TotalPond PF1200UV Manual

Pressurized filter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
REMINDER
CALL 1-888-412-6001
BEFORE RETURNING TO STORE.
PACKAGE CONTENTS
Part
A
Tank with UV clarifier
B
C
D
E
Bio media balls
F
G
H
I
J
K
L
WARNINGS AND CAUTIONS
WARNING
WARNING – Improper connection of the appliance-grounding conductor can result in a risk of electric
•
shock. Check with a qualified electrician or service representative if you are in doubt whether the
appliance is properly grounded. Do not modify the plug provided with the appliance; if it will not fit the
outlet, have a proper outlet installed by a qualified technician.
Do not operate any appliance if it has a damaged cord or plug, or if it is malfunctioning or if it is
•
damaged in any manner.
Always unplug the appliance from the outlet before putting on or taking off parts, before cleaning or
•
when not in use.
Connect only to a circuit that is protected by a ground-fault circuit-interrupter (GFCI).
•
Risk of Electric Shock - Do not use the UV filter if the quartz tubing around the lamp is broken.
•
Immediately unplug and seek an authorized repair service or discard the unit.
GROUNDING INSTRUCTIONS – This appliance must be grounded. In the event of a malfunction or
•
breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for
electric current. This appliance is equipped with a cord having an appliance-grounding conductor and a
Pressurized Filter
Up to 1200 gallons
Description
O-ring
Cover
Lid
Coarse filter
Fine filter
Adapter
Gasket
Locking ring
Small adapter
Small gasket
Questions, problems, missing parts? Before returning
to your retailer, call our customer service department at
1-888-412-6001, 8 a.m.-6 p.m., EST, Monday-Friday, or
email us at customercare@totalpond.com. Or visit our
website www.totalpond.com.
Quantity
1
D
1
1
1
C
12
1
1
B
2
2
2
1
1
1
52236 / PF1200UV
ITEM #
A
H
I
J
K
E
F
G
H
I
J
L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PF1200UV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TotalPond PF1200UV

Summary of Contents for TotalPond PF1200UV

  • Page 1 Questions, problems, missing parts? Before returning to your retailer, call our customer service department at CALL 1-888-412-6001 1-888-412-6001, 8 a.m.-6 p.m., EST, Monday-Friday, or BEFORE RETURNING TO STORE. email us at customercare@totalpond.com. Or visit our website www.totalpond.com. PACKAGE CONTENTS Part Description...

  • Page 2: Important Notes

    grounding plug. The plug must be plugged into an appropriate outlet that is installed and grounded in accordance with all local codes and ordinances. CAUTION UV light may cause irritation to the skin and/or eyes. Avoid exposure. • DANGER – ULTRAVIOLET RADIATION – Diconnect Power Before Replacing Lamp. •...
  • Page 3 ASSEMBLY INSTRUCTIONS 1. If using 3/4 in. ID tubing, proceed to step 2. If using 1 in. ID tubing, cut the adapter as shown using a hacksaw. Fig. 1 Cut ring Fig. 1 2. Assemble the locking ring, adapter and gasket. Fig.
  • Page 4 4. Place the fine filter pad inside the tank. Then place the coarse filter pad over the fine filter pad. Fig. 4 NOTE: The coarse filter pad is black. The fine filter pad is blue. Fig. 4 5. Connect the small adapter to the adapter using the locking ring. Be sure to place the gasket between adapter and tank, place the small gasket between the small adapter and adapter.
  • Page 5 8. Place the cover (with the o-ring attached) over the top of the tank. Fig. 8 Fig. 8 9. Screw the lid onto the top of the tank. Make sure that it is secure, or the filter will leak. Fig. 9 Fig.
  • Page 6 12. Connect a length of tube from the outlet of a pump to the inlet of the filter (upper hole). Connect a length of tubing from the outlet of the filter (lower hole) to a water feature. Fig. 12 NOTE: Pump and tubing is NOT INCLUDED. The adapter is compatible with 1 in.
  • Page 7 3. Carefully remove the old bulb by firmly pulling on the base. Lamp Carefully install the new bulb. Fig. 15 holder NEW Bulb OLD Bulb Fig. 15 4. Reinstall the lamp holder and locking ring. Fig. 16 NOTE: This clarifier has a safety feature that only allows the UV Locking light to turn on if the lamp holder is fully seated into the lamp ring...

  • Page 8: Important Note

    (blue) is a fine pad designed to trap smaller debris. Both pads should be removed and washed with clean water when they are visibly soiled. Filter pads should be replaced annually. Use TotalPond Replacement Filter item # RF13026. •...

  • Page 9: Replacement Parts List

    O-ring 1 Glass tube gasket Glass tube Glass tube locking nut O-ring 2 TotalPond replacement filters can be purchased at Home Depot, item #RF13026. TotalPond replacement UV bulbs is available by calling the customer service department, item #UVRB. Printed in China...

  • Page 10: Limited Warranty

    All TotalPond® electrical products are warranted to the user against defective material and workmanship, under normal working conditions for 1 year from the date of purchase. All TotalPond® liners are warranted to the user against defective workmanship, under normal working conditions for 20 years from the date of purchase.
