Summary of Contents for LG W2443T
- Page 1 User’s Guide W2443T W2443S ake sure to read the Important Precautions before using the product. Keep the User's Guide(CD) in an accessible place for future reference. ee the label attached on the product and give the information to your dealer when you ask for service.
-
Page 2: Important Precautions
Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential electrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing. - Page 3 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.
- Page 4 Important Precautions NOTE THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTRERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT.SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT. NOTE This epuipment has been tested and found to comply with the limits for a class B digital device,pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment generates,uses and can radiate radio frequency...
- Page 5 Important Precautions On Cleaning Unplug the display before cleaning the face of the display screen. Use a slightly damp (not wet) cloth. Do not use an aerosol directly on the display screen because over-spraying may cause electrical shock. When cleaning the product, unplug the power cord and scrub gently with a soft cloth to prevent scratching.
-
Page 6: Connecting The Display
Connecting the Display Connecting the stand Place the monitor with its front facing downward on a soft cloth. Assemble the stand base into stand body in the correct direction as shown in the picture, then tighten the screw which is attached to the stand base. Stand Base Screw Stand Body... -
Page 7: Positioning Your Display
Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Positioning your display Adjust the position of the panel in various ways for maximum comfort. Tilt Range: -5˚~15˚... -
Page 8: Connecting With The Pc
Connecting the Display W2443T Connecting with the PC Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connect signal input cable and power cord in order, then tighten the screw of the signal cable. - Page 9 Connecting the Display W2443S Connecting with the PC Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connect signal input cable and power cord in order, then tighten the screw of the signal cable.
-
Page 10: Control Panel Functions
Control Panel Functions Front Panel Controls W2443T W2443S Button Use this button to enter 4:3 IN WIDE, PHOTO EFFECT menus. For more information, refer to page 12. MENU Button Use this button to enter or exit the On Screen Display. -
Page 11: Power Indicator
When two input signals are connected, you can select the input signal (D-SUB/DVI) you want. When only one signal (SOURCE Hot key) is connected, it is automatically detected. The default setting is D-Sub. (Only W2443T ) AUTO/SET Use this button to enter a selection in the On Screen Display. -
Page 12: On Screen Display (Osd) Control Adjustment
On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls. -
Page 13: On Screen Display(Osd) Selection And Adjustment
On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. : Analog Input only Main menu Sub-menu Description 4:3 IN WIDE To adjust the image size NORMAL PHOTO To adjust the screen color mode EFFECT GAUSSIAN BLUR SEPIA... - Page 14 On Screen Display(OSD) Selection and Adjustment The OSD screen will appear when you press the button on the front of the monitor. MENU : Exit : Move SET : Select Main menu Description To select the image size of the screen. 4:3 IN WIDE WIDE •...
- Page 15 On Screen Display(OSD) Selection and Adjustment The OSD screen will appear when you press the button on the front of the monitor. Menu Name Icons Sub-menu Name F-ENGINE Active state Inactive state When the F-ENGINE is executed, two kinds of tones are displayed as shown in the image.
- Page 16 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. Press the MENU Button, then the main menu of the OSD appears.
- Page 17 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description PICTURE To adjust the brightness of the screen. BRIGHTNESS To adjust the contrast of the screen. CONTRAST Set your own gamma value. : -50 / 0 / 50 GAMMA On the monitor, high gamma values display whitish images and low gamma values display blackish images.
- Page 18 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description TRACKING HORIZONTAL To move image left and right. To move image up and down. VERTICAL To minimize any vertical bars or CLOCK stripes visible on the screen background. The horizontal screen size will also change.
- Page 19 Activate this function when white and black colors are present in the W2443T screen. Use this function to set the power POWER indicator on the front side of the monitor INDICATOR to ON or OFF.
-
Page 20: Troubleshooting
Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the • Check and see if the power cord is connected display connected? properly to the power outlet. Is the power indicator •... -
Page 21: Display Image Is Incorrect
Troubleshooting Display image is incorrect Display Position is • Press the AUTO/SET button to automatically incorrect. adjust your display image to the ideal setting. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display. -
Page 22: Have You Installed The Display Driver
Troubleshooting Display image is incorrect The screen color is • Check if the signal cable is properly connected mono or abnormal. and use a screwdriver to fasten if necessary. • Make sure the video card is properly inserted in the slot. •... -
Page 23: Specifications
Specifications W2443T Display 23.6 inches (59.9 cm) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 59.9 cm 0.266 x 0.266 mm (Pixel pitch) Horizontal Freq. 30 - 83 kHz (Automatic) Sync Input Vertical Freq. 56 - 75 Hz (Automatic) Input Form Separate Sync. - Page 24 Specifications W2443S Display 23.6 inches (59.9 cm) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 59.9 cm 0.266 x 0.266 mm (Pixel pitch) Horizontal Freq. 30 - 83 kHz (Automatic) Sync Input Vertical Freq. 56 - 75 Hz (Automatic) Input Form Separate Sync.
-
Page 25: Preset Modes (Resolution)
Specifications Preset Modes (Resolution) Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 720 x 400 31.468 640 x 480 31.469 640 x 480 37.500 VESA 800 x 600 37.879 800 x 600 VESA 46.875 1024 x 768 48.363 VESA 1024 x 768 60.123 VESA... -
Page 26: Installing The Wall Mount Plate
Installing the Wall mount plate This monitor satisfies the specifications of the Wall mount plate or the interchange device. Place the monitor face down on the cushion or soft cloth. Loosen the screw which is attached to the stand base, then take off the stand base from stand body. - Page 27 Digitally yours...
