Hitachi FT01 User Manual

Hitachi FT01 User Manual

Finger touch unit
Hide thumbs Also See for FT01:
Table of Contents

Advertisement

Quick Links

Download this manual
Finger Touch Unit
FT01
Model name
Thank you for purchasing a Finger Touch Unit specially designed for LCD
projectors.
Be sure to read this manual and the User's Manual supplied with the LCD
them away in a safe place for future reference.
Disclaimer

Table of Contents

Safety Symbols .................................................................. 2
Overview ........................................................................ 2
Regulatory notices ............................................................ 6
About Electro-Magnetic Interference .................................... 6
IN the US ........................................................................ 7
Contents of package ......................................................... 8
Part names ..................................................................... 9
Installation ..................................................................... 10
Installation Precautions ................................................... 10
Installation Procedure ................................................... 12
Finger Touch Unit adjustment procedure .............................. 17
Basic Finger Touch Operations .......................................... 23
Inspection and Cleaning ................................................... 23
Troubleshooting ............................................................ 24
NOTE
slightly from your product.
this manual.
permitted without express written consent.
describes are subject to change without prior notice.
we
damages arising from incorrect use or handling that exceeds normal
operating limits.
............................................................... 28
FT01
User's Manual
1


Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FT01 and is the answer not in the manual?

Questions and answers

Related Manuals for Hitachi FT01

Summary of Contents for Hitachi FT01

  • Page 1: Table Of Contents

    FT01 Finger Touch Unit FT01 User’s Manual Model name Thank you for purchasing a Finger Touch Unit specially designed for LCD projectors. Be sure to read this manual and the User’s Manual supplied with the LCD them away in a safe place for future reference.

  • Page 2: Safety Symbols

    FT-01 Safety Symbols The following symbols are used in this manual to help you use this product safely Read through the safety instructions below so you can operate the product correctly. result in serious personal injury or even death due to WARNING incorrect handling.
  • Page 3 FT-01 WARNING injury. Do not look directly into the laser output port. Do not point the laser beam towards people. Do not allow children to use. Use the Finger Touch Unit by securing it correctly to the screen. Continued use of the device when it is not functioning properly can company.
  • Page 4 FT-01 WARNING Do not place in locations where oil is used. of the plastic can also cause the device to fall when installed in a high Do not place in a locations with kitchens or locations where machine oil or other oils are used. the cables supplied with the device are not scratched or otherwise suitable cables.
  • Page 5 FT-01 CAUTION other parts can be damaged. Do not place near sources of heat or expose to direct sunlight or warm air. Do not insert this device or any of its accessories into a microwave oven. Do not cover this device with a cloth or other object. salt and mineral components contained in tap water are atomized by an breakdown or malfunction can result.

  • Page 6: Regulatory Notices

    Regulatory notices About Electro-Magnetic Interference In CANADA CAN ICES-3(B) / NMB-3(B). In the US, and other places where the FCC regulations are applicable Declaration of Conformity HITACHI / Dukane Trade name Model Number FT-01 Address U.S.A. Telephone Number +1 -800-448-2244 This device complies with part 15 of the FCC Rules.

  • Page 7: About Waste Electrical And Electronic Equipment

    FT-01 About Waste Electrical and Electronic Equipment Following information is only for EU-member states: The mark shown to the right is in compliance with the Waste Electrical and Electronic Equipment Directive 2002/96/EC (WEEE). The mark indicates the requirement NOT to dispose the equipment as according to local law.

  • Page 8: Contents Of Package

    FT-01 Contents of package Check that the items listed in the table below are included in this package. If any given in the table below. Symbol Part name Quantity Appearance Finger Touch Unit USB cable Double-sided tape Magnetic sheet Fixing screw Adjusting bar IR FILTER ** User's...

  • Page 9: Part Names

    FT-01 Part names Adjusting knob This knob is used to adjust the height and angle of the infrared laser beam. USB (B-type) mini-connector This is connected to the option port of the projector. Laser output port This is the window where the infrared laser beam is output.

  • Page 10: Installation

    FT-01 Installation Installation Precautions This device is an optional product for the LCD projectors. It cannot be used with other projectors. exceed 2 mm. Curvature or bending of the screen can cut off the infrared laser beam generated by the Finger Touch Unit so that the Finger Touch function does not operate. performed.
  • Page 11 FT-01 Install the Finger Touch Unit in the middle of the right and left edges of the projector display screen. Set the gap between the laser output port of the Finger Touch Unit and the projector display screen to 50 to 100 mm. screen edge by at least 50 mm.

  • Page 12: Installation Procedure

    FT-01 Installation Procedure WARNING ・ The Finger Touch Unit should never be installed by the customer. Be sure to always request installation by your dealer or service company. ・We will not be liable for any accidents or injuries that occur due to improper installation or improper usage of this device.
  • Page 13 FT-01 Installing the Finger Touch Unit Secure the Finger Touch Unit (A) in place using one of the three methods below. (1) Securing using double-sided tape Double-sided tape (C) Peel off the backing paper (red side) of strips to the Finger Touch Unit as shown Red side may be deteriorated unless four strips of double-sided tape are used.
  • Page 14 FT-01 Installing the Finger Touch Unit (continued) (2) Securing using magnetic sheet Magnetic sheet (D) CAUTION to bumpy metal surfaces. (3) Installation using screws Tightening torque:0.98N m(10kgf cm) Φ3.5 Fixing screws (E) CAUTION Be sure to always use screws when installing at heights of 2 meters or higher.
  • Page 15 FT-01 Connecting the USB cable (B) (1) Use a Phillips-head screwdriver to remove the cover of the option port of the projector. Use the USB cable (B) to connect the Finger Touch Unit (A) to the projector option port. Option port USB cable (B) Projector's Ports CAUTION...
  • Page 16 FT-01 Using the drop-prevention bar The Finger Touch Unit is provided with a drop-prevention bar that can be used with a commercially-available wire to prevent dropping of this device. Wire Drop-prevention bar Overall installation image An image of the Finger Touch Unit installation is shown below. Finger Touch Unit Laser Screen...

  • Page 17: Finger Touch Unit Adjustment Procedure

    FT-01 Finger Touch Unit adjustment procedure The adjustment procedure using a Windows PC is shown below. If using a Mac USB TYPE B port and the computer USB IWB button on the remote control (1) Use the IWB button on the remote control supplied with the projector to set the ★...
  • Page 18 FT-01...
  • Page 19 FT-01 (6) Secure the supplied adjusting bars (F) to the right and left edges of the projector display screen. Align the white print surface of the Adjusting bar sided tape to secure in place. Adjusting bar (F) (7) Set all the adjusting knobs so that they protrude about 8mm from the case.
  • Page 20 FT-01 (8) Turn the adjusting knob appears. (9) Turn the adjusting knob (10) Turn the adjusting knob the vertical center.
  • Page 21 FT-01 (11) to make the (12) Turn the adjusting knob clockwise until only one Adjusting bars each appears at the bottom right and bottom left of the screen. (13) Turn the adjusting knob counter-clockwise until two Adjusting bars each appear at the bottom right and bottom left of the screen. NOTE failed.
  • Page 22 FT-01 NOTE turn all the adjusting knobs from steps (8) to (14) again. ・ turn all the adjusting knobs adjustment from steps (8) to (14) again. (15) Gently attach the cover so that it does not touch the adjusting knobs. NOTE may also come off when removing the cover.

  • Page 23: Basic Finger Touch Operations

    FT-01 (20) This completes the adjustment of the Finger Touch Unit. Basic Finger Touch Operations Finger touch operations can be used to perform Windows mouse operations. Left-click Double-click Performing two quick clicking operations results in a double-clicking operation. Right-click performs a mouse right-click operation. Drag Inspection and Cleaning Cleaning the Finger Touch Unit...

  • Page 24: Troubleshooting

    FT-01 Troubleshooting WARNING and contact your dealer or service company. Phenomena that may be easy to be mistaken for machine defects according to the following table. Problem Checkpoints Ref. page Finger Touch Is the projector positioned too close to the screen? Use by installing at a position where the screen size function does is 60 to 100 inches when the digital zoom is set to the...
  • Page 25 FT-01 Troubleshooting (Continued) Problem Checkpoints Ref. page Finger Touch may have failed. function does not operate. (continued) − and cursor are not Is the projector installed in a tilted position? aligned. − Actual resolution may be different due to output image with a black frame depending on the type of laptop PC.
  • Page 26 FT-01 Troubleshooting (Continued) Problem Checkpoints Ref. page touch on an obstacle around the screen. operations Perform up to step (5) of the Finger Touch Unit are unstable adjustment procedure ( or stop. Perform the followings when there is an obstacle emitting (continued) removing them around the screen.
  • Page 27 FT-01 Troubleshooting (Continued) Problem Checkpoints Ref. page Are the Finger Touch Unit and projector installed correctly? touch Check each installation position. positioning alignment Is the computer image projected within the area of the cannot be screen? performed Use by installing at a position where the screen size correctly.
  • Page 28 FT-01 Item Model FT-01 Power supply/Rated current 200mA Power consumption Temperature range 0~40°C (Operating) 178 (W) x 58 (H) x 44 (D) mm Size below. Weight (mass) approx. 110g Trademark acknowledgment ® ® are registered trademarks of Microsoft Corporation in the U.S.
