Summary of Contents for ViewSonic ND4200
- Page 2 To meet your future needs, and to receive any additional product information as it becomes available, please register your product on the Internet at: www.viewsonic.com. The ViewSonic product also comes with a CD-ROM that has a registration form that you can print and mail or fax to ViewSonic Corporation. Model Name: Model Name:...
-
Page 3: Table Of Contents
System Services Configuration ....17 FTP server ........18 ViewSonic ND4200/ND5000... - Page 4 Specifications ....... . 35 Limited Warranty ......36 ViewSonic ND4200/ND5000...
-
Page 5: Introduction
• Detachable speakers Requirements The ND4200/ND5000 Network Display requires: • ViewSonic ND4200/ND5000 Network Display connected to AC power and a network or internet connection • Streaming video server and/or live encoder • Wireless network connection if using the ND4200/ND5000 wireless support... -
Page 6: Two Modes Of Operation
Two Modes of Operation Standalone The setup allows the ND4200/ND5000 Network Display to act as an independent network device controlled by one server. Ethernet cable ND4200/ND5000 Network Display TAS Managed You can purchase Tivella Administration Server (TAS) separately through Tivella (www.tivella.com or a Tivella dealer/reseller). -
Page 7: Two Modes Of Communication
Two Modes of Communication There are two modes of communication with the ND4200/ND5000 Network Display: an HTTP web interface and a Telnet advanced command line interface. This document focuses on the web interface only. Features • Bright plasma type display ideal for advertisement and video playback •... -
Page 8: Front View
Front View ViewSonic ND4200/ND5000 CHANNEL Up / Down SELECT items on a menu VOLUME decrease VOLUME increase Remote Control IR Sensor POWER LED POWER ON/OFF Standby/ON... -
Page 9: Back View
Back View Side View Hand grip Power button ViewSonic ND4200/ND5000... -
Page 10: Remote Control
Remote Control POWER button On/Standby ViewSonic ND4200/ND5000... -
Page 11: Setting Up The Network Display
See your IT Administrator for a code to the switch or a router. The Router shown is a ViewSonic WMG100. Connect the AC power cord from the Network Display to an AC power source like a wall outlet. - Page 12 Connect Multiple Network Displays (optional) You can daisy chain several Network Displays together. The two built-in Ethernet ports make the ViewSonic Network Displays unique because you do not need separate network switches or PCs for each Network Display. Media content on each Network Display can be scheduled independently when connected to an external server.
-
Page 13: Connect External Speakers (Optional)
2. Connect External Speakers (optional) speaker speaker Back of Network Display 3. Turn Power On to the Network Display Power button O (Off) I (On) ViewSonic ND4200/ND5000... -
Page 14: Put Batteries In Remote Control
4. Login Open an Internet Browser, i.e., Internet Explorer. In the URL address field, type in the default IP address of the ND4200/ND5000 (192.168.12.100) > press Enter. A prompt appears asking for a User Name and Password. The default name admin and the password admin automatically appear in the corresponding fields >... -
Page 15: Management
• iptv://<ip-multicast-address>/videoport/audioport • playlist=http://<ip-address>/<playlist-file-located-on-WEB-server> In the Browser field, enter a startup web screen (for example, http:// www.viewsonic.com). Note: The MAC address is a read-only field that displays the built-in MAC address of the unit. ViewSonic ND4200/ND5000 Continued . . . -
Page 16: Browser Configuration
In the Screen rotation angle (clockwise) field, select one from the pull- down menu for the angle of rotation of the HTML content displayed on-screen. This feature is useful when the NMP-500 is installed vertically. In the Browser Proxy field, select Enabled or Disabled from the pull-down menu. ViewSonic ND4200/ND5000... - Page 17 In the Screen Width field, type the width of the screen that is displaying your graphics image. If any changes were made to this screen, do the following: • To enable the changes, click Apply • To save the changes, click the Administration menu > click Save Configuration > click Save. ViewSonic ND4200/ND5000...
-
Page 18: Vnc Client
VNC full screen mode lets you set the client to start up as full screen all the time. VNC auto restart mode reconnects the client in the event of network interruption. Delay before restart VNC sets the time between reconnects. ViewSonic ND4200/ND5000... -
Page 19: Video/Audio Configuration
Move the Audio Channel Volume (right) slider: values range between 0 and 100 If any changes were made to this screen, do the following: • To enable the changes, click Apply • To save the changes, click the Administration menu > click Save Configuration > click Save. ViewSonic ND4200/ND5000... -
Page 20: Tas Configuration
If any changes were made to this screen, do the following: • To enable the changes, click Apply • To save the changes, click the Administration menu > click Save Configuration > click Save. ViewSonic ND4200/ND5000... -
Page 21: System Services Configuration
NMP-500 settings. If any changes were made to this screen, do the following: • To enable the changes, click Apply • To save the changes, click the Administration menu > click Save Configuration > click Save. ViewSonic ND4200/ND5000... -
Page 22: Ftp Server
FTP server FTP server is only for Network Displays with local storage. The FTP server allows you to use an FTP client for uploading files. ViewSonic ND4200/ND5000... -
Page 23: Actions
(for example, 239.1.1.7) In the Port field, type the Port number used to receive the multicast. To tell the system to listen to the UDP multicast stream from the IP on the Port that you entered, click Start. ViewSonic ND4200/ND5000... -
Page 24: Video Http
In the URL field, type the URL that corresponds to the HTTP stream that you want to appear on the display (for example: http:192.168.12.x/movie.mpg, or, http://<server-ip>/file.mpg). To tell the system to listen to the HTTP stream from the entered URL, click Start. ViewSonic ND4200/ND5000... -
Page 25: Playlist
A Playlist can be created for the http streams. Example of a looped Playlist: loop http http://192.168.12.x/movie1.mpg http http://192.168.12.x/movie2.mpg http http://192.168.12.x/movie3.mpg For a Playlist that is not looped, list the desired content without the keyword "loop." ViewSonic ND4200/ND5000... -
Page 26: Vnc Client
In the VNC server field, type the IP Address of the VNC server. In the Password field, type the password of the VNC server whose IP is entered above. IMPORTANT! The password must be at least six (6) characters (can be alpha-numeric). To display the remote desktop click Start. ViewSonic ND4200/ND5000... -
Page 27: Transparency
Display) shown below on the right with your video or other images: 0 = no OSD, 255 = no video, 128 = equal transparency between video and OSD layers. OSD not transparent To apply the entered transparency value to the image on the NMP-500, click Apply. ViewSonic ND4200/ND5000 OSD very transparent... -
Page 28: Go To Url
To go to a web page on the browser, click Actions > Go to URL. The screen shown below appears. In the URL field, type the desired URL. To redirect the browser to the URL that you entered, click Go. The web page appears on your display. ViewSonic ND4200/ND5000... -
Page 29: Administration
In the Height of destination window, type the height of the destination window. If any changes were made to this screen, do the following: • To enable the changes, click Apply • To save the changes, click the Administration menu > click Save Configuration > click Save. ViewSonic ND4200/ND5000... -
Page 30: Security
In the Repeat Password field, re-type the new password. If any changes were made to this screen, do the following: • To enable the changes, click Apply • To save the changes, click the Administration menu > click Save Configuration > click Save. ViewSonic ND4200/ND5000... -
Page 31: Save Configuration
To save your settings on the NMP-500, click Administration > Save Configuration. The screen shown below appears. Click Save. Default Settings To restore the NMP-500 back to factory settings, click Administration > Default Settings. The screen shown below appears. Click Restore. User-defined settings will be lost. ViewSonic ND4200/ND5000... -
Page 32: Reboot
To reboot the NMP-500, click Administration > Reboot. The screen shown below appears. Click Reboot. The NMP-500 reboots. Firmware Upgrade To upgrade the firmware on the NMP-500, click Administration > Firmware. The screen shown below appears. Click Browse to open the firmware file > click Start upgrade. ViewSonic ND4200/ND5000... -
Page 33: Help
HELP Status Status refers to the log where you can track activity on a specific NMP-500. To show the Status log, click Help > Status. The screen shown below is for information only (no inputs). ViewSonic ND4200/ND5000... -
Page 34: License
To activate the license on the NMP-500, click Help > License. The License Key may appear automatically in the screen shown below (read-only). About To show the current version of the product, click Help > About. The screen shown below appears (information only). ViewSonic ND4200/ND5000... -
Page 35: Appendix
APPENDIX Screens Management ViewSonic ND4200/ND5000... - Page 36 Actions Administration ViewSonic ND4200/ND5000...
-
Page 37: Customer Support
You need the product serial number when you contact Customer Support. Website Country/Region (for email address also) United States www.viewsonic.com Canada www.viewsonic.com ViewSonic ND4200/ND5000 T = Telephone F = FAX T: (800) 688-6688 F: (909) 468-1202 T: (866) 463-4775 F: (909) 468-5814... -
Page 38: Fcc Information
Notice: This class A digital apparatus complies with Canadian ICES-003. AVIS: Cet appeil numerique de la Classe A conforme a la norme NMB-003 du Canada. User Information for All Countries Notice: Use the cables that are included unless otherwise specified. ViewSonic ND4200/ND5000... -
Page 39: Specifications
Wall mount kit, Detachable speakers Specifications are subject to change without notice. Corporate names and trademarks stated herein are the property of their respective companies. ViewSonic ND4200/ND5000 ND5000 1366 x 768 @ 60 Hz 1184mm (W) x 700mm (H) x 63mm (D) Height without stand 50"... -
Page 40: Limited Warranty
“Warranty Period”, as indicated below. If a product proves to be defective in material or workmanship during the Warranty Period, ViewSonic will, at its sole option, repair or replace the product with a similar product. Replacement products or parts may include remanufactured or refurbished parts or components. - Page 41 11. ViewSonic will not be responsible for any damage to, loss of, or consequential loss from the inability to use, any programs, data or other information stored on any media or any part of any Product serviced hereunder.
- Page 42 E. A description of the problem. Mobile and wireless products, customer should provide the user name and the password or disable password protections in order to allow ViewSonic access to the device for the performance of warranty service. 3. Bring or ship the product prepaid in the original container, with the associated accessories, to ViewSonic or any ViewSonic authorized service center.
