Related Manuals for Beko RFNE200E40WN
Summary of Contents for Beko RFNE200E40WN
- Page 1 Freezer User manual Gefrierschrank Bedienungsanleitung Congélateur Manuel d'utilisation Congelatore Manuale utente GF200E40WCHN - RFNE200E40WN EN / DE / FR / IT 58 5315 0000AB...
- Page 2 Please read this user manual first! Dear Customer, We hope that your product, which has been produced in modern plants and checked under the most meticulous quality control procedures, will provide you an effective service. Therefore, read this entire user manual carefully before using the product and keep it as a reference.
-
Page 3: Table Of Contents
CONTENTS 1 Your Freezer 4 Preparation 2 Important Safety Warnings 5 Using your freezer Intended use ..........5 Freezing fresh food ........19 General safety ..........6 Recommendations for preservation of For products with a ........10 frozen food ..........19 water dispenser; ........10 Placing the food ........19 Child safety ..........10 Deep-freeze information .... -
Page 4: Your Freezer
Your Freezer 1. Thermostat 2. Flap (Fast-Freeze compartment) 3. Drawers 4. Adjustable front feet C Figures that take place in this instruction manual are schematic and may not correspond exactly with your product. If the subject parts are not included in the product you have purchased, then it is valid for other models. -
Page 5: Important Safety Warnings
Important Safety Warnings Please review WARNING: following information. Do not damage the Failure to observe this refrigerant circuit. information may cause WARNING injuries material damage. Otherwise, all e l e c t r i c a l warranty and reliability appliances inside commitments... -
Page 6: General Safety
other residential • For products with a type environments; freezer compartment; – bed and breakfast type Do not put bottled environments; and canned liquid – catering and similar beverages in the non-retail applications. freezer compartment. Otherwise, these may General safety burst. - Page 7 • Do not damage the • Ensure highly alcoholic parts, where the beverages are stored refrigerant is circulating, securely with the lid with drilling or cutting fastened and placed tools. The refrigerant upright. that might blow out • Never store spray cans when the gas channels containing flammable of the evaporator, pipe...
- Page 8 Consult with the service • Never connect agent if you have any your refrigerator to concerns. electricity-saving systems; they may • Electrical safety of your damage the refrigerator. refrigerator shall be guaranteed only if the • If there is a blue light earth system in your on the refrigerator, do house complies with...
- Page 9 • Never place objects on top of the refrigerator; otherwise, these objects may fall down when you open or close the refrigerator’s door. • As they require a precise • Do not plug the temperature, vaccines, refrigerator if the wall heat-sensitive medicine outlet is loose.
-
Page 10: For Products With A
between devices 80 psi (5.5 bar), use a should be at least 8cm. pressure limiting valve Otherwise, adjacent in your mains system. If side walls may be you do not know how humidified. to check your water • The product shall never pressure, ask for the be used while the help of a professional... -
Page 11: Compliance With Weee Directive And Disposing Of The Waste Product
the key should be kept Package information away from reach of Packaging materials of the product children. are manufactured from recyclable materials in accordance with our • Children must be National Environment Regulations. Do supervised to prevent not dispose of the packaging materials them from tampering together with the domestic or other with the product. -
Page 12: Things To Be Done For Energy Saving
Ignore this warning if your • Thawing frozen food in fridge product's cooling system compartment will both provide contains R134a. energy saving and preserve the food Type of gas used in the product is quality. stated in the type label which is on the left wall inside the refrigerator. -
Page 13: Installation
Installation Check the following before you The manufacturer will not be start to use your freezer: liable for any event caused by 1. Attach 2 plastic wedges as disregarding the information illustrated below. Plastic wedges supplied in this user manual. are intended to keep the distance Points to be paid attention which will ensure the air circulation... -
Page 14: Electrical Connection
4. When the compressor starts to Disposing of the packaging operate, a sound will be heard. The The packing materials may be liquid and gases sealed within the dangerous for children. Keep the refrigeration system may also give rise to noise, even if the compressor packing materials out of the reach of children or dispose of them by is not running and this is quite normal. -
Page 15: Placing And Installation
Placing and Installation 6. If the product will be placed in an alcove, remember to leave at If the entrance door of the room least 5 cm clearance between the where the freezer will be installed is product and the ceiling, rear wall and not wide enough for the freezer to the side walls. - Page 16 Reversing the doors Proceed in numerical order . 45 ° 180°...
-
Page 17: Preparation
Preparation • Original packaging and foam • For a freestanding appliance; ‘this refrigerating appliance is not materials should be kept for future intended to be used as a built-in transportations or moving. appliance’ . • The baskets/drawers that are • Your refrigerator should be installed provided with the chill compartment at least 30 cm away from heat must always be in use for low energy... -
Page 18: Using Your Freezer
Using your freezer 1.Freezer Set Function This function allows you to make the Quick Freezer indicator will remain freezer compartment temperature lit when the Quick Freezer function is setting. enabled. To cancel this Press this button to set the function press Quick Freezer button temperature freezer again. -
Page 19: Freezing Fresh Food
Freezing fresh food 3. Take special care not to mix already frozen food and fresh food. • It must be preferred to wrap or cover Recommendations for the food before placing them in the preservation of frozen food refrigerator. • Hot food must cool down to the • Prepacked commercially frozen food room temperature before putting should be stored in accordance with... -
Page 20: Deep-Freeze Information
Freezing of Foodstuff Crisper Vegetables and fruits To activate fast freeze function, please turn the knob to MAX position. Delicatessen products Freshzone 50 hours after the fast freeze function (cheese, butter, salami compartment and etc.) was activated, the appliance with automaticly switch to normal function. -
Page 21: Maintenance And Cleaning
Maintenance and cleaning Never use gasoline, benzene or Check door seals regularly to ensure similar substances for cleaning they are clean and free from food purposes. particles. We recommend that you unplug the To remove door racks, remove all the appliance before cleaning. -
Page 22: Troubleshooting
Troubleshooting Please review this list before calling the service. It will save your time and money. This list includes frequent complaints that are not arising from defective workmanship or material usage. Some of the features described here may not exist in your product. The refrigerator does not operate. - Page 23 The operation noise increases when the refrigerator is running. • The operating performance of the refrigerator may change due to the changes in the ambient temperature. It is normal and not a fault. The refrigerator is running frequently or for a long time. • New product may be wider than the previous one.
- Page 24 Food kept in the fridge compartment drawers is frozen. • The fridge temperature is adjusted to a very high value. >>>Adjust the fridge temperature to a lower value and check. Temperature in the fridge or freezer is very high. • The fridge temperature is adjusted to a very high value. >>>Fridge compartment temperature setting has an effect on the temperature of the freezer.
- Page 25 Humidity occurs on the outside of the refrigerator or between the doors. • There might be humidity in the air; this is quite normal in humid weather. When the humidity is less, condensation will disappear. Bad odour inside the refrigerator. • No regular cleaning is performed.
