- Page 1 GDS100/110 HDS100/110 3Gb/s, HD and SD down converter and synchronizer with optional audio shuffler Installation and Operation manual Committed.
- Page 2 TECHNICAL MANUAL GDS100/110 HDS100/110 Lange Wagenstraat 55 NL-5126 BB Gilze The Netherlands Phone: +31 161 850 450 Fax: +31 161 850 499 E-mail: Info@axon.tv Web: www.axon.tv...
- Page 3 ● NEVER operate this product in an explosive atmosphere. Warranty: Axon warrants their products according to the warranty policy as described in the general terms. That means that Axon Digital Design BV can only warrant the products as long as the serial numbers are not removed.
-
Page 4: Table Of Contents
Table of Contents Introduction to Synapse An Introduction to Synapse Local Control Panel Remote Control Capabilities Unpacking and Placement Unpacking Placing the card A Quick Start When Powering-up Changing settings and parameters Front Panel Control Example of changing parameters using front panel control Synapse Cortex Software Menu Structure Example The GDS100/110 Card... - Page 5 Timecode_Inp VITC_Ln_In VITC_Ln_Ctrl VITC_Ln_625 VITC_Ln_525 VITC_Ln_Dup ATC_Dem_Sel ATC_Emb_Sel Aux_TC_SRC AUX_Dem_Sel AUX_Emb_Sel Aux_VITC_Ln_In Aux_Ln_625 Aux_Ln_525 Aux_TC_DLY Ins_CtrlA Ins_Prst_ActA Ins_Prst_EditA #VI-InsertA #VI-DataA #WSS-InsertA #WSS-StndA #WSS-ExtndA #VI-DataA #S2016-InsertA #S2016-DataA #CC_Ena_A GainA R-GainA G-GainA B-GainA BlackA R-BlackA G-BlackA B-BlackA CVBS-Hue Audio-Bus-IO Audio_Ctrl Audio_Prst_act Audio_Prst_Edit #Audio-Dly-sInp1 #Audio-Dly-sInp2 #EmbA_Grp...
- Page 6 sInp2 sInp2_VI sInp2_WSS-Stnd sInp2_WSS-Extnd sInp2_S2016 sInp2_CRC_EDH sInp2-Map sInp3_WSS-Stnd sInp3_WSS-Extnd sInpCVBS IODelayA FunctionA Contact_Status GPIA GPIB GPIC OP47-Det-A WST-Det-A CC_Det_A SDI1DemFrmt01/02 ~ SDI1DemFrmt15/16 SDI2DemFrmt01/02 ~ SDI2DemFrmt15/16 IP_Addr0 MAC0 Events Menu Introduction What is the Goal of an event? Events Announcements Input_A Input_B Ref-Status Active_Out_A...
- Page 7 Statuses: GPO status Example 1: Two pools in binary mode Example 2: One pool in binary mode and one in priority mode Example 3: Two pools in priority mode GNU Public License version 2...
-
Page 8: Introduction To Synapse
Synapse High density, intuitive operation and high quality processing are key features of this system. Synapse offers a full range of converters and processing modules. Please visit the AXON Digital Design Website at www.axon.tv to obtain the latest information on our new products and updates. -
Page 9: Unpacking And Placement
Unpacking and Placement Unpacking The Axon Synapse card must be unpacked in an anti-static environment. Care must be taken NOT to touch components on the card – always handle the card carefully by the edges. The card must be stored and shipped in anti-static packaging. Ensuring that these precautions are followed will prevent premature failure from components mounted on the board. -
Page 10: A Quick Start
A Quick Start When Powering- On powering up the Synapse frame, the card set will use basic data and default initialisation settings. All LED’s will light during this process. After initialisation, several LED’s will remain lit – the exact number and configuration is dependant upon the number of inputs connected and the status of the inputs. -
Page 11: Example Of Changing Parameters Using Front Panel Control
Example of With the display as shown below changing parameters using front panel control RRC18 [Select Card] >S01=SFS10 Pressing the ► selects the SFS10 in frame slot 01. The display changes to indicate that the SFS10 has been selected. In this example the Settings menu item is indicated. -
Page 12: Synapse Cortex Software
Synapse Cortex can be used to change the settings of Synapse Synapse Cortex modules from a PC, either locally or remotely. The software enables Software communication based on TCP/IP between the Setup PC and Synapse frames/modules. Each Synapse frame is addressed through its rack controller’s unique IP address, giving access to each module, its menus and adjustment items. -
Page 13: The Gds100/110 Card
The GDS100/110 Card Introduction The GDS100/110 and HDS100/110 are low latency down converters with 16 channel audio transparency. The GDS100/110 is compatible with 270Mb/s, 1.5Gb/s and 3Gb/s for full 1080p/50 or 1080p/59.94 use. The HDS100/110 are compatible with SD-SDI (270Mb/s) and HD-SDI (1.5Gb/s) and can be future upgraded to 3Gb/s compatibility ... -
Page 14: Conversion Capabilities
S2016 insertion 16-presets Embedder shuffling/Gain/Phase 16-presets (110 only) 5 GPI inputs assignable to different preset banks Input selection Down conversion aspect ratio Transparent aspect ratio (equal in-output) Insertion of VI, WSS, AFD (S2016) ... -
Page 15: Applications
Transmission output down conversion with backup input Applications GDS110 and HDS110 only: Combining embedded audio channels of 2 inputs into 1 (see image below) CROSS INPUT AUDIO SHUFFLING EXPLAINED 3GB/S, HD, SD OUT A1 3GB/S, HD, SD IN A EMBEDDING CONVERTION 3GB/S, HD, SD OUT A2... -
Page 16: Important Notice
Important notice Historically, closed captions were transmitted in NTSC line 21 according to EIA-608. This allows two caption data bytes per field to be transmitted.With the introduction of HD and DTV a new Closed Caption specification was made, EIA-708. This allows sending more data per field, for extended language, color support, PMT and EIT and timecode data. -
Page 17: Settings Menu
Settings Menu Introduction The settings menu displays the current state of each GDS- HDS100/110 setting and allows you to change or adjust it. Settings can be changed using the front panel of the Synapse frame (SFR18, SFR08 or SFR04) or with Cortex. Also the SCP08 control can be used. -
Page 18: Inp_Sela
#Inp_SelA With this item you can select which input you want to use for Channel A. Can be SDI-1 (SDI input 1), SDI-2 (SDI input 2) or Analog (CVBS in). You can also choose a Zoneplate or Colorbar as input. Can also be set to Off to switch off channel A entirely. -
Page 19: V-Delay
#V-delay V-Delay setting allows adjustment of the vertical phase of the output signal with respect to the selected reference input. The V-Delay setting gives a delay in addition to the reference timing. For example: if the V-Delay is set to 10 TV HD lines, the output signal will be delayed by reference timing + 10 TV HD lines. -
Page 20: Pos-Prst_Act
■ V_only: vertical filters will be active which “soften” the image and prevents “ring”-effects in down converted content. ■ H_And_V: same horizontal filter as described under H_Only will be active, together with the vertical filters described under V_only. ■ H2_Only: less steep filter with aliasing and soft for C for less ringing, more sharpness but with aliasing: H2_And_V: same horizontal filter as described under ■... -
Page 21: H-Pos-A
#H-Pos-A Controls the horizontal positioning offset in pixels for channel A. Only works correctly when zooming in, for instance when downconverting using Center-Cut aspect ratio conversion. #V-Pos-A Controls the vertical positioning offset in pixels for channel A. Only works correctly when zooming instance... -
Page 22: Prsteditview
PrstEditView With this setting set to Follow Active, the edit preset settings (like for instance UP_Prst_editA and UP_Prst_editB) will follow the active preset when the active preset is changed. This to avoid confusion when changing the active. Set to Independent the edit preset will not automatically follow active preset changes. -
Page 23: Dn_H-Scalea
CenterCut LBox-16:9 LBox-14:9 Anam-702 Anamorphic scaling based on 702 active pixels instead of 720 pixels Variable Dependant on Dn_H-scale and Dn_V-scale settings. # Dn_H-scaleA The horizontal scaling of the TV picture of channel A in down converter mode is set using #Dn_H-scaleA. #Dn_H-scaleA can be set within the range of 50% to 200% of the input signal (only used when #Dn_ArcA is set to variable). -
Page 24: Tr_Prst_Acta
Tr_Prst_ActA With this item you can manually change the currently active preset of channel A in Transparent mode. Can be any preset between 1 and 16. By default it is set to 1. All menu settings that are preceded with a ‘#Tr‘-prefix are part of the preset. -
Page 25: Timecode_Inp
Timecode_Inp With this card it is possible to copy the embedded timecode information of either input SDI-1 or input SDI-2 to the output. With this setting you select which input you want to use, or switch the timecode inserting Off (default). VITC_Ln_In With this setting you can select what line of the input you want to copy the VITC data from (only when input is SD). -
Page 26: Aux_Tc_Src
The Axon devices can be set to de-embed either or any of the two, both for the original timecode input and the auxiliary timecode input. This can be set by AUX_Dem_Sel and ATC_Dem_Sel. -
Page 27: Aux_Ln_625
Aux_Ln_625 Here you choose the auxiliary timecode line number in which you are going to insert VITC when the output is SD625. Aux_Ln_525 Here you choose the auxiliary timecode line number in which you are going to insert VITC when the output is SD525. Aux_TC_DLY Here you set the delay in frames which should be applied to the auxiliary time code inserter. -
Page 28: Wss-Extnda
#WSS-ExtndA With the #VI-InsertA setting set to on, you can select VI values with this setting, which you want to be inserted in Channel A. possible are all WSS values between 4:3_0 and 4:3_7 and the settings between 16:9_0 and 16:9_7. Default is 4:3_0. #VI-DataA With the #WSS-InsertA setting set to extended, you can select WSS extended values with this setting, which you want to be inserted in Channel A. -
Page 29: R-Blacka
R-BlackA R-BlackA controls the Red-Black of channel A. The control range is between –128bits and 127 bits in steps of 1 bit The default setting is 0 bit. G-BlackA G-BlackA controls the Green-Black of channel A. The control range is between –128bits and 127 bits in steps of 1 bit The default setting is 0 bit. -
Page 30: Audio-Dly-Sinp2
#Audio-Dly-sInp2 With this item you can delay all audio on input 2 between -10000ms and 10000ms with 0.01ms increments, allowing for precise control (GDS/HDS110 only) (2 sample accuracy in practice). Default is 0ms. This item is part of the audio presets. This audio delay is calculated on top of the tracked video delay. -
Page 31: Embb1_Inp ~ #Embb4_Inp
#EmbB1_Inp ~ With these settings you can select where the corresponding audio #EmbB4_Inp channels (channel B1 till channel B4) of the outputs are coming from. In this card you can choose to get the audio from the de- embedder of SDI input 1 (Demb-SDI1) or SDI input 2 (Demb- SDI2), the embedder of the active input (Demb-Input,dependant on the current active input), from the ADD-ON bus groups, or to mute the corresponding channel (set to off). -
Page 32: Embd_Grp
#EmbD_Grp With this setting you select in to which audio group (= 4 audio channels) of the outputs you want to embed the last 4 forwarded audio channels coming from the de-embedders/add-on bus. Can be group1, group2, group3 or group4. You can also choose to not use these 4 audio channels for anything by setting this item to off. -
Page 33: Contact _1 ~ Contact_5
GPI_A-mode ~ Selects the mode for the corresponding GPI pool. Possible settings GPI_C-mode are: Prio: Each contact triggers another value, so values are one- hot encoded. Prio_latched: This mode functions like Prio Mode, but the card latches the value. Each contact triggers another value, so values are one-hot encoded. -
Page 34: Status Menu
Status Menu Introduction The status menu indicates the current status of each item listed below. sInp1 This status item indicates the presence and format of a valid signal in input 1. This is displayed as: 1080P60 1080p50 1080i60 ... -
Page 35: Sinp1_Wss-Stnd
sInp1_WSS-Stnd This status item displays the detected standard WSS value of input 1. this is displayed as follows: 1_vid 2_vid 3_vid 4_vid 5_vid 6_vid 7_vid 8_vid 1_flm 2_flm 3_flm ... -
Page 36: Sinp1_S2016
sInp1_S2016 This item displays the detected SMPTE 2016 (AFD) values of input 1. This is displayed as follows: AFD0 AFD1 AFD2 AFD3 AFD4 AFD5 AFD6 AFD7 AFD8 AFD9 AFD10 ... -
Page 37: Sinp2_S2016
sInp2_S2016 Displays the detected S2016 value found in input2. This is displayed as listed under sInp1_S2016. sInp2_CRC_EDH This item indicates CRC and EDH errors on input 2. Can be: Error NoPCM sInp2-Map Displays the mapping of the 3Gb/s input, if the format is 1080p50 or 1080p60 on input 2. -
Page 38: Contact_Status
Contact_Status Displays the currently closed GPI contacts. This is displayed as for instance 10100 when contacts 1 and 3 are closed and for instance 01110 when contacts 2, 3 and 4 are closed. GPIA Displays the current value of GPI pool A GPIB Displays the current value of GPI pool B GPIC Displays the current value of GPI pool C OP47-Det-A Displays whether or not there’s OP47 detected on channel A... -
Page 39: Ip_Addr0
NET STATUS IP_Addr0 This item displays the status of the IP address. It can be manual, DHCP asking, DHCP Leased or DHCP Infin. MAC0 This item displays the MAC address of the card. IP0 This item displays the current IP address of the card. NM0 This item displays the current Netmask of the card. -
Page 40: Events Menu
Events Menu Introduction An event is a special message that is generated on the card asynchronously. This means that it is not the response to a request to the card, but a spontaneous message. What is the Goal of The goal of events is to inform the environment about a changing an event? condition on the card. -
Page 41: The Message String
The Message String The message string is defined in the card and is therefore fixed. It may be used in controlling software like Synapse Set-up to show the event. The Tag The tag is also defined in the card. The tag has a fixed meaning. When controlling or monitoring software should make decisions based on events, it is easier to use the tag instead of interpreting a string. -
Page 42: Led Indication
LED Indication Error LED The error LED indicates an error if the internal logic of the card is not configured correctly or has a hardware failure. Input_A LED This LED indicated the presence of a valid SDI video signal on input A. -
Page 43: Block Schematic
Block Schematic GDS100 – GDS110 - HDS100 - HDS110 S2016 DETECTION 3Gb/s, HD, SD OUT A1 3Gb/s, HD, SD IN 1 3Gb/s, HD, SD OUT A2 FRAME COLOR LOW LATENCY SYNC CORR. DOWN CONVERSION EMB A EMB B EMB C EMB D &... -
Page 44: Connector Panels
HD/SD-SDI PROCESSED OUTPUT A2 GPI INPUT/OUTPUT HD/SD-SDI PROCESSED OUTPUT B1 HD/SD-SDI PROCESSED OUTPUT B2 CVBS INPUT For fiber connectivity see www.axon.tv !Unused inputs and outputs must be terminated with the correct impedance! GPI pinning Function GPI in 1 GPI in 2... -
Page 45: Card Dip-Switches For Bhx And Fiber Configuration
Appendix 1 Card dip-switches for BHX and fiber configuration There are dip-switches on the circuit board of the card itself. With these dip-switches you can change the power-voltages that is put on the backpanel. By default the switches are set to off, putting no power on the backpanel. - Page 46 which have a short initialization time, or which have a delayed trigger-signal onboard. “Direct Backpanel Switchover” dipswitch set to OFF (default): Will make the BHX-backpanel switch after about 15 seconds from the moment the BHX-backpanel detects the trigger signal from the connected synapse card.
-
Page 47: Gpi's Explained
Appendix 3 GPI’s explained Introduction This appendix describes the functionality of the GPI’s generally used within the Synapse based products. General functionality The physical contacts of a General Purpose Interface can be assigned by the user. In our cards the General Purpose Interface contacts (GPI contacts) will be named as General Purpose Input (GPI) or General Purpose Output (GPO). -
Page 48: Take
Binary mode. N is defined as a character in the range from A-Z depending on the number of pools. The default output value of a pool is always 0. This translates to preset 1 in Axon products. In priority mode, the contact which has the highest priority defines the pool value. -
Page 49: Pool Mode: Gpo
Pool Mode: GPO Every GPO pool can be set up to process the input values in two ways. This setting is called GPO_n-Mode and can be set into Priority (Prio) or Binary mode. N is defined as a character in the range from A-Z depending on the number of pools. -
Page 50: Statuses: Contact Status
Contact-Status shows the current logical value of the Statuses: Contact physical contacts, formatted as a concatenated string containing status one character per pin: 1 for asserted, 0 for non-asserted and _ for unassigned. Statuses: GPI status GPI_n is an integer which reflects the value of the pool. Statuses: GPO status GPO_n is an integer which reflects the value of the pool. - Page 51 Let’s say we would like to control the GXG up-converter presets Example 2: One pool using Pool A (Up_CtrlA set to GPI_A) in binary mode and the in binary mode and audio presets using Pool B (Audio_Ctrl set to GPI_B) in one in priority mode priority mode.
- Page 52 Pool A now works as follows: Contact_1 Contact_2 Preset value status status Up-converter Preset 1 Up-converter Preset 1 Up-converter Preset 2 Up-converter Preset 2 (because highest gets priority) Table 9 Pool value in priority mode Pool B now works as follows: Contact_3 Contact_4 Preset value...
- Page 53 GNU Public License is included below. Under this license you are eligible to receive a copy of the source code of this software including any changes. Axon Digital Design shall provide the source code on request either through physical distribution or electronic communication. For physical distribution you may be charged a fee that covers distribution costs.
- Page 54 Accompany it with the information you received as to the offer to distribute corresponding source code. (This alternative is allowed only for noncommercial distribution and only if you received the program in objects code or executable form with such an offer, in accord with Subsection b above.) The source code for a work means the preferred form of the work for making modifi cations to it.
- Page 55 NO WARRANTY 11. BECAUSE THE PROGRAM IS LICENSED FREE OF CHARGE, THERE IS NO WARRANTY FOR THE PROGRAM, TO THE EXTENT PERMITTED BY APPLICABLE LAW. EXCEPT WHEN OTHERWISE STATED IN WRITING THE COPYRIGHT HOLDERS AND/OR OTHER PARTIES PROVIDE THE PROGRAM “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
