- Page 1 NOTICE D’UTILISATION • OPERATING INSTRUCTIONS ISTRUZIONI D’USO • INSTRUCCIONES DE USO BEDIENUNGSANLEITUNG KPA8FIA0R5IBA KPA9FIB0R5IBA Split air conditioner system • Condizionatore d’aria split system Climatiseurs split • Split-klimagerät Acondicionador de aire de consola partida sistema split 37.4254.076.00 11/2015...
-
Page 2: Table Of Contents
CONTENTS NAME OF PARTS AND OPERATION SELECTOR SWITCH INSTALLATION LOCATION ELECTRICAL REQUIREMENTS SAFETY INSTRUCTIONS USING THE REMOTE CONTROL UNIT REMOTE CONTROL UNIT HOW TO SET THE PRESENT TIME COOLING HEATING AUTOMATIC OPERATION DEHUMIDIFYING (DRY) FAN ONLY ADJUSTING THE FAN SPEED NIGHT MODE/ENERGY SAVING HIGH POWER MODE SETTING THE TIMER... -
Page 3: Name Of Parts And Operation Selector Switch
NAME OF PARTS AND OPERATION SELECTOR SwITCh OFF LAMPS FUNTION 1. Remote control unit. 2. Remote control sensor: Detects the room temperature It is possible to set the air conditioner in order to let the around the remote control unit, the air conditioner is OPERATION, TIMER and STANDBY lamps always OFF, controlled accordingly. -
Page 4: Installation Location
INSTALLATION LOCATION USING ThE REMOTE CONTROL UNIT hOw TO INSTALL BATTERIES We recommend this air conditioner to be installed Remove trhe lid in the rear part of the remote control properly by qualified installation technicians in unit and check the settings of the four microswitches accordance with the installation instructions provided with the unit. -
Page 5: Remote Control Unit
REMOTE CONTROL UNIT DISPLAY I FEEL mode is active Information is displayed when the remote controller is switched (remote controller on. If switched off, only the operating mode, the room temperature sensor active) and the clock are shown Filter Ti0 is ON Operation mode Room... -
Page 6: How To Set The Present Time
hOw TO SET ThE PRESENT TIME DEFROSTING OF OUTDOOR UNIT hEAT EXChANGER 1. Press the button ST three times. When the outdoor temperature is low, frost or ice may The time indication alone flashes. appear on the heat exchanger coil, reducing the heating 2. -
Page 7: Dehumidifying (Dry)
A U T O M A T I C O P E R A T I O N I N M U L T I S P L I T FAN ONLY CONFIGURATION When the air conditioning system configuration is multisplit If you want to make air circulate without any temperature and there is more than one indoor unit connected, the control, press... -
Page 8: Setting The Timer
SETTING ThE 1 hOUR TIMER SETTING ThE TIMER A) hOw TO SET ThE ON TIME This function causes the unit to operate for one hour at the set conditions, regardless of whether the unit is on or off. 1. Press the ST button once. The ON and time indications flash. -
Page 9: Adjusting The Air Flow Direction
ADJUSTING ThE AIR FLOw DIRECTION CAUTION hORIZONTAL (manual) Do not move the flap with your hands when the air The horizontal air flow can be adjusted by moving the conditioner is running. vertical vanes to the left or right, as indicated in the following figures. -
Page 10: Operation Without The Remote Control Unit
AIR FILTER OPERATION wIThOUT ThE REMOTE CONTROL UNIT The filter behind the front panel should be checked and cleaned at least once every two weeks. If you have lost the remote control unit or it has troubles, follow the steps below. 1. -
Page 11: Tips For Energy Saving
TIPS FOR ENERGY SAVING A C T I V A T E D C A R B O N A I R F I L T E R (ACCESSORY SUPPLIED ON REQUEST) DO NOT: Block the air intake and outlet of the unit. The activated carbon air filter is to be added to the If they are obstructed, the unit will not work well, and standard filter. -
Page 15: Explanation And Use Of The Remote Control Unit's Microswitches
EXPLANATION AND USE OF ThE REMOTE CONTROL UNIT’S MICROSwITChES Switch 1 and 2: These switches are used to match the remote control with the specific internal units. Switch 3 and 4: these switches have been provided for future use; they have no function today. - Page 16 Z.I. Route départementale 28 01600 Reyrieux France Tél. 33 4 74 00 92 92 - Fax 33 4 74 00 42 00 Technibel is a trademark of NIBE ENERGY SYSTEM FRANCE...
