CHILDREN'S
ELECTRONIC TOY CAR
With remote control function
Model No.: JE009
Item No.: 5156
•
Suitable for 2+ years
•
Maximum user weight: 20kg
•
Adult assembly required
OWNER'S MANUAL
Read and understand this entire manual before using!
Please keep this manual for future reference as it contains important
information.
Before first time use, charge the battery for at least 8-10 hours.
Advertisement
Related Manuals for Hunter Products JE009
Summary of Contents for Hunter Products JE009
- Page 1 CHILDREN'S ELECTRONIC TOY CAR With remote control function Model No.: JE009 Item No.: 5156 • Suitable for 2+ years • Maximum user weight: 20kg • Adult assembly required OWNER'S MANUAL Read and understand this entire manual before using! Please keep this manual for future reference as it contains important information.
- Page 2 Table of Contents 1. About Your New Vehicle 2. Parts List 3. Parts Diagram 4. Assembly Steps 5. How To Operation Your Vehicle 6. Charging The Vehicle 7. Troubleshooting Guide 8. Maintaining Your Vehicle 9. Disposal Of Battery About Your New Vehicle Thank you for your purchasing our products, we wants your child to enjoy this product for years to come.
- Page 3 Parts List Q’ty REMARKS Q’ty REMARKS Par t PART Par t PART PART PART PICTURE PICTURE (pcs) (pcs) NAME NAME Vehicle Gear body Placed Outer Driving in the assembly bush wheel package 1pcs Ø10 Ø10 for spare wahser cap nut Inner Wheel bush cover...
- Page 4 Parts List Assembly package Q’ty REMARKS Q’ty REMARKS Par t Par t PART PART PART PART PICTURE PICTURE (pcs) (pcs) NAME NAME Placed Steering on the Ø5 nut steering wheel wheel Placed Placed M5x12 M5x35 on the in vehicle steering screw screw body wheel Remote...
- Page 5 PLEASE NOTE: IN CASE OF PRODUCT FAULT DO NOT RETURN THIS PRODUCT TO STORE. PLEASE CONTACT HUNTER PRODCUTS CUSTOMER SERVICE TOLL FREE NUMBER: 1800 224 094 OR VISIT WWW.ELECTRICRIDEON.COM.AU...
- Page 6 Assembly Steps • Your new vehicle requires adult assembly. Please set aside at least 40 minutes for assembly. Children can be harmed by small parts, sharp edges and sharp points in the vehicle's unassembled state. Care should be taken in unpacking and assembly of the vehicle.
- Page 7 Assembly Steps 3. Steering Shaft assembly Match to the Ø10nut steering gear Ø10nut Split pin Split pin Ø10nut Steering shaft ● Turn the vehicle on its side. ● Turn the vehicle on its side. ● Insert the straight end of steering shaft through the hole in the vehicle body. And make the steering shaft Ø...
- Page 8 Assembly Steps 4. Steering Wheel assembly ● Remove the M5x35 machine screw with Steering wheel a screwdriver ● Insert the steering wheel onto end of M5x35 the steering shaft, line up the holes in the machine screw Ø5 nut steering wheel and the holes in steering shaft, insert the M5x35 machine screw and Ø5 nut back in the same location and tighten it with a screwdriver.
- Page 9 Assembly Steps 7. Motor Hood assembly ● Fit the motor hood on the motor. Ø3x12 screw ● Tighten the Ø3x12 screws*3 to secure Motor hood 8. Seat assembly ● Insert the tabs on the seat into the slots Seat on the vehicle body. M5x12 ●...
- Page 10 How To Operate Your Vehicle WARNING! PREVENT INJURIES AND DEATHS: • NEVER LEAVE CHILD UNATTENDED. DIRECT ADULT SUPERVISION IS REQUIRED. Always keep child in view when child is in vehicle. • Never use in roadways, near cars, on or near steep inclines or steps, swimming pools or other bodies of water.
- Page 11 How To Operate Your Vehicle Use Operation( Ensure the power switch has been turned on IMPORTANT! Power switch Conversion switch Always stop vehicle when changing the Forward-backward speed or direction to avoid damage the switch gear box and motor. NOTE! If you want to use the remote control operation.
- Page 12 Charging Your Vehicle handling. • Do not open the battery. Battery contains lead acid and other materials that are toxic and corrosive. • Do not open the charger. Exposed wiring and circuitry inside case may cause electric shock.• Only adults may handle or charge the battery. NEVER allow child to handle or charge the battery.
- Page 13 Troubleshooting Guide PROBLEM: The vehicle does not run ■ PROBLEM CAUSE: The battery may low on power. After each use, or once a month minimum, charge the battery for a full 10 hours. Do not leave the battery on the charger for more than 20 hours. POSSIBLE CAUSE: Thermal fuse has tripped.
- Page 14 Troubleshooting Guide PROBLEM: The vehicle does not run very long. ■ POSSIBLE CAUSE: Battery may be undercharged. You may not be charging the battery long enough. After each use, or once a month minimum, charge the battery for 8 to 10 hours. Do not leave the battery on the charger for more than 20 hours. POSSIBLE CAUSE: Battery is old.
- Page 15 HUNTER PRODUCTS Level 2, 424 Warrigal Road Moorabbin 3189 Ph: 1800 224 094 or visit www.electricrideon.com.au...
- Page 16 ● Return an exhausted battery to your local approved lead-acid battery recycle, such as a local seller of automotive batteries. ● Contact your local waste management officials for other information regarding the environmentally sound recycling and disposal of lead-acid batteries. HUNTER PRODUCTS CUSTOMER SERVICE TOLL FREE NUMBER: 1800 224 094 OR VISIT WWW.ELECTRICRIDEON.COM.AU...
- Page 17 Remote Control Electronic Toy Car Operation Instructions Adult operating required CONVERSION SWITCH Forward-backward switch Foot pedal Power switch INDICATOR LIGHT LEFT JOY STICK RIGHT JOY STICK ON-OFF SWITCH HOW TO USE THE REMOTE CONTROLLER 1. Press the CONVERSION SWITCH on the vehicle to “Remote control” . 2.
