Great Outdoors Grill Company 7000 Series Owner's Manual And Assembly Manual

Cmf corp portable gas barbecue grill owner's manual 7000
Hide thumbs Also See for 7000 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
O w n e r 's M a n u a l
ASSEMBLER / INSTALLER:
Leave these instructions with the consumer
CONSUMER / USER:
Read all of these instructions, and keep them in a safe place for future reference.
FOR YOUR SAFETY
If you smell gas:
1
Shut o gas to the appliance.
2
Extinguish any open ame.
3
Open lid.
4
If odor continues, immediately call
your gas supplier or re department.
Model 7000
Portable Gas
Barbecue Grill
and A s s e m b l y
FOR YOUR SAFETY
1
Do not store or use gasoline or other
ammable vapors and liquids in the vi
cinity of this or any other appliance.
2
An unconnected liquid propane cylin
der should not be stored in the vicinity
of this or any other appliance.
AO000102-901
Series
G u i d e
-
-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7000 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Great Outdoors Grill Company 7000 Series

Summary of Contents for Great Outdoors Grill Company 7000 Series

  • Page 1 Shut o gas to the appliance. Extinguish any open ame. Open lid. If odor continues, immediately call your gas supplier or re department. Model 7000 Series Portable Gas Barbecue Grill and A s s e m b l y FOR YOUR SAFETY...

  • Page 2: Table Of Contents

    Service Note: If you are experiencing difficulties or are dissatisfied with your purchase, please contact CFM at the telephone number listed above prior to returning your grill to the store. CFM Corporation 2695 Meadowvale Boulevard Mississauga, Ontario L5N 8A3 Canada (800) 668-5323 www.cfmcorp.com...

  • Page 3: Chapter One - Installation

    Series 7000 Models Installation Chapter Important Information Necessary to Safely Use a Gas Grill. The L.P. Gas Fuel Supply System Correct Filling and Handling of the L.P. Gas Fuel Cylinder...

  • Page 4: Choosing A Safe Location

    • Do not use lighter fluid or charcoal briquettes in a gas grill. The flow of combustion and venti- lation air is not to be obstructed. The ventilation openings of the cylinder enclosure must be kept free and clear from other debris.

  • Page 5: Portable L.p. Gas Grills

    The L.P. FUEL SUPPLY SYSTEM An L.P. gas grill requires a fuel delivery sys- tem made up of an L.P gas supply cylinder, a fuel regulator with hose and a gas-control valve.
  • Page 6 Portable L. P. Gas Barbecue Grills DANGER: Do not insert any foreign objects into the valve outlet. You may damage the back check. A damaged back check can cause a leak, which could result in explo- sion, fire, severe personal injury, or death. The cylinder must be arranged for vapor with- drawal.

  • Page 7: Take These Instructions To The L.p. Gas Dealer

    Take These Instructions to the L.P. Gas Dealer. When using a cylinder exchange, be sure the exchanged cylinder is a Type 1 cylinder; a 510 POL cylinder will not fit a Type 1 regulator. 1 L.P. G ILLING AND URGING DANGER! Purging and filling of L.P.

  • Page 8: Chapter Two - Assembly

    Series 7000 Models Assembly Instructions Chapter Getting Started 1. Please follow the steps in the order that they are presented. 2. Assemble the grill where you plan to use it. 3. You may want to place an old towel or cloth...

  • Page 9: Step 1 ( Identify Parts )

    ( 1 ) ceramic briquettes ( 1 package ) rock grate ( 1 ) grease pan ( 1 ) heat shield ( 1 ) Model 7000 (LP Gas L.P. gas Grills only) cylinder ( 1 ) cylinder retainer wire ( 1 )

  • Page 10: Step 2 ( Assemble Pillar To Base )

    Assembly Step 2 • Assemble the Pillar to Base. tools needed: 3/8” open-end wrench 7/16” open-end wrench Locate these parts: base ( 1 ) pillar ( 1 ) Use hardware bag “A”: 1/4-20 ( 4 ) 1. Lock the preassembled casters on base by pushing down on the latch.
  • Page 11 Your grill will now look like this > 2. Position the pillar upside down, and set the base onto the pillar as shown. Working from the open side of pillar: 3. Insert four bolts through the holes in the pillar and through the four holes in the base.

  • Page 12: Step 3 ( Attach Grill Bottom )

    Assembly Step 3 • Attach the Grill Bottom. tools needed: ⁄ " open-end wrench ⁄ " open-end wrench Locate these parts: Use hardware bag “B”: 1/4-20 ( 4 ) heat shield ( 1 ) hinge strut 1/4-20 x 1” ( 4 ) grill bottom ( 1 ) 1.
  • Page 13 Grill bottom as shown from below back. IMPORTANT : Make sure the control-valve ends are inside the burner tubes extending through the grill bottom. (See detail). 5. Insert four bolts into matching holes in the grill bottom and secure with nuts. Your grill will now look like this >...

  • Page 14: Step 4 ( Assemble Grill Lid )

    Assembly Step 4 • Assemble the Grill Lid tools needed: 7/16" open-end wrench flat-blade screwdriver Locate these parts: handle ( 1 ) handle standoff ( 2 ) grill lid ( 1 ) 1. Position the back of the lid so that the rear holes are in line with the hinge struts on the back of the grill bottom.
  • Page 15 3. Hold the lid to align the hinge holes. 4. Insert a hinge pin through the hinge hole in the lid and into the hole in the bottom hinge strut. 5. After the hinge pin is in place, insert a hair pin through the hole of the hinge pin to secure it.

  • Page 16: Step 5 (Side Tables )

    Assembly Step 5 • Attach the Side Tables to the Grill. tools needed: 3/8" open-end wrench 7/16" open-end wrench Locate these parts: side table ( 2 ) 1. Insert 3/4" bolts through holes in the support arms of the side tables. 2.

  • Page 17: Step 6 ( Rock Grate And Briquettes )

    Assembly Step 6 • Install the Rock Grate and Briquettes. No tools are needed. Locate these parts: rock grate ( 1 ) ceramic briquettes ( 1 box ) 1. Place the single rock grate into the grill bottom. 2. Open the package containing the ceramic briquettes and place them on the rockgrate.

  • Page 18: Step 7 ( Cooking Grids )

    Assembly Step 7 • Install the Cooking Grids. No tools are needed. Locate these parts: 4. Set the two porcelain coated cooking grids on the front and back ledges formed inside the grill bottom for a level cooking surface. 5. Set the warming rack onto the back of the cooking grids.

  • Page 19: Installing An L.p. Gas Cylinder

    Installing an L.P. Gas Cylinder. no tools needed Locate these parts: cylinder retainer wire L.P. gas ( 1 ) cylinder grease pan ( 1 ) (Behind and below the grill bottom.) WARNING: Connect the L.P. cylinder to the grill outdoors only. Fill the cylinder before connecting.

  • Page 20: Connecting An L.p. Gas Cylinder

    Connecting an L.P. Gas Cylinder. Connecting the Regulator to Cylinder 1. The top knob on the supply cylinder must be closed. See that the top cylinder knob is turned clockwise to a full stop. 2. Check that all the grill burner knobs are turned off.

  • Page 21: Connecting To Natural Gas (Model 7000N Only)

    Model 7000N • Connecting to Natural Gas DANGER: EXPLOSIVE AND FLAMMABLE! If the appliance is for connection to natural gas, the gas connections should be made by a qualified installer or a licensed plumber. The gas-supply line must not be installed by the consumer. The valve-orifices and fuel supply hose sys- tem necessary for use with natural gas is differ- ent than the system required for L.P.
  • Page 22 Model 7000N • Connecting to Natural Gas (for specially equipped natural-gas grills only) OPERATING THE QUICK-CONNECT Follow all directions on tags attached to hose. 1. To connect the fuel-supply hose to the fuel supply, the shut-off valve must be closed. 2.
  • Page 23 Series 7000 Models Use and Care Directions Chapter Leak Testing the Fuel Supply System Lighting Instructions Replacement Parts...

  • Page 24: Leak Testing

    DANGER To prevent fire or explosion hazard: · Do not smoke while performing a leak test. · Do not permit any sources of ignition in the area when testing for leaks. · Perform leak tests outdoors only. · Never perform a leak test near a fire or flame.

  • Page 25: Lighting Instructions

    IGNITER LIGHTING SYSTEM The Igniter System consists of an igniter unit, a gas-collector box, two ceramic electrodes, and lead wires. Gas is collected in the metal collector box located at the burner. When the igniter knob is turned, an electric spark is creat- ed at the ceramic electrodes.

  • Page 26: Match Lighting

    MATCH LIGHTING IMPORTANT! The match-lighting hole is found under the front right corner of the grill bottom. When match lighting the grill, use the gas-control knob on your RIGHT-HAND side (closest to the match-lighting hole). Repeat steps 1 to 4 of “Lighting Instructions.” STEP 5.

  • Page 27: Using Your Gas Grill

    YELLOW BLUE Holes in burner FLAME CHECK Checking the Burner Flame Using Your Gas Grill CONTROL SETTINGS The high flame setting is for quick searing of meat. Sear foods, then finish cooking on a lower setting. A medium setting works best for cooking steaks, pork chops, and hamburgers.
  • Page 28 “W-A” and with a tag stating “Suitable for Use with Outdoor Appliances.” Replacement Parts for Series 7000 Grills Replacement parts are available direct from our warehouse. Some components are not available preassembled and may be ordered separately. For convenience, the following parts list is provid- ed along with a representation of the items listed.
  • Page 29 Breakdown of Preassembled Components Preassembled Components quantity description Bottom/Burner Assembly consisting of: Cast Brass Burner Venturi Tube w/gasket AZ000506 #8-32 x 1⁄ 2 " Screw Bottom Grill Casting Pillar Assembly consisting of: Pillar Casting #10-24 x 3⁄ 8 " Screw Printed Control Plate 10 x 24 x 1⁄...
