Back Panel
1 Antenna IN
2 Antenna OUT
3 Internet
4 Composite Video
5 Audio Left & Right
6 Optical
7 HDMI
2
8
x USB ports
9 Power

The Power Adapter

120400
• Model: RJ-AS
100–240
• Input: V~,
12
• Output: DC V DC/
• SAA Approval: SGS-
2013-03-20
• Approval Date:
For more information, please visit www.uec.com.au for a list of power supplies and regulators.
For assistance:
support@uec.com.au
www.uec.com.au
Connects to the TV terrestrial antenna
Antenna loop through connection to other devices such as TV
or another STB / PVR / VCR
Ethernet port for internet connectivity
Connects to the video inputs on TV
Connects to the analogue inputs on TV
Connects to the Digital Audio optical input on TV
or AV Home Theatre System
Connects to the high definition (HDMI) input on TV
or AV Home Theatre System
USB port provision for Wi-Fi / External Hard Drive / USB upgrade
and/or future use
12
+ VDC input from the supplied power pack
3
1 2 4
003
E
2.0 50 60
A Max, / Hz
4
A DC
130179
-EA
5 6 7 8
9
