Model/Modelo/Modèle
21987LF & 21988LF
Series/Series/Seria
Write purchased model number here.
Escriba aquí el número del modelo comprado.
Inscrivez le numéro de modèle ici.
You may need / Usted puede necesitar / Articles dont vous pouvez avoir besoin:
For easy installation of your Delta faucet
you will need:
・To READ ALL the instructions completely before
beginning.
・To READ ALL warnings, care and maintenance
information.
・To purchase the correct water supply hook-up.
Para instalación fácil de su llave Delta
usted necesitará:
・LEER TODAS las instrucciones completamente
antes de empezar.
・LEER TODAS los avisos, cuidados, e información
de mantenimiento.
・Comprar las conexiones correctas para el
suministro de agua.
Pour installer votre robinet Delta
facilement, vous devez:
・LIRE TOUTES les instructions avant de débuter.
・LIRE TOUE LES les avertissements ainsi que toutes
les instructions de nettoyage et d'entretien.
・Acheter le bon nécessaire de raccordement.
www.deltafaucet.com
TWO HANDLE WASHERLESS
86377
KITCHEN FAUCET
LLAVE DE FREGADEROS DOS
MANIJAS SIN ARANDELAS
ROBINET SANS RONDELLE À DEUX
MANETTES POUR ÉVIER DE CUISINE
21987LF
86377
1
21988LF
05/30/2016
Rev. B
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Delta 21988LF
Summary of Contents for Delta 21988LF
- Page 1 Inscrivez le numéro de modèle ici. 21987LF 21988LF You may need / Usted puede necesitar / Articles dont vous pouvez avoir besoin: For easy installation of your Delta faucet you will need: ・To READ ALL the instructions completely before beginning.
- Page 2 For Models Without A Spray Unit For Models With A Spray Unit SHUT OFF WATER SUPPLIES. Remove old faucet. Remove old SHUT OFF WATER SUPPLIES. Remove old faucet. Place gasket (1) faucet. Place gasket (1) on bottom of new faucet. proceed to step 3. on bottom of new faucet.
- Page 3 Set faucet into place and screw locknuts (1) onto threaded shanks (2) CONNECT TO WATER SUPPLIES. (HOOK-UPS NOT PROVIDED). and hand tighten. No wrench is required. Determine which type of connection you will be making. (1) Ball nose risers (3/8" O.D. copper tubing) with coupling nuts (not supplied) (A) or (2) 1/2"...
- Page 4 Care Instructions Care should be given to the cleaning of this product. To clean: ・ Wipe gently with a damp cloth. ・ Blot dry with a soft towel. Maintenance If spray attachment does not function properly: SHUT OFFWATER SUPPLIES A. Remove and clean Diverter Assembly (5) (page 5), or B.
- Page 5 ▲ Specify Finish Especifíque el Acabado Précisez le Fini RP42995▲ Hot & Cold Lever handles w/Buttons & Screws Manijas en Palanca con Botones y Tornillos de agua fría y caliente Manettes - leviers d’eau chaude et d’ eau froide avec boutons et vis RP74130▲...
- Page 6 Si la reparación o su reemplazo no es práctico, Delta Faucet Company tiene DELTA FAUCET COMPANY NO SE HACE RESPONSABLE POR CUALQUIER DAÑO ESPECIAL, la opción de reembolsarle su dinero por la cantidad del precio de compra a cambio de la devolución...
Need help?
Do you have a question about the 21988LF and is the answer not in the manual?
Questions and answers
How do I disconnect the sprayer hose?
To disconnect the sprayer hose on a Delta 21988LF, reach up to the top of the snap-on connection, squeeze the two tabs together, and gently pull down on the hose. The tabs move about 0.05 inches inward to release the connection.
This answer is automatically generated
How do you remove diverter RP41700 from Delta kitchen faucet 21988LF?
The manual does not provide step-by-step instructions for removing the diverter RP41700. However, it states that if the spray attachment does not function properly, you should remove and clean the Diverter Assembly (5) or replace it using Repair Kit RP41702. For detailed steps, refer to the illustrated instructions on the back of the Repair Part Kit.
This answer is automatically generated
