Summary of Contents for LG C19JE
- Page 1 FCC ID : BEJC19JE APPENDIX F : USER’S MANUAL...
-
Page 2: Canadian Doc Notice
Regulatory Information FCC Compliance Statement CE Conformity Notice (for Europe) This equipment has been tested and found to comply within Products with the “ C E ” Marking comply with the EMC the limits of a Class B digital device pursuant to Part 15 of Directive(89/336/EEC) and LOW VOLTAGE Directive the FCC Rules. - Page 3 Regulatory Information cont. scheme, which provides for international environmental Lead can be found in picture tubes, display screens, solder, labelling of personal computers. The labelling scheme was and capacitors. Lead damages the nervous system and in developed as a joint effort by the TCO (The Swedish higher doses causes lead poisoning.
- Page 4 Regulatory Information cont. TCO99 The energy requirements include a demand that the computer and/or display, after a certain period of inactivity, shall reduce its power consumption to a lower level in one or more stages. The length of time to reactivate the computer shall be reasonable for Congratulations! the user.
- Page 5 (U.S.A only) is a set of power-saving guidelines NERGY issued by the U.S. Environmental Protection Agency(EPA). As an ENERGY STAR Partner LG Electronics U.S.A.,Inc. has determined that this product meets the ENERGY STAR guidelines for energy efficiency. EPA POLLUTION PREVENTER...
-
Page 6: Important Precautions
Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential eletrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this monitor, observe the following basic rules for its installation, use, and servicing. - Page 7 Important Precautions To Prevent Fire or Hazards: Always turn the monitor OFF if you leave the room for more than a short period of time. Never leave the monitor ON when leaving the house. Keep children from dropping or pushing objects into the monitor's cabinet openings.
-
Page 8: Connecting The Monitor
Connecting the Monitor Before setting up the monitor, ensure that the power is turned off to the monitor, computer system, and other attached devices. Carefully set the monitor face-down with the underside facing you. Connecting the Tilt/Swivel stand Align the hooks on the tilt/swivel stand with the matching slots in the base of the monitor. -
Page 9: Using The Computer
Connecting the Monitor Using the Computer Connect the signal cable. When mated, tighten the thumbscrews to secure the connection. Connect the power cord into a properly power outlet that is easily accessible and close to the monitor. NOTE This is a simplified representation of the rear view. This rear view represents a general model;... -
Page 10: Control Panel Functions
Control Panel Functions Front Panel Controls MENU SELECT Control Function Power Button Use this button to turn the monitor on or off. This Indicator lights up green when the monitor Power (DPMS) operates normally. If the monitor is in DPM Indicator (Energy Saving) mode, this indicator color changes to amber. -
Page 11: On Screen Display (Osd) Control Adjustment
On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the monitor is quick and easy with the On Screen Display Control system. A short example is quick and easy given below to familiarize you with the use of the controls. -
Page 12: On Screen Display(Osd) Selection And Adjustment
On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Main menu Sub menu Reference To adjust the brightness and Brightness contrast of the screen Contrast BRIGHTNESS/ CONTRAST V Position To adjust the position of the screen H Position... -
Page 13: To Adjust The Brightness And Contrast Of The Screen
On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. NOTE The order of icons may differ depending on the model (A8~A11). -
Page 14: To Adjust The Size Of The Screen
On Screen Display(OSD) Selection and Adjustment To adjust the size of the screen OSD Adjust Description Vertical Size To adjust image height. Horizontal Size To adjust image width. To adjust the shape of the screen OSD Adjust Description Tilt To correct image rotation. Side Pincushion To correct a concave or convex bowing of the image. -
Page 15: To Customize The Color Of The Screen
On Screen Display(OSD) Selection and Adjustment To customize the color of the screen OSD Adjust Description PRESET 6500K/ 9300K Select the screen color. • 6500K: Slightly reddish white. • 9300K: Slightly bluish white. Select the screen temperature which you TEMP prefer among reddish or bluish or any color in between. -
Page 16: To Improve The Clarity And Stability Of The Screen
On Screen Display(OSD) Selection and Adjustment To improve the clarity and stability of the screen OSD Adjust Description DEGAUSS To manually demagnetize the screen to avoid showing incorrect images or colors. RECALL You can use this function to reload the modified parameters for screen display operation, as specified by the user after purchase: Position, Size, Side Pincushion,... -
Page 17: Troubleshooting
Troubleshooting Check the following before calling for service. No image appears Is the power cord of the Check and see if the power cord is connected properly to monitor connected? the power outlet. Is the power indicator light Press the Power button. Is the power on and the Adjust the brightness and the contrast. - Page 18 Troubleshooting The screen color is not normal. Do you see basic Set the color depth to 256 colors or higher: use ' C ontrol discoloration (16 colors)? Panel' ' D isplay' ' S ettings' ' C olor Palette' Is the screen color unstable Check the connection of the signal cable.
-
Page 19: Specifications
Specifications Picture Tube 19 inches (18.0 inches viewable) 90 degree deflection 0.26mm dot pitch ARAS(Anti-Reflective Anti-Static) coating Sync Input Horizontal Freq. 30 - 98kHz (Automatic) Vertical Freq. 50 - 160Hz (Automatic) Input Form Separate TTL, Positive/Negative CompositeTTL, Positive/Negative Signal Input 15 pin D-Sub Connector Video Input Input Form... -
Page 20: Preset Modes (Resolution)
Specifications Preset Modes (Resolution) Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) VESA 43.269 640 x 480 53.674 VESA 800 x 600 VESA 68.677 1024 x 768 91.146 VESA 1280 x 1024...
