- Page 1 Player P5050, P5100, and P5200 Product Manual P5050 P5100 P5200...
-
Page 2: Table Of Contents
Product Features Amazon Alexa Voice Control Integration NV-P5050-xx 3-Zone Player (Ethernet) NV-P5100-xx 3-Zone Player (Ethernet) Prerequisites NV-P5200-xx 3-Zone Player (Ethernet) Connecting Alexa to Your Legrand Nuvo Player Setup Additional Music Service Providers Setup and Installation Supported Alexa Commands Network Requirements Specifications Installing the NV-P5050-xx, NV-P5100-xx, and NV-P5200-xx Players... -
Page 3: Quick Links
QUICK LINKS SETTINGS MENU GENERAL What do all of the options on the settings menu do? What is the Nuvo Player Portfolio System? What is a zone? Where can I can I find more information on my Nuvo Player? How do I add a component to my system? The LED on my Player is flashing. -
Page 4: Overview
OVERVIEW Welcome to the Nuvo Player Portfolio Audio System! This system offers you the opportunity to enjoy your favorite music from any room of your home, at any time, with simplicity of operation. Imagine playing music from your personal library or easily streaming true, high-fidelity music from the Internet by touching a button on your Apple or Android Wi-Fi-enabled portable device. -
Page 5: Product Features
PRODUCT FEATURES NV-P5050-XX 3-ZONE PLAYER (ETHERNET) FRONT PANEL Item Name Description Standby LED Indicator Indicates if the player is powered on. Power Toggles the power on and off. Zone 1 LED Indicator Indicates the status of Zone 1. Zone 2 LED Indicator Indicates the status of Zone 2. -
Page 6: Nv-P5100-Xx 3-Zone Player (Ethernet)
NV-P5100-XX 3-ZONE PLAYER (ETHERNET) FRONT PANEL Item Name Description Standby LED Indicator Indicates if the player is powered on. Power Toggles the power on and off. TFT Back-Lit Display Displays zone names, status, meta data, and networking information. Touch-capable for setup. Zone 3 USB connection port for adding digital music files to the system music library. -
Page 7: Nv-P5200-Xx 3-Zone Player (Ethernet)
NV-P5200-XX 3-ZONE PLAYER (ETHERNET) FRONT PANEL Item Name Description Standby LED Indicator Indicates if the player is powered on. Power Toggles the power on and off. TFT Back-Lit Display Displays zone names, status, meta data, and networking information. Touch-capable for setup. Zone 3 USB connection port for adding digital music files to the system music library. -
Page 8: Setup And Installation
SETUP AND INSTALLATION NETWORK REQUIREMENTS A live Internet connection is necessary for initial setup of your Nuvo Player Portfolio System. For wired Ethernet connectivity, a minimum 100 MB wired network is necessary for proper communication. Wireless-compatible devices use dual band 802.11n wireless communication. To ensure that all components are compatible and communicating correctly, it is strongly suggested that network routers using the older 802.11g protocol be upgraded to support Multicast and UPnP and be Wi-Fi Certified before you proceed with the setup. -
Page 9: Setting Up Your System Using The App
SETTING UP YOUR SYSTEM USING THE APP Once you have connected your system to the local network, you are ready to begin adding components in their desired locations, naming those locations for local control, and creating your multi-zone music system. The process is easily done from a compatible mobile device using the Nuvo Player app. - Page 10 Figure 7 Figure 8 Figure 9 Figure 10 Add a zone (See Figure 7). • For the NV-P5050-XX players: Press the Setup button for the zone. • For NV-P5100-XX and NV-P5200-XX players: Tap the display, then choose a zone. Select Connect. The component shows as connected.
-
Page 11: Using The Nuvo Player App
USING THE NUVO PLAYER APP The Nuvo Player app offers wireless system control from any Wi-Fi-enabled mobile device. The Nuvo Player app is available on the App Store or on Google Play. Both versions offer the same look and control options. When used with tablets, the display is optimized for a view of the complete system’s operation on one screen. -
Page 12: Direct Stream
DIRECT STREAM If audio files such as MP3, AAC, FLAC, or other audio files are on the mobile device running the app, they can be streamed directly to a zone by selecting the This <Device> icon. When This <Device> has been selected, all music playable by the device is cataloged and listed in categories such as Artists, Albums, Tracks, Playlists, etc., similar to what is presented when using the Library Source (See Figure 15). -
Page 13: Media Servers
MEDIA SERVERS This music streaming service is for DLNA/UPnP media servers on a local network. It is an alternative option to a Windows share when users have a local library to share. Devices include NAS drives, Windows machines, Mac OS machines with additional software, etc. -
Page 14: The Settings Menu
THE SETTINGS MENU The SETTINGS menu has several selections important to the control and operation of your system. Press the (gear icon) located at the bottom of the DASHBOARD (See Figure 23) to access the SETTINGS menu (See Figure 24). On smaller format devices, if you are on the Now Playing screen or browsing musical selections (See Figure 25), the (home icon) at the top of the screen returns the app to the DASHBOARD. -
Page 15: Keypads
Figure 28 Figure 29 Figure 30 Figure 31 The ZONE SETTINGS screen contains simple slider adjustments or on/off choices that control the sound for the selected zone. • Bass, Treble, and Balance: These three sliders offer individual control of each sound setting. •... -
Page 16: This App
THIS APP When This App is selected, a page appears with the app’s current software version information, a Reset button that disassociates the app from the system, and scanning options (See Figure 34 – Figure 38). Figure 34 Figure 35 Figure 36 Figure 37 Figure 38... -
Page 17: Music Services
MUSIC SERVICES When Music Services is selected (See Figure 43), the active streaming music services on the system display (See Figure 44) along with a button for adding new services (See Figure 45). Most services require an online subscription account. The associated user name and password for the music service account must be added under this menu selection for the service to be active on the system. -
Page 18: International
Figure 50 Figure 51 Figure 52 INTERNATIONAL The International selection (See Figure 53), offers a Location setting (See Figure 54). When a country location is set (See Figure 55), the legal wireless broadcast channel is set for the selected region. This is an important selection. Language and Time Zone options are available for further customization (See Figure 56). -
Page 19: The Music Share Software
The Music Share Software allows music content from shared network locations and libraries, to be streamed from any zone in the sys tem. From your computer, go to http://www.legrand.us/resources-and-downloads/software-downloads to download the music share software. Follow the prompts for installing the software (See Figure 62). - Page 20 You can also choose to share a specific folder or drive on the network. The A specific folder... choice opens a browsing window (See Figure 66). From there you can choose a shared folder with music content or a drive that is shared with the network.
-
Page 21: Troubleshooting
TROUBLESHOOTING FRONT PANEL LEDS An important indicator of each Nuvo component’s operation is the LED light on the front panel. The color of the LED, and the solid or flashing state, provides a visual reference for the status of operation. Refer to the chart for an explanation of the functions and LED status (See Figure 68). - Page 22 Verify the wireless settings of Dual Band 2.4GHz/5GHz devices. NOTE: This will require logging into the customer’s ISP Network Appliance. Legrand recommends that the 2.4GHz and 5GHz wireless networks be assigned separate SSID’s to ensure a consistent connection. Player Portfolio Audio System | Product Manual...
-
Page 23: Amazon Alexa Voice Control Integration
NOTE: Amazon, Echo, Alexa, and all related logos are trademarks of Amazon.com, Inc. or its affiliates. PREREQUISITES Enabling voice control of your Legrand Nuvo Player through devices with Amazon Alexa requires the following: • A device with Amazon Alexa, such as Amazon Echo, connected to your home network •... - Page 24 Select Register. Sign up for an ARTIK Cloud account or sign in if you already have an account. Select Open. Select Open Alexa. Ensure you are in the Select Skills & Games. Devices section of the Alexa app and then click the Menu icon.
- Page 25 Read the instructions Use your ARTIK Cloud listed under “Before username and password to you continue.” Confirm sign into your account. your setup, then select Your Samsung ARTIK Cloud Continue. account will link with your Alexa account. This completes your Nuvo Player Alexa skill setup.
-
Page 26: Setup Additional Music Service Providers
SETUP ADDITIONAL MUSIC SERVICE PROVIDERS To play selections from Music Service Providers (MSPs) other than Amazon Music, link your account for the MSP with Alexa. Each service has a different setup. IMPORTANT: Use the same account information that you use for your MSP app when linking to Alexa using the ARTIK Cloud account. If you do not, you will not be able to access the features unique to your MSP account, such as playlists IHEARTRADIO No account setup is required. -
Page 27: Specifications
SPECIFICATIONS IOS AND ANDROID REQUIREMENTS • iOS 6 or later required • Android 2.1x or later required NV-P5050-XX AMPLIFIER Input/Output Connectors Line Output Line Input (3) TRS 3.5 mm stereo jack Output Level 0–2.0 V RMS Line Output (3) TRS 3.5 mm stereo jack Output Impedance 470 Ohms Speaker Output... -
Page 28: Nv-P5100-Xx Amplifier
NV-P5100-XX AMPLIFIER Input/Output Connectors Line Input (Digital) Sample Rates 44.1 kHz–192 kHz Line Input (3) TRS 3.5 mm mini TOSLINK Combo Receiver Bit Rate 24 B Line Output (3) TRS 3.5 mm mini TOSLINK Signal-to-Noise Ratio, 120 dBA Combo Receiver Rated Output Trigger Output (3) TS 3.5 mm stereo jack 5 VDC... -
Page 29: Nv-P5200-Xx Amplifier
NV-P5200-XX AMPLIFIER NOTE: Using multiple P5200 units in a single installation will require dedicated power. Please use one dedicated 15 amp circuit for every two P5200’s installed. The P5200 is capable of creating large amounts of output power. When the P5200 is used at high levels of output, it can generate a substantial amount of heat. The P5200 must be installed in a manner that allows for adequate dissipation of heat. -
Page 30: Regulatory Compliance
Ce document contient des informations importantes sur la sécurité et la conformité réglementaire du produit. Pour plus de détails concernant les instructions d’utilisation et d’installation, veuillez consulter notre site Web à l’adresse http://www.legrand.us/nuvo. aspx. Pour nous joindre : Soutien technique :... - Page 31 Este documento contiene información importante relativa al cumplimiento normativo y de seguridad del producto. Para obtener información más detallada sobre las instrucciones de uso e instalación, visite nuestra página web en http://www.legrand.us/nuvo.aspx. Póngase en contacto con nosotros: Asistencia técnica: Teléfono gratuito: +1.800.223.4162, opt.
- Page 32 This product has demonstrated EMC compliance under conditions that included the use of compliant peripheral devices, USB cables, and Ethernet network cables between components. Responsible party (contact for FCC matters only): Legrand Home Systems Inc., dba Nuvo Technologies 3015 Kustom Drive Hebron, KY 41048 Exposure to Radio Frequency Energy The radiated output power of this device is well below the FCC and EU radio frequency exposure limits.
- Page 33 Europe - EU Declaration of Conformity A copy of the EU Declaration of Conformity is available at: www.legrand.us/aboutus/sustainability/high-performance-buildings/eco-iconography.aspx This equipment can be used in the following countries: Player Portfolio Audio System | Product Manual...
- Page 34 Important Safety Information (English) Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this product near water or moisture or let objects or liquids enter the product. Install according to manufacturer's instructions. Clean only with a dry, soft cloth. Do not block the ventilation openings.
- Page 35 Wichtige Sicherheit Auskunft (Deutsch) Lesen Sie diese Anweisungen. Behalten Sie diese Anweisungen. Beachten Sie alle Warnungen. Folgen Sie allen Anweisungen. Verwenden Sie dieses Produkt nicht in Wassernähe oder bei Feuchtigkeit und vermeiden Sie das Eindringen von Gegenständen oder Flüssigkeiten in das Produkt. lnstallieren Sie immer nach den Anweisungen des Herstellers.
- Page 36 Informações importantes de segurança (Português) Leia estas instruções. Guarde estas instruções. Tenha em atenção todos os avisos. Siga todas as instruções. Não utilize este produto junto de água ou humidade, nem deixe que os objetos ou líquidos entrem em contacto com o produto. Instale de acordo com as instruções do fabricante.
- Page 37 Quando decidir descartar este produto e/ou sua bateria, faça-o de acordo com as leis e diretrizes ambientais locais. Para informações sobre o programa de reciclagem da Apple, pontos de coleta e telefone de informações, visile www.legrand.us/nuvo.aspx. Player Portfolio Audio System | Product Manual...
- Page 38 3015 Kustom Drive Hebron, KY 41048 United States 844.334.8044 www.legrand.us/nuvo...
