PLEASE READ THIS MANUAL

BEFORE INSTALLING

AND USING APPLIANCE.

IMPORTANT: Read all instruc-

tions and warnings carefully

before starting installation. Fail-

ure to follow these instructions

may result in a possible fire

hazard and will void the warranty.

WARNING: If the information in

this manual is not followed ex-

actly, a fire or explosion may

result causing property damage,

personal injury or loss of life.

FOR YOUR SAFETY

Installation and service must be

performed by a qualified installer,

service agency, or the gas sup-

plier. Do not store or use gasoline

or other flammable vapors and

liquids in the vicinity of this or

any other appliance.

FOR YOUR SAFETY

If you smell gas:

1. Open windows

2. Do not touch electrical

switches.

3. Do not try to light any appli-

ance.

4. Extinguish any open flame.

5. Do not use the phone in your

building.

6. Immediately call your gas

supplier from a neighbor's

phone.

7. Follow your gas supplier's

instructions.

8. If you cannot reach your gas

supplier, call the fire depart-

ment.

This is an unvented gas-fired

heater. It uses air (oxygen) from

the room in which it is installed.

Provisions for adequate combus-

tion and ventilation air must be

provided.

Vent-Free

Gas Room Heaters

UVHB10

Homeowner's Installation and

Operating Manual

INSTALLER: DO NOT DISCARD THIS MANUAL

Leave in fireplace for homeowner.

20004232 10/02 Rev. 1

Table of Contents

Need help?

Do you have a question about the UVHB10 and is the answer not in the manual?

Questions and answers

Summary of Contents for pyromaster UVHB10

Page 1 Provisions for adequate combus- tion and ventilation air must be provided. Vent-Free Gas Room Heaters UVHB10 Homeowner's Installation and Operating Manual INSTALLER: DO NOT DISCARD THIS MANUAL Leave in fireplace for homeowner. 20004232 10/02 Rev. 1...
Page 2: Table Of Contents
PYROMASTER UVHB10 Vent-Free Heaters ® This gas room heater should be installed by a qualified installer in accordance with local building codes and with current National Fuel Gas Code. ANSI Z223.1. This heater should not be installed in a confined space unless provisions are made for adequate combustion and ventilation air.
Page 3: Corner Cabinet Dimensions
7 " 12 " 45 " 4232c Fig. 1 UVHB10 Series FPS1213N dimensions. UVHB10 Series Gas Appliance 7" 39 " 26 " 14 " " 15 " 47 " 4232 Fig. 2 UVHB10 Series, FPS1212NC and FPS1214W specifications and dimensions. 20004232...
Page 4: Specifications
PYROMASTER UVHB10 Vent-Free Heaters ® Description The UVHB10 vent-free heater is designed to be in- stalled into an FPS1212NC, FPS1214W or FPS1213N (corner) mantel cabinet only. It may not be installed in any other manner. The UVHB10 is available in Natural or Propane gas, equipped with an oxygen depletion sensor with a standing pilot.
Page 5: Installation
Preparing the UVHB10 The UVHB10 may only be used with the approved mantel and hearth assembly. 1. After determining a location, open the mantel hearth base carton and place into position on a solid surface. NOTE: Be sure to level the base before setting the UVHB10 heater in place.
Page 6 12. Reassemble unit by following Steps 1- 3 in reverse order. Fan Operation The FK24 fan has a heat sensor that will not allow the fan to come on until heater reaches a preset tempera- ture, approximately 100-120° F. Once the heater reaches temperature use the speed control knob to turn fan on and off to adjust fan speed.
Page 7: First Firing
In locations that do not allow unvented heaters, the chimney must have a permanent chimney opening of not less than 29 square inches. P103 UVHB10 Vent-Free Heaters ® Yellow Tip Blue LG150...
Page 8: For Your Safety Read Before Lighting
PYROMASTER UVHB10 Vent-Free Heaters ® Lighting And Operating Instructions FOR YOUR SAFETY READ BEFORE LIGHTING WARNING:If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This heater has a pilot which must be lit manu- ally.
Page 9: Cleaning The Standing Pilot Control System
Typically, the top 1/8" of the thermopile should be engulfed in the pilot flame. (Fig. 10, Page 7) The air shutter is set at the factory, no adjustment should be necessary. UVHB10 Vent-Free Heaters ®...
Page 10: Troubleshooting
PYROMASTER UVHB10 Vent-Free Heaters ® With proper installation and maintenance, your new Gas Appliance should provide years of trouble-free service. If you do experience a problem, this guide will help a CERTIFIED SERVICE PERSON in the diagnosis of problems and the corrective action to take.
Page 11 11a/b CFM Harris Systems reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time, without notice. Replacement Parts List - UVHB10 Ref. Description Top Trim Right Side Trim Screen Top & Bottom Louvre...
Page 12: Replacement Parts
In addition, such action may void the coverage provided by the owner’s insur- ance. Contact CFM Harris Systems for questions concerning prices and policies covering replacement parts. Parts may be ordered through your CFM Harris Systems distributor or dealer. You will need the following information when ordering replacement parts: 1.
Page 13 (4). These warranties are limited to repair, replacement or furnishing a replacement for sale, as specified in Paragraphs A and B, for a part found to CFM Harris Systems’ satisfaction, after examination, to be defective in materials or workmanship under normal conditions, use and service.
