Dear Customer,
Thank you for choosing this quality product from ASKO.
We hope it will meet your expectations and fulfill your needs for many years to
come. Scandinavian design combines clean lines, everyday functionality, and
high quality. These are key characteristics of all our products and the reason
they are greatly appreciated throughout the world.
To get the most out of your new dishwasher, we recommend that you read the
operating instructions before using it. The operating instructions also include
information on how you can help protect the environment.
Do you need this Use&Care Guide in spanish? Log onto
www.askona.com/customer-care to download.
¿Necesita esta Instrucciones de uso y cuidado en español? Entre en
www.askona.com/customer-care y descárguesela.
Operating Instructions
Dishwasher
ASKO D5656XXLHS
Advertisement
Table of Contents
Related Manuals for Asko D5656XXLHS
Summary of Contents for Asko D5656XXLHS
- Page 1 Dear Customer, Thank you for choosing this quality product from ASKO. We hope it will meet your expectations and fulfill your needs for many years to come. Scandinavian design combines clean lines, everyday functionality, and high quality. These are key characteristics of all our products and the reason they are greatly appreciated throughout the world.
-
Page 2: Table Of Contents
Contents Front panel Care and maintenance instructions Important safety instructions Troubleshooting Before washing for the first time Technical information Loading the dishwasher Service Using the dishwasher Program chart Settings Notes Front panel On/Left-on mode Rinse aid indicator Delayed start Program selector Child lock (button lock) 10 Set time (for the Time program) Program symbol... -
Page 3: Important Safety Instructions
Important safety instructions SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE Should a child swallow dishwasher detergent or rinse aid, give plenty to drink immediately, i.e., one or two glasses of milk or water. Do not try to induce vomiting. Seek medical WARNING! advice immediately: Call the National Capital Poison Center at 1-800-222-1222. -
Page 4: Before Washing For The First Time
Before washing for the first time Water supply Setting the rinse aid dosage The machine can be connected to either a hot (max. 160 °F, 70 The section Settings describes how to set rinse aid amount. The °C) or cold water supply. We recommend a cold water supply. rinse aid amount can be set from (Off) to (High dose). -
Page 5: Loading The Dishwasher
Loading the dishwasher Economic dishwashing Typical load for 10 place settings Run programs only with a full load Wait until the dishwasher is fully loaded before running a program, this way you save energy. Use the Rinse & Hold program to rinse the dishes if there are any unpleasant odors while you wait for the dishwasher to become fully loaded. - Page 6 Middle basket The middle basket's wire basket with spray pipes is suitable for short objects. The middle basket's utensil basket has space for ladles, whisks, serving cutlery, and similar items. Wire basket Utensil basket Washing larger items The two baskets in the middle basket can be removed, or the entire middle basket can be removed, to create more space be- tween the upper and lower baskets if larger items are being washed.
-
Page 7: Using The Dishwasher
Using the dishwasher Vase and bottle holder Add detergent Washing large plates Move adjustable tines and their mounts to widen the distance between the tine rows to adapt the lower basket to plates with a diameter greater than 9 3/4" (25 cm). 1 Prewash detergent compartment 2 Main wash detergent compartment Cutlery basket... -
Page 8: On/Left-On Mode
WARNING! Normal wash Children must be supervised – dishwasher detergent is corro- This program is recommended for daily, regular, or typical use sive! to completely wash a full load of normally soiled dishes, such as plates, serving dishes, cups, and glasses. No options are recom- mended. - Page 9 Start the dishwasher High temperature Press and hold Start/Stop until the display shows (the door Activate this option for improved dishwashing results. The ma- open symbol). This indicates that the dishwasher is ready to start. chine then uses a higher temperature for the main wash. This Close the door properly, otherwise the dishwasher will not start.
- Page 10 Once the program has finished Once the program has finished, "End" appears on the display. At the end of the program, one short signal will sound. Chapter Settings describes how to change this function. Once the cycle is complete, the dishwasher uses standby power only.
-
Page 11: Settings
Settings Do as follows to open the settings menu: First, open the door. Turn off the dishwasher using the On/Left-on mode button (press and hold). Release the button. Press and hold the On/Left-on mode button until the display lights up. Within five seconds, press and hold the Program selector and the Long dry button. - Page 12 Button press Options Settings Description Operation volume This sound is used to confirm each button press. (Off) (Low) (High) Press Start/Stop to save the setting value and continue to the next setting. LCD contrast For adjusting the contrast of the display on the front (Display on the front of the door) door.
-
Page 13: Care And Maintenance Instructions
Care and maintenance instructions Coarse filter NOTE! The coarse filter traps larger food particles, which cannot get The dishwasher must not be used without the filters in place! past the drain pump. Empty the coarse filter as necessary. Dishwashing results may be affected if the coarse filter is incor- 1 Lift the coarse filter by the handle. - Page 14 Door When cleaning the edge around the door, use only a slightly damp cloth (with a little cleaner if necessary). WARNING! Do not use a spray bottle or the like around the door lock. This is to ensure that water does not penetrate the door catch and come into contact with the electrical components.
-
Page 15: Troubleshooting
Troubleshooting Display Type of fault Action Overfilling Call the Customer Care Center. Water outlet fault See "Water remains in the dishwasher above the filters" in the table below. Water inlet fault Check that the water supply valve is on. Inlet valve leakage Turn off the water supply valve and call the Customer Care Center. - Page 16 Problem Possible causes Action The dishwasher does not start. The Start/Stop start button has been pressed Press and hold Start/Stop until the display for too short a time. shows (the door open symbol). This indicates that the dishwasher is ready to start. The door is not properly closed.
- Page 17 Problem Possible causes Action The touch buttons do not react when You have pressed the touch buttons too soon Wait a moment then try again. pressed. after opening the door. Dirt on the touch buttons. Clean with a dry or slightly damp cloth. Open the door until the display illuminates or close the door and wait 30 seconds.
-
Page 18: Technical Information
Technical information Technical data Height: 34-3/8" - 36-1/2" (873-927 mm) Width: 24" (610 mm) Depth: 22-7/8" (581 mm) Weight: 110 lb (50 kg) Water pressure: 4.2–140 psi Electrical connection: See serial number tag and rating plate. Rated power: See serial number tag and rating plate. Weight can vary due to different specifications. -
Page 19: Service
ASKO service company is not available. as well, contact us at the address information below: 9 The removal and reinstallation of the ASKO Product if it is in- stalled in an inaccessible location or is not installed in accor- ASKO Distribution North America, LLC dance with ASKO’s published installation instructions. -
Page 20: Program Chart
Program chart... -
Page 21: Notes
Notes... - Page 22 Notes...
- Page 23 Notes...
- Page 24 Quick guide Load the baskets (See page 5.) Do not rinse dishes under running water before loading them in the dishwasher. Simply scrape off large food particles before loading the dishwasher. Check that the spray arms can rotate freely Check also that the water supply valve is on. Add detergent The detergent compartment has a small compartment for prewash and a large compartment for the main wash.
