Summary of Contents for OV Solutions CT-213H-BTM32
- Page 1 Digital Detection Module Quick Guide V1.03...
-
Page 2: Packing List
Packing List Name Unit Digital detection module Screw kit (There are two types and the actual screw kit shall prevail. Screw kit 1: two M4x16 pan head screws, two M4 nuts, and two M3x6 pan head screws; screw kit 2: two M3x6 pan head screws) Special statement Product Overview The digital detection module is a non-contact device for human body temperature... - Page 3 protection provided by the equipment may be impaired. 2 Appearance and Size Appearances and sizes vary with device type. The actual product shall prevail. Appearance and Size 1 Appearance and Size 2 3 Structure and Cable Structures and cables vary with device type. The actual product shall prevail. Structure and Cable 1...
- Page 4 Temperature sensor 4-pin cable Structure and Cable 2 Temperature Indicator sensor 4-pin cable 4 Bracket Introduction When the digital detection module is used in combination with a face recognition access control terminal or face recognition terminal, a bracket (purchased...
-
Page 5: Device Installation
separately) is required for installation. The bracket is delivered with four M4x11 screws and two M4 wing nuts. Hole description Hole for fixing a 7-inch face recognition access control terminal Hole for fixing a 10-inch face recognition access control terminal Hole for fixing a 7-inch face recognition terminal Device Installation... - Page 6 Diameter Selection for Extension Power Cables The device is powered by DC 12V/2A and the lower limit of the operating voltage is DC 9V (12V–25%). 0.8mm 1.25mm 1.63mm Wire Diameter (mm) (20 AWG) (18 AWG) (16 AWG) (14 AWG) Transmission Distance (m) 2 Wiring description The figure below shows the wiring between the digital detection module and...
-
Page 7: Installation Steps
Installation Steps NOTE! Before installing the digital detection module, connect the cables between the module and a face recognition access control terminal/face recognition terminal by referring to section "Device Wiring" and sections related to the wiring in the quick guide of the face recognition access control terminal/face recognition terminal. 1 Wall mount The figure below shows the process of installing the digital detection module on a wall when the module is to be used in combination with a face recognition access... - Page 8 M4 wing nuts The figure below shows the process of installing the digital temperature measurement module on a standing pole when the module is to be used in combination with a face recognition terminal. 1. Remove the black panel. 2. Remove the four screws on the back and two screws at the bottom, and...
-
Page 9: Device Startup
Device Startup 1 Device power-on After the device is installed correctly, connect the power adapter (provided separately) to the mains supply to start the device. 2 Device configuration Local configuration When the digital detection module is used in combination with a face recognition access control terminal, you can enable the temperature measurement function on the Authentication Scene interface of the face recognition access control terminal. - Page 10 Configuration on the Web interface You can also log in to the Web interface of the terminal and choose Setup > Intelligent > Advanced Setting to enable the temperature measurement function. 3 Device operations When the temperature needs to be measured, a person needs to get close to occupy the human shape on the screen and aim the forehead center at the red circle.
- Page 11 FAQs Failure/ Solution Symptom What 1. Check whether the measurement distance is proper. The should I do recommended measurement distance is 20–30cm for single if some point series and 50–70cm for matrix series. people's temperatu 2. Check whether the people get close to occupy the human shape res cannot on the screen and aim the forehead center at the red circle.
- Page 12 Failure/ Solution Symptom What 1. Check whether a person has behaviors that affect the body should I do temperature, for example, getting out of a hot car, doing when a strenuous exercise, or carrying hot drinks and hot food. If yes, high the person needs to stay in the measurement area calmly and temperatu...
- Page 13 About This Manual ⚫ This manual is intended for multiple product models, and the photos, illustrations, descriptions, etc, in this manual may be different from the actual appearances, functions, features, etc, of the product. ⚫ This manual is intended for multiple software versions, and the illustrations and descriptions in this manual may be different from the actual GUI and functions of the software.
- Page 14 The following are necessary measures for the network security of your device: ⚫ Change default password and set strong password: You are strongly recommended to change the default password after your first login and set a strong password of at least nine characters including all three elements: digits, letters and special characters.
- Page 15 ⚫ Store or use the device in a proper environment that meets environmental requirements, including and not limited to, temperature, humidity, dust, corrosive gases, electromagnetic radiation, etc. ⚫ Make sure the device is securely installed or placed on a flat surface to prevent falling. ⚫...
- Page 16 ➢ Remplacer la batterie par un type incorrect; ➢ Disposer d’une batterie dans le feu ou un four chaud, écraser mécaniquement ou couper la batterie; ⚫ Disposer la batterie utilisée conformément à vos règlements locaux ou aux instructions du fabricant de la batterie. Regulatory Compliance FCC Statements This device complies with Part 15 of the FCC Rules.
