Summary of Contents for ViewSonic CD4225
-
Page 2: Table Of Contents
For Long Life Use of Public Display ... 33 Controlling the LCD monitor via RS-232C Remote Control ...34 Appendix: Installing stands ...35 Features ...36 Troubleshooting...37 Specifications...38 Product Specifications... 38 Supported Input Signal Resolution... 39 Note for Daisy-Chain Connection... 40 Customer Support...41 Limited Warranty...42 Mexico Limited Warranty...43 ViewSonic CD4225... - Page 3 ViewSonic CD4225...
- Page 4 ViewSonic CD4225...
- Page 5 ViewSonic CD4225...
- Page 6 ViewSonic CD4225...
-
Page 7: Safety Precautions
• Use the preset Size and Position controls with standard signals. • Use the preset Color Setting. • Use non-interlaced signals. • Do not use primary color blue on a dark background, as it is difficult to see and may produce eye fatigue due to insufficient contrast. ViewSonic CD4225... -
Page 8: Package Contents
Package Contents Your new CD4225 monitor box should contain the following: LCD monitor Quick Start Guide Power cord for North America VGA cable CD Wizard Wireless Remote Control AAA battery (x 2) Optional accessories Stand (STND-013) Speaker Monitor stand (x 2) -
Page 9: Parts Name And Functions
• Receives the signal from the wireless remote control. • Automatically detects ambient lighting condition and adjusts screen brightness. • Indicates the power status of the monitor. Status Color Power ON Green Power OFF Power Standby Orange Failure detected Flashing red Control Panel ViewSonic CD4225... -
Page 10: Terminal Panel
To input audio signals from external equipment such as a computer. SPEAKER OUT (8 Ω, 6W x 2) To output audio signals for external speakers from the LINE-IN, AUDIO-IN or HDMI jack. ViewSonic CD4225 Description Locks/unlocks all control buttons except the Power button ( Locks/unlocks the Menu/Enter button. - Page 11 Connects to the RS-232 output connector of a computer, or the RS232C-OUT connector of a multi- connected CD4225 monitor. RS232C-OUT (mini D-Sub 9 pin) Connects to the RS232C-IN connector of another CD4225 monitor. Y Pb Pr IN Connects to equipment such as a DVD player, HDTV device or Laser disc player.
-
Page 12: Remote Control
Remote Control ViewSonic CD4225 MUTE button To switch the mute function on/off. Power button Switches the power on/off. *If the Power indicator on the monitor is not glowing, then no controls will work. Number buttons These buttons are not used and do not work. -
Page 13: Installing The Remote Control Batteries
• Do not allow water or other liquid to splash the remote control. If the remote control gets wet, wipe it dry immediately. • Avoid exposure to heat and steam. • Other than to install the batteries, do not open the remote. ViewSonic CD4225... -
Page 14: Setup Procedure
“Power Save“ and “Image Retention“. 10. When CD4225 is installed in portrait position Conditions CD4225 can be installed in portrait position, under the following conditions: Caution: • Portrait position is effective only when wall-mounted or ceiling-mounted. • The stands (legs) can not be fitted to the monitor in portrait position. - Page 15 Do not place monitor in landscape in any other manner. How to set-up 1. Remove the stands (legs) if attached. 2. The ViewSonic logo should be on the LEFT side when facing the monitor. Counterclockwise ViewSonic CD4225 20 - 80% (without condensation)
-
Page 16: How To Mount And Attach Options To The Lcd Monitor
(Recommended torque: 470 - 635N•cm). The mounting interface should comply with the UL1678 standard in North America. The mounting means should strong enough to bear the weight of the monitor (approx. 24.5kg without stand). ViewSonic recommends using mounting interface that comply with TÜV-GS standard. -
Page 17: Ventilation Requirements For Enclosure Mounting
As shown in the figure, secure the monitor to a solid wall or pillar using rope (commercially available) strong enough to bear the weight of the monitor. (CD4225: approx. 26.4 kg) When you use screw hooks (commercially available), ring screw hooks, not C-shaped screw hooks (with opening), are recommended. -
Page 18: Connections
• First turn off the power of all the attached equipment and make connections. • Refer to the user manual included with each separate piece of equipment. Wiring Diagram LCD monitor (second monitor) PC or equipment with digital interface * Cables are not supplied ViewSonic CD4225... -
Page 19: Connecting A Personal Computer
• The LINE-IN jack can be used for audio input. • The SPEAKER OUT jack outputs sound from the selected Audio input. LCD monitor (second monitor) To analog RGB output To audio output * Cables are not supplied ViewSonic CD4225... -
Page 20: Connecting With Digital Interface Equipment
• The LINE-IN jack can be used for audio input. • The signal input from HDMI connector cannot be output to the VGA OUT connector. LCD monitor (second monitor) To DVI-D To HDMI To DVI-D output output output To audio output * Cables are not supplied ViewSonic CD4225... -
Page 21: Connecting A Dvd Player With Component Out
HDMI output of the DVD player. • The AUDIO-IN jacks can be used for audio input. Do not reverse the audio left and right jacks. To audio output ViewSonic CD4225 LCD monitor (second monitor) To HDMI output To Y Pb Pr output... -
Page 22: Connecting To External Speakers
Connect the LCD Monitor to External Speakers • Connect the lead wires of the external speakers to the SPEAKER OUT jacks of the LCD monitor. Do not reverse the audio left and right jacks. External speakers * Cables are not supplied ViewSonic CD4225... -
Page 23: Basic Operation
The power management feature on your new monitor has been set to the ”ON” mode. This allows your monitor to enter a Power Saving Mode when no signal is applied. This could potentially increase the life and decrease the power consumption of the monitor. ViewSonic CD4225 1. Pressing the Power button. NOTE:... -
Page 24: Selecting A Video Source
Selecting a video source Normally the CD4225 LCD monitor automatically searches for available video sources after it is turned on. You can also manually select one if multiple video sources are connected to the LCD monitor. To select a video source using the control panel: 1. -
Page 25: Osd (On-Screen-Display) Controls
OSD (On-Screen-Display) Controls Remote Control Control Panel ViewSonic CD4225 1. Press the MENU button to open Main menu. 2. Press the button to select sub-menu. 3. Press the ENTER button to decide. 4. Press the button to select function, or control which you like. -
Page 26: Osd Screen
Picture Mode Contrast Brightness Color Temp Temp Adjust Sharpness Standard 1360 x 768 60Hz Volume Mute 1360 x 768 60Hz ViewSonic CD4225 Picture VGA Setting Option Input Audio Special Diagnostic 1360 x 768 60Hz Auto Adjustment Language Clock OSD H. Pos. -
Page 27: Picture
• It is adjustable to get a distinct image or a soft one as you prefer and set independently for each picture mode. • Press the or PLUS (+) button to increase sharpness. • Press the or MINUS (-)/Auto button to decrease sharpness. ViewSonic CD4225... -
Page 28: Vga Setting
V. Position • Controls Vertical Image position within the display area of the LCD. • Press the or PLUS (+) button to move the screen up. • Press the or MINUS (-)/Auto button to move the screen down. ViewSonic CD4225... -
Page 29: Option
• Enables or disables the auto input source detection function of the monitor. Once disabled, the input source can only be selected manually. • Press the ENTER button on the remote control, or the Menu/Enter button on the control panel to change setting. ViewSonic CD4225... -
Page 30: Input
• Selects the signal connected to the DVI-IN input terminal as the input source. HDMI • Selects the signal connected to the HDMI input terminal as the input source. YPbPr • Selects the signal connected to the Y Pb Pr IN input terminal as the input source. ViewSonic CD4225... -
Page 31: Audio
• Press the or MINUS (-)/Auto button to decrease volume. Mute • Turns audio off temporarily. • Press the ENTER button on the remote control, or the Menu/Enter button on the control panel to turn this function on or off. ViewSonic CD4225... -
Page 32: Special
Monitor ID • By connecting multiple CD4225 monitors to a PC using RS-232C cables, you can control any one monitor or all the monitors on the PC. Assign arbitrary ID number to each of multi-connected CD4225... - Page 33 • If activated, all OSD settings (except the Language setting) will be restored to the factory settings. • Press the ENTER button on the remote control, or the Menu/Enter button on the control panel to activate the reset. ViewSonic CD4225...
-
Page 34: Diagnostic
• Displays the operating hours of the LCD monitor since it was first turned on. Ambient • Displays current ambient brightness around the LCD monitor. 5V Detect • Displays current 5V voltage detection result. 12V Detect • Displays current 12V voltage detection result. ViewSonic CD4225... -
Page 35: For Long Life Use Of Public Display
1. Fixed image should not be displayed for long period, and changed to another images with short cycle. 2. When not in use, please turn off the monitor. 3. Reducing the environmental temperature is effective for long life use. ViewSonic CD4225... -
Page 36: Controlling The Lcd Monitor Via Rs-232C Remote Control
This LCD monitor can be controlled by connecting a personal computer with a RS-232C terminal. Functions that can be controlled by a personal computer are: Connection LCD Monitor + PC NOTE: Two kinds of RS-232 protocols are provided: serial connection and non-serial connection. ViewSonic CD4225... -
Page 37: Appendix: Installing Stands
2. Place the stands on the monitor as shown. NOTE: Install the stands so that their longer portions come to the front. 3. Use the M4 screws and a suitable screwdriver to secure the stands on the LCD monitor. M4 screw holes ViewSonic CD4225... -
Page 38: Features
• All metal (aluminum) construction • Industrial-grade superior reliability • VESA mounting compliance with carrying handles • Various mounting schemes for player carriers PC-Based Multi-panel Management • Full-function display controls • Real-time diagnostics for detecting voltage and temperature ViewSonic CD4225... -
Page 39: Troubleshooting
NOTE: As with all personal display devices, VIEWSONIC recommends displaying moving images and using a moving screen saver at regular intervals whenever the screen is idle or turning off the monitor when not in use. -
Page 40: Specifications
Complied Regulatory and Guidelines Power Management Plug & Play Note: Specifications and functions of this monitor are subject to change without prior notice. ViewSonic CD4225 Analog Input Diagonal: 42.02" / 106.73 cm Color: Over 16 million colors (depending on video card used) (typ.) -
Page 41: Supported Input Signal Resolution
1600 x 1200 @ 60Hz 1920 x 1080 @ 60Hz 576i (50Hz) 480i (60Hz) 480p (60Hz) 576p (50Hz) 720p (50Hz) 720p (60Hz) 1080i (50Hz) 1080i (60Hz) 1080p (50Hz) 1080p (60Hz) Note: • : supported • Blank: not supported ViewSonic CD4225 Input source HDMI... -
Page 42: Note For Daisy-Chain Connection
ViewSonic CD4225... -
Page 43: Customer Support
ViewSonic CD4225... -
Page 44: Limited Warranty
ViewSonic CD4225... -
Page 45: Mexico Limited Warranty
ViewSonic CD4225... - Page 46 ViewSonic CD4225...
