LCD TV
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at
www.samsung.com/register
Model _____________ Serial No. _____________
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Samsung LE26C450E1W
Summary of Contents for Samsung LE26C450E1W
- Page 1 Contact SAMSUNG WORLDWIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Country Customer Care Centre EIRE 0818 717100 0845 SAMSUNG (7267864) © 2010 Samsung Electronics Co., Ltd. All rights reserved.
-
Page 2: Securing The Installation Space
The reception quality of TV may be affected due to differences in broadcasting method between the countries. Please check the TV performance in the local SAMSUNG Authorized Dealer, or the Samsung Call Centre whether it can be improved by reconfiguring TV setting or not. -
Page 3: Table Of Contents
Getting Started Connections Basic Features Advanced Features Other Information S.MODE P.MODE This function can be used by pressing the button on the TOOLS remote control. MEDIA.P GUIDE Accessories Viewing the Control Panel Viewing the Remote Control Connecting to an Antenna Plug &... -
Page 4: Accessories
✎ Please make sure the following items are included with your LCD TV. If any items are missing, contact your dealer. ✎ The items’ colours and shapes may vary depending on the models. Remote Control & Batteries (AAA x 2) Owner’s Instructions See separate guide for installing the stand. -
Page 5: Viewing The Remote Control
I-II DUAL SUBT. Use these buttons in the Media Play and Anynet (� μ: Controls recording on Samsung recorders with the Anynet ✎ NOTE Use the remote control within 23 feet from the TV. Bright light may affect the performance of the remote control. -
Page 6: Connecting To An Antenna
When the TV is initially powered on, basic settings proceed automatically. ✎ Preset: Connecting the mains and antenna. Power Input When the TV is initially powered on, a sequence of on-screen prompts will assist in configuring basic settings. Press the POWERP button. -
Page 7: Connecting To An Av Device
Connections Using an HDMI / DVI Cable: HD connection (up to 1080p) Available devices: DVD, Blu-ray player, HD cable box, HD STB (Set-Top-Box) satellite receiver, cable box, satellite receiver (STB) Red White 26” 32” ✎ HDMI (DVI) IN 1, 2, 3 / PC/DVI AUDIO IN When using an HDMI/DVI cable connection, you must use the connection, use a DVI to HDMI cable or DVI-HDMI (DVI to HDMI) adapter for video connection and the jacks for audio. -
Page 8: Connecting To An Audio Device
Using an Optical or Audio Cable Connection Available devices: digital audio system, amplifier, DVD home theatre ✎ The product colour and shape may vary depending on the model. ✎ DIGITAL AUDIO OUT (OPTICAL) When a digital audio system is connected to the of both the TV and the system. -
Page 9: Changing The Input Source
P.SIZE S.MODE Changing the Input Source Source List Use to select TV or other external input sources such as DVD / Blu-ray players / cable box / STB satellite receiver connected to the TV. TV / Ext. / AV / Component / PC / ■... -
Page 10: Using The Info Button (Now & Next Guide)
P.SIZE Using the INFO button (Now & Next guide) The display identifies the current channel POWER and the status of certain audio-video settings. The Now & Next guide shows daily TV programme information for each channel according to the broadcasting time. ◄, ►... -
Page 11: Channel Manager
Channel Manager Delete or set favourites channels and use the programme guide for digital broadcasts. Select a channel in the Channels, My Channels or Scheduled screen. 1futech * 24ore.tv abc1 Radio BBC World bid-up.tv Data/Other Boonerang Analogue Cartoon Nwk Class News \ Coming Soon Discovery Antena... -
Page 12: Channel Menu
Channel Menu Retuning channels ¦ Antenna (Air / Cable) Before your television can begin memorizing the available channels, you must specify the type of signal source that is connected to the TV (i.e. an Air or a Cable system). Country The PIN input screen appears. -
Page 13: Picture Menu
Channel Manager Option Menu (in Channel Manager) Set each channel using the Channel Manager menu options (Lock / Unlock, Timer Viewing, Sort, Delete, Select All / Deselect All). Option menu items may differ depending on the channel status. 1. Select a channel and press the 2. -
Page 14: Economical Solutions
Economical Solutions ¦ ECO Solution Energy Saving (Off / Low / Medium / High / Picture ■ Off / Auto) : Adjust the brightness of the TV in order to reduce power consumption. If you select Picture Off, the screen is turned off, but the sound remains on. - Page 15 Size : Your cable box/satellite receiver ■ may have its own set of screen sizes as well. However, we highly recommend you use 16:9 mode most of the time. Auto Wide: Automatically adjusts the picture size to the 16:9 aspect ratio. 16:9 : Adjusts the picture size to 16:9 for DVDs or wide broadcasting.
-
Page 16: Sound Menu
PC may differ in which case the same basic set-up information will almost always be applied. (If not, contact your computer manufacturer or Samsung Dealer.) 1. Click on “Control Panel” on the Windows start menu. -
Page 17: Audio Description
DUAL Audio Description (not available in all locations) GUIDE SUBT. (digital channels only) This function handles the Audio Stream for the AD (Audio Description) which is sent along with the Main audio from the broadcaster. Audio Description (Off / On) ■... -
Page 18: Setup Menu
Setup Menu Setting the Time ¦ Time Clock : Setting the clock is for using various timer ■ features of the TV. The current time will appear every time you press button. INFO ✎ If you disconnect the power cord, you have to set the clock again. -
Page 19: Other Features
Change PIN : Change your personal ID number required ■ to set up the TV. ✎ If you forget the PIN code, press the remote control buttons in the following sequence, which resets the PIN to “0-0-0-0”: POWER → 8 → 2 → 4 → MUTE POWER Other Features... -
Page 20: Support Menu
PIP mode, the Software Upgrade Software Upgrade can be performed via a broadcasting signal or by downloading the latest firmware from samsung.com to a USB memory device. Current Version the software already installed in the TV. ✎ Software is represented as “Year/Month/Day_Version”. -
Page 21: Contact Samsung
HD Connection Guide Refer to this information when connecting external devices to the TV. Contact Samsung View this information when your TV does not work properly or when you want to upgrade the software. You can find information regarding our call centres, and how to download products and software. -
Page 22: Connecting To A Pc
Using an HDMI/DVI Cable / a D-sub Cable R-AUDIO-L R-AUDIO-L Display Modes (D-Sub and HDMI/DVI Input) Optimal resolution is 1360 X 768 @ 60 Hz. Mode Resolution 640 x 350 720 x 400 640 x 480 832 x 624 640 x 480 800 x 600 VESA DMT 1024 x 768... -
Page 23: Media Play
Before connecting your device to the TV, please back up your files to prevent them from damage or loss of data. SAMSUNG is not responsible for any data file damage or data loss. Connect a USB HDD to the dedicated port, USB (HDD) port. -
Page 24: Screen Display
Screen Display ¦ Move to the desired file using the up/down/right/left buttons and then press the ENTERE or � (Play) button. The file is played. ✎ Supports the Device Mode and Contents Mode in Media Play homepage. Information: You can ascertain the selected file name and the number of files and page. - Page 25 Supported Video Formats File Extention Container Video Codec Divx 3.11 / 4.x / 5.1 / 6.0 *.avi *.mkv H.264 BP / MP / HP MPEG4 SP / ASP Divx 3.11 / 4.x / 5.1 / 6.0 *.asf H.264 BP / MP / HP MPEG4 SP / ASP *.wmv Window Media Video v9...
- Page 26 Playing movie continuously (Resume Play) If you exit the playing movie function, the movie can be played later from the point where it was stopped. 1. Select the movie file you want to play continuously by pressing the ◄ or ► button to select it from the file list section. 2.
-
Page 27: Playing The Multiple Files
Playing the multiple files ¦ Playing the selected video/music/photo files 1. Press the Yellow button in the file list to select the desired file. 2. Repeat the above operation to select multiple files. ✎ NOTE The ( c) mark appears to the left of the selected files. To cancel a selection, press the yellow button again. - Page 28 Videos/Music/Photos Play Option menu During playing a file, press the TOOLS Category You can move the other file directly. Title Repeat Mode You can play movie and music files repeatedly. Picture Size You can adjust the picture size to your preference. (Mode1 / Mode2 / Original) Picture Setting You can adjust the picture setting.
-
Page 29: Anynet
What is Anynet Anynet is a function that enables you to control all connected Samsung devices that support Anynet remote. The Anynet system can be used only with Samsung devices that have the Anynet device has this feature, check if there is an Anynet To connect to Home Theatre 1. -
Page 30: Setting Up Anynet
If you have selected external input mode by pressing the Make sure to switch to an Anynet Recording ¦ You can make a recording of a TV programme using a Samsung recorder. 1. Select Recording. ✎ When there are more than two recording devices When multiple recording devices are connected, the recording devices are listed. -
Page 31: Listening Through A Receiver
Listening through a Receiver ¦ You can listen to sound through a receiver (i.e Home Theatre) instead of the TV speaker. 1. Select Receiver and set to On. 2. Press the EXIT button to exit. ✎ If your receiver supports audio only, it may not appear in the device list. ✎... -
Page 32: Analogue Channel Teletext Feature
The index page of the Teletext service gives you information on how to use the service. For Teletext information to be displayed correctly, channel reception must be stable. Otherwise, information may be missing or some pages may not be displayed. ✎... -
Page 33: Installing The Wall Mount
For detailed information on installing the wall mount, see the instructions provided with the Wall Mount items. Contact a technician for assistance when installing the wall mount bracket. Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you elect to install the TV on your own. -
Page 34: Anti-Theft Kensington Lock
The Kensington Lock is a device used to physically fix the system when using it in a public place. The appearance and locking method may differ from the illustration depending on the manufacturer. Refer to the manual provided with the Kensington Lock for proper use. ✎... -
Page 35: Troubleshooting
If you have any questions about the TV, first refer to this list. If none of these troubleshooting tips apply, please visit “www.samsung.com,” then click on Support, or contact the call centre listed on the back-cover of this manual. Issues... - Page 36 Try pointing the remote directly at the TV from 5~6 feet away. • Programme the Cable/Set top box remote control to operate the TV. Refer to the Cable/Set user manual for the SAMSUNG TV code. • Check the supported resolution of the TV, and adjust the external device’s output resolution accordingly.
- Page 37 Issues Solutions and Explanations Your settings are lost after 30 minutes or • every time the TV is turned off. You have intermittent loss of audio or • video. • You see small particles when you look • closely at the edge of the frame of the TV. The PIP menu is not available.
-
Page 38: Specifications
Panel native Environmental Considerations Operating Temperature Operating Humidity Storage Temperature Storage Humidity TV System Colour/video system Sound System HDMI IN 1 ~ 3 Stand Swivel (Left / Right) Model Name Screen Size (Diagonal) Sound Output Dimensions (WxDxH) Body With stand Weight Body With Stand... -
Page 39: Index
Amplify Antenna Anynet Audio Out 8, 29 Auto Adjustment Auto Volume Background Music Balance L/R Basic View Batteries Black Tone Blanking Bracket Brightness Change PIN 6, 19 Channel Manager Clock Colour Tone Component Connecting to a PC Connecting to an Audio Device Digital Audio Out 8, 29 DivX... - Page 40 Warning! Important Safety Instructions Please read the appropriate section that corresponds to the marking on your Samsung product before attempting to install the product. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
-
Page 41: Warranty Card
2. Samsung’s obligations are limited to the repair or, at its discretion, replacement of the product or the defective part. 3. Warranty repairs must be carried out by Authorised Samsung Dealers or Authorised Service Centres. - Page 42 This page is intention- ally left blank.
