- Page 1 Model SyncMaster 700TSn, 820TSn Select Language Safety Instructions Install Programs PDF Manuals Registration Introduction Connections Using the Software Adjusting the LCD Display Troubleshooting Specifications Information Appendix © 2007 Samsung Electronics Co., Ltd. All rights reserved.
- Page 2 Quick Setup Guide Cables contact your dealer. to buy optional items. LCD Display Warranty Card (Not available in all locations) D-Sub Cable Power Cord Select Language Main Page Model SyncMaster 700TSn, 820TSn Package Contents User's Guide, MDC Software, MagicInfo Software...
- Page 3 Other Batteries (AAA X 2) Remote Control (Not available in all Sold separately Wall Mount KIT LAN Cable Front MENU Opens the on-screen menu and exits from the menu or closes the adjustment menu. Navigate buttons (Up-Down buttons) Moves from one menu item to another vertically or adjusts selected menu values. Adjust buttons (Left-Right buttons)/ Volume buttons Moves from one menu item to another horizontally or adjusts selected menu values.
- Page 4 Changing the source is only allowed for external devices that are connected to the LCD Display at the time. [PC] → [BNC] → [DVI] → [AV] → [S-Video] → [Component] → [HDMI] → [MagicInfo] >> Click here to see an animation clip. Push the PIP button to turn the PIP screen On / Off.
- Page 5 POWER IN The power cord plugs into the LCD Display and the wall plug. REMOTE OUT/IN You can use a wired remote control by connecting it to your monitor. RS232C OUT/IN (RS232C Serial PORT) MDC(Multiple Display Control) Program Port DVI / PC / HDMI IN [HDMI/PC/DVI/BNC AUDIO IN](HDMI/PC/DVI/BNC Audio Connection Terminal (Input)) DVI / PC / HDMI IN [HDMI]...
- Page 6 Note • The number of LCD Displays that can be connected to loopout may differ depending on the cables, signal source etc. With cables where there is no degradation or signal source, up to ten LCD Displays can be connected. Note •...
- Page 7 ON / OFF Turns the LCD Display On/Off. MagicInfo MagicInfo Quick Launch Button. MDC Quick Launch Button. LOCK Activates or deactivates all function keys on both the remote control and the LCD Display except for the Power and LOCK buttons. MagicInfo buttons Used for MagicInfo.
- Page 8 This is displayed on the lower left corner of the screen. The audio resumes if MUTE or - VOL + is pressed in the Mute mode. TTX/MIX TV channels provide text information services via teletext. - This fuction does not work for this monitor. MENU Opens the on-screen menu and exits from the menu screen or closes the screen adjustment menu.
- Page 9 The image in the PIP window will appear on the main screen, and the main screen image will appear in the PIP window. SIZE Switches the PIP Picture Size. Rewind STOP Stop PLAY / PAUSE Play/Pause Fast forward Default Manual Change Mono © 1995~2008 SAMSUNG. ALL Rights Reserved...
-
Page 10: Mechanical Layout
820DXn Mechanical Layout Monitor Head Speaker Installation VESA Bracket Wall Bracket Installation 1. Mechanical Layout 2. Monitor Head... -
Page 11: Installation Vesa Bracket
After your order is placed, installation professionals will visit you and install the bracket. At least 2 persons are needed in order to move the LCD Monitor. Samsung is not responsible for any product damage or any injury caused by installation at customer's discretion. Dimensions... -
Page 12: Wall Bracket Installation
4. Wall Bracket Installation Contact a technician for installing the wall bracket. Samsung Electronics is not responsible for any damages to the product or harm to customers when the installation is done by the customer. This product is for installing on cement walls. The product may not stay in place when installed on plaster or wood. -
Page 13: To Mount The Product On The Wall Bracket
There are two hinges(left and right). Use the correct one. To mount the product on the wall bracket The shape of the product may vary depending on the model. (The assemblies of the plastic hanger and the screw are the same) D. -
Page 14: Wall Bracket Angle Adjustment
1. Mount the product on the wall bracket and make sure it is properly fixed to the left and right plastic hangers. 2. Be careful when installing the product on the bracket as fingers can be caught in the holes. 3. - Page 15 1. Fix the product to the wall bracket. 2. Hold the product at the top in the center and pull it forward (direction of the arrow) to adjust the angle. 3. You can adjust the bracket angle between -2°and 15 °. Make sure to use the top center, and not the leftor the right side of the product to adjust the angle.
- Page 16 700DXn Mechanical Layout Monitor Head Speaker Installation VESA Bracket Wall Bracket Installation 1. Mechanical Layout 2. Monitor Head...
- Page 17 After your order is placed, installation professionals will visit you and install the bracket. At least 2 persons are needed in order to move the LCD Monitor. Samsung is not responsible for any product damage or any injury caused by installation at customer's discretion. Dimensions...
- Page 18 4. Wall Bracket Installation Contact a technician for installing the wall bracket. Samsung Electronics is not responsible for any damages to the product or harm to customers when the installation is done by the customer. This product is for installing on cement walls. The product may not stay in place when installed on plaster or wood.
- Page 19 There are two hinges(left and right). Use the correct one. To mount the product on the wall bracket The shape of the product may vary depending on the model. (The assemblies of the plastic hanger and the screw are the same) D.
- Page 20 1. Mount the product on the wall bracket and make sure it is properly fixed to the left and right plastic hangers. 2. Be careful when installing the product on the bracket as fingers can be caught in the holes. 3.
- Page 21 1. Fix the product to the wall bracket. 2. Hold the product at the top in the center and pull it forward (direction of the arrow) to adjust the angle. 3. You can adjust the bracket angle between -2°and 15 °. Make sure to use the top center, and not the leftor the right side of the product to adjust the angle.
- Page 22 Appendix Note • Only the supplied bolts should be used. Caution Samsung Electronics will not be responsible for damages caused by using a base other than those specified. Installing the Semi Stand Caution The resolution may differ for each product model. For information on the optimal resolution, refer to the user manual.
- Page 23 Using a Power cord with Earth In the event of failure, the earth lead may cause electric shock. Make sure to wire the earth lead in correctly, before connecting the AC power. When un-wiring the earth lead, make sure to disconnect the AC power in advance.
- Page 24 • Turn on both your computer and the LCD Display. Note • The DVI cable or BNC cable is optional. Contact a local Samsung Electronics Service Center Connecting a VCR AV input devices such as VCRs or Camcorders are connected via the AV IN [VIDEO] or AV IN [S-VIDEO] of the LCD Display using an S-VHS or BNC cable.
- Page 25 Connect a set of audio cables between the COMPONENT AUDIO IN [L-AUDIO-R] on the LCD Display and the AUDIO OUT jacks on the DVD player. Connect a Component cable between the BNC/COMPONENT IN - P the P , Y, P jacks on the DVD player.
- Page 26 • The audio-video cables shown here are usually included with a Camcorder. (If not, check your local electronics store.) If your camcorder is stereo, you need to connect a set of two cables. Connecting a DTV Set Top Box Note •...
- Page 27 • Connect a set of audio cables between the AUX L, R jacks on the AUDIO SYSTEM and the AUDIO OUT [L-AUDIO-R] on LCD Display. Connecting to a Wired Remote Control Note • You can control your monitor by allowing it to receive the remote control signals of other devices through the REMOTE OUT terminal.
- Page 28 HDMI / PC / DVI-D AUDIO IN terminal of the monitor. Connecting a LAN Cable Connect the LAN cable. Connecting a USB device You can connect USB devices such as a mouse or keyboard. © 1995~2008 SAMSUNG. ALL Rights Reserved...
-
Page 29: Troubleshooting
85Hz, you will see the black screen because the LCD Display does not support over 85Hz. Note • Refer to Display. Specifications > Preset Timing Modes for the resolutions or frequencies supported by the LCD Select Language Main Page Model SyncMaster 700TSn, 820TSn Self-Test Feature Check... - Page 30 Do not use benzene, thinner or other flammable substances, or a wet cloth. • We recommend that a Samsung cleansing agent is used to prevent damage to the screen. Maintaining the Flat Panel Display Screen. Clean with a soft cloth (cotton flannel) smoothly.
- Page 31 Problems related to the Screen Note • Problems related to the LCD Display screen and their solutions are listed. Problems The screen is blank and the power indicator is off. "Check Signal Cable" message. "Not Optimum Mode " message. The picture rolls vertically. The image is not clear;...
- Page 32 • Problems related to audio signals and their solutions are listed below. Problems No sound. The sound level is too low. The sound is too high or too low. Problems related to the Remote Control Note • Problems related to the remote control and their solutions are listed. Problems The remote control buttons do not respond.
- Page 33 Windows / Computer Manual). Windows ME/2000: Set the resolution at the Control Panel → Display → Screen Saver. Set the function in the BIOS-SETUP of the computer. (Refer to the Windows / Computer Manual). © 1995~2008 SAMSUNG. ALL Rights Reserved...
