TotalPond MF13010 Manual

Mechanical filter box up to 500 gallons

Download this manual

PACKAGE CONTENTS

Part

Filter box bottom

Coarse filter pad

Bio media balls

PREPARATION

Before beginning assembly of product, make sure all parts are present. Compare parts with package

contents list and diagram above. If any part is missing or damaged, do not attempt to assemble, install or

operate the product. Contact customer service for replacement parts.

•

Estimated Assembly Time: 15 minutes

•

No tools required for assembly.

PRODUCT DESCRIPTION

The MF113010 is a general purpose, mechanical / biological filter system. It is designed to filter the water

and promote healthy bacteria that will provide a balanced environment in your pond. This filter is designed

to work with a water pump that can circulate a minimum of 200 gallons per hour. As a pre-filter, the

MF13010 reduces pond debris and particulate before they enter the pump and other pond accessories.

This pre-filtration reduces the clogging of your pump and accessories and minimizes the need for cleaning.

Mechanical Filter Box

Up to 500 gallons

Description

Filter box top

Fine filter pad

Questions, problems, missing parts? Before returning

to your retailer, call our customer service department at

1-888-412-6001, 8 a.m.-6 p.m., EST, Monday-Friday, or

email us at customercare@geoglobalpartners.com. Or

visit our website www.total-pond.com.

Quantity

ITEM # MF13010

Need help?

Do you have a question about the MF13010 and is the answer not in the manual?

Page 1 200 gallons per hour. As a pre-filter, the MF13010 reduces pond debris and particulate before they enter the pump and other pond accessories. This pre-filtration reduces the clogging of your pump and accessories and minimizes the need for cleaning.
Page 2 ASSEMBLY INSTRUCTIONS 1. Place your pump inside the filter box, close to the center. Make sure that the outlet points up. Route the cord through Pump the hole in the top corner of the filter box bottom. Fig. 1 NOTE: Pump is NOT INCLUDED. This filter is compatible with pump models MD11300, MD11500, DD11210 DD11330 and DD11560.
Page 3 NOTE: From here, a coupler or a diverter valve can be used. a. To flow water to the fountain head only, use the coupler. (Proceed to step 5) b. To flow water to the fountain head and a spitter, use the diverter. (Skip to step 8) 5.
Page 4 9. Connect the extension tubes to the diverter valve. Pay attention to the markings on the ends of the diverter valve. Extension tube The end with the “P” connects to the pump. The end with the “ ↑ ” points up, and connects to the fountain head. Fig. 9 Diverter valve NOTE: Tubes and diverter valve are NOT INCLUDED.
Page 5: Care And Maintenance
REPLACEMENT PARTS LIST For replacement parts, call our customer service department at 1-888-412-6001, 8 a.m.-6 p.m., EST, Monday-Friday. Part Description Filter box top Filter box bottom TotalPond replacement filters can be purchased at Home Depot, item #RF13021. Printed in China...
