spread outwards as they travel Control Panel ................ -
Page 4: Unpacking & Installing
Unpacking & By following the basic steps on these two pages you will be able to quickly check that your oven is operating correctly. Please pay particular attention to the guidance on where to install your oven. When unpacking your Installing oven make sure you remove all accessories and packing. - Page 5 Plug your oven into a standard household socket. Make Press the STOP/CLEAR button, and press sure your oven is the only appliance connected to the the START button one time to set 30 socket. If your oven does not operate properly, unplug it seconds of cooking time.
-
Page 6: Control Panel
Control Panel 1. STEAM COOK: Steam cook allows you to cook most of your favorite food 7. DISPLAY WINDOW: You can show time of day, cooking time, power level quickly by selecting the food type and the weight of the food. and cooking categories. -
Page 7: Setting The Clock
Setting the You can set either12 hour clock or 24 hour clock. In the following example I will show you how to set the time for 14:35 when using the 24 clock. Clock Make sure that you have removed all packaging from your oven. Make sure that you have correctly installed your oven as described earlier in this book. -
Page 8: Child Lock
Child Lock Press STOP/CLEAR. Press and hold STOP/CLEAR until “L” appears on the display and Your oven has a safety feature that BEEP sounds. prevents accidental running of the oven. The CHILD LOCK is now set. Once the child lock is set, you will be unable to use any functions and no The time will disappear on the display but will reappear on cooking can take place. -
Page 9: Convection Cooking
Convection In the following example I will show you how to use the convection to cook some food for 50 minutes for 220°C temp. Cooking The convection oven has a temperature 1. To Preheat 2. To Cook range of 40°C and 100°C~250°C Press STOP/CLEAR. -
Page 10: Speed Combi Cooking
Speed combi In the following example I will show you how to programme your oven with micro power 360W and grill for a cooking time of 25 minutes. Cooking Press STOP/CLEAR. Speed Combi (Co-1, 2, 3) Press SPEED COMBI to select grill combination mode(Co-1, 2, 3). Your oven has a combination cooking feature which allows you to cook food with heater and microwave at the same... - Page 11 Speed combi In the following example I will show you how to programme your oven with micro power 360W and at a temperature 200°C for a cooking time of 25 minutes. Cooking Press STOP/CLEAR. Speed Combi (Co-4) Press SPEED COMBI to select speed combination mode(Co-4). You can set four kinds of micro power level(0W, 180W, 360W, 600W) in speed combi mode(Co-4).
- Page 12 Speed combi In the following example I will show you how to programme your oven with:- micro power 360W and at a convection temperature 200 °C for a cooking time of 25 minutes. Cooking Press STOP/CLEAR. Speed Combi (Co-5) Press SPEED COMBI to select convection combination mode. Turn DIAL knob until display shows “Co-5”.
-
Page 13: Steam Cook
Steam In the following example I will show you how to cook 0.6 kg of whole fish. Cook Press STOP/CLEAR. Press STEAM COOK once. This feature allows you steamed cook. CAUTION: 1. Always use oven gloves when removing a STEAMER from the oven. It’s very hot. 2. - Page 14 STEAM COOK GUIDE Weight Initial Function Food Utensil Instructions Range Temperature Steam St 1 Vegetables 0.20 - 0.80 kg Steam water bowl Room 1. Clean vegetables and cut into similar sized pieces. Cook (Small cut) Steam plate 2. Pour 300ml tap water into the steam water bowl. Place the steam plate Steam cover on the steam water bowl.
- Page 15 STEAM COOK GUIDE Weight Initial Function Food Utensil Instructions Range Temperature Steam St 5 Shellfish 0.10 - 1.00 kg Steam cover Refrigerated 1. Clean the food and season as desired. Cook Steam plate 2. Pour 300ml tap water into the steam water bowl. Place the steam Steam water bowl plate on the steam water bowl.
- Page 16 STEAM COOK GUIDE Weight Initial Function Food Utensil Instructions Range Temperature Steam St 9 Eggs 2-9 eggs Steam cover Refrigerated 1. Pour 300ml tap water into the steam water bowl. Place the steam plate on Steam plate the steam water bowl. Place the eggs on the steam plate. Cover with the Cook Steam water bowl steam cover.
- Page 17 Speed Auto In the following example I will show you how to cook 0.2kg of kuku sabzi(SC 5). Cook Press STOP/CLEAR. Press SPEED AUTO COOK. Speed auto cook menus are programmed. Speed auto cook allows you to cook most of your favorite food quickly by selecting the food type and the weight of the food.
-
Page 18: Speed Auto Cook
SPEED AUTO COOK GUIDE Weight Function Category Utensil Instructions Limit Speed SC 1 Rice 0.10 - 0.40kg Microwave- Best Iranian Rice 100g 200g 300g 400g Auto safe bowl Water 250ml 500ml 750ml 1000ml Cook (deep glass pot) Oil(liquid) 1 spoonful 2 spoonfuls 3 spoonfuls Low rack... - Page 19 Weight Function Category Utensil Instructions Limit Speed SC 3 Whole 0.80 - 1.50kg Rotisserie A complete chicken approx. 1.2kg (with skin) 2 big onions Auto chicken Metal tray 3 spoonfuls of olive oil 3 spoonfuls of saffron (Dissolved in water) Cook Salt 1.
- Page 20 Weight Function Category Utensil Instructions Limit Speed SC 5 Kuku 0.20 - 0.50kg Shallow glass Vegetables 0.2kg 0.3kg 0.4kg 0.5kg Auto Sabzi Weight of dish(Ht. 2.5cm), Big egg 2 pieces 3 pieces 4 pieces 5 pieces Cook vegetables High rack Melted oil 3 spoonfuls 3 spoonfuls...
- Page 21 Weight Function Category Utensil Instructions Limit Speed SC 8 Hamburger 0.10 - 0.40kg Metal tray Prepared Hamburger Auto Cook 1. Grease on the metal tray with oil. Place the hamburger on the metal tray and brush with oil on the hamburger. 2.
- Page 22 Weight Function Category Utensil Instructions Limit Speed SC 11 Cake 0.50kg Deep glass pot Prepared cake powder 0.5kg Auto Low rack 3 pieces Cook Metal tray 120g Milk or water 300ml 1. Mix the eggs completely. Add the cake powder, oil and milk(or water) and mix them again.
-
Page 23: Defrost
The temperature and density of food varies, I would recommend that the food is checked before cooking Defrost commences. Pay particular attention to large joints of meat and chicken, some foods should not be completely thawed before cooking. For example fish cooks so quickly that it is sometimes better to begin cooking while still slightly frozen. -
Page 24: Defrosting Guide
Defrosting Guide * Food to be defrosted should be in a suitable microwave proof container and place uncovered on the metal tray. * If necessary, shield small areas of meat or poultry with flat pieces of aluminum foil. This will prevent thin areas becoming warm during defrosting. Ensure the foil does not touch the oven walls. -
Page 25: Grill Cooking
Grill In the following example I will show you how to use the Grill-1 to cook some food for 12 minutes and 30 seconds. Cooking Press STOP/CLEAR. Press GRILL to select grill mode. This feature will allow you to brown and crisp food quickly. -
Page 26: Micro Power Cooking
Micro Power In the following example I will show you how to cook some food on 600W power for 5 minutes and 30 seconds. Cooking Make sure that you have correctly installed your oven as described earlier in this book. Press STOP/CLEAR. -
Page 27: Micro Power Level
Micro Power This oven is equipped with 5 power levels to give you maximum flexibility and control over cooking. The table below shows the examples of food and their recommended cooking power levels for use with this oven. Level POWER LEVEL OUTPUT ACCESSORY * Boil Water... -
Page 28: Two Stage Cooking
Two stage In the following example I will show you how to cook some food in two stages. The first stages will cook your food for 11 minutes on HIGH(900W); the second will cook for 35 minutes on 360W. Cooking Press STOP/CLEAR. -
Page 29: Quick Start
Quick In the following example I will show you how to set 2 minutes of cooking on high power(900W). Start Press STOP/CLEAR. The Quick Start feature allows you to set Press Q-START four times to select 2 minutes on HIGH power (900W). 30 seconds intervals of HIGH Your oven will start before you have finished the fourth press. -
Page 30: More Or Less Cooking
More or Less In the following example I will show you how to change the preset Speed Auto Cook programmes for a longer or shorter cooking time. Cooking Press STOP/CLEAR. If you find that your food is over or Set the required SPEED AUTO COOK programme. undercooked when using the Speed Auto *See Speed Auto Cook. - Page 31 Rotisserie In the following example I will show you how to cook 1kg of whole chicken(SC 3). Installation & Cooking Press STOP/CLEAR. Press SPEED AUTO COOK. Don’t hold the chicken vertically while blacing it inside the rotisserie. (as show in the picture) Turn DIAL knob until display shows “SC 3”.
-
Page 32: Rotisserie Installation & Cooking
Rotisserie Installation & Cooking Insert the shaft of right Put the shaft of left plate on the plate into the shaft of holder of rotisserie. motor. To Clean ROTISSERIE & METAL TRAY When cooking is completed, Press START. separate the ROTISSERIE from the food. - Page 33 Rotisserie In the following example I will show you how to cook 0.8kg of kebab(SC 2). Installation & Cooking Press STOP/CLEAR. Press SPEED AUTO COOK. Turn DIAL knob until display shows “SC 2”. Press ENTER for category confirmation. Turn DIAL knob until display shows “0.80kg”. Prepare foods with the rotisserie.
- Page 34 Rotisserie Installation & Cooking Insert the shaft of right Put the shaft of left plate on the plate into the shaft of holder of rotisserie. motor. To Clean ROTISSERIE & METAL TRAY When cooking is completed, Press START. separate the ROTISSERIE from the food.
-
Page 35: Rotisserie Assembly
Rotisserie Assembly Screw the barbecue bars into the right plate. Screw the barbecue bar clockwise into the right plate CAUTION Rotisserie is not a toy. Assemble the left plate Keep the Rotisserie away from the child. Push barbecue bars into left plate. Assemble skewers Install the handle on the Insert the pointed edge of... -
Page 36: Important Safety Instructions Read Carefully And Keep For Future Reference
Important safety instructions WARNING Please ensure cooking times are correctly Read carefully and keep for future reference set as over cooking may result in FIRE and subsequent DAMAGE to the OVEN. 1 Do not attempt to tamper with, or make any adjustments or repairs to the 12 Before cooking, pierce the skin of potatoes, apples or any such fruit or door, control panel, safety interlock switches or any other part of the oven. - Page 37 Important safety instructions Read carefully and keep for future reference 24 Only use utensils that are suitable for use in microwave ovens. 37 This connection may be achieved by having the plug accessible or by incorporation a switch in the fixed wiring in accordance with the wiring 25 When heating food in plastic or paper containers, keep an eye on the rules.
-
Page 38: Microwave-Safe Utensils
Microwave-safe Utensils Never use metal or metal trimmed utensils in using microwave function Paper Microwaves cannot penetrate metal. They will bounce off any metal object in Paper plates and containers are convenient and safe to use in using the oven and cause arcing, an alarming phenomenon that resembles microwave function, provided that the cooking time is short and foods to be lightning. -
Page 39: Food Characteristics & Microwave Cooking
Food characteristics & Microwave cooking Keeping an eye on things Moisture content of food The recipes in the book have been formulated with great care, but your success in Since the heat generated from microwaves tends to evaporate moisture, relatively dry food preparing them depends on how much attention you pay to the food as it cooks. - Page 40 Food characteristics & Microwave cooking Stirring To Clean Your Oven Stirring is one of the most important of all microwaving techniques. In conventional cooking, food is stirred for the purpose of blending. Microwaved food, however, is stirred 1 Keep the inside of the oven clean in order to spread and redistribute heat.
-
Page 41: Questions & Answers
Questions & Answers Q What’s wrong when the oven light will not glow? Q Is it possible to cook popcorn in this oven? A There may be several reasons why the oven light will not glow. A Yes, if using one of the two methods described Light bulb has blown below Relay is failed... -
Page 42: Plug Wiring Information/Technical Specifications
Plug wiring information/ Technical Specifications WARNING Technical Specification This appliance must be earthed MP9489SCR Power Input 220 V~ 50 Hz The wires in this mains lead are colored in accordance with the Output 900 W (IEC60705 rating standard) following codes Microwave Frequency 2450 MHz BLUE ~ Neutral...
