Emprex 9019URF Quick Installation Manual

9019URF Keyboard with Mouse & Dual Mode Joystick Mouse

Hardware Installation

1. Plug in the receiver connector into your
available USB port on PC.
2. Take the keyboard and make sure the
batteries on the back are installed correctly.
(Follow the polarity signs in the battery
compartment.)
ID Button Setting
This ID-recognition function helps to protect
against interference from other RF keyboards in
the same environment. Remember to set the ID
when you replace the batteries or your keyboard
kits do not work properly.
The word CONNECT labels the ID button on
each unit.
The LED under ID button of receiver shows
connecting condition.
1. Your PC must be on to change the ID setting.
2. Press ID button on the top of the receiver
once.
3. Press ID button on the upper-left corner on
the keyboard front side once.
Attention: The whole procedure should be
completed within 1 minute.

Software Installation

In order to take advantage of the special button functionality of the keyboard you will have to
install the keyboard driver which is located on the driver disk included in the box.
1. Remove any existing keyboard software from the computer.
2. Insert the driver CD in your computers, and run "SetupKey.exe".
3. Follow the on screen instructions to finish the installation procedure. The driver default will
be installed at C:\Program Files\KMaestro.
The driver icon will show on Windows system tray when all setup procedures are finished,
the operating system need not to be restarted.
Quick Installation Guide
Front View of USB Connector
ID Button(LED)
Back View of USB Connector
Plugging in USB
Connector
1.5V 2pcs
( - )
(+)
Bottom view of
9019URF
keyboard
ID Button on Receiver
(With a LED under the ID button)
Mouse Left Button
Mouse Right Button
ID Button
Scroll Down
Scroll Up
Sticker
Mouse Middle Button
Front View of 9019URF Keyboard
9019URF QG 英
3100506040 v1.0
