General Safety Information & Replacement Parts
TABLE OF CONTENTS
General Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Air Compressor and Air Tool Safety . . . . . . . . . . . . . . . . . . . 2-3
Tool Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Maintenance / Lubrication . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Service Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-10
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
WARNING: Risk of injury to persons. Read and
understand operation instructions. Always become familiar
with all the instructions and warnings before operating any
pneumatic tool.
DIE GRINDER SERIES
DIE GRINDERS
Extended Die Grinder
Angle Die Grinder
FLORIDA-PNEUMATIC.COM
Please contact 1-800-356-3392 for further assistance.
UT8728 / UT8729
UT8728
Die Grinder
UT8728E
UT8729-12
UT8729-18
Advertisement
Table of Contents
Related Manuals for Florida Pneumatic Universal Tool UT8728
Summary of Contents for Florida Pneumatic Universal Tool UT8728
-
Page 1: Table Of Contents
UT8728 / UT8729 Universal Tool DIE GRINDER SERIES ™ DIE GRINDERS General Safety Information & Replacement Parts UT8728 Die Grinder UT8728E Extended Die Grinder UT8729-12 UT8729-18 Angle Die Grinder TABLE OF CONTENTS General Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Air Compressor and Air Tool Safety . -
Page 2: General Safety Information
• Make sure there are no electrical cables, gas pipes etc. that could • Whenever universal twist couplings (claw couplings) are used, lock cause a hazard if damaged by use of the tool. pins must be installed. • Do not exceed the maximum air pressure stated on the tool. 7.2.2.10 DUST AND FUME HAZARDS • Use whip check safety cables to safeguard against possible hose to • Dust from some work processes can cause cancer, birth defects or tool and hose to hose connection failure. other respiratory diseases. Risk assessment of these hazards and • Never carry an air tool by the hose. implementation of appropriate controls is essential. Universal Tool a Division of Florida Pneumatic Manufacturing Corporation 851 Jupiter Park Lane, Jupiter FL 33458... -
Page 3: Air Compressor And Air Tool Safety
Safety Information (continued) AIR COMPRESSOR AND AIR TOOL SAFETY WARNING: Some dust created by power sanding, sawing, grinding, drilling and other construction activities contains 1. Risk of Bursting. Do not adjust the regulator to result in output chemicals known to cause cancer, birth defects or other pressure greater than the marked maximum pressure of this air reproductive harm. -
Page 4: Installation
□ Recommended lubricants: Air tool oil or any other high grade turbine oil containing moisture absorbent, rust inhibitors, metal wetting agents, and an EP (extreme pressure) additive. Universal Tool a Division of Florida Pneumatic Manufacturing Corporation 851 Jupiter Park Lane, Jupiter FL 33458... -
Page 5: Operation
Operation Operating the die grinder Installing the grinding stone □ This Die Grinder is designed to operate on 90 PSIG. Lower WARNING: Disconnect the tool from the air supply before pressure (below 90 PSIG) will reduce performance of servicing or changing accessories. the tool. -
Page 6: Troubleshooting
There are no other warranties expressed or implied and Universal Tool shall not be liable for incidental, consequential or special damages, or any other damages,costs or expenses excepting only the cost or expense of repair or replacement as described above. Universal Tool a Division of Florida Pneumatic Manufacturing Corporation 851 Jupiter Park Lane, Jupiter FL 33458... -
Page 7: Service Parts
UT8728 Service Parts / Exploded View Drawing Die Grinder FLORIDA-PNEUMATIC.COM Please contact 1-800-356-3392 for further assistance. - Page 8 UT8728E Service Parts / Exploded View Drawing Extended Die Grinder Universal Tool a Division of Florida Pneumatic Manufacturing Corporation 851 Jupiter Park Lane, Jupiter FL 33458...
- Page 9 UT8729-12 Service Parts / Exploded View Drawing Angle Die Grinder Part Number Description Part Number Description Qty . 9872801 MOTOR HOUSING 9389521A CYLINDER PIN 1 9872802B-12 THROTTLE LEVER ASSEMBLY 9872822 CYLINDER PIN 2 W/LASER ETCHED 9308003 THROTTLE LEVER PIN 9872923 FRONT PLATE 9308004 THROTTLE VALVE O-RING...
- Page 10 END PLATE-REAR 9872938 BEARING RETAINER 9872918 ROTOR 9872939 WOODRUFF KEY 9389517 ROTOR BLADE 9R8ZZ BALL BEARING 9389521N CYLINDER 9872938 BEARING RETAINER 9872939 WOODRUFF KEY Universal Tool a Division of Florida Pneumatic Manufacturing Corporation 851 Jupiter Park Lane, Jupiter FL 33458...
-
Page 11: Warranty
Warranty Limited Warranty: Universal Tool warrants its tools to be free from defects in material and workmanship for one year from the date of purchase. This warranty does not apply to tools which have been abused, misused, modified or repaired by someone other than Universal Tool or its authorized service centers. - Page 12 Universal Tool ™ Questions, problems, missing parts? Call Customer Service 8 a.m.-5 p.m., EST, Monday-Friday 1-800-356-3392 FLORIDA-PNEUMATIC .COM Retain this manual for future use. Universal Tool a Division of Florida Pneumatic Manufacturing Corporation 851 Jupiter Park Lane, Jupiter FL 33458...
