Microwave convection/grill oven

Advertisement

Quick Links

MICROWAVE
CONVECTION/GRILL OVEN
OWNER'S
MANUAL
KOC-9U0TSL
Before operating this oven, please read
this manual completely.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KOC-9U0TSL and is the answer not in the manual?

Questions and answers

Summary of Contents for DAEWOO ELECTRONICS KOC-9U0TSL

  • Page 1 MICROWAVE CONVECTION/GRILL OVEN KOC-9U0TSL OWNER’S MANUAL Before operating this oven, please read this manual completely.
  • Page 2: Table Of Contents

    PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. (b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces.
  • Page 3: Installation And Earthing Instructions

    INSTALLATION AND EARTHING INSTRUCTIONS How to examine your microwave oven after unpacking. number BS 1362. We recommend the use of good quality plugs and wall sockets Unpack oven, remove all packing material, and examine the that can be switched off when the machine is not in use. oven for any damage such as dents, broken door, latches or IMPORTANT-The wires in the mains lead fitted to this appliance cracks in the door.
  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE When using electrical apliances, basic safety precautions should be followed, including the following: WARNING-To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave energy: 11.
  • Page 5 General Use Listed below are, as with all appliances, certain rules to follow and safeguards to assure top performance from this oven: 11. Do not use the oven for any reason other than food preparation, such as for drying clothes, paper, or any 15.
  • Page 6: Which Utensils Can Be Used In The Oven

    TO AVOID EXPLOSION AND SUDDEN BOILIING 1. Eggs Never cook eggs in their shells. Steam will build up inside WARNING the shell during cooking and the egg will explode. If you want to cook or reheat eggs which have not been Liquids, such as water, coffee, or tea are able to be broken up by scrambling or mixing, you must always overheated beyond the boiling point without appearing to be...
  • Page 7: Cooking Instructions

    COOKING INSTRUCTIONS Only use utensils that are suitable for use in microwave ovens. To cook food in the microwave oven, the microwaves must be able to penetrate the food, without being reflected or absorbed by the dish used. Care must therefore be taken choosing the utensil. If the utensil is marked microwave-safe, you do not need to worry. The following table lists various of utensil and indicates whether and how they should be used in a microwave oven.
  • Page 8: Control Panel

    CONTROL PANEL 1 Display : Cooking time, power level, program indicators and present time are displayed. MW ( ): When blinking, the oven is operating in MICROWAVE COOK mode. Grill ( ): When blinking, the oven is operating in GRILL mode. Combi ( ): When blinking, the oven is operating in COMBI mode.
  • Page 9: Accessories

    ACCESSORIES This oven comes with several accessories. They can be used in various ways to facilitate cooking. 1 Metal Tray - Place food or appropriate cookware directly on the metal tray and ensure it is correctly placed on the coupler. when using the oven for convection cooking, combination cooking, auto cooking or grill cooking.
  • Page 10: Before Operation

    BEFORE OPERATION SETTING THE CLOCK When your oven is plugged in, the display will show “ :0” and a tone will sound. If the AC power goes off and comes back on, the display will show “:0”. Your oven has a multiple(12hr/24hr) clock system. To set the clock, follow the procedure below. Grill Example : To set 5:30 in a 24hr clock system.
  • Page 11: Child Lock And Power Save Mode

    CHILD LOCK AND POWER SAVE MODE Grill Child lock : The Child Lock function helps to prevent accidents from children operating the oven without being monitored by the parents. Power save mode : This function is used for saving energy. Combi Convection To set child lock...
  • Page 12: Operation

    OPERATION Tips : Please read this OPERATION section for the proper safety information and the operating instructions before use of the oven. Prior to setting the controls, place one cup of water in the oven, in a heat-proof glass measuring cup, for testing purposes. The oven could be damaged if operate the oven in microwave mode without anything in the cavity.
  • Page 13: Grill Cooking

    GRILL COOKING The Grill enables you to heat and make food to turn brown quickly without using microwave. Grill Combi Convection 1. Press the Grill button once. The GRILL indicator ( )lights. This is the Grill High mode. “gr-H” shows in display. Press Grill button twice.
  • Page 14: Convection Cooking(With Pre-Heat)

    CONVECTION COOKING(With pre-heat) For convection cooking, it is recommended that you preheat the oven to the appropriate temperature (except for the 40C that displays only) before placing food in the oven. The maximum preheating time is 30 minutes. If cooking is not started immediately after preheating, the convection indicator will continue to flash and the preheated oven temperature will be displayed.
  • Page 15: Convection Cooking(Traditional Cooking)

    CONVECTION COOKING(Traditional cooking) The convection mode enables you to cook food in the same way as in a traditional oven. Microwaves are not used. Grill Always use oven gloves when touching the utensils in the oven, as they will be very hot. Combi Convection 1.
  • Page 16: Combination Cooking

    COMBINATION COOKING (Microwave + Upper Grill + Lower Grill) This function allows you to combine convection operation with microwave to produce traditional baked or roasted results in less time. Always use microwave-safe and oven-proof cookware. Glass or ceramic dishes are ideal as they allow the microwaves to penetrate the food evenly.
  • Page 17: Weight Defrost Mode

    (1) WEIGHT DEFROST MODE Weight Defrost automatically sets the defrosting times and power levels to give even defrosting results for frozen food. During the defrosting process the oven will beep to remind you to check the food. When the oven beeps, open the door, turn the frozen Grill food over and close the door, and press the START/SPEEDY COOK button again.
  • Page 18: Auto Cook

    AUTO COOK This function allows you to simply and automatically cook a range of popular foods. Grill Always use oven gloves when touching the utensils in the oven. Combi Convection 1. Press the Auto Cook button once. The Auto Cook indicator ( ) lights.
  • Page 19: Speedy Cook

    SPEEDY COOK Grill The Speedy Cook function allows the oven to cook immediately on full power. The Speedy Cook function has been pre-programmed to increase the cooking time in increments of 30 seconds up to the maximum time of 5 minutes. Combi Convection 1.
  • Page 20: Steam Cleaning

    STEAM CLEANING This function is for cleaning the oven by steam and heating element. Before cleaning, put 150~200cc water in a mug cup and place the mug cup in the centre of the tray. 1. Press the STEAM CLEANING button. The STEAM indicator ( ) lights.
  • Page 21: General Guide Lines

    GENERAL GUIDE LINES Covering food helps: Since microwave cooking to some extent is different from traditional cooking, the following general guidelines should be considered • To reduce spattering whenever you use your microwave oven • To shorten cooking times • To retain food moisture If the food is undercooked All covering, which will allow microwaves to pass through are Check if:...
  • Page 22: Keep The Oven Clean

    KEEP THE OVEN CLEAN DOOR While the oven door is still warm, any spatters or food soils should be wiped off with a damp sudsy cloth or sponge. Rinse with water and wipe dry with a cloth. If steam or condensation appears around this area, wipe with a cloth.
  • Page 23: Before Calling For Service

    BEFORE CALLING FOR SERVICE You can often correct operating problems yourself. Note: If your microwave/grill oven fails to work properly, It is quite normal for steam to be emitted around the door locate the operating problem in the chart below and during the cooking cycle.
  • Page 24: Questions And Answers

    QUESTIONS AND ANSWERS * Q : Will the microwave oven be damaged if it operates * Q : What does “standing time” mean? while empty? A : “Standing time” means that food should be removed A : Operating the oven empty in MW mode can cause from the oven and covered for additional time to allow it damage to the oven.
  • Page 25: Specifications

    SPECIFICATIONS Power supply 230V~, 50Hz Power consumption 1500W Microwave Output power 900W (IEC 705) Frequency 2,450MHz Grill power consumption 1950W Convection power consumption 1950W Combination heating power consumption 1950W Outside Dimension(WXDXH) 546(21.5)x438(17.2)x329(13)mm (inch) Cavity Dimensions(WXDXH) 350(13.8)x367(14.4)x240(9.4)mm (inch) Net Weight Approx. 18.2Kg (40.1 lbs.) Timer 60 minutes Select function...
