  • Page 1 AS55X Series SERVICE MANUAL...

  • Page 3: Table Of Contents

    AS 551 / 4V BRI ........................29 AS 551 / 2V BRI ........................30 AS 551 Slave .......................... 31 AS550 BRI/VoIP........................32 WLL550 Pro (wireless local loop) ..................33 LED status ..........................34 RESET button ......................... 37 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...
  • Page 4 General .......................... 60 5.6.2 MSN-GSM link list ......................62 5.6.3 Charge ..........................62 5.6.4 Causes ..........................63 SIP access ..........................66 5.7.1 General .......................... 66 5.7.2 Extended (expert mode) ....................69 5.7.3 Names and passwords ....................72 www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)
  • Page 5 ProviderSimSwitch ....................... 118 5.11.9 Fax extension ....................... 118 5.12 Special settings ........................119 5.12.1 Timers .......................... 120 5.12.2 Unnamed bits ......................123 5.12.3 Unnamed bytes ......................129 5.12.4 Unnamed words ......................135 5.12.5 Unnamed long words ....................136 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...
  • Page 6 Release Notes ..........................148 Release 3.0 .......................... 148 8.1.1 New and improved features ..................148 8.1.2 Problem solution ......................148 Release 3.01 ........................148 8.2.1 New and improved features ..................148 8.2.2 Problem solution ......................149 Release 3.03 ........................149 www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)
  • Page 7 Release 3.17 ........................164 8.13.1 New and improved features ..................164 8.13.2 Problem solution ......................165 8.14 Release 3.19 ........................165 8.14.1 New and improved features ..................165 8.14.2 Problem solution ......................165 8.15 Release 3.20 ........................166 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...
  • Page 8 Problem solution ......................167 8.16 Release 3.21 ........................168 8.16.1 New and improved features ..................168 8.16.2 Problem solution ......................169 8.17 Release 3.22 ........................169 8.17.1 New and improved features ..................169 8.17.2 Problem solution ......................170 www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)

  • Page 9: General Functions

    PABX. Please consider that only the last call to one destination can be saved. A previous existing call-setup will always be overwritten by the new one. It is mandatory that both sides transmit their number (CLIP). For programming instructions see 5.8.2, 5.8.3, 5.10.2 and 7.5. 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...

  • Page 10: Callback Termination

     Freely entered number via DTMF. It is possible to send this short message automatically or controlled by the customer via DTMF code. The calling party name is available for the SMS callback request for SIP calls. For programming instructions see 5.8.5 www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)

  • Page 11: Gsm Channel Groups

    VPN prefix. These channels are combined to a GSM channel group and the routing function of the AS55x chooses one ready channel of this group if a call-setup to this VPN is made. For programming instructions see 5.8.3, 5.10.2, 5.10.3, 5.11.1 and 5.11.5 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...

  • Page 12: Internet

    GSM network. No channel to the PSTN will be used. For programming instructions see 5.8.3, 5.10.3 and 5.11.1. more about the PassThrough backup mode here > 1.14 www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)

  • Page 13: Simswitch

    SMS short messages. If you want to implement the SMS features into your applications, ask your local dealer for “API for sending and receiving short messages via AS55X”. This is a small proprietary API only for sending and receiving SMS via AS55x. For programming instructions see 5.11.4. 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...

  • Page 14: Gsm-Pbx

    Wireless channel statistics (min. / max. signal quality, call attempts to GSM, calls to GSM connected minutes to GSM, ...) o SIM Switch information (active SIM, connected minutes for each SIM) For programming instructions see 0. www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)

  • Page 15: Passthrough Backup Mode

    Finally the “ProviderSimSwitch“ will remain at the SIM with the best available network. If a network connection is lost for more than 10 seconds or if a new search is triggered manually, the network search will restart considering the previous network data. For programming instructions see 5.11.8 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...

  • Page 16: Dtmf Codes (Wll550 Pro)

    The already known code '#721#' keeps its function, internet access without data roaming. Both codes are irrelevant, if internet access is configured with the service software. Please keep in mind, your SIM contract must permit data roaming as well! www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)
  • Page 17  To select a SIM card of the ’ProviderSimSwitch‘ manually #79nm# n is the place holder for the channel (1 or 2) m is the place holder for the SIM- card (1 or 2) Example: #7921# activates SIM card 1 of channel 2 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...
  • Page 18 SERVICE MANUAL AS55X www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)

  • Page 19: Technical Features

    800/850/AWS/1900/2100MHz Gemalto/Cinterion PLS8-E Five Band LTE 800/900/1800/2100/2600 MHz, FDD-Band (20,8,3,7,1) Tri Band UMTS (WCDMA) 900/1800/2100 MHz, FDD-Band (8,3,1) Dual Band GSM 900/1800 MHz Antenna: 1x antenna splitter 6 to 1 - SMA female connector 3V Mini-SIM cards 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...
  • Page 20 DHCP, DNS, STUN, ARP, VLAN, TELNET, SNMP DSS1, QSIG  Codecs: G.711 a-law/μ-law  Maintenance: Service software (https://www.kuhnt.com) Interfaces: local: USB (security: password) remote: LAN, GSM (security: username and password)  Size: 19 inch rack aluminium (AS551) / 1 rack unit (1U)

  • Page 21: As551/4V Bri

    800/850/AWS/1900/2100MHz Gemalto/Cinterion PLS8-E Five Band LTE 800/900/1800/2100/2600 MHz, FDD-Band (20,8,3,7,1) Tri Band UMTS (WCDMA) 900/1800/2100 MHz, FDD-Band (8,3,1) Dual Band GSM 900/1800 MHz Antenna: 1x antenna splitter 6 to 1 - SMA female connector 3V Mini-SIM cards 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...
  • Page 22 DHCP, DNS, STUN, ARP, VLAN, TELNET, SNMP DSS1, QSIG  Codecs: G.711 a-law/μ-law  Maintenance: Service software (https://www.kuhnt.com) Interfaces: remote: LAN, GSM (security: username and password)  Size: 19 inch rack aluminium (AS551 / 4V BRI) / 1 rack unit (1U)

  • Page 23: As551/2V Bri

    800/850/AWS/1900/2100MHz Gemalto/Cinterion PLS8-E Five Band LTE 800/900/1800/2100/2600 MHz, FDD-Band (20,8,3,7,1) Tri Band UMTS (WCDMA) 900/1800/2100 MHz, FDD-Band (8,3,1) Dual Band GSM 900/1800 MHz Antenna: 1x antenna splitter 6 to 1 - SMA female connector 3V Mini-SIM cards 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...
  • Page 24  Protocols: DHCP, DNS, STUN, ARP, VLAN, TELNET, SNMP DSS1, QSIG  Codecs: G.711 a-law/μ-law  Maintenance: Service software (https://www.kuhnt.com) Interfaces: remote: LAN, GSM (security: username and password)  Size: 19 inch rack aluminium / 1 rack unit (1U) Size:...

  • Page 25: As551 Slave

    800/850/AWS/1900/2100MHz Gemalto/Cinterion PLS8-E Five Band LTE 800/900/1800/2100/2600 MHz, FDD-Band (20,8,3,7,1) Tri Band UMTS (WCDMA) 900/1800/2100 MHz, FDD-Band (8,3,1) Dual Band GSM 900/1800 MHz Antenna: 1x antenna splitter 6 to 1 - SMA female connector 3V Mini-SIM cards 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...
  • Page 26 19 inch rack aluminium (AS551 Slave) / 1 rack unit (1U) Size: width: 483mm, height: 45mm, depth: 300mm Weight: AS551 Slave: ca. 2,4 kg  Environment Operating temperature: 5°C to 40°C Storage temperature: -10°C to 70°C Humidity: 0% to 90% www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)

  • Page 27: As550 Bri/Voip

    SIP 2.0 / UDP as server, client or peer-to-peer Additional protocols: ARP, DHCP, DNS, STUN, VLAN, SNMP, TELNET Authentification: MD5  Codecs: G.711 a-law/μ-law  Maintenance: Service software (https://www.kuhnt.com) Interfaces: remote: LAN, GSM (security: username and password) 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...
  • Page 28 SERVICE MANUAL AS55X  Size: Desktop aluminium box width: 153mm, height: 35mm, depth: 185mm Weight: ca. 750g without power supply  Environment Operating temperature: 5°C to 40°C Storage temperature: -10°C to 70°C Humidity: 0% to 90% www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)

  • Page 29: Wll 550 Pro (Wireless Local Loop)

    Network protocols: DHCP, DNS, ARP  Maintenance: Service software AS55X-Service for WINDOWS operating systems (Download link: https://www.kuhnt.com/down/55xwin32.zip) Interfaces: LAN, Reverse IP or GSM CS-data (Secured by: username and password)  Size/weight: Aluminium desktop case. Approx. width 125 (154*) x height 35 x depth 185 mm * with mounting bracket Approx.

  • Page 30: Exterior View / Connectors

    16. Slave 1 Connector (channel 7-14) 17. IEC power connector for build in power supply not for AS 551 Master VoiP not available for SimSwitch AS 551 Master (VoiP) / 2V and SimSwitch AS 551 Master (VoiP) / 4V www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)

  • Page 31: As 551 / 4V Bri

    10/100 Mbps connector for LAN (for SIP communication and configuration) 7. Power LED 8. ISDN NT LED 9. Antenna connection SMA connector (female) 10. Channel status LED 11. Ground connection 12. IEC power connector for build in power supply 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...

  • Page 32: As 551 / 2V Bri

    6. ISDN NT LED 7. ISDN NT (ISDN Master) RJ 45 connector for PassThrough output or NT-Simulation 8. Channel status LED 9. Antenna connection SMA connector (female) 10. Ground connection 11. IEC power connector for build in power supply www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)

  • Page 33: As 551 Slave

    Expansion with up to eight slots for 3V Mini-SIM cards. 4. Channel status LED 5. Antenna connection SMA connector (female) 6. Ground connection 7. Master RJ 45 Connectors for the AS551 Master (max. 0,5m) 8. IEC power connector for build in power supply 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...

  • Page 34: As550 Bri/Voip

    9. ISDN TE (ISDN Slave) RJ 45 connector for clock synchronisation, PassThrough input or ISDN Subscriber 10. ISDN TE LED 11. ISDN NT LED 12. ISDN NT (ISDN Master) RJ 45 connector for PassThrough output or NT-Simulation www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)

  • Page 35: Wll550 Pro (Wireless Local Loop)

    (GSM/fax, phone) 5. RESET button 6. SMA connector main antenna, auxiliary SMA connector for LTE diversity 7. Power supply: 12V – 30V DC 8. Telephone-/PBX-connector (FXO)- RJ11 9. G3 fax connector (FXO) - RJ11 10. Earth terminal, GND 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...

  • Page 36: Led Status

    LED is red if there is no connection or an error is occurred o LED is blinking green if ISDN TEI exchange was successful but ISDN layer 2 is down (only in ISDN point-to-multipoint mode) www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)
  • Page 37 LED is blinking red seven times if no registration is possible for more than two minutes. The module will restart then. o LED is blinking red eight times if the designated network is permitted and no login is possible 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...
  • Page 38 LED is blinking red thirteen times if an error occurred within the multiplex mode (“Telnet mode”)  Online LED (WLL550 Pro only) o LED is steady green if the internet connection (WAN) is successfully established www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)

  • Page 39: Reset Button

    ** ReverseIP-connections are remote service session to a manufacturer’s service computer. To protect your data it is recommended to init a remote service session by appointment only. An internet access via mobile phone network or LAN is mandatory! 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...

  • Page 40: Service Software

    The recent firm- and software releases you will also find on our website under: https://www.kuhnt.com. The current version of your service software can be checked under the “About this program” button in the menu bar or it is also listed in the topic of the window.
  • Page 41 4. Button to start the programming session (local, remote or demo) 5. To switch between configuration (see 4.1), installation data (see 6), and services (see 6. Configuration or data area 7. Button to abort the current programming session 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...

  • Page 42: Access Type

    GSM is classified as remote access and secured by username and password. All AS55X with a USB connection are additionally equipped with a physical remote access switch to control remote access. Notice: It is not possible to change the local access password via remote access. www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)

  • Page 43: Lan

    WLL550 gateway. The available physical connections are GPRS via GSM, UMTS, LTE or LAN, depending on the type of the gateway. By default this feature is not shown. If you want to use the Reverse IP access or uses the Reset-Button. Please contact your local dealer for further information. 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...

  • Page 44: Import / Export Function

    If you press “Import” the next window opens and you have also to choose “yes” or “no”. If you press “no”, you can import a text file, which was exported from an AS55X. If you press “yes”, your clipboard data from one of the listed menus will be inserted to your table. www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)

  • Page 45: Configuration

    Dialling tone GSM -> ISDN/SIP Dialling tone for call-setup direction from GSM network This tone or announcement requests the calling subscriber from the GSM network to type in DTMF digits for suffix dialling. default: special dialling tone 1 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...
  • Page 46 • Eurovision melody I • Eurovision melody II • “GSM gateway, please dial mobile phone number” • “GSM gateway, please dial extension number” • “Calling mobile phone, please hold the line” • “GSM gateway, please enter callback code” www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)
  • Page 47 • Ringing tone 425 khz • Interrupted ringing tone 425 khz • Single short tone 425 khz • Busy tone 425 khz • Four busy tone 425 khz 1850 khz • Tone sequence 1450 khz 950 khz 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...

  • Page 48: Volume Levels

    Audio level directed ISDN to GSM - Audio level GSM -> ISDN/SIP: Audio level directed GSM to ISDN - Tone level -> ISDN/SIP: Tones and announcements directed to ISDN/SIP - Tone level -> GSM: Tones and announcements directed to GSM www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)

  • Page 49: Lan Settings

    IP address is in use.  Direct connection to endpoint AS55X is directly connected to the PBX without any network equipment between. Keep in mind that a “crossover cable” might be necessary. You only have to configure local IP address. 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...

  • Page 50: Advanced Network Configuration

    10Mbps because normally the other network clients use 100Mbps or 1000Mbps. Then the switch has to buffer the received messages from the other clients. If there is much traffic, this can cause an overflow and packets will be lost. Default value: Auto negotiation www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)
  • Page 51 LAN messages will be traced. You can distinguish between sent and received traffic data. Though this setting will cause a lot of unnecessary trace data (especially audio data). It is not recommended for normal operation. Default value: both unchecked 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...

  • Page 52: Isdn Pri Settings

    4 and 5 in slave mode. If this checkbox is checked, the AS55X transmits on pin 4 and 5 in master mode and transmits on pin 1 and 2 in slave mode. Default value: unchecked www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)

  • Page 53: Main Interface Protocol

    Notice: Some GSM networks use non standard tones. Therefore the tone detection can fail. Notice: Some PBXs generate the tones itself before ISDN CONNECT message. Therefore you cannot hear the AS55X generated tones and announcements. 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...
  • Page 54 GSM network to the ISDN interface. If the PBX should generate tones, it can be set here. This function is controlled by the progress indicator “in-band information available”, but not all PBXs do interpret this indicator correctly. Default value: ... by AS55X www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)

  • Page 55: Synchronisation Interface (Isdn Aux)

    (a single terminal) on this ISDN Bus. The AS55X gets its clock rate from the PBX. Notice: If the ISDN AUX interface is not connected or the received clock rate is incorrect, the AS55X generates its own clock. 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...

  • Page 56: Isdn Bri Settings

    The correct setting of the synchron interface (ISDN AUX)depends on the ISDN-line, the signal is picked off from. Preferably the synchron signal should be taken from a wired network interface of the PBX. If the PBX has only a PRI network interface, www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)

  • Page 57: Protocol Options

    AS55X to PBX, a fixed setting of the concerned information elements is necessary. If the type, used by the PBX is unknown, it can be found in the trace of a call setup from the PBX. Default value: DSS1 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...
  • Page 58 In this case the AS55X answers directly with CONNECT. This option shall suppress the ringing tone generation by the PBX. Notice: Some GSM networks use non standard tones. Therefore the tone detection can fail. o Immediately CONNECT www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)
  • Page 59 ISDN interface. If the PBX is wanted to generate this tone, it can be set here. This function is controlled by the progress indicator “in-band information available”, but not all PBXs do interpret this indicator correctly. Default value: ... by AS55X 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...

  • Page 60: Pots (Fxo) Settings

    Select the maximum length of the called numbers in international form. E.g. for the longest dial number +491234567890 select 12 digits. If you are not sure about the maximum lengths of the number set this value to higher than 15. Default value: www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)

  • Page 61: Fax Settings

    If unnamed bit 74 (Special settings) is set, the presentation of the number will be restricted, even if it is requested for voice calls. > needs FW 3.16 < 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...

  • Page 62: Isdn Access

    E.g. for the longest GSM number +491234567890 select 12 digits. This setting does not depend on the really dialled number format in ISDN. En bloc transferred numbers can be longer than this value. Default value: www.kuhnt.com 55Xseries_manual_V3.22 (18-08-15)
  • Page 63 With this setting, the type of CLIP digits can be changed in order to get a number for a callback that will be accepted by the PBX. Default value: No change o Type of CLIP to ISDN: 55Xseries_manual_V3.22 (18-08-15) www.kuhnt.com...

  • Page 64: Msn-Gsm Link List
