- Page 1 CASCADA LPR1280 LPS1280 FOUNTAIN LIGHT Operating Instructions...
-
Page 2: Table Of Contents
CONTENTS Preface ................................3 Features ................................3 Precautions ................................3 Components ...............................4 Assembling and Installation ..........................5 Connection .................................6 Controls ................................7 Appearance ................................8 Technical Specifications .............................9 Warranty ................................10 Declaration of Conformity ..........................11 _________________________________________________________________________________... -
Page 3: Preface
PREFACE PRECAUTIONS CASCADA series modular • The fountain light has to be installed and underwater/outdoor fountain light with built-in used in accordance with the instructions of driver is designed to use the latest LED lighting this manual only. technology. • The power supply has to be disconnected The modular designed casing enables the before installation. -
Page 4: Components
COMPONENTS Model Description LPR1280 Rear Cable Inlet LPS1280 Side Cable Inlet Color of lighting Desription Red + Green + Blue Warm White Cool White Mounting assembly Description -blank- Fountain Light FLM12 Flood Light SLM12 Surface Light HFL12 Outdoor Light, Round HFL-SQ12 Outdoor Light, Square (1) Fountain light... -
Page 5: Assembling And Installation
ASSEMBLING AND INSTALLATION The modular fountain LED light CASCADA series can be used as stand-alone unit or combined with the following assemblies. • Flood-light mounting assembly • Surface-light mounting assembly • Outdoor light mounting assembly The assembling and installation have to be realized by qualified personnel. The CASCADA has to be assembled and fixed as shown in the drawings below:... -
Page 6: Connection
Note: • Do not cover the FOUNTAIN light body with any kind of temperature isolating material. The FOUNTAIN light is protected by a temperature sensor against over-heating. When the temperature of the FOUNTAIN light exceeds 85°C the FOUNTAIN light is automatically switched off. -
Page 7: Controls
CONTROLS Single-color warm white (WW) or cool white (CW) Control by momentary switch Remote control by momentary switch can be used to turn-on and turn-off the light and to control the luminosity. Turning on / off Press the momentary switch momentary. Dimming When the light is on, press the momentary switch longer until the desired power is achieved. -
Page 8: Appearance
Setting the Custom Color At the selected Rainbow Color Spectrum mode press the momentary switch shortly to turn the light off. After that press the momentary switch for 5 seconds or until the light is switched to the selected color and then the Custom Color is set and selected. Dimming When the light is turned-on press the momentary switch until the desired illumination is achieved. -
Page 9: Technical Specifications
TECHNICAL SPECIFICATIONS Power supply 12 – 24 Vdc, max. 1.4 A/12 Vdc or 650 mA/24 Vdc Lens angle 15° Optical window High-grade polycarbonate glass Luminous flux max. 1.900 lm ASTEL protocol default address Operating temperature -10°C - +50°C Casing Stainless steel (316L) Protection IP 68 Dimensions... -
Page 10: Warranty
WARRANTY 1. The equipment manufactured by ASTEL d.o.o. is warranted to be free from defects in workmanship and materials under normal use and service. 2. This Warranty is in effect for of two years from the date of purchase by the user. Proof of purchase must be included, to establish that it is inside the warranty period. -
Page 11: Declaration Of Conformity
DECLARATION OF CONFORMITY according to IEC Guide 22 and EN 45014 Manufacturer's Name: ASTEL, Podjetje za projektiranje, proizvodnjo in trgovino, d.o.o. Manufacturer's Address: Dutovlje 138 6221 Dutovlje Slovenija declares that the products Item, Product Name and Model Number: 1. Fountain LED light CASCADA series conform to the following Product Specifications: EMC: EN 55015:2006 + A1:2007... - Page 12 ASTEL d.o.o., Dutovlje 138, 6221 Dutovlje, Slovenia Tel: +386 5 7310771, +386 5 7310772 Fax:+386 5 7310789 info@astel-lighting.com E-mail: www.astel-lighting.com Web:...
