Cotell IH2500E Installation Manual

Wall-mount
Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

IH2500E-A-WM
IH2500E (Wall-Mount)
Installation Guide
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IH2500E and is the answer not in the manual?

Questions and answers

Related Manuals for Cotell IH2500E

Summary of Contents for Cotell IH2500E

  • Page 1 IH2500E-A-WM IH2500E (Wall-Mount) Installation Guide...
  • Page 2 IH2500E-A-WM IH2500E-M-WM Infotainment Connectivity Panel Accessories VGA cable  HDMI Cable  User guide  Screws  AV Cable  Bracket  Faceplate  IH2500E-M-WM FEATURES Wall-mount  Ergonomic design with stylish outlook  High quality casing  Customizable logo ...
  • Page 3 IH2500E-A-WM IH2500E-M-WM DIAGRAM ITEM FEATURE DESCRIPTION USB input HDMI HDMI input Audio & Video Audio & Video input S-Video S-Video input VGA+Audio VGA+Audio input RJ45 Internet connection Universal Power Socket Universal power supply(110VAV or 220VAC) +5V USB charger +5V charger...

  • Page 4: Installation Procedure

    IH2500E-A-WM BRACKET DIAGRAM （in mm） INSTALLATION PROCEDURE Remove the bracket; Create depression in the wall according to the size of the junction box (in mm).
  • Page 5 IH2500E-A-WM 1. Fasten the bottom of the junction box to the wall 2. Place the universal power cord through the junction box 3. Insert all the cables through the Junction box and ensure that they are securely fastened. Connect the other end of the cables to the relevant connections (Power, Internet & TV outlets)

  • Page 6: Operation

    IH2500E-A-WM 4. Place the IH2500E-M-WM core into the junction box and fasten the 4 screws provided. Clip in the upper faceplate. 5. Test all function to ensure they are workable. OPERATION General 1. Turn the TV to Appropriate HDMI channel using the TV remote control 2.
  • Page 7 IH2500E-A-WM Note: Input Selection The IH2500B Infotainment connectivity panel will not instruct the TV to switch its input port. If the connectivity panel is connected on port “HDMI2”, then the user will have to manually select the “HDMI2” input via the TV remote control.

  • Page 8: Important Safety Instructions

    IH2500E-A-WM IMPORTANT SAFETY INSTRUCTIONS WHEN USING YOUR INFOTAINMENT CONNECTIVITY PANEL, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK AND INJURY TO PERSONS. INCLUDING THE FOLLOWINGS: 1. READ AND UNDERSTAND ALL INSTRUCTIONS IN THIS MANUAL.

  • Page 9: Warranty Exclusions

    8. Damages in transit. 9. Any damage resulting from unauthorized modification or repair of the Infotainment connectivity panel. COTELL PRODUCT SUPPORT If you need technical assistance with this product, please contact COTELL INTERNATIONAL LIMITED : Telephone : 86-755-2583 1520 : 86-755-8885 9899 Email Sales@cotell.cn...
