C&H Active Module Carrier VX402C-64 User Manual

Active module carrier
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
U S E R ' S
M A N U A L
A C T I V E M O D U L E
C A R R I E R
M O D E L
V X 4 0 2 C - 6 4
Document Part No: 11028504B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Active Module Carrier VX402C-64 and is the answer not in the manual?

Questions and answers

Related Manuals for C&H Active Module Carrier VX402C-64

Summary of Contents for C&H Active Module Carrier VX402C-64

  • Page 1 U S E R ’ S M A N U A L A C T I V E M O D U L E C A R R I E R M O D E L V X 4 0 2 C - 6 4 Document Part No: 11028504B...
  • Page 2 C&H Technologies, Inc. (C&H) provides this manual "as is" without warranty of any kind, either expressed or implied, including but not limited to the implied warranties of merchantability and fitness for a particular purpose. C&H may make improvements and/or changes in the product(s) and/or program(s) described in this manual at any time and without notice.

  • Page 3: Revision History

    C&H Technologies, Inc. makes every attempt to provide up-to-date manuals with the associated equipment. Occasionally, changes are made to the equipment wherein it is necessary to provide amendments to the manual. If any amendments are provided for this manual they are printed on colored paper and will be provided with the module and manual.
  • Page 4 This manual describes the operation and use of the C&H Model VX402C-64 VXI Active Carrier Module (Part Number 11028500 Revision B or higher). This VXI module is one of a number of test and data acquisition/control modules in the VME and VXI format provided by C&H. Contained within this manual are the physical and electrical specifications, installation and startup procedures, functional description, and configuration guidelines to adequately use the product.

  • Page 5: Table Of Contents

    1.0 GENERAL DESCRIPTION ... 7 1.1 PURPOSE OF EQUIPMENT... 7 1.2 SPECIFICATIONS OF EQUIPMENT... 8 1.2.1 Key Features ... 8 1.2.2 Electrical ... 8 1.2.3 Mechanical... 10 1.2.4 Environmental... 10 1.2.5 Bus Compliance ... 10 2.0 INSTALLATION ... 11 2.1 UNPACKING AND INSPECTION ... 11 2.2 HANDLING PRECAUTIONS...
  • Page 6 LIST OF FIGURES Figure 1. Front Panel and Top View (Top Shield Not Shown) ...7 Figure 2. Power Schematic (-0001 version)...8 Figure 3. Power Schematic (-0002 version)...9 Figure 4. Power Schematic (-0003 & -0004 versions)...9 Figure 5. Functional Block Diagram ...13 Figure 6.

  • Page 7: General Description

    1.0 GENERAL DESCRIPTION The VX402C-64 Active Carrier allows an A- or B-size VME, VXI, or VME64 module to be used in a C-size VXI mainframe chassis. Throughout the rest of this manual, the VME/VXI card being carried will be referred to as the VME module. The carrier provides an actively-buffered electrical interface for the standard VME bus signals.

  • Page 8: Specifications Of Equipment

    1.2 SPECIFICATIONS OF EQUIPMENT 1.2.1 Key Features  Provides direct access to the VME module’s front panel I/O connections  Supplies buffered data, address, interrupt, and trigger lines (ECL and TTL)  Includes direct SUMBUS connections, as well as a prototyping area with fused ±12V power supplies for buffered SUMBUS connections (jumper selectable) ...

  • Page 9: Figure 4. Power Schematic (-0003 & -0004 Versions)

    BACKPLANE (7 PINS) INTERNAL LOGIC Figure 3. Power Schematic (-0002 version) BACKPLANE (7 PINS) INTERNAL LOGIC +24V or -24V (1 PIN) Figure 4. Power Schematic (-0003 & -0004 versions) VME64 CONNECTORS (7 PINS) VME64 CONNECTORS (7 PINS) OUT- ISOLATED DC-DC OUT+ +3.3V CONVERTER...

  • Page 10: Mechanical

    Table I. Power Supply Capabilities VXI +5V Supply Capability VXI +24V Supply Capability VXI -24V Supply Capability Internal +5V Power Consumption Remaining +5V Power Available +3.3V Converter Efficiency +5V Power Available to VME Module +3.3V Power Available to VME Module n/a = not applicable 1.2.3 Mechanical The mechanical dimensions of the VX402C-64 are in conformance with the VXI bus...

  • Page 11: Installation

    2.0 INSTALLATION 2.1 UNPACKING AND INSPECTION In most cases the VX402C-64 is individually sealed and packaged for shipment. Verify that there has been no damage to the shipping container. If damage exists then the container should be retained as it will provide evidence of carrier caused problems. Such problems should be reported to the carrier immediately as well as to C&H.

  • Page 13: Functional Description

    3.0 FUNCTIONAL DESCRIPTION 3.1 GENERAL VX402C-64 is a general purpose carrier module for VXI C-Size chasses. The module provides actively buffered signals, which meet all VME specifications, to the VME module. A functional block diagram is shown in Figure 5. To VME Module Figure 5.

  • Page 14: Triggers

    3.2 TRIGGERS Both ECL and TTL triggers are supplied through the VX402C-64. There are switches on the carrier which are used to set the direction of the triggers (to the backplane and from the backplane). 3.2.1 TTL TRIGGERS Eight TTL Trigger lines pass through the VX402C-64 to the front panel: TTLTRG0-7. Each trigger line may be set as an input or output trigger.

  • Page 15: Ecl Triggers

    3.2.2 ECL TRIGGERS The VX402C-64 supports two ECL Trigger lines: ECLTRG0-1. Each trigger line may be set as an input or output trigger. The trigger direction is set using switch S2 which can be seen in Figure 7. The trigger directions are clearly marked on the board itself. ECLTRG0 ECLTRG1 Figure 7.

  • Page 16: Pass-Through Connectors

    3.3.3 PASS-THROUGH CONNECTORS One major difference between the VME bus and the VXI bus is that the outer rows of the P2 connector are not defined on the VME bus and they are defined on the VXI bus. For this reason, the VX402C-64 Active Module Carrier provides a Pass-Through Connector system that be used to optionally connect or not connect the VME P2 Rows A &...

  • Page 17: Table Ii. Vxi/Vme Pass-Through Connections

    A one-to-one cable that connects Pin 1 (C32) on the VXI side to Pin 1 (C32) on the VME side, and so on, could only be used if the VME module was designed to meet all of the VXI bus specifications for these pins.

  • Page 18: Figure 9. Sumbus Custom Area

    3.4 SUMBUS CONFIGURATION The VX402C-64 provides a direct connection of the SUMBUS signal through the pass-through connector to the front connectors. The board also has a prototyping area so that the user can hardwire a custom buffer for the SUMBUS signal. 3.4.1 SUMBUS CUSTOM AREA The SUMBUS custom area consists of a prototyping grid, ±12V supplies, and two jumpers for configuring the signal.

  • Page 19: Sumbus Jumper Settings

    3.4.2 SUMBUS JUMPER SETTINGS In order to use the SUMBUS signal, the jumpers J11 and J12 must be configured properly. The three different settings for the jumpers can be seen in Figure 10. The SUMBUS signal can be connected directly to the front panel (A), connected through the prototyping area (B), or disconnected (C).

  • Page 21: Operating Instructions

    4.0 OPERATING INSTRUCTIONS While the VX402C-64 is an active carrier, it is designed to be completely transparent to the host interface. For this reason, the VME module can be accessed as if it were plugged directly into the host backplane. In order to operate the VME module, first set up the hardware configurations on the VX402C-64.

  • Page 23: Appendix A - Connectors

    APPENDIX A - CONNECTORS ACFAIL* BGIN0* BGOUT0* BGIN1* BG0UT1* BGIN2* BG0UT2* SYSFAIL* BGIN3* BERR* BGOUT3* SYSRESET* LWORD* +12 V +5VSTBY +5 V Figure A-1. P1 Pin Configuration NOTE: BGINx tied directly to BGOUTx SYSCLK DS1* DS0* WRITE* DTACK* IACK* IACKIN* IACKOUT* IRQ7* IRQ6*...
  • Page 24 CLK10+ CLK10- RSV1 -5.2V LBUSC00 LBUSC01 LBUSC02 LBUSC03 LBUSC04 LBUSC05 LBUSC06 LBUSC07 LBUSC08 LBUSC09 -5.2V LBUSC10 LBUSC11 TTLTRG1* TTLTRG3* TTLTRG5* TTLTRG7* RSV3 +24V -24V Figure A-2. P2 Pin Configuration ECLTRG0 ECLTRG1 LBUSA00 LBUSA01 -5.2V LBUSA02 LBUSA03 LBUSA04 LBUSA05 -5.2V LBUSA06 LBUSA07 LBUSA08 LBUSA09...
  • Page 25 BD08 BD09 BD10 BD11 BD12 BD13 BD14 BD15 BSYSFAIL* BBERR* +3.3V BSYSRESET* BLWORD* +3.3V BAM5 BA23 +3.3V BA22 BA21 +3.3V BA20 BA19 +3.3V BA18 BA17 +3.3V BA16 BA15 +3.3V BA14 BA13 +3.3V BA12 BA11 +3.3V BA10 BA09 +3.3V BA08 +12 V Figure A-3.
  • Page 26 Figure A-4. J2 Pin Configuration NOTES: 1. Signals on Rows A & C are only connected, if the pass-through cable is installed. 2. +3.3V supplied on Version -0001 only CLK10+n CLK10-n GND14 RSV1 -5.2V5 BA24 LBUSC00n BA25 LBUSC01n BA26 GND12 BA27 LBUSC02n BA28...
  • Page 27 TO FRONT CONNECTOR J2 -24Vn BSUMBUSn +24Vn GND02 RSV3n GND03 BTTLTRG7*n BTTLTRG6*n BTTLTRG5*n BTTLTRG4*n GND05 BTTLTRG3*n BTTLTRG2*n BTTLTRG1*n BTTLTRG0*n GND06 LBUSC11n LBUSC10n -5.2V1 LBUSC09n LBUSC08n GND08 LBUSC07n LBUSC06n -2V1 LBUSC05n LBUSC04n GND10 LBUSC03n LBUSC02n GND12 LBUSC01n LBUSC00n -5.2V5 GND14 BECLTRG1n CLK10-n CLK10+n BECLTRG0n...
  • Page 29 N O T E S :...

  • Page 31: Reader's Comment Form

    READER'S COMMENT FORM Your comments assist us in improving the usefulness of C&H's publications; they are an important part of the inputs used for revision. C&H Technologies, Inc. may use and distribute any of the information that you supply in any way that it believes to be appropriate without incurring any obligation whatsoever.
  • Page 32 In its continuing effort to improve documentation, C&H Technologies, Inc. provides this form for use in submitting any comments or suggestions that the user may have. This form may be detached, folded along the lines indicated, taped along the loose edge (DO NOT STAPLE), and mailed.
