WLL550 Pro – Operating manual
WLL550 Pro
Operating manual
REV 2, REV 3, REV 4
(min. required FW REV 3.17)
WLL550Pro_EN_V2.1.pdf - 1/34
www.kuhnt.com
2015-04-10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WLL550Pro and is the answer not in the manual?

Questions and answers

Related Manuals for Kuhnt WLL550Pro

Summary of Contents for Kuhnt WLL550Pro

  • Page 1 WLL550 Pro – Operating manual WLL550 Pro Operating manual REV 2, REV 3, REV 4 (min. required FW REV 3.17) WLL550Pro_EN_V2.1.pdf - 1/34 www.kuhnt.com 2015-04-10...
  • Page 2 WLL550 Pro – Operating manual WLL550Pro_EN_V2.1.pdf - 2/34 www.kuhnt.com 2015-04-10...

  • Page 3: Table Of Contents

    2.7……….. Factory defaults (Reset)…………..25 2.8……….. DTMF Codes……........….. 25 3....Installation..........27 4....Services............28 5....Special settings....………….….. 30 5.1……….. Unnamed bits……………………….…... 30 5.2……….. Unnamed bytes…………………………. 31 6………….. Technical data……………………..… 32 7………….. Glossary / Tips…………………..... 35 WLL550Pro_EN_V2.1.pdf - 3/34 www.kuhnt.com 2015-04-10...
  • Page 4 WLL550 Pro – Operating manual WLL550Pro_EN_V2.1.pdf - 4/34 www.kuhnt.com 2015-04-10...

  • Page 5: Basic Functions

    4. SIM card reader with status LED – channel 2 (GSM/fax, phone) 5. RESET button 6. SMA antenna connector 7. Power supply: 12V – 30V DC 8. Telephone-/PBX-connector (FXS)- RJ11 9. G3 fax connector (FXS) - RJ11 10. Earth terminal, GND WLL550Pro_EN_V2.1.pdf - 5/34 www.kuhnt.com 2015-04-10...

  • Page 6: Phone

    All settings in global and individual call setup are exclusively for voice calls and do not concern fax calls. Hint: There is no fax service available within the LTE and UMTS networks. For programming instruction see 2.2 WLL550Pro_EN_V2.1.pdf - 6/34 www.kuhnt.com 2015-04-10...

  • Page 7: Internet

    WLL550 Pro radio modules for SMS short messaging. ‘SMS Center‘,‘SMS API‘ and ‘TELNET ‘ are 'Extended feature' that needs to be enabled within the WLL550 Pro. For further information please refer to 2.5 WLL550Pro_EN_V2.1.pdf - 7/34 www.kuhnt.com 2015-04-10...
  • Page 8 WLL550 Pro – Operating manual WLL550Pro_EN_V2.1.pdf - 8/34 www.kuhnt.com 2015-04-10...

  • Page 9: Installation - Configuration

    The service tool for WLL550 Pro ‘AS55X-Service' is available as a direct download at: > www.kuhnt.com/down/55xwin32.zip < . If the WLL550 Pro is set to factory defaults it works as a DHCP server that can be directly connected with the LAN of your computer.
  • Page 10 * Hint: Using the RESET button will delete all configuration and security data! When you are successfully connected, you will first see this: There are no factory defaults for username and password! Just confirm with the 'ENTER' button or click 'OK' leaving both form fields empty. WLL550Pro_EN_V2.1.pdf - 10/34 www.kuhnt.com 2015-04-10...
  • Page 11 Now you can adjust the basic configuration within the configuration menu: - LAN settings for WLL550 Pro > Configuration > LAN settings > LAN interface mode Usually the default setting as 'default gateway' works for all types of installations and setups. WLL550Pro_EN_V2.1.pdf - 11/34 www.kuhnt.com 2015-04-10...
  • Page 12 - APN settings for the internet access > Configuration > GSM access > internet Check the 'Go Online' box to activate automatic internet access or type in the APN settings manually by filling the form fields WLL550Pro_EN_V2.1.pdf - 12/34 www.kuhnt.com 2015-04-10...
  • Page 13 With this basic setting your WLL550 Pro should work fine already. Advanced users may continue with the configuration of some individual settings. Please keep in mind to download the modifications into the WLL550 Pro before you quit the service session! > Configuration > Download to AS55X WLL550Pro_EN_V2.1.pdf - 13/34 www.kuhnt.com 2015-04-10...

  • Page 14: Phone/Fax (Pots Settings)

    (e.g. *8 004944130005…) for each fax to identify the service. This prefix (*8) is not a part of the called number is deleted by the WLL550 Pro. Default value: Phone and fax at different interfaces Fax call prefix Default value: not reported WLL550Pro_EN_V2.1.pdf - 14/34 www.kuhnt.com 2015-04-10...
  • Page 15 E.g. for the longest number +491234567890 select 12 digits. Please note! If you are not sure about the maximum lengths of the number set it to a value higher than 15. Default value: WLL550Pro_EN_V2.1.pdf - 15/34 www.kuhnt.com 2015-04-10...

  • Page 16: Fax Function (Fax Settings)

    Please enter a text for each receipt in the form field. The function is activated by completing the form field. You can a write free text and enter a placeholder for the destination number with the ‘Insert destination number‘ button. For further information please refer to 5. Special settings WLL550Pro_EN_V2.1.pdf - 16/34 www.kuhnt.com 2015-04-10...

  • Page 17: Configuration Internet

    All WLL550 Pro Rev2 additionally indicate an active internet access with the 'Online' LED on the front panel. To disconnect the WLL550 Pro from the internet the device must be switched off or all internet settings have be removed from the configuration setup. WLL550Pro_EN_V2.1.pdf - 17/34 www.kuhnt.com 2015-04-10...
  • Page 18 Some WLL550 Pro are equipped with a single GSM radio module only. However to reduced access to the internet is possible by GPRS via Dial-up network and Telnet*. *Telnet is optional, please ask your service partner for details. WLL550Pro_EN_V2.1.pdf - 18/34 www.kuhnt.com 2015-04-10...

  • Page 19: Configuration Of Network

    WLL550 Pro. But the WLL550 Pro will work as ‘default gateway ‘as well if the routers WAN interface is set to DHCP client. LAN settings within the WLL550 Pro service tool AS55X-Service: > Configuration > LAN settings > LAN interface mode WLL550Pro_EN_V2.1.pdf - 19/34 www.kuhnt.com 2015-04-10...

  • Page 20: Configuration Of Short Messaging. 20 2.6

    (software options) of your WLL550 Pro for an ‘SMS Center‘ or ‘TELNET ‘ subscription. You need at least one of them. The ‘SMS Center‘ is a free client software that is available at www.kuhnt.com. It uses the LAN to communicate with the WLL550 Pro. Basic requirements are a Microsoft Windows operation system with .NET Frameworks 2.0 or higher.
  • Page 21 WLL550 Pro – Operating manual WLL550Pro_EN_V2.1.pdf - 21/34 www.kuhnt.com 2015-04-10...
  • Page 22 It is helpful to define a minimum signal field strength for each radio channel to improve the quality of the various network services. A network search automatically starts if the field strength goes below that limit. WLL550Pro_EN_V2.1.pdf - 22/34 www.kuhnt.com 2015-04-10...
  • Page 23 6. Status LED of the GSM radio channel 7. Antenna connector SMA (female) 8. Power jack for external power supply 9. Phone jack for analogue telephone, PABX or Tel-Fax combination devices. 10. Phone jack for G3-fax machine 11. Earth terminal, GND WLL550Pro_EN_V2.1.pdf - 23/34 www.kuhnt.com 2015-04-10...
  • Page 24 Default value: not reported General recommendation: Call forwarding for all services on channel GSM2 might be useful to improve your availability. Deactivate your mailboxes or turn off call forwarding to the mailboxes WLL550Pro_EN_V2.1.pdf - 24/34 www.kuhnt.com 2015-04-10...

  • Page 25: Factory Defaults (Reset)

    WLL550 Pro.  To restart the best net detection with the ’ProviderSimSwitch‘ , please use this codes #77# all GSM/UMTS/LTE channels #771# LTE/UMTS/GSM channel one only #772# GSM channel two only WLL550Pro_EN_V2.1.pdf - 25/34 www.kuhnt.com 2015-04-10...
  • Page 26 Dial '1#' for all GSM codes starting with a single hash '#' and dial '2#' for all GSM codes starting with a double hash '##' Example: To cancel all call forwarding by the GSM code ##002# dial 2#002# instead WLL550Pro_EN_V2.1.pdf - 26/34 www.kuhnt.com 2015-04-10...

  • Page 27: Installation

    WLL550 Pro devices. Set an individual name here. Download firmware Local firmware updates of a WLL550 Pro. Firmware files are available from your service or at www.kuhnt.com. Always use the newest AS55X-Service software to configure new firmware features . Enter upgrade code Software modules 'Extended features' can be activated by a upgrade key WLL550Pro_EN_V2.1.pdf - 27/34...

  • Page 28: Services

    View LAN status Shows the status of the network interface View WAN status Shows the status of the WAN interface View statistics Shows some statistical data about incoming and outgoing calls. This values are polled repeatedly. WLL550Pro_EN_V2.1.pdf - 28/34 www.kuhnt.com 2015-04-10...
  • Page 29 Adjust WLL550 Pro system clock or synchronizes it with your computer clock. View device data Shows various hard- and software information. View test licence Shows the status of the 'test licence' Reverse IP connection Setup for a Remote IP session WLL550Pro_EN_V2.1.pdf - 29/34 www.kuhnt.com 2015-04-10...

  • Page 30: Special Settings

    SIM. This can result into confusion by the recipient, which number should be used for a reply. If unnamed bit 74 is set, the presentation of the number will be restricted, even if it is requested for voice calls. Default value: Not set WLL550Pro_EN_V2.1.pdf - 30/34 www.kuhnt.com 2015-04-10...

  • Page 31: Unnamed Bytes

    1, it exclusively registers to a GSM Network and if the byte 121 is set to 2, if exclusively registers to a UMTS network. This setting is globally for all channels. Default value: WLL550Pro_EN_V2.1.pdf - 31/34 www.kuhnt.com 2015-04-10...

  • Page 32: Technical Data

    Network protocols: DHCP, DNS, ARP  Maintenance: Service software AS55X-Service for WINDOWS operating systems (Download link: http://www.kuhnt.com/down/55xwin32.zip) Interfaces: LAN, Reverse IP or GSM CS-data (Secured by: username and password)  Size/weight: Aluminium desktop case. Approx. width 125 (154*) x height 35 x depth 185 mm * with mounting bracket Approx.
  • Page 33 WLL550 Pro – Operating manual WLL550Pro_EN_V2.1.pdf - 33/34 www.kuhnt.com 2015-04-10...
  • Page 34 WLL550 Pro – Operating manual WLL550Pro_EN_V2.1.pdf - 34/34 www.kuhnt.com 2015-04-10...

  • Page 35: Glossary / Tips

    - Block roaming for the LTE/UMTS channel ‘GSM1‘ by entering a ‘netcode ‘ if you are not sure about the roaming cost for data traffic - Deactivate call forwarding into mail boxes for all SIM cards. Code: ##002# WLL550Pro_EN_V2.1.pdf - 35/34 www.kuhnt.com 2015-04-10...
  • Page 36 WLL550 Pro – Operating manual Friedrich Kuhnt GmbH - Stubbenweg 15 - 26125 Oldenburg – Germany ©2012-2015 www.kuhnt.com WLL550Pro_EN_V2.1.pdf - 36/34 www.kuhnt.com 2015-04-10...
