- Page 1 Portable DVD Player Owner’s Manual Model: DP9821P/ DP9821PB DP9821PG Before connecting, operating or adjusting this product, please read this instruction booklet carefully and completely. P/NO : 3834RD0077U...
-
Page 2: Safety Precautions
Safety Precautions CAUTION: VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN CAUTION AND INTERLOCKS DEFEATED. RISK OF ELECTRIC SHOCK CAUTION: The apparatus should not be exposed to water (dripping or splashing) DO NOT OPEN and no objects filled with liquids, such as vases, should be placed on the appara- tus. - Page 3 Safety Precautions (Continued) NOTES ON COPYRIGHTS: It is forbidden by law to copy, broadcast, show, broadcast via cable, play in public, or rent copyrighted material without permission. This product features the copy protection function developed by Macrovision. Copy protection signals are recorded on some discs. When recording and playing the pictures of these discs on a VCR, picture noise will appear.
-
Page 4: Table Of Contents
Table of Contents Introduction Playing an Audio CD and MP3/WMA Disc ....... . . 25-27 Audio CD and MP3/WMA Disc Features . -
Page 5: Before Use
Before Use To ensure proper use of this product, please read this owner’s manual DVD and finalized DVD±R/RW carefully and retain for future reference. Video CDs. Audio CDs. This manual provides information on the operation and maintenance of your DVD player. Should the unit require service, contact an authorized MP3 discs. -
Page 6: Disc-Related Terms
Before Use (Continued) Storing Discs VCD (Video CD) After playing, store the disc in its case. Do not expose the disc to direct A VCD holds up to 74 minutes (650 MB disc) or 80 minutes (700 MB sunlight or sources of heat and never leave it in a parked car exposed to disc) of MPEG-1 full-motion video along with quality stereo sound. -
Page 7: Maintenance And Service
Before Use (Continued) PBC: Playback Control (Video CD only) Keeping the exterior surfaces clean Playback control is available for Video CD (VCD) version 2.0 disc for- • Do not use volatile liquids such as insecticide spray near the unit. mats. PBC allows you to interact with the system via menus, search func- tions, or other typical computer-like operations. -
Page 8: Types Of Playable Discs
Before Use (Continued) Types of Playable Discs NOTES • Depending on the conditions of the recording equipment or the CD-R/RW (or DVD±R/±RW) disc itself, some CD-R/RW (8 cm / 12 cm disc) (or DVD±R/±RW) discs cannot be played on the unit. Video CD (VCD) •... -
Page 9: Identification Of Controls
Identification of Controls 1. LCD screen Main Unit 2. Speaker 3. COLOR control buttons : – ; black and white, + ; color 4. BRIGHT control buttons : – ; dark, + ; light 5. POWER Switches the player ON and OFF. 6. -
Page 10: Main Unit
Identification of Controls (continued) Main Unit 10 11 12 1. Remote sensor 7. STOP Stops playback. 2. Charge indicator During recharging, charge indicator is red. 8. Volume Control If recharging is complete, charge indicator changes to green color. 9. Earphone jack 3. -
Page 11: Remote Control
Identification of Controls (continued) 1. AUDIO 10. SUBTITLE Remote Control Selects an audio language (DVD). Selects a subtitle language. 2. POWER 11. A-B Switches DVD Player ON and OFF. Repeat sequence. 3. • Reverse SKIP/SEARCH ( S 12. SLOW ( , , / . . ) Search backward*/ go to beginning of Reverse/ Forward slow playback. - Page 12 Identification of Controls (continued) Insert the battery (Lithium battery) Button-type battery (Lithium battery) 1. Pinch the battery holder clip together then pull the tab to remove the battery holder. 2. Insert the battery with the + facing in the same direction as the + on the battery holder.
-
Page 13: Power Connections
Power Connections AC Adapter Follow steps 1 to 3 to connect. When disconnecting, reverse the order. Caution AC adapter • Do not connect the power plug to a power outlet other than that • This AC adapter operates on 100-240V~ 1.5A 50-60Hz. indicated on the label, as this can result in a risk of fire or electric •... -
Page 14: Automotive Adapter
Power Connections (continued) This DVD player and its automotive adapter are designed for use in vehicles that have 12 volt, negative ground electrical sys- Automotive tems. (This is standard for most vehicles.) If your vehicle has a different type of electrical system, the DC power system can- Adapter not be used. - Page 15 Power Connections (continued) Battery Pack • Charge the battery pack before using it for the first time. Detaching the battery pack To separate the battery pack, pull the switch which is locate beside the Attaching the battery pack battery pack then slide down the battery pack at the same time. 1.
-
Page 16: Battery Pack
Power Connections (continued) Charging the battery pack Recharging and play times 1. Attach the battery pack to the player. Recharging Play time 2. Connect the AC power adapter to the player and without player LCD On LCD Off the plug into an AC outlet. Approx. -
Page 17: Playing A Disc
Playing a Disc 1. Prepare the power supply. The picture mode and size The picture shown on the LCD depends on the display mode and the 2. Open the outer cover and press POWER button. size recorded on the disc. 3. -
Page 18: On-Screen Display
On-Screen Display You can display the general playback status on the screen. Some items Example: On-Screen Display during can be changed using the menu. To use the on-screen display: playing DVD Video 1. Press DISPLAY during playback. Items Selection Method b / B, Numbers 2. - Page 19 On-Screen Display (continued) Example: On-Screen Display during Example: On-Screen Display during playing VCD playing divx movie disc Items Selection Method Items Selection Method b / B, Numbers Track Number 1 / 3 b / B, Numbers Track Number ENTER 1 / 3 ENTER (or PBC mode) Numbers,...
-
Page 20: General Features
General Features Moving to another CHAPTER/TRACK DivX Use the b B v V buttons to select the title/chapter you want to view, then press ENTER to start. Press TITLE or MENU to return to When a title on a disc has more than one chapter or a disc has more than the menu screen. -
Page 21: Still Picture And Frame-By-Frame Playback
General Features (continued) Still Picture and Frame-by-Frame Playback Repeat A-B DivX DivX To repeat a sequence. 1. Press PAUSE on the remote control during playback. Advance the 1. Press A-B at your chosen starting point. “ A * ” appears briefly on picture frame-by-frame by pressing PAUSE repeatedly. -
Page 22: Marker Search
General Features (continued) 7. Press ENTER to recall a marker. Marker Search DivX Press CLEAR to clear a marker. Storing a MARKER in the DVD memory is similar to marking your page Play resumes from the point corresponding to the in a book. -
Page 23: Zoom
General Features (continued) Special DVD Features Zoom DivX Checking the contents of DVD discs: Menus Use zoom to enlarge the video image. DVDs may offer menus that allow you to access special features. To use 1. Press ZOOM during playback or still playback to activate the Zoom the disc menu, press MENU. -
Page 24: Camera Angle
General Features (continued) Camera Angle Last Scene Memory VCD1.1 If the disc contains scenes recorded at different camera angles, you can This player memorizes last scene from the last disc that is viewed. The change to a different camera angle during playback. last scene remains in memory even if you remove the disc from the player or switch off the player. -
Page 25: Playing An Audio Cd And Mp3/Wma Disc
Playing an Audio CD or MP3/WMA Disc The DVD player can play MP3/WMA formatted recordings on ID3 TAG CD-ROM, CD-R, or CD-RW discs. • When playing a file containing information such as track titles, you can see the information by pressing DISPLAY. Audio CD [ Title, Artist, Album, Year, Comment ] Once you insert an audio CD a menu appears on the screen. -
Page 26: Audio Cd And Mp3/Wma Disc Features
Playing an Audio CD or MP3/WMA Disc (continued) Audio CD and MP3 / WMA Disc Features Repeat Track/All/Off You can play a track/all on a disc. Pause 1. Press REPEAT when playing a disc. The repeat icon appears. 1. Press PAUSE during playback. 2. -
Page 27: Mp3 / Wma Disc Compatibility With This Player Is Limited As Follows
Playing an Audio CD or MP3/WMA Disc (continued) MP3 / WMA disc compatibility with this player is limited as Customers should note that permission is required in order to follows: download MP3 / WMA files and music from the Internet. Our com- pany has no right to grant such permission. -
Page 28: Programmed Playback
Programmed Playback The program function enables you to store your favorite tracks from any VIDEO CD disc in the player memory. List Program A program can contain 30 tracks. Track1 Track5 Track2 Track2 Track3 Track3 Track4 Track1 1. Insert a disc. Track5 Audio CD or MP3/WMA Discs: Clear All... -
Page 29: Repeat Programmed Tracks
Programmed Playback (continued) Repeat Programmed Tracks 1. Press REPEAT when playing a disc. The repeat icon appears. 2. Press REPEAT to select a desired repeat mode. • Track: repeats the current track • All: repeats all the tracks on programmed list. •... -
Page 30: Viewing A Jpeg Disc
Viewing a JPEG Disc Using this DVD Player you can view discs with JPEG files. TIPS • Press MENU to move to the next page. 1. Insert a disc and close the tray. The PHOTO menu appears on the screen. •... -
Page 31: Moving To Another File
Viewing a JPEG Disc (continued) JPEG disc compatibility with this player is limited as follows: JPEG Moving to another File • Depending upon the size and number of JPEG files, it could take a long time Press SKIP/SEARCH (. or >) or cursor (b or B) once while for the DVD player to read the disc’s contents. -
Page 32: Playing A Dvd Vr Format Disc
Playing a DVD VR format Disc This unit will play DVD-R/RW discs recorded using the DVD-Video NOTES format that have been finalized using a DVD-recorder. • Unfinalized DVD-R/RW discs cannot be played in this player. • Some DVD-VR disc are made with CPRM data by DVD RECORDER. Player •... -
Page 33: Playing A Divx Movie Disc
Playing a DivX Movie Disc Using this DVD Player you can play DivX video disc. DivX disc compatibility with this player is limited as follows: • Available resolution size of the DivX file is under 720x576 (W x H) pixel. 1. -
Page 34: Initial Settings
Initial Settings By using the Setup menu, you can make various adjustments to items LANGUAGE such as picture and sound. You can also set a language for the subtitles LANGUAGE and the Setup menu, among other things. For details on each Setup menu English Menu Language item, see pages 34 to 39. -
Page 35: Display
Initial Settings (continued) DISPLAY AUDIO DISPLAY Each DVD disc has a variety of audio output options. Set the player’s AUDIO options according to the type of audio system you use. TV Aspect 16 : 9 Wide Display Mode Widescreen AUDIO Progressive Scan Dolby Digital Bitstream... -
Page 36: Others
Initial Settings (continued) OTHERS Sample Freq. (Frequency) The PBC, Auto Play, B.L.E. and DivX(R) VOD settings can If your receiver or amplifier is NOT capable of handling 96 kHz signals, be changed. select 48 kHz. When this choice is made, this unit automatically converts OTHERS any 96 kHz signals to 48 kHz so your system can decode them. - Page 37 Initial Settings (continued) NOTES DivX DivX(R) VOD If you rent the DivX VOD file, it has several options of viewing limits as You can display the DivX DRM (Digital Rights Management) shown below. Registration code for your unit only. Display the number which you can watch the file. •...
-
Page 38: Lock (Parental Control)
Initial Settings (continued) LOCK (Parental Control) Input a 4-digit code and press ENTER. Enter it again and press ENTER to verify. If you make a mistake before pressing ENTER, LOCK press CLEAR. Unlock Rating Password 3. Select a rating from 1 to 8 using the v / V buttons. Area Code Rating 1-8: Rating one (1) has the most restrictions and rating eight (8) is the least restrictive. - Page 39 Initial Settings (continued) Password (Security Code) Area Code You can enter or change password. Enter the code of the area whose standards were used to rate the DVD video disc, based on the list in the reference chapter. 1. Select Password on the LOCK menu then press B. 1.
-
Page 40: Setting Up The Player
Setting up the Player The picture and sound of a nearby TV, VCR, or radio may be distorted during playback. If this occurs, position the player away from the TV, VCR, or radio, or turn off the unit after removing the disc. DVD Player Connections Depending on your TV and other equipment there are various ways you can connect the player. -
Page 41: Audio Connection To Optional Equipment
Setting up the Player (continued) Audio Connection to Optional Equipment Amplifier equipped with 2-channel analog stereo or Dolby Pro Logic ll / Pro Logic: Connect the AUDIO OUT jacks on the DVD player to Connect the DVD player to your optional equipment for audio output. the audio left and right IN jacks on your amplifier, receiver, or stereo system, using the audio cables. -
Page 42: Troubleshooting
Troubleshooting Symptom Cause Correction No power. • The power cord is disconnected. • Plug the power cord into the wall outlet securely. • The battery is discharged. • Recharge the battery. No picture on the LCD or • The video cable is not connected securely. •... -
Page 43: Language Code List
Language Codes Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu. Language Code Language Code Language Code Language Code Abkhazian 6566 Fiji 7074 Lingala 7678 Singhalese 8373 Afar 6565 Finnish 7073 Lithuanian 7684... -
Page 44: Area Codes
Area Codes Choose an area code from this list. Area Code Area Code Area Code Area Code Afghanistan Ethiopia Malaysia Saudi Arabia Argentina Fiji Maldives Senegal Australia Finland Mexico Singapore Austria France Monaco Slovak Republic Belgium Germany Mongolia Slovenia Bhutan Great Britain Morocco South Africa... -
Page 45: Specifications
Specifications DVD Player Liquid Crystal Display Power supply: Panel size: 7 inches wide (diagonal) DC 9.5V (AC adapter terminal), DC 7.4V (Battery) Projection system: Y/C stripe Power consumption: 15W with battery Driving system: TFT active matrix Weight: 1.46 lbs (0.66 kg) (without battery pack) Resolution: 234 x 480 x 3 (effective pixel rate: more than 99.99%) External dimensions (W x H x D): 7.5 x 1.1 x 6.3 inches (190 x 28 x 159.5 mm)
