- Page 1 OWNER’S MANUAL DVD Home Theater System Please read this manual carefully before operating your set and retain it for future reference. DH6330H (DH6330H, S63H1-S/ W, S63H2-C)
- Page 2 Getting Started Safety Information CAUTION CAUTION: This product employs a Laser System. RISK OF ELECTRIC SHOCK To ensure proper use of this product, please read DO NOT OPEN this owner’s manual carefully and retain it for future CAUTION: TO REDUCE THE RISK OF ELECTRIC reference.
- Page 3 Getting Started Notes on Copyrights This device is equipped with a portable battery or accumulator. y This product incorporates copyright protection Safety way to remove the battery or the technology that is protected by U.S. patents battery from the equipment: Remove the and other intellectual property rights.
-
Page 4: Table Of Contents
Table of Contents Table of Contents Optional – To display and exit the Setup menu – Language – Display – Audio Getting Started – Lock (Parental Control) – Others Safety Information Unique Features – Portable In Operating – USB Direct Recording –... - Page 5 Table of Contents Troubleshooting Troubleshooting Appendix Maintenance – Handling the Unit – Notes on Discs Area Code List Language code List Trademarks and Licenses Specifications...
-
Page 6: Getting Started
Getting Started Unique Features Accessories Please check and identify the supplied accessories. Portable In Listens to music from your portable device. (MP3, Notebook, etc) USB Direct Recording Remote control (1) Battery (1) Records music from CD to your USB device. Full HD up-scaling Views Full HD picture quality with simple setup. -
Page 7: Introduction
Getting Started Introduction Symbols Used in this Manual DVD-Video, DVD±R/RW in Video mode or VR mode and finalized Playable Discs Audio CDs This unit plays DVD±R/RW and CD-R/RW that contains audio titles, DivX, MP3, WMA and/or Video files contained in the JPEG files. -
Page 8: Playable File Requirement
When setting the optin to Live File System, y Playable Audio format : “AC3”, “PCM”, “MP3”, “WMA”. you cannot use it on LG players. (mastered/ Love y Sampling frequency : within 32 to 48 kHz (MP3), File System : Disc format sysyem for Windows... -
Page 9: Remote Control
- You can control the sound in the menu or exits the setup level, input source, and power menu. switching of LG TVs as well. Hold POWER (TV) and press PR/ TITLE: If the current DVD title has CH (W/S) button repeatedly a menu, the title menu appears until the TV turns on or off. -
Page 10: Front Panel
Getting Started Front panel a Disc Tray g T (PLAY/PAUSE) Starts playback. b Display window Pauses playback temporarily, press again to exit Shows the current status of the unit. pause mode. c Microphone jacks 1/2 h I (STOP) d PORT. IN Stops playback. -
Page 11: Rear Panel
Getting Started Rear panel f VIDEO OUT a Power cord Connects to a TV with video inputs. b Speaker connectors Connects the speaker cables g HDMI OUT Connects to TV with HDMI inputs. c Cooling Fan (Interface for digital audio and video) d Antenna Connector h OPTICAL IN FM- Connects the FM wired antenna... -
Page 12: Connecting
Connecting Assembling the 1. Attach the base to the speaker. speaker Preparation Speaker Speaker cables Screw Base... - Page 13 Connecting 2. Secure the connection with a supplied screw. 4. Connect the speaker wire to the terminal on the speaker. Make sure the wire marked black goes in to the terminal marked "-"(minus) and the other wire goes in to the terminal marked "+"(plus) 3.
-
Page 14: Attaching The Speakers To The Unit
Connecting Attaching the speakers Color Speaker Position to the unit Grey Rear Rear right Blue Rear Rear left Green Center Center 1. Connect the wires to the unit. Match each wire’s colored band to the same Orange Sub woofer Any front position colored connection terminal on the rear of the Front Front right... -
Page 15: Positioning The System
Connecting Positioning the system Front left speaker (L)/ Front right speaker (R): Place the front speakers to the sides of the monitor or screen and as flush with the screen The following illustration shows an example of surface as possible. positioning the system. -
Page 16: Connections To Your Tv
Connecting Connections to Your HDMI Out Connection If you have a HDMI TV or monitor, you can connect it to this unit using a HDMI cable (Type A, High Speed HDMI™ Cable). Connect the HDMI OUT jack on the unit to the Make one of the following connections, depending HDMI IN jack on a HDMI compatible TV or monitor. -
Page 17: Video Connection
Yellow Cable). Some functions of this unit are controlled by the TV’s remote control when this unit and LG TV’s with SIMPLINK are connected through HDMI connection. Controllable functions by LG TV’s remote control; Play, Pause, Scan, Skip, Stop, Power Off, etc. -
Page 18: Resolution Setting
Connecting Video Output Resolution Setting Resolution The unit provides several output resolutions for HDMI OUT. You can change the resolution using [Setup] menu. Displayed resolution in display window and 1. Press n HOME. outputted resolution may different according to 2. Use A/D to select the [Setup] and press connection type. -
Page 19: Optional Equipment Connection
Connecting Optional Equipment PORT. IN (PORTABLE) In Connection Connection Connect an output of portable device (MP3 or PMP etc) to the AUDIO (PORT. IN) input connector. AUX In Connection Connect an Output of auxiliary device to the AUX (L/R) INPUT Connector. Unit MP3 player, etc... -
Page 20: Usb Connection
Connecting USB Connection Compatible USB Devices y MP3 Player : Flash type MP3 player. Connect the USB port of USB Memory (or MP3 player, etc.) to the USB port on the front of the unit. y USB Flash Drive : Devices that support USB2.0 or USB1.1. -
Page 21: Optical In Connection
Connecting OPTICAL In connection Home theater speaker ez setup Connect an optical output of Unit (or Digital Device etc) to the OPTICAL IN connector. Listen to sound from TV, DVD and Digital Device with 5.1(2.1 or 2)ch mode. Even in power off mode, if you press OPTICAL, then power is on and automatically changed to AUX OPT mode. -
Page 22: Antenna Connection
Connecting Antenna Connection Connect the supplied FM antenna for listening to the radio. Connect the FM Wire antenna to the FM antenna connector. Note Be sure to fully extend the FM wire antenna. -
Page 23: System Setting
System Setting Adjust the setup To display and exit the Setup menu settings 1. Press n HOME. Displays the [Home Menu]. By using the Setup menu, you can make various adjustments to items such as picture and sound. You can also set a language for the subtitles and the Setup menu, among other things. -
Page 24: Language
System Setting Language Display Mode The Display Mode setting works only when the TV Menu Language Aspect mode is set to 4:3. Select a language for the Setup menu and then on [Letterbox] screen display. Displays a wide picture with bands on the upper and lower portions of the screen. -
Page 25: Audio
System Setting Audio [Speaker] Select a speaker that you want to adjust. 5.1 Speaker Setup Note Certain speaker settings are prohibited by Make the following settings for the built-in 5.1 the Dolby Digital licensing agreement. channel surround decoder. 1. Select [5.1 Speaker Setup] on the [Audio] menu. 2. -
Page 26: Lock (Parental Control)
System Setting Lock (Parental Control) DRC (Dynamic Range Control) Make the sound clear when the volume is turned down (Dolby Digital only). Set to [On] for this effect. Initial Setting the Area Code: When you use this unit for the first time, you have Vocal to set the Area Code. -
Page 27: Others
System Setting Others Password You can enter or change password. DivX(R) VOD 1. Select [Password] on the [Lock] menu and then press D. ABOUT DIVX VIDEO: DivX® is a digital video 2. Press b ENTER. format created by DivX, LLC, a subsidiary of Rovi Corporation. -
Page 28: Operating
Operating Using the Home Menu Basic Operations 1. Press n HOME. 1. Insert the disc by using the B OPEN/CLOSE or Displays the [Home Menu]. Connect the USB device to the USB port. 2. Press n HOME. Displays the [Home Menu]. 3. -
Page 29: Other Operations
Operating Other Operations Do this Press Z STOP. Stop Press d PLAY, MONO/ Displaying Disc Information Playback STEREO. on-screen Press M PAUSE/STEP. Pause You can display various information about the disc Press M PAUSE/STEP loaded on-screen. Frame-by- repeatedly to play title Frame- Frame playback 1. -
Page 30: To Display The Dvd Menu
Operating To display the DVD Menu numbers you entered. Then input the correct numbers. For example, to find a scene at 1 hour, 10 minutes, and 20 seconds, enter “11020” by using When you play a DVD which contains several menu, numerical buttons. -
Page 31: Marked Playback
Operating Marked Playback To delete all Markers Use WSAD to select [Deselect All] then press b ENTER in program edit mode. The mark function enables you to store your Note favourite files from any disc or USB device in the unit memory. -
Page 32: Viewing A Photo File
Operating Viewing a PHOTO file About help menu in the full screen Menu Buttons Operation This unit can play discs with photo files. Displaying the Option Menu INFO/ menu. 1. Select [Photo] on the [Home Menu] and press DISPLAY b ENTER. Moving to another file. -
Page 33: Sleep Timer Setting
Operating Sleep Timer Setting System Select - Optional Press SLEEP one or more times to select delay time You must select the appropriate system mode for between 10 and 180 minutes, after the unit will your TV system. Press and hold M PAUSE/STEP turn off. -
Page 34: Radio Operations
Operating Radio Operations Deleting a saved station 1. Press PRESET - / + to select a preset number you want to delete. Be sure that FM aerials are connected. (Refer to the page 22.) 2. Press CLEAR, the preset number will blink in the display window. -
Page 35: Sound Adjustment
Operating Note Sound adjustment y In some of surround modes, some speakers, there’s no sound or low sound. It depends on the mode of surround and the source of Setting the surround mode audio, it is not defective. y You may need to reset the surround mode, This system has a number of pre-set surround after switching the input, sometimes even sound fields. -
Page 36: Advanced Operations
Operating Note Advanced Operations y You can check the recording percentage rate for the USB record on the screen during the recording. (Audio CD or MP3/ WMA CD Recording to USB only) y During recording MP3/WMA, there is no You can record music or sound source to USB sound. -
Page 37: Troubleshooting
Troubleshooting Troubleshooting PROBLEM CORRECTION No power Plug the power cord into the wall outlet securely. Select the appropriate video input mode on the TV so the picture from the unit appears on the TV screen. No picture Connect the video cables securely to both the TV and unit. Select the correct input mode of the unit so you can hear the sound from the unit. -
Page 38: Appendix
Appendix Maintenance Notes on Discs Handling Discs Handling the Unit Do not touch the playback side of the disc. Hold the disc by the edges so that fingerprints do not get on the surface. Never stick paper or tape on the When shipping the unit disc. -
Page 39: Area Code List
Appendix Area Code List Choose an area code from this list. Area Code Area Code Area Code Area Code Singapore Afghanistan Fiji Monaco Argentina Finland Mongolia Slovak Republic Australia France Morocco Slovenia Nepal South Africa Austria Germany Belgium Great Britain Netherlands South Korea Bhutan... -
Page 40: Language Code List
Appendix Language code List Use this list to input your desired language for the following initial settings: [Disc Audio], [Disc Subtitle] and [Disc Menu]. Language Code Language Code Language Code Language Code Afar 6565 French 7082 Lithuanian 7684 Sindhi 8368 Frisian 7089 Macedonian... -
Page 41: Trademarks And Licenses
Appendix Trademarks and Licenses Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. -
Page 42: Specifications
Appendix Specifications General Power requirements Refer to main label. Power consumption Refer to main label. Dimensions (W x H x D) 360 x 60.5 x 299 mm without foot Net Weight (Approx.) 2.66 kg Operating temperature 41 °F to 95 °F (5 °C to 35 °C) Operating humidity 5 % to 90 % Bus Power Supply (USB) - Page 43 Appendix Front Speaker Type 2 way 3 speaker Impedance Rated 3 Ω Input Power 167 W Max. Input Power 334 W Net Dimensions (W x H x D) 200 x 500 x 200 mm Net Weight 1.3 kg Rear Speaker Type 2 way 3 speaker Impedance Rated...
