INSTALLATION AND
MAINTANANCE MANUAL
PROJECTOR LIFT
SI-H L 50 HC
ORIGINAL INSTRUCTIONS IN ITALIAN LANGUAGE
Translation into English language
This document is property of Euroscreen Srl.
Any distribution, reproduction, copying or publication of this document is prohibited.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SI-H L 50 HC and is the answer not in the manual?

Questions and answers

Related Manuals for Euroscreen SI-H L 50 HC

Summary of Contents for Euroscreen SI-H L 50 HC

  • Page 1 INSTALLATION AND MAINTANANCE MANUAL PROJECTOR LIFT SI-H L 50 HC ORIGINAL INSTRUCTIONS IN ITALIAN LANGUAGE Translation into English language This document is property of Euroscreen Srl. Any distribution, reproduction, copying or publication of this document is prohibited.
  • Page 2 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC INDEX In order to guarantee the best performances of your lift, please READ CAREFULLY this installation manual GENERAL INFORMATION Projector lift description Manufacturer’s rights Contents and map of this manual...

  • Page 3: General Information

    Installation and maintanance manual Projector lift Mod. SI-H L 50 HC 1.0 GENERAL INFORMATION PROJECTOR LIFT DESCRIPTION The projector lift SI-H L 50 HC is a motorized lift for videoprojectors. Therefore it can be included in the definition of machinery following the Directive 2006/42/CE and modifications. The present installation manual, the conformity certification and the technical labels on the lift are conform to this directive.

  • Page 4: Symbols Legend

    Installation and maintanance manual Projector lift Mod. SI-H L 50 HC AIM, CONTENTS AND TO WHOM IT MAY CONCERN THIS MANUAL This installation manual is addressed to: -end user of the product, owner, people in charge of the product; -people in charge of di disintalling and moving;...

  • Page 5: Technical Assistance

    Installation and maintanance manual Projector lift Mod. SI-H L 50 HC TECHNICAL ASSISTANCE Manufacturer’s customer service is available to support you with technical information about: -queries concerning this installation manual; -supply of spare parts; -maintenance procedures; -severe repairing; -possible malfunctions of the product.
  • Page 6 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC 1.7.6 Warranty is officially voided in cas: Of repairing, modifications or components’ removing and substitution not previously agreed and authorized by the manufacturer. In case of improper use from the end user. Lack of checking of the projector lift following the check register on chapter 6.0...
  • Page 7 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC PRODUCT IDENTIFICATION LABELS This lift is identified by product identification labels that indicate its essential technical specifications. 1.8.1 Product identification label n. 01. Euroscreen SRL Via Stiria n. 45/16 This label reports the following...
  • Page 8 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC 1.8.2 Warning label n. 01 This label reports the following information: Near the lift scissors, there is danger of cutting and crushing while the lift is operating. WARNING Position Warning label n.
  • Page 9 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC 1.8.3 Warning label n. 02 This label reports the following information: A) Maximum load allowed (projector + tile of the false ceiling) READ THE INSTRUCTIONS CAREFULLY MAX LOAD __ KG Position Warning label n. 02 This document is property of Euroscreen Srl.
  • Page 10 CORRECT USE OF THE PROJECTOR LIFT 1.9.1 The product SI-H L 50 HC is a motorized lift for videoprojectors. It is developed to be installed and used indoor only. After the ceiling installation of the lift and the projector made by professional technicians only, the end user is only authorized to operate the lift up and down.

  • Page 11: General Description

    Projector lift Mod. SI-H L 50 HC Installation and maintanance manual GENERAL DESCRIPTION OF THE PROJECTOR LIFT GENERAL DESCRIPTION The drawing here under points out the main components of the lift. Left structural profile 30x30 (mm) Fix pulley Back structural profile 30x30 (mm) Ceiling mounting Braided steel cable...

  • Page 12: Mechanical Specifications

    Installation and maintanance manual Projector lift Mod. SI-H L 50 HC DIMENSIONS OF CLOSED PROJECTOR LIFT The drawings here under 2.2.a - 2.2.b indicates maximum dimensions of the closed lift. 2.2.a - side view 2.2.b - rear view MECHANICAL SPECIFICATIONS The drawings here under 2.3.a - 2.3.b indicate maximum dimensions of the...

  • Page 13: Technical Specifications

    Installation and maintanance manual Projector lift Mod. SI-H L 50 HC TECHNICAL SPECIFICATIONS The measures are expressed in millimeters DIMENSION LIFT CLOSED 684x140x740 (WxHxD) 680x540x740 DIMENSION LIFT OPENED (WxHxD) 520x520 MAXIMUM SIZE FIXING POINTS OF PROJECTOR (WxD) MAXIMUM PROJECTOR DIMENSIONS...

  • Page 14: Safety Standards

    Installation and maintanance manual Projector lift Mod. SI-H L 50 HC SAFETY STANDARDS AND RESIDUAL RISKS SAFETY STANDARDS -The lift has to be used specifically for what it is purposed. The manufacturer cannot be held liable for eventual damages and injuries to people, animals and objects in case of improper or wrong use of the lift itself. (see chapter 1.9).

  • Page 15: Description Of Safety Devices

    Installation and maintanance manual Projector lift Mod. SI-H L 50 HC DESCRIPTION OF SAFETY DEVICES The lift is equipped with two safety screws fixed one onto the bottom left profile and one onto the bottom right profile. The safety screws are fixed in a specific position so that, in case one or both steel cables break, the stabilizing scissors will stop at the adjusted end stop.
  • Page 16 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC RESIDUAL RISKS (rs) 3.3.1 During the use of the lift, please take care of areas that have residual risks for people or objects, in case of incorrect use or evaluation error or inattention eluding the norms specified in this installation manual and indications on product identification labels.
  • Page 17 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC 3.3.2 Other residual risks -Do not lift up or down people or animals. -On the lift have to be installed videoprojectors only. -Do not mount more load under the lift than the maximum load specified on the warning label n. 02 (see 1.8.3).
  • Page 18 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC User has to pay attention also to other factors that can influence the noise level of the product. Among the others, two of these factors are: correct installation and careful maintenance of the lift. In case of continuous unusual noises and vibrations, the lift is probably damaged.

  • Page 19: Installation

    Installation and maintanance manual Projector lift Mod. SI-H L 50 HC INSTALLATION PACKAGING CONTENTS When you open the packaging, please CHECK that it contains ALL the components below. In case one or more components are missing, please refer to the dealer you purchased the product from.
  • Page 20 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC pcs. 01 Small carton box containing all accessories listed here under fig.B fig.C fig.I pcs. 01 pcs. 04 pcs. 01 Up/down switcher “L” form metal brackets for Installation and maintenance...
  • Page 21 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC INSTALLATION “L” FORM METAL CEILING MOUNTING BRACKETS Use the screws and washers to mount the “L” form metal brackets to the left and right profile of the lift, as shown below.
  • Page 22 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC CEILING MOUNTING OF THE PROJECTOR LIFT INSTALLATION OF THIS LIFT HAS TO BE CARRIED OUT FROM AT LEAST TWO QUALIFIED PERSONS. Before proceeding with the ceiling mounting, we advice to mark the fixing points where to fix the ceiling mounting brackets in the most accurate way.
  • Page 23 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC Without removing the panels from the lift structure (in order to keep tension onto the steel cables), lift up the lift (using proper safety devices) aligning the brackets with the drilled holes. Mount the lift to the ceiling using the suitable bolts/screws and wall plugs (NOT SUPPLIED) suitable for the kind of ceiling and the weight that have to be supported (max ø8).
  • Page 24 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC MOUNTING OF THE VIDEOPROJECTOR Connect the projector lift to the mains as explained in chapter 4.5 and lower the plate for fixing the projector to the desired height in order to fix the video- projector with suitable screws (not supplied).
  • Page 25 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC IT IS ABSOLUTELY FORBIDDEN TO POSITION THE POWER CABLE OF THE LIFT IN THE RESIDUAL RISK AREA OF THE LIFT AS SHOWN IN THE DRAWING HERE AT THE RIGHT SIDE. OTHERWISE THE CABLE CAN BE CUT DURING OPERATION OF THE LIFT.

  • Page 26: Electrical Connection

    Installation and maintanance manual Projector lift Mod. SI-H L 50 HC ELECTRICAL CONNECTION 4.5.1 Parts of the up/down switcher included in the box Fixing screws for upper tile to the bottom tile Bottom tile of the switcher Upper tile with electric fruit...
  • Page 27 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC 4.5.2 Use power cable with appropriate section for the motor power. The cable has to be protected from high temperatures, oils, collisions, crushes and sharp edges. Check that the mains tension is the same as the one indicated on the product identification label n.
  • Page 28 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC END-STOPS SETTINGS 4.6.1 In order to fix the “UPPER WARNING: in case the installer needs END POSITION” to modify this end-stop, it is allowed to lower the closed stop position. Do...
  • Page 29 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC USE OF COMPONENTS FOR FIXING THE FALSE CEILING TILE 4.7.1 The supplied components allow to install the lift inside a false ceiling. THE FALSE CEILING PLATE IS NOT SUPPLIED WITH THE LIFT.
  • Page 30 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC 4.7.2 Mounting The following drawings explain how to mount the components above mentioned. Inside the right and left lower structural profile, there are two nuts to be used to screw the screws (Fig.
  • Page 31 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC The sliding brackets (fig. 01) have to be positioned in the suitable point in order to fix correctly the false ceiling plate. After fixing the threaded bars (fig. 04) and defined the right length, the false ceiling plate can be mounted using two types of screws.

  • Page 32: Out Of Order

    Installation and maintanance manual Projector lift Mod. SI-H L 50 HC 5.0 OUT OF ORDER At the end of the life of the lift, it has to be waste. Please follow the procedure below. If the machine has to be stored before wasting, please make the following operations: - Disconnect it from the mains;...
  • Page 33 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC 6.0 REGISTRO CONTROLLI/CHECK REGISTER 6.0 CHECK REGISTER HALF - YEARLY CHECK 6.1 - VERIFICA SEMESTRALE / HALF - YEARLY CHECK Half-yearly, the following checks have to be carried on: -Check if rolling up and rolling down is working properly, without frictions or decelerations.
  • Page 34 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC DATA/DATE Osservazioni/Notes a.y. Esito positivo Positive result Esito negativo Negative result Firma/Signature DATA/DATE Osservazioni/Notes a.y. Esito positivo Positive result Esito negativo Negative result Firma/Signature DATA/DATE Osservazioni/Notes a.y. Esito positivo...
  • Page 35 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC DATA/DATE Osservazioni/Notes a.y. Esito positivo Positive result Esito negativo Negative result Firma/Signature DATA/DATE Osservazioni/Notes a.y. Esito positivo Positive result Esito negativo Negative result Firma/Signature DATA/DATE Osservazioni/Notes a.y. Esito positivo...
  • Page 36 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC DATA/DATE Osservazioni/Notes a.y. Esito positivo Positive result Esito negativo Negative result Firma/Signature DATA/DATE Osservazioni/Notes a.y. Esito positivo Positive result Esito negativo Negative result Firma/Signature DATA/DATE Osservazioni/Notes a.y. Esito positivo...
  • Page 37 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC DATA/DATE Osservazioni/Notes a.y. Esito positivo Positive result Esito negativo Negative result Firma/Signature DATA/DATE Osservazioni/Notes a.y. Esito positivo Positive result Esito negativo Negative result Firma/Signature DATA/DATE Osservazioni/Notes a.y. Esito positivo...
  • Page 38 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC DATA/DATE Osservazioni/Notes a.y. Esito positivo Positive result Esito negativo Negative result Firma/Signature DATA/DATE Osservazioni/Notes a.y. Esito positivo Positive result Esito negativo Negative result Firma/Signature DATA/DATE Osservazioni/Notes a.y. Esito positivo...
  • Page 39 Installation and maintanance manual Projector lift Mod. SI-H L 50 HC DATA/DATE Osservazioni/Notes a.y. Esito positivo Positive result Esito negativo Negative result Firma/Signature DATA/DATE Osservazioni/Notes a.y. Esito positivo Positive result Esito negativo Negative result Firma/Signature DATA/DATE Osservazioni/Notes a.y. Esito positivo...
