Page 1
OWNER’S MANUAL DVD Home Theater System Please read this manual carefully before operating your set and retain it for future reference. DH6535D (DH6535D, S72D3-F/ W) DH6535D-F0_DMARLLK_ENG_6022.indd 1 2014-07-15 5:24:49...
Page 2
This product shall not be placed in a built- in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instruction has been adhered to. DH6535D-F0_DMARLLK_ENG_6022.indd 2 2014-07-15 5:24:50...
Page 3
Safety way to remove the battery or the battery from the equipment: Remove the LG Electronics hereby declares that this/these old battery or battery pack, follow the steps product(s) is/are in compliance with the essential in reverse order than the assembly. To prevent...
– Deleting all the saved stations – OPTICAL In connection – Deleting a saved station – Home theater speaker ez setup – Improving poor FM reception Antenna Connection Sound adjustment – Setting the surround mode Advanced Operations – Recording to USB DH6535D-F0_DMARLLK_ENG_6022.indd 4 2014-07-15 5:24:50...
Page 5
Table of Contents Troubleshooting Troubleshooting Appendix Maintenance – Handling the Unit – Notes on Discs Area Code List Language code List Trademarks and Licenses Specifications DH6535D-F0_DMARLLK_ENG_6022.indd 5 2014-07-15 5:24:50...
Views Full HD picture quality with simple setup. Home Theater Speaker ez Setup FM antenna (1) Speaker cables (2) Listen to sounds from TV, DVD and Digital device with vivid 5.1 (2.1 or 2.0) ch mode. HDMI Cable (1) Video cable (1) DH6535D-F0_DMARLLK_ENG_6022.indd 6 2014-07-15 5:24:51...
If you try to play a DVD with a different regional operation and indicates that the function explained code from your unit, the message “Check in this owner’s manual is not available on that Regional Code” appears on the TV screen. specific media. DH6535D-F0_DMARLLK_ENG_6022.indd 7 2014-07-15 5:24:51...
When setting the optin to Live File System, y Playable Audio format : “AC3”, “PCM”, “MP3”, “WMA”. you cannot use it on LG players. (mastered/Live y Sampling frequency : within 32 to 48 kHz (MP3), File System : Disc format sysyem for Windows...
- You can control the sound in the menu or exits the setup level, input source, and power menu. switching of LG TVs as well. Hold POWER (TV) and press PR/ TITLE: If the current DVD title has CH (W/S) button repeatedly a menu, the title menu appears until the TV turns on or off.
1/! (POWER) Connects a USB device. Switches the unit ON or OFF. e R (OPEN/CLOSE) Opens or closes the disc tray. f T (PLAY/PAUSE) Starts playback. Pauses playback temporarily, press again to exit pause mode. DH6535D-F0_DMARLLK_ENG_6022.indd 10 2014-07-15 5:24:52...
(Interface for digital audio and video) d Antenna Connector h OPTICAL IN FM- Connects the FM wired antenna Connects to optical audio equipment. e AUX (L/R) INPUT Connects to an external source with 2 channel audio outputs. DH6535D-F0_DMARLLK_ENG_6022.indd 11 2014-07-15 5:24:52...
When connecting a woofer cord to the player, insert the connector until it clicks. 2. Connect the wires to the speakers. Connect the other end of each wire to the correct speaker according to the color coding: DH6535D-F0_DMARLLK_ENG_6022.indd 12 2014-07-15 5:24:52...
Turn it slightly speakers other than the subwoofer should be toward the center of the room to reduce the wall placed at the same distance from the listening reflections. position ( ). Unit DH6535D-F0_DMARLLK_ENG_6022.indd 13 2014-07-15 5:24:53...
When the HDMI connection with HDCP is not verified, TV screen is changed to black or green screen or the snow noise may occur on the screen. In this case, check the the HDMI connection, or disconnect the HDMI cable. DH6535D-F0_DMARLLK_ENG_6022.indd 14 2014-07-15 5:24:53...
Cable. Yellow Some functions of this unit are controlled by the TV’s remote control when this unit and LG TV’s with SIMPLINK are connected through HDMI connection. Controllable functions by LG TV’s remote control; Play, Pause, Scan, Skip, Stop, Power Off, etc.
ENTER to confirm your selection. Note If your TV does not accept the resolution you have set on the player, you can set resolution to 480p (or 576p) as follows: Press Z STOP for more than 5 seconds. DH6535D-F0_DMARLLK_ENG_6022.indd 16 2014-07-15 5:24:53...
3. Select the PORTABLE or AUX (L/R) INPUT (mono), connect it to the left (white) audio jack function by pressing P RADIO&INPUT. on the unit. 4. Turn on the portable player or external device and start it playing. DH6535D-F0_DMARLLK_ENG_6022.indd 17 2014-07-15 5:24:54...
External HDD, Card readers, Locked devices, or hard type usb devices are not supported. y USB port of the unit cannot be connected to PC. The unit can not be used as a storage device. DH6535D-F0_DMARLLK_ENG_6022.indd 18 2014-07-15 5:24:54...
AUX OPT directly. 3. Listen sound with 5.1(2.1 or 2)ch speaker. 4. To escape from AUX OPT by using the OPTICAL. Function is retuned to previous one. To the digital optical output jack of your component DH6535D-F0_DMARLLK_ENG_6022.indd 19 2014-07-15 5:24:54...
Connecting Antenna Connection Connect the supplied FM antenna for listening to the radio. Connect the FM Wire antenna to the FM antenna connector. Note Be sure to fully extend the FM wire antenna. DH6535D-F0_DMARLLK_ENG_6022.indd 20 2014-07-15 5:24:54...
2. Use WSAD to select a language then press b ENTER. b ENTER To confirm menu. The confirm menu will appear. Select 3. Use AD to select the [Enter] then press b ENTER to finish the language setup. DH6535D-F0_DMARLLK_ENG_6022.indd 21 2014-07-15 5:24:54...
4. Adjust options using WSAD buttons. and press b ENTER. Press b ENTER again to 5. Returns to the previous menu by pressing x stop. Adjust the volume to match the volume RETURN. of test signals memorized in the system. DH6535D-F0_DMARLLK_ENG_6022.indd 23 2014-07-15 5:24:55...
Rating one (1) has the most restrictions and rating eight (8) is the least restrictive. [Unlock] If you select unlock, parental control is not active and the disc plays in full. 4. Press b ENTER to confirm your rating selection. DH6535D-F0_DMARLLK_ENG_6022.indd 24 2014-07-15 5:24:55...
2. Input a password and press b ENTER. 3. Select the first character using WS buttons. 4. Press b ENTER and select the second character using WS buttons. 5. Press b ENTER to confirm your Area code selection. DH6535D-F0_DMARLLK_ENG_6022.indd 25 2014-07-15 5:24:55...
[Photo] option when the USB device is not the USB storage device or disc automatically. connected and a disc is not inserted. y The DTS is not supported. In case of DTS audio format, audio is not output. DH6535D-F0_DMARLLK_ENG_6022.indd 26 2014-07-15 5:24:55...
- Audio CD/ MP3/ WMA : Track/ All/ Random/ Off In the pause mode, press SCAN (c or v) to select Slowing down the playing the required speed. (DVD, DivX speed only) The DivX file cannot be slow down reverse playback. DH6535D-F0_DMARLLK_ENG_6022.indd 27 2014-07-15 5:24:55...
4. Press x RETURN to exit the On-Screen display. To start playing at any chosen time on the file or title. 1. Press m INFO/DISPLAY during playback. 2. Press WS to select the time clock icon and “--:--:--” appears. DH6535D-F0_DMARLLK_ENG_6022.indd 28 2014-07-15 5:24:55...
4. Select the play mode by using the and press ENTER. [Mark Play] Marked playback. [Current Play] Normal playback. Note If you want to select all files on the list, select [Select All] and press b ENTER. DH6535D-F0_DMARLLK_ENG_6022.indd 29 2014-07-15 5:24:55...
Viewing a particular show. b ENTER Select file. d Rotate – Press ENTER to rotate the photo. Returning to the x RETURN e Go to list – Press ENTER to return [Photo] Close [Home Menu]. menu. DH6535D-F0_DMARLLK_ENG_6022.indd 30 2014-07-15 5:24:55...
Power Resume - Optional Even if the power suddenly goes out, turn on the unit and then it plays a position where the contents is being played. System will periodically save current playback status. DH6535D-F0_DMARLLK_ENG_6022.indd 31 2014-07-15 5:24:55...
6. Repeat the steps 2 to 5 to store other stations. Deleting all the saved stations 1. Press and hold CLEAR for two seconds. “ERASE ALL” will flash up on the unit display. 2. Press CLEAR to erase all saved of the radio stations. DH6535D-F0_DMARLLK_ENG_6022.indd 32 2014-07-15 5:24:55...
LOUDNESS sound. You can enjoy the sound BYPASS without equalizer effect. You can enjoy the harmonious P-FRONT sound. This mode is suited (POWER FRONT) for front-positioned speakers -Optional when they are all placed in a row. DH6535D-F0_DMARLLK_ENG_6022.indd 33 2014-07-15 5:24:55...
The making of unauthorized copies of copy- protected material, including computer programs, files, broadcasts and sound recordings, may be an infringement of copyrights and constitute a criminal offense. This equipment should not be used for such purposes. Be responsible Respect copyrights. DH6535D-F0_DMARLLK_ENG_6022.indd 34 2014-07-15 5:24:56...
The remote control doesn’t work There is an obstacle in the path between the remote control and well / at all the unit. Remove the obstacle. The battery in the remote control are flat. Replace the battery with new ones. DH6535D-F0_DMARLLK_ENG_6022.indd 35 2014-07-15 5:24:56...
Maintaining the Unit The unit is a high-tech, precision device. If the optical pick-up lens and disc drive parts are dirty or worn, the picture quality could be diminished. For details, please contact your nearest authorized service center. DH6535D-F0_DMARLLK_ENG_6022.indd 36 2014-07-15 5:24:56...
Jamaica Philippines Ukraine Costa Rica Japan Poland United States Croatia Kenya Portugal Uruguay Czech Republic Kuwait Romania Uzbekistan Denmark Libya Russian Vietnam Federation Ecuador Luxembourg Zimbabwe Saudi Arabia Egypt Malaysia Senegal El Salvador Maldives Ethiopia Mexico DH6535D-F0_DMARLLK_ENG_6022.indd 37 2014-07-15 5:24:56...
Licensing LLC in the United States and other countries. “DVD Logo” is a trademark of DVD Format/Logo Licensing Corporation. DivX®, DivX Certified® and associated logos are trademarks of Rovi Corporation or its subsidiaries and are used under license. DH6535D-F0_DMARLLK_ENG_6022.indd 39 2014-07-15 5:24:56...
167 W + 167 W (3 Ω at 1kHz) Front 167 W + 167 W (3 Ω at 1 kHz) Surround mode Subwoofer 167 W (3 Ω at 60 Hz) Tuner FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz DH6535D-F0_DMARLLK_ENG_6022.indd 40 2014-07-15 5:24:56...
Page 41
3 Ω Input Power 167 W Max. Input Power 334 W Net Dimensions (W x H x D) (273 x 390 x 364) mm Net Weight 7.4 kg Design and specifications are subject to change without notice. DH6535D-F0_DMARLLK_ENG_6022.indd 41 2014-07-15 5:24:56...
