Emprex 9089URF Quick Installation Manual

無線鍵盤滑鼠 Wireless Keyboard & Mouse & USB Dongle
Important Information
®
- For Windows 2000 operating system, please go to
"KeyMaestro Input Device Driver" to have the Multimedia Player functions.
-
For Windows® XP and Windows Vista® operating systems, you could use the keyboard immediately after plugging the
keyboard connector into the PC. If you want to enjoy the full functionality of the keyboard, please visit our website at
http://www.emprex.com/ to download and install the "KeyMaestro Input Device Driver." Once the driver has been
installed, these hot keys are reprogrammable. They can be configured as a string, a combination key, a web site, an
existing file, or a function that the driver pre-defines for you.
Hardware Installation
1. PC Notebook: Plug the receiver connector directly into your available USB port on
PC.
2. Make sure the batteries of the keyboard and mouse are installed correctly. Please
follow the polarity signs in the battery compartment.
3. Please make sure the slide switch on the back of the mouse is switched to "on"
before using the mouse. When not in use, please turn the power switch to "off" for
power saving.
4. After you plug the receiver USB connector into your PC USB port, please hold the
keyboard close to the receiver within 1M and press any key to pair ID.
Pairing Procedure
You could use the keyboard immediately after plugging the receiver into PC. If it can' t
work, please follow the steps below to process ID setting of the Wireless Kit.
The pairing button locates on the top of the receiver with a LED under to show the
pairing or data reception status.
The ID-recognition function helps to protect against interference from other RF
products in the same environment. Remember to pair ID when other RF products
affect your keyboard kit.
1. Press the pairing/connect button on top of the receiver first. Receiver LED
indicator will blink slowly to indicate it' s ready to receive keyboard/mouse pairing
information.
2. Next, press the pairing/connect button on the bottom of the mouse once.
3. Then press the pairing/connect button on top of the receiver again.
4. Finally, press the pairing/connect button on the bottom of the keyboard once.
Receiver LED indicator flashes 3 times rapidly as its ID paired with this keyboard and
mouse.
Note:
- Each procedure should be completed within 60 seconds.
- Make sure your PC is on and running when doing the pairing procedure.
- You don' t have to pair ID again after changing batteries.
- The keyboard can operate freely up to a radius of about 1.5m and the mouse can
operate freely up to 1m from the receiver.
-
Keyboard battery life is up to 18 months and mouse battery life is up to 3 months. It
depends on the intensity of usage.
System Requirements
w Available USB port
w CD-ROM drive (for CD and Video operation)
w Standard sound card (for CD and Video operation)
w Microsoft® Internet Explorer 5.0 or later version (for the Internet keys)
w
Microsoft® Windows® 2000, Windows® XP or Windows Vista® operating system
Driver Installation
n
USB Device Driver
The USB device driver is included with your Windows operating system.
During the initial installation of the keyboard USB device, the system will automatically detect that a new hardware device
has been added and will bring up the "Add New Hardware Wizard" dialogue box. Follow the Wizard's USB driver installation
steps. Once this installation step is completed, the basic functions of the USB device will work under the operating system.
The additional functions are provided only after the KeyMaestro driver is installed.
n
KeyMaestro Input Device Driver
1. After you download the driver, please find the "SetupKey.exe" in the directory and double-click this file.
2. Follow the on-screen instructions to install the driver.
3.
The driver icon will show at the bottom right of the Windows system tray when the driver is loaded.
9089URF / EMPREX
9089URF Quick Installation Guide
http://www.emprex.com/ website to download and install the
Front view of Back view of
USB connector USB connector
Pairing/connect button on top
of the receiver
(With a LED indicator under
the pairing/ connect button)
Power Switch
ID pairing button /
connect button
Pairing/ connect button on the
bottom of the mouse
Pairing/connect button on the
bottom of the keyboard
English
